Panasonic PLCD42HD Instruction Manual

42-inch wuxga premium tft-lcd monitor
Hide thumbs Also See for PLCD42HD:
Table of Contents

Advertisement

Quick Links

Download this manual
PLCD42HD
42-INCH WUXGA
PREMIUM TFT-LCD MONITOR
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Panasonic PLCD42HD

Summary of Contents for Panasonic PLCD42HD

  • Page 1 PLCD42HD 42-INCH WUXGA PREMIUM TFT-LCD MONITOR INSTRUCTION MANUAL...
  • Page 2 Please read this manual thoroughly before use, and keep it handy for future reference.
  • Page 3 SAFETY INSTRUCTION ………………………………………………………………….. CAUTIONS ………………………………………………………………... FCC RF INTERFERENCE STATEMENT ……………………………... CONNECTING WITH EXTERNAL EQUIPMENT ………………………………………. REMOTE FUNCTIONS ……………………………………………………………………. CONTROLS AND FUNCTIONS ………………………………………………………….. MOUNTING GUIDE ……………………………………………………………………….. D-SUB CONNECTOR PIN ASSIGNMENTS ……………………………………………. POWER MANAGEMENT …………………………………………………………………. SPECIFICATIONS …………………………………………………………………………. TROUBLE SHOOTING GUIDE …………………………………………………………... 2 ~ 3 8 ~ 31...

  • Page 4: Important Safety Instruction

    INSTRUCTION MANUAL ……………………………………………………………………. 1 Important Safety Instruction 1. Read these instructions. 2. Keep these Instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 5 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus the apparatus has been exposed to rain or moisture does not operate normally or has been dropped.
  • Page 6 This symbol is intended to alert the user to the presence of uninsulated : dangerous voltage with in the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This symbol is intended to alert the user to the presence of important operating and maintenance(servicing) instructions in the literature accompanying the appliance.
  • Page 7 BE CAREFUL OF HEAVY OBJECT Neither the monitor itself nor any other heavy object should rest on the power cord. Damage to a power cord can cause fire or electrical shock. 4 ……………………………………………………………………. INSTRUCTION MANUAL...

  • Page 8: Doc Compliance Notice

    communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.
  • Page 9 1. HDMI IN 2. DVI IN 3. PC VGA IN 4. PC STEREO IN 5. AUDIO OUT 6. COMPONENT IN 7. COMPONENT AUDIO L/R IN 8. Trigger Input 9. AV 1 IN Composite signal input for AV 1 10. AV 1 OUT Video looping out for AV 1 11.

  • Page 10: Remote Controller

    B. REMOTE CONTROLLER 1. POWER( Turn the power ON or OFF. There will be a few seconds delay before the display appears. 2. SOURCE Select pc or video(AV1/AV2/S-Video/Component/HDMI/DVI/PC) sources. 3. AUTO Auto geometry adjustment in PC Source. 4. HOLD Stop the Trigger & Auto switching functions. 5.
  • Page 11 C. FRONT KEY CONTROL 1. SOURCE/SELECT Select PC or video. Select On Screen Display menu. 2. MENU Activate and exit the On Screen Display. 3 / 4. ▼ / ▲ These buttons allow user to enter the sub-menu of the activated function. The up(▲) button is HOLD function and stop the Trigger &...
  • Page 12 OSD MENU DESCRIPTION A: CUSTOM MENU (Only Video Input) 1) Press the MENU button and then press the up(▲) or down(▼) button to select the Custom. 2) Press the up(▲) or down(▼) button to select the sub menu. 3) Press the left(◀) or right(▶) button to adjust the picture setting. 4) Press the MENU button to save.
  • Page 13 B. Picture / Sound Menu (Only Video Input) 1. Picture Mode 1) Press the MENU button and then press the up(▲) or down(▼) button to select the Picture / Sound. 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Picture Mode. 4) Press the right(▶) or SOURCE/SELECT button.
  • Page 14 3. Mute 1) Press the up(▲) or down(▼) button to select the Mute. 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the On or Off. 4) Press the MENU button to save. 4.
  • Page 15 5. Size 1) Press the up(▲) or down(▼) button to select the Size 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Size option. 4) Press the MENU button to save. 6. NR 1) Press the up(▲) or down(▼) button to select the NR.
  • Page 16 7. 3D Comb 1) Press the up(▲) or down(▼) button to select the 3D Comb. 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the On or Off. 4) Press the MENU button to save. B.
  • Page 17 2-1. Color Tone 1) Press the up(▲) or down(▼) button to select the Color Tone. 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the left(▶) or SOURCE/SELECT button again. 4) Press the up(▲) or down(▼) button to select the Color Tone option. 5) Press the MENU button to save.
  • Page 18 2-2. Color Tone (Custom) 1) Press the up(▲) or down(▼) button to select the Custom in the Color Tone. 2) Press the Menu button to save. 3) Press the up(▲) or down(▼) button to select the Red(R), Green(G) or Blue(B). 4) Press the left(◀) or right(▶) button to adjust color density.
  • Page 19 3. Size 1) Press the up(▲) or down(▼) button to select the Size. 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Size option. Input 4. PC control (Only PC 1) Press the up(▲) or down(▼) button to select the PC. 2) Press the right(▶) or SOURCE/SELECT button.
  • Page 20 C. PIP MENU (Only Video Input) 1) Press the MENU button and then press the up(▲) or down(▼) button to select the PIP. 1. PIP 1) Press the right(▶) or SOURCE/SELECT button. 2) Press up(▲) or down(▼) button to select the On or Off. 3) Press the MENU button to save.
  • Page 21 2. Input Source 1) Press the up(▲) or down(▼) button to select the Input Source. 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Source option. 4) Press the MENU button to save. 3.
  • Page 22 4. Position 1) Press the up(▲) or down(▼) button to select the Position. 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Position option. 4) Press the MENU button to save. 5. Swap 1) Press the up(▲) or down(▼) button to select the Swap.
  • Page 23 5. Sound Select 1) Press the up(▲) or down(▼) button to select the Sound Select. 2) Press the right(▶) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Sound Select option. 4) Press the MENU button to save. C.

  • Page 24: Setup Menu

    D. SETUP MENU 1) Press the MENU button and then press the up(▲) or down(▼) button to select the Setup. 1. Reset 1) Press the right(▶) or SOURCE/SELECT button 2) Press the right(▶) or SOURCE/SELECT button again. 3) Press SOURCE/SELECT button to execute the reset. Reset: All settings go to the factory initialization.
  • Page 25 2. Language 1) Press the up(▲) or down(▼) button to select the Language. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select language. 4) Press the MENU button to save. 3. OSD Tone 1) Press the up(▲) or down(▼) button to select the OSD Tone.
  • Page 26 4. Blue Screen 1) Press the up(▲) or down(▼) button to select the Blue Screen. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the On or Off. 4) Press the MENU button to save. 5.
  • Page 27 6. Trigger 1) Press the up(▲) or down(▼) button to select the Trigger. 2) Press the right( ) or SOURCE/SELECT button. 6-1. Trigger Enable 1) Press the up(▲) or down(▼) button to select the Trigger Enable. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the On or Off.
  • Page 28 6-2. Trigger Input 1) Press the up(▲) or down(▼) button to select the Trigger Input . 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Trigger Input option. 4) Press the Menu button to save. 6-3.
  • Page 29 6-4. Trigger Time 1) Press the up(▲) or down(▼) button to select the Trigger Time. 2) Press left( ) or right( ) button to adjust Trigger Time setting. 3) Press the MENU button to save. 6-5 Trigger Option 1) Press the up(▲) or down(▼) button to select the Trigger Option. 2) Press the right( ) or SOURCE/SELECT button.
  • Page 30 6-6. Display Type 1) Press the up(▲) or down(▼) button to select the Display Type. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Display Type option. 4) Press the Menu button to save. PIP &...

  • Page 31: Auto Switching

    7. Auto switching 1) Press the up(▲) or down(▼) button to select the Auto switching. 2) Press the right( ) or SOURCE/SELECT button. 7-1. Auto switching On/Off 1) Press the right( ) or SOURCE/SELECT button. 2) Press the up(▲) or down(▼) button to select the On or Off . 3) Press the Menu button to save.
  • Page 32 7-2. Auto switching Inputs enabled 1) Press the up(▲)or down(▼) button to select the Inputs enabled. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Input. 4) Press the right( ) or SOURCE/SELECT button. 1) Press the up(▲) or down(▼) button to select the On or Off.
  • Page 33 7-3. Auto switching Time 1) Press the up(▲) or down(▼) button to select the Time. 2) Press the left( ) or right( ) button to adjust the Time setting. 3) Press the MENU button to save. 8. Image Rotation 1) Press the up(▲) / down(▼) button to select the Image Rotation. 2) Press the right(▶) or ENTER button.
  • Page 34 8-1. Image Rotation On/Off 1) Press the right(▶) or SOURCE/SELECT button. 2) Press the up(▲) or down(▼) button to select the On or Off . 3) Press the Menu button to save. 8-2. Image Rotation Min(Time control) 1) Press the up(▲) or down(▼) button to select the Time. 2) Press the left(◀) or right(▶) button to adjust the Time setting.

  • Page 35: Wall Mount Installation

    Using the wall mount design and the (130x130)x634 hole pattern on the back panel to install the LCD monitor to the wall. Wall-mount Installation 1. The Monitor fixing bracket to the monitor using the fixing screws provided. 2. The monitor fixing bracket assembled with monitor 32 ……………………………………………………………………. INSTRUCTION MANUAL...

  • Page 36: Pin Assignments

    ▶ PIN ASSIGNMENTS Pin 1 RED VIDEO GREEN VIDEO BLUE VIDEO GROUND GROUND RED GROUND GREEN GROUND BLUE GROUND ACCESSORY ▶ 1. User’s Manual 2. Power Cord 5. Trigger Cable SIGNAL CABLE DETECT GROUND SDA(for DDC) H-SYNC.(or H+V SYNC.) V-SYNC. SCL(for DDC) 3.

  • Page 37: Led Indicator

    INSTRUCTION MANUAL ……………………………………………………………………. 33 This monitor features a power management system to “power down” upon receipt of the VESA DPMS(The display power management signaling) from a VESA DPMS video card. The VESA DPMS-compliant video card performs this signaling system through not sending horizontal, vertical, or sync signal.

  • Page 38: Input Signal

    34 ……………………………………………………………………. INSTRUCTION MANUAL 42˝ Diagonal AM-TFT(Active-Matrix) Pixel pitch(mm) : 0.4845mm(H) x 0.4845mm(V) LCD- Type BRIGHTNESS: 500cd/㎡(Typical) CONTRAST RATIO: 1300:1(Typical) VIEWING ANGLE: 178°/178°(H/V) RESPONSE TIME: 5msec(G-to-G) RESOLUTION (H x V) 1920X1080 @60Hz HORIZONTAL: 31- 80KHz FREQUENCY VERTICAL: 56-75Hz VIDEO(2ch input 1.0Vp-p, 75Ω terminated, loop-through out) S-VIDEO(1ch input (Y/C), loop-through out) COMPONENT(Y,Pb,Pr, Sound L/R) DVI D(Digital Video Interface)

  • Page 39: Weee Symbols

    ELECTRICAL AC100-240V,50/60Hz (Auto Switching) RATINGS ▶▶ NOTE : Technical specifications are subject to change without notice. INSTRUCTION MANUAL ……………………………………………………………………. 35 WEEE Symbols...

  • Page 40: Instruction Manual

    Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
  • Page 42 P/N: L39ME0187 Rev.0...
