Operating Instructions

PLEASE READ BEFORE USE AND
SAVE.
KX-TGA400B is the optional cordless
handset for the KX-TG4000B. These
operating instructions cover most of the
features of this cordless handset.
Please read the KX-TG4000B operating
instructions for further details.
Installation ................................... 1
Location of Controls..................... 2
Making Calls ................................ 3
Answering Calls........................... 4
Intercom....................................... 4
Transferring a Call ....................... 4
in the Directory ............................ 5
Caller ID Service.......................... 6
Viewing the Caller List ................. 7

Installation

Connecting the AC adaptor to the charger

Power Outlet
(AC 120 V, 60 Hz)
AC Adaptor
• USE ONLY WITH Panasonic AC ADAPTOR KX-TCA1 (Order No. KX-TCA1-G).
• The AC adaptor must remain connected at all times. (It is normal for the adaptor to
feel warm during use.)
Printed in Japan
Model No.
Contents
Voice Mail System ....................... 7
Listening to Messages................. 9
Tone Phone .................................10
Wall Mounting..............................11
Using the Belt Clip .......................12
Battery Replacement ...................12
Bottom
of the
charger
Fasten the AC adaptor
cord to prevent it from
being disconnected.
PQQX12631ZA
- 1 -
2.4GHz Cordless Handset
KX-TGA400B
Accessories (included)
For extra orders, call
1-800-332-5368.
Charger .................one
AC Adaptor............one
Order No. KX-TCA1-G
Belt Clip.................one
Order No. PQKE10101Z1
SS0700NA1090

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TGA400B

Summary of Contents for Panasonic KX-TGA400B

  • Page 1: Table Of Contents

    Power Outlet (AC 120 V, 60 Hz) AC Adaptor • USE ONLY WITH Panasonic AC ADAPTOR KX-TCA1 (Order No. KX-TCA1-G). • The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) Printed in Japan 2.4GHz Cordless Handset...

  • Page 2: Location Of Controls

    – “ ” flashes on the display, or – the handset beeps intermittently while it is in use. Handset battery information After your Panasonic battery is fully charged: Operation While in use (TALK) While not in use (Standby) • Clean the charge contacts of the handset and the charger with a soft, dry cloth once a month.

  • Page 3: Registering Cordless Handsets

    Press H to select “HS registration”. Making Calls Four calls can be handled simultaneously on separate telephone lines by the base unit and 3 cordless handsets (or by 4 cordless handsets). Press (TALK) • You can press a line button instead of pressing Dial a phone number.

  • Page 4: Answering Calls

    Answering Calls Four calls can be handled simultaneously by the base unit and 3 cordless handsets (or by 4 cordless handsets). Press (TALK) • You can press the called line button instead of pressing (TALK) • You can also answer a call by pressing any dialing button (0) to (9), (*) or (#).

  • Page 5: Storing Names And Numbers In The Directory

    Storing Names and Numbers in the Directory You can store names and phone numbers in the directory. The cordless handset can store up to 50 items. All directory items are sorted by the first word in alphabetical order. Using the directory, you can make a call by selecting a name on the display.

  • Page 6: Dialing From The Directory

    , and press (ENTER) Caller ID Service This unit is compatible with a Caller ID service offered by your telephone company. After subscribing to a Caller ID service, the calling party’s information will be displayed after the first ring. The unit can record information of up to 30 different callers in the Caller List.

  • Page 7: Viewing The Caller List

    Viewing the Caller List If you have received new calls, “Received calls” will be displayed in the standby mode. Caller List information includes the caller’s name and phone number, and the time and date the call was received. Make sure that the cordless handset is in the standby mode. Press to enter the list.

  • Page 8: Automated Attendant System

    You can use the Voice Mail System by accessing your mailbox. Each cordless handset user can only access his/her own mailbox. The general delivery mailbox is managed by the base unit user (operator). The cordless handset users can access this mailbox. You can also access the Voice Mail System features remotely from a touch tone phone.

  • Page 9: Listening To Messages

    Setting the handset answer mode If you turn ON the answer mode of your handset, calls will be greeted with a greeting message (see on the right) and callers can leave messages in your mailbox. To take calls, leave this mode OFF (factory preset).

  • Page 10: Delivering Your Own Message

    Delivering Your Own Message You can send an identical message of up to 3 minutes, to several mailboxes. While the handset is in the standby mode, press • If the direct handset access mode is OFF (p. 8), enter the mailbox password and press •...

  • Page 11: Wall Mounting

    Using an Optional Headset Plugging an optional headset into the cordless handset allows a hands-free phone conversation. Please use only the Panasonic KX-TCA88 headset. To order, call the accessories telephone number on page 1. Connecting the headset to the cordless handset Open the headset jack cover, and connect the headset to the headset jack as shown.

  • Page 12: Using The Belt Clip

    To attach the belt clip Battery Replacement If “Recharge” is displayed and/or “ fully charged, replace the battery with a new Panasonic HHR-P506 (PQHHR150AA21) battery. To order, call the accessories telephone number on page 1. Remove the cover by sliding while pressing the arrow.

  • Page 13: Fcc And Other Information

    — Consult the dealer or an experienced radio/TV technician for help. Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America One Panasonic Way, Secaucus, New Jersey 07094 Panasonic Sales Company, Division of Matsushita Electric of Puerto Rico, Inc.
