NOISES ............................... 23 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
English 3 SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety •...
4 www.electrolux.com • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • If the appliance is equipped with an Ice maker or a water dispenser, fill them with potable water only.
Page 5
English 5 2.3 Use 2.5 Care and cleaning WARNING! WARNING! Risk of injury, burns, electrical Risk of injury or damage to the shock or fire. appliance. • Before maintenance, deactivate the • Do not change the specification of this appliance and disconnect the mains appliance.
Page 6
6 www.electrolux.com SINGLE DOOR REFRIGERATOR FEATURES ERB5007 Dairy compartment FlexStore™ door bins Deli drawer Use the chiller drawer to store foods like small goods, fresh or cooked meat and cheese. Door storage bin To remove the chiller drawer, pull it forward, then lift it up and pull it further forward.
Page 7
English 7 SINGLE DOOR REFRIGERATOR FEATURES ERB5004 Dairy compartment FlexStore™ door bins Deli drawer Use the chiller drawer to store foods like small goods, fresh or cooked meat and cheese. Door storage bin To remove the chiller drawer, pull it forward, then lift it up and pull it further forward.
Page 8
8 www.electrolux.com SINGLE DOOR FREEZER FEATURES EFB5007 & EFB5004 Twist & serve ice Refer to the section “Using your Refrigerator” for details on removing, relocating and using this feature. Storage bins Refer to the section “Using your Refrigerator” for details on removing, and using this feature.
English 9 ABOUT THE USER INTERFACE Control – ERB5007/ERB5004 Models Quick Chill Quick chill on/off icon Colder Refrigerator temperature scale icons Less Cold Temp Temperature adjust/quick chill Quick Chill on/off button Hold 3sec DESCRIPTION OPERATION / PRIMARY FUNCTION Refrigerator temperature scale icons •...
Page 10
10 www.electrolux.com ABOUT THE USER INTERFACE Control – EFB5007 / EFB5004 Models Quick Freeze on/off icons Quick Freeze/ drinks chill on/off button Drinks Chill on/off iconsl Temperature adjust button Freezer temperature scale icons DESCRIPTION OPERATION / PRIMARY FUNCTION Quick Freeze on/ off icon Indicates the status of the Quick Freeze function.
English 11 INSTALLING YOUR NEW REFRIGERATOR Unpacking When positioned in a corner area, spacing of at least 350mm (300mm for multi-door models) on the hinge side will allow the doors to open enough to ENVIRONMENT enable the removal of bins and shelves. Most of the packing materials are recyclable.
Page 12
12 www.electrolux.com Check the alignment of the refrigerator to the Fitting the handles surrounding cupboards to see if it is level. You can adjust the level as detailed in step 2 and 3. aligned to cupboards top of refrigerator is ie.
Page 13
• • This accessory is for indoor use only. • This accessory is intended for domestic use only. Electrolux will not accept any liability for possible damage caused by improper or incorrect use. • When cleaning, use only a soft cloth with an unscented mild soap and lukewarm water.
Page 14
14 www.electrolux.com INSTALLATION Assemble bar handle to door Position the handle over handle mounts. Step 1. Tighten the set screw on the top pedestal in clockwise direction to secure the handle onto the door. Step 2. Tighten the set screw on the...
English 15 USING YOUR REFRIGERATOR NutriPlus (Anti-Oxidant Filter) Installing Filter Cartridge Refrigerators work by transferring heat from the Your filter can be found in the crisper. To enjoy food inside to the outside air. This operation the full benefit of NutriPlus , it is important to makes the back and sides of the refrigerator feel install it after turning on the refrigerator.
Page 16
16 www.electrolux.com Drawers fitted with telescopic slides To remove the drawer for cleaning. 1. Empty food from the drawer. 2. Remove the drawer by pulling it forward and lifting the front to unhook it from the slides. Once you have removed the drawer, ensure the slides are pushed back so they are fully closed.
Page 17
English 17 CLEANING YOUR REFRIGERATOR CAUTION WARNING BEFORE CLEANING: Turn the refrigerator off at Never use hot water, solvents, commercial the power point and unplug the cord to prevent kitchen cleaners, aerosol cleaners, metal any chance of electrocuting yourself. polishes, caustic or abrasive cleaners, or scourers to clean your refrigerator.
18 www.electrolux.com FOOD STORAGE GUIDE CATEGORY PRODUCT REFRIGERATOR FREEZER STORAGE TIPS MEAT Keep cold meat at the back of the Sausages and Mince 1-2 Days 2-3 Months refrigerator where it is coldest. Chops and Steak 3-4 Days 4-6 Months Cold Meats...
English 19 TROUBLESHOOTING Appliance does not operate at desired temperature In a modern frost free refrigerator / freezer, cold air is circulated around the various compartments through air vents using a high efficiency fan. CONCERN WHAT TO DO Ensure food is allowed to cool before placing inside the refrigerator. Refrigerator is too warm Ensure the appliance is set up as per instructions on page 11.
Page 20
20 www.electrolux.com Refrigerator operation CONCERN WHAT TO DO Appliance will not run Ensure that the cord is plugged into a live power outlet and outlet is switched on. It is normal for the freezer fan not to Ensure that the household circuit breaker has not tripped or that the fuse has not operate during the automatic defrost cycle, blown.
Page 21
If you have a problem, and the problem persists after you have made the checks mentioned, contact your nearest Electrolux approved Service Centre or the dealer you bought the refrigerator from. Be ready to quote the model number, the 9-digit PNC and 8-digit serial number, which is stated on the label inside the refrigerator...
22 www.electrolux.com NOISES There are some sounds during normal running (compressor, refrigerant circulation). HISSS! BRRR SSSRRR! SSSRRR! HISSS! HISSS! CRACK! CRACK! BLUBB! BLUBB!
Page 23
22 صوت الضوضاء .)تصدر بعض األصوات أثناء التشغيل العادي (الضاغط، دورة التبريد HISSS! BRRR SSSRRR! SSSRRR! HISSS! HISSS! BLUBB! BLUBB! CRACK! CRACK!
Page 24
21 Arabic ل خطاء وإصلاحهاا ستكشافا تشغيل الباب ماذا تفعل ا لمشكلة .هذا أمر طبيعي وس ي ُ عاد إغالقه. يحدث هذا عندما يتم إغالق باب الثالجة بسرعة كبيرة .باب الفريزر يطرقع عند الفتح إذا بقي باب الفريزر مفتو ح ً ا، فهذا يشير إلى أن الجهاز يحتاج إلى ”.إمالة...
Page 25
20 تشغيل الثالجة ماذا تفعل المشكلة .تأكد من أن السلك موصول بمأخذ التيار المباشر ومنفذ التشغيل يعمل الجهاز ال يعمل من الطبيعي أن تتوقف مروحة الفريزر عن العمل أثناء دورة .تأكد من أن قاطع الدائرة المنزلية لم يتعثر أو أن المصهر لم ينفجر...
Page 26
19 Arabic تنظيف الثالجة الجهاز ال يعمل على درجة الحرارة المطلوبة .في الثالجة / الفريزر الحديث الخالي من الثلوج، يتم تدوير الهواء البارد حول األجزاء المختلفة من خالل فتحات التهوية باستخدام مروحة عالية الكفاءة ماذا تفعل المشكلة .تأكد من ترك الطعام يبرد قبل وضعه داخل الثالجة الثالجة...
Page 27
18 دليل تخزين الطعام نصائح للتخزين الفريزر الثالجة المنتج الفئة .أب ق ِ اللحم البارد في مؤخرة الثالجة؛ ألن هذا أبرد مكان 2-3 أشهر 1-2 يوم نقانق ولحم مفروم لحوم 4-6 أشهر 3-4 أيام اللحم المقطع والستيك يمكن أن يسبب البالستيك تعرق اللحم إذا ح ُ فظ في الثالجة...
Page 28
17 Arabic تنظيف الثالجة إيقاف تشغيل الثالجة إذا قمت بإيقاف تشغيل الثالجة لفترة طويلة، فاتبع الخطوات التالية لتقليل فرص :حدوث تعفن تحذير .1. أخرج جميع األطعمة قبل التنظيف: قم بإيقاف تشغيل الثالجة من نقطة الطاقة وافصل السلك لمنع أي فرصة .للتعرض لصدمة كهربائية .2. انزع...
Page 29
16 تنبيه األرفف الزجاجية تجنب مطل ق ً ا إغالق الباب أثناء تمديد المنزلقات التليسكوبية. فقد يؤدي ذلك إلى إتالف إلزالة األرفف، اسحبها برفق لألمام حتى يصبح الرف .المنزلق و/أو الثالجة أو يؤدي إلى فصل المنزلق عن الثالجة خال ي ً ا من موجهات الرف. إلعادة الرف، تأكد من عدم...
Page 30
15 Arabic إزالة الخواص استخدام الثالجة :إزالة درج الخضروات .تعمل الثالجات من خالل نقل الحرارة الموجودة في الطعام الداخلي إلى الهواء الخارجي تؤدي هذه العملية إلى تدفئة أو حتة تسخين الجزء الخلفي وجوانب الثالجة خصو ص ً ا عند 1. قم بتفريغ الطعام من درج الخضروات. في بعض الموديالت يجب إزالة سالت .بدء...
Page 33
12 تركيب الثالجة الجديدة .5. إذا وجدت الثالجة تتأرجح من زاوية إلى أخرى، فهذا يعني أن األرضية غير مستوية .يمكنك العثور على قطعة بالستيكية أو ورق صلب ووضعها بثبات أسفل البكرة .5 6. وقد تحتاج اآلن إلى تعديل التركيب من خالل تكرار الخطوات 3 و 4 و...
Page 34
11 Arabic تركيب الثالجة الجديدة تركيب الثالجة فك التغليف 1. قم بلف الثالجة في مكانها. تم تصميم البكرات للحركة لألمام والخلف فقط. إنها البيئة .ليست مثل عجالت الكرسي. تحريك الثالجة بالجانب قد يتلف األرضية والبكرات قبل تحريك الثالجة، تأكد أن صامولة ضبط االرتفاع وقاعدة التثبيت معدة بالكامل معظم...
Page 40
5 Arabic العناية والتنظيف االستخدام !تحذير !تحذير .خطر التعرض لإلصابة أو إتالف الجهاز هناك احتمال التعرض لإلصابة، أو الحروق، أو .الصدمة الكهربائية أو نشوب حريق أوقف تشغيل الجهاز وافصل قابس التيار الرئيسي عن • .ال تغير مواصفات هذا الجهاز • .مقبس...
Page 41
4 • في حالة تلف سلك اإلمداد الكهربي، يجب استبداله من ق ِ بل الشركة ال م ُ صنعة أو .وكيل الصيانة التابع لها أو غيره من األشخاص المؤهلين لتفادي التعرض للخطر .• إذا كان الجهاز مزو د ًا بصانع ثلج أو بموزع ماء، امألهما بماء الشرب فقط...
Page 42
3 Arabic معلومات األمان قبل تركيب الجهاز واستخدامه، يرجى قراءة التعليمات الواردة بعناية. الشركة المصنعة غير مسؤولة في حالة التركيب واالستخدام غير الصحيح، والذي قد يؤدي إلى حدوث إصابات وتلف الجهاز. احتفظ دائ م ً ا بالتعليمات الواردة مع .الجهاز للرجوع إليها الح ق ً ا سالمة...
Page 43
نحن نفكر فيك . لقد اخترت منت ج ً ا يتميز بعقود من الخبرات االحترافية واالبتكار. جهاز رائعElectrolux نشكرك على شراء أحد أجهزة وأنيق، صممناه ونحن نضع احتياجاتك في ذهننا. عند استخدامك له، يمكنك الشعور باألمان لمعرفتك بأنك ستحصل على نتائج...
