Technical Service Guide
March 2021
2020 Plastic Tub Value Model
Dishwasher
GDF450P*R0**
GDF450P*R1**
GDF510P*R0**
GDF510P*R1**
GDF511P*R0BB
GDF511P*R0**
GDF511P*R1**
GDF535P*R0**
GDF535P*R1**
GDT535P*R0**
HDF310PGR0**
HDF310PGR1**
HDF330PGR0**
HDF330PGR1**
HDF360P*R0**
HDF360P*R1**
XDF250PGR1**
XDF350P*R1**
31-9354
Advertisement
Table of Contents
Related Manuals for Haier GE GDF450P R0 Series
Summary of Contents for Haier GE GDF450P R0 Series
- Page 1 Technical Service Guide March 2021 2020 Plastic Tub Value Model Dishwasher GDF450P*R0** HDF360P*R0** GDF450P*R1** HDF360P*R1** GDF510P*R0** XDF250PGR1** GDF510P*R1** XDF350P*R1** GDF511P*R0BB GDF511P*R0** GDF511P*R1** GDF535P*R0** GDF535P*R1** GDT535P*R0** HDF310PGR0** HDF310PGR1** HDF330PGR0** HDF330PGR1** 31-9354...
-
Page 2: Safety Information
5. Locate the Warranty page. GE Appliances, a Haier Company Copyright © 2021 All rights reserved. This service guide may not be reproduced in whole or in part in any form without written permission from GE Appliances, a Haier Company. – 2 –... -
Page 3: Table Of Contents
Table of Contents Safety Information ........................2 Warranty ............................2 Table of Contents ..........................3 Safety Requirements ........................6 Nomenclature ..........................7 Specifications ..........................8 Product Specifications ......................8 Electrical Specifications ......................8 Operation and Cycle Information ....................9 Troubleshooting ..........................12 Flashing Lights ........................12 Will Not Start .........................12 Component Locator Views ......................13 Front Control .........................13 Right Side View ........................13 Left Side View ........................14... - Page 4 Circulation Diagnostics ......................26 No Circulation ........................27 Circulation Motor and Pump Assembly .................28 Main Conduit ........................29 Middle Conduit ........................29 Spray Arms ...........................29 Upper Rack ...........................30 Lower Rack ...........................30 Tub Gasket ...........................31 Latch System ........................32 Dry System ...........................33 Heat Element Removal ......................34 Heater Components ......................35 Structure ............................37 Toe Kick ..........................37...
- Page 5 Door ..............................49 Door Removal ........................49 Outer Door Panel ........................51 Front Control Console ......................52 User Interface (UI) Control Board ..................53 Door Gasket .........................53 Detergent Dispenser ......................53 Door Strike ..........................54 Error Mode ...........................55 Service Mode ..........................56 Critical Faults ..........................57 Fault Codes ..........................58 Demo Mode ..........................59 Sabbath/Door Wake Up Mode ......................59 Wiring Diagram ..........................60...
-
Page 6: Safety Requirements
Safety Requirements GEA Factory Service Employees are required to use safety glasses with side shields, safety gloves and steel toe shoes for all repairs. Prescription Safety Glasses Plano Type Safety Glasses Safety Glasses must be ANSI Z87.1-2003 compliant Cut Resistant Sleeve(s) Electrically Rated Glove and Dyneema®Cut Resistant Dyneema®... -
Page 7: Nomenclature
Nomenclature Model Number G D F 5 3 5 P G R 0 B B Brand Color G: GE BB: Black H: Hotpoint CC: Bisque Engineering SS: Stainless Digit WW: White Configuration 0 - 99 D: Built-In Model Year R: 2021 Control Appearance F: Front Control Exterior Finish... -
Page 8: Specifications
Specifications Product Specifications • Approximate Shipping Weight (lb.) ~ 70 pounds (depending on model) • Height w/ Legs Retracted (in.) 33 3/8-in. • Height w/Legs Extended (in.) 34 5/8-in. • Overall Width (in.) 24 3/4-in. • Overall Depth (in.) 24-in. Electrical Specifications AC Voltage DC Voltage... -
Page 9: Operation And Cycle Information
Operation and Cycle Information This section of the guide provides details on segments of cycles, timing of cycles, temperature expectations, and cycling of the heater during the dry portion of a cycle. Auto Hot Start At the beginning of the main wash, the dishwasher checks the temperature of the water, and if it is below 90°F, then it will add up to 10 minutes of time to heat the water to 90°F by circulating the water while the heater is on. - Page 10 Cycle Times (Estimated) NOTES: Cycle times will vary depending on options selected, incoming water temperature, and soil level (some models). • Incoming water temperature of 120°F to 140°F is recommended. • Circulation has built-in pauses (see Two Port Diverter in the Circulation System section of this guide).
- Page 11 Target / Max Temperature Limits Cycle Rinse Normal Heavy 1-Hour Everyday Heavy Duty Heater Algorithm, Dry Cycle Normal with Heated Dry Time Calrod Description (minutes) Calrod on Calrod Pulse - 2 minute on/1 minute off Calrod off - Cool Down Normal with Temp Boost or Steam/Sani Selected Calrod on Calrod Pulse - 1 minute on/1 minute off...
-
Page 12: Troubleshooting
Troubleshooting This troubleshooting section is an overview of diagnostic capabilities of the electronic control. The control also features retrieval of fault codes when Consumer Error Mode is initiated; operation of loads is achieved in Service Mode. Single mounting screw Details on Error Mode and Service Mode, as well as Service LED are located in the Main Control Board section of this service guide. -
Page 13: Component Locator Views
Component Locator Views Appearances may vary throughout this service guide. Some models do not have all features shown, or may be different depending on the model number. Front Control Front Console Pocket Handle Outer Door Panel Right Side View Offset Leg Door Hinge Pulley Cable Pulley Hinge... -
Page 14: Left Side View
Left Side View Door Latch Harness (Part of the DC Harness) High Drain Loop Hose Fill Funnel Fill Hose Offset Leg Door Hinge Wishbone Link Black Door Spring – 14 –... -
Page 15: Toe Kick Area
Toe Kick Area Toe Kick Screws (x2) Water Valve Junction Box Insulation Toe Kick Sump Bottom View Level Leg Machine Control Sump Junction Box Water Valve Drain Hose Heater Tower Nuts – 15 –... -
Page 16: Inside Tub (Bottom) View
Inside Tub (Bottom) View Fill Funnel Main Conduit Sump Diverter Exposed Heater Coarse Filter Heater Clip Fine Filter and Basket Assembly Sump (Bottom) View Pressure Sensor Sump Thermistor Sump Latch Cam Sump Latch Cam Floating Seal Drain Pump Circulation Pump Sump Latch Cam –... -
Page 17: Inside View
Inside View Upper Rack Upper Spray Arm Main Conduit Tub Gasket Silverware Basket Lower Rack Lower Spray Arm Detergent Module Latch Striker – 17 –... -
Page 18: Racks
Racks Mid Conduit Small Cup Shelve Upper Rack Rollers and Brackets Upper Rack Silverware Basket Lower Rack Rollers and Carrier Lower Rack – 18 –... -
Page 19: Tub
Sump Module Removal Sump Module 1. Remove power to the dishwasher. Located on the top side of the sump are the 2. Remove the upper and lower racks. diverter components. The bottom of the diverter is molded into the sump. A check ball or two-port 3. - Page 20 9. Disconnect the thermistor sensor harness. 12. Push the sump from the bottom into the tub. 13. Grasp the sump from inside. Using care, tilt and lift to bring the sump into the tub. Bring the drain pump up and in first. This allows access to disconnect the wiring in the next step.
-
Page 21: Sump Gasket
Sump Gasket Ultra-Fine Filter Good filtration is key to good wash performance. Stressing or softening the gasket ribs (pressing the ribs against a hard surface, see below) will The ultra-fine filter and basket assembly is make a new gasket seat easier. Lubricating with consumer removable with a twist lock design. -
Page 22: Fine Filter
The ultra-fine filter water path is shown below. Fine Filter Water enters the top of the filter, into the sump and through the ultra-fine filter mesh screen. The fine filter is located on the sump assembly The water mixes with the water that has passed and should be cleaned each year or as needed through the fine filter, passes the turbidity sensor for optimum performance. -
Page 23: Two-Port Diverter
Operation Two-Port Diverter 1. The “bypass” allows water to bypass the The two-port diverter is the key component which check ball in the diverter as described in allows low water use, by alternating water to the the next step. The dishwasher is in OFF lower spray arm or mid spray arm, bottle wash or standby mode, no pump operation. - Page 24 3. The wash pump cycles OFF for one second. 6. When the wash pump starts, the check ball Water that is in the rear conduit forces the again seals the rear port, or upper spray arms. check ball to the lower spray port. The cycle repeats.
-
Page 25: Circulation System
Circulation System With only 0.75 to 0.95 gallons of water, filtration is the start of improved performance. Water is cleaned through the fine and ultra-fine filters before it enters the main pump. Water must also flow through the Piranha Hard-Food Disposal and finally into the wash pump assembly. Clean filtered water then flows into the diverter system which directs it to either the lower spray arm or mid spray arm. -
Page 26: Circulation Diagnostics
7. The clear door has a latch strike. When Circulation Diagnostics pushed into the latched position, it will activate the door switch assembly. The Clear Door Diagnostic Tool dishwasher may not start if the door is installed to low. The clear door (Part #: WX05X20002) provides technicians with a tool to accurately diagnose 8. -
Page 27: No Circulation
No Circulation Circulation Motor Fuse The circulation motor fuse is located on the main control board. The fuse is not removable. Test continuity between each fuse by touching the touch pads TP501 and TP502. The machine control board has a conformal coating (clear coat). Press hard to break this coating. If an open fuse is found, replace the machine control and circulation pump. -
Page 28: Circulation Motor And Pump Assembly
Circulation Motor and Pump Assembly The circulation motor is a DC Brushed Motor; it has onboard AC to DC rectification. Resistance cannot be properly checked on this motor because of the rectifier and diodes inside the motor shield. Circulation Pump Motor Assembly Removal 1. -
Page 29: Main Conduit
Mid Conduit The middle conduit is replaced as an assembly, Main Conduit and individual parts for the assembly are not available separately. The main conduit supplies water to the mid spray arm. Spray Arms Main Conduit Removal The lower and mid spray arms are twist lock 1. -
Page 30: Upper Rack
Tub Rollers Upper Rack The tub rollers are attached to the tub with a The upper rack is non-adjustable. It is fixed to screw in each roller. one position. To Remove the Tub Rollers 1. Remove the upper rail by removing the rear end cap. -
Page 31: Tub Gasket
To remove the lower rack brackets, insert a flat-blade screw-driver under the tab and pry up. Then slide the assembly off of the rack Gasket Gasket Track Gasket Stop Tub Gasket Installation 1. The center of the gasket has a mark Pinch the clips inward and pull the rollers off of which is placed pointing to the inside of brackets. -
Page 32: Latch System
3. Remove two screws, (R2 Robertson / Carpenters Bit or #2 Phillips screw-driver). Tub gasket seated firmly into track 5. Always run the dishwasher to test for leaks. Latch System The door switch is rated at 13.5 VDC. The tub latch is located on top of the tub. -
Page 33: Dry System
Dry System Introduction Operation The dual wattage Calrod heater serves both to heat the water during a wash cycle and to heat the air during the dry cycle. Heat and air circulation are required for good dry performance. Air circulation is natural convection with air entering through the fill funnel. -
Page 34: Heat Element Removal
Element Removal by Uninstalling the Heat Element Removal Dishwasher The heater may be removed by one of two 1. Disconnect power to the dishwasher. methods. The first method requires door and 2. Remove the lower rack. sump removal to gain access to the element nuts. The second method requires the dishwasher be 3. -
Page 35: Heater Components
Heater Nut and Ground Clip Heater Components Plastic tub dishwashers have a grounding clip Heater Support Bracket installed on the tub. The heater is then grounded to the clip by a grounding nut. The grounding nut must be installed back on the grounding clip. The grounding clip and nut is critical for proper operation of the CSM. - Page 36 Diagnostics Heat Element will not come on Access main control, enter service mode. Check for 120 VAC connector at J503-1 WR to J503-2 VX? Check resistance Check thermistor* Check Thermistor*, connector J503 -1 connec�ons and DC is it within White/Red to Pin 2 Violet harness, are they OK? specifica�ons? 14 29 ohms?
-
Page 37: Structure
Structure The tub and structure section of this guide will Junction Box and House Wiring cover the toe kick, junction box, racks, leveling Connection legs, door balance, gaskets, main control board, door, door components, as well as the removing The junction box is located behind the toe kick and separation of the screwless appearance door. -
Page 38: Leveling Legs
Leveling Legs Right Door Balance System The silver spring attaches to the rear of the There are four leveling legs located on the base vertical leg base assembly. There is one hole rails of the dishwasher. in the leg and is not adjustable. The spring To access the leveling legs, remove the toe kick connects to a pulley cable which connects to the and insulation (on some models). -
Page 39: Fill System
Fill System Water Level The dishwasher has a fill volume of approximately To check for proper water level, place the .75-.90 gallons of water and is a DC volt circuit. dishwasher in Service Mode and run the Fill Test. The water valve is rated at 13.5 VDC, resistance Water must reach the level shown below. -
Page 40: Fill Funnel And Hose
Testing the Pressure Sensor: To verify the Fill Funnel and Hose pressure sensor is receiving power, remove the connector from the sensor and test for 5 VDC The fill funnel is located on the left side of the between pin 2 (+) and pin 3 (-) on the sensor. To dishwasher tub. -
Page 41: Fill Valve
4. Pull fill funnel away from the tub. Locking Fill Valve tabs and guide tabs help secure the fill funnel to the side of the tub. 1. Remove power to the dishwasher. 2. Remove the toe kick. 3. Remove one 1/4-inch hex-head screw from the bracket to the left leg assembly. -
Page 42: No Fill Diagnostics
No Fill Diagnostics Dishwasher not filling Are any fault codes displayed? Enter Service No repair needed, Mode, fill test (60 second possible home water fill) Does it fill? pressure fluctuation Is the fill level correct? Check for house Is water supply Check for plumbing fault, kinked fill Replace... -
Page 43: Main Control Board
Main Control Board Diagnosing the machine control board is covered in this section. Many components can be checked from the main control, which can be accessed with the door on or removed if needed. Some connectors are located through the bottom cover to allow easy access to the AC supply connector, door harness and ACM or Appliance Control Module. -
Page 44: To Access Main Control Board
To Access Main Control Board Thermistor To Access Main Control Board The thermistor monitors water temperature in the tub. If the thermistor opens or shorts it will cause 1. Remove power to the dishwasher. an error (see Error Mode section of this service guide). -
Page 45: Current Sensor Module (Csm)
Current Sensor Module (CSM) A CSM is a protective device located on the main control board. This device is designed to trip if current leakage to ground is above 20mA ± 5mA is detected. The CSM functions similar to commercially available GFCI's. If tripped, all control panel LED's will be flashing until the CSM is reset. -
Page 46: Drain System
Drain System Yellow Dark Blue J504-2 J504-1 Operation Drain Pump Drain water will back flush the fine filter through the coarse filter, allowing food particles to settle Failure to Drain Symptoms through the floor plate and into the drain pump. It may be normal for the drain pump to start and •... -
Page 47: Failure To Drain Flowchart
Failure to Drain Flowchart – 47 –... -
Page 48: Drain Pump
6. Pull out on the pump to finish removal. Drain Pump Drain Pump Removal or Replacement 1. Remove power to the dishwasher. 2. Remove the door (see Door Removal, under Door, in the Tub section of this service guide). 3. Remove the sump assembly (see Sump Module Removal, under Sump Module in the Tub section of this service guide). -
Page 49: Door
Door The door receives DC voltage only and has a 5. Locate the left door balance cable and insert screwless appearance. The door contains a an Allen wrench or tool formed into a hook (as User Interface (UI) board with all tactile switches shown below). - Page 50 Caution: If the cable is released, the spring and 8. Locate the right door balance cable and insert an Allen wrench or tool formed into a hook (as cable may become disconnected. Depending shown below). on the model and installation, reconnecting may require the dishwasher to be removed from installation.
-
Page 51: Outer Door Panel
To Separate the Door 3. Press the tabs firmly together while sliding the inner panel onto the outer panel, using care 1. Remove the door. to make sure the outer panel mates properly to the front or top console. The illustration 2. -
Page 52: Front Control Console
UI Control Board Removal Front Control Console 1. Remove front control console. There are several front control User Interface 2. Push down on the three tabs while pulling up (UI) configurations. There is a 2, 3, and 4 on the user interface control board. button configuration. -
Page 53: User Interface (Ui) Control Board
User Interface (UI) Control Board User Interface Control Board J101 Front View User Interface Control Board Back View Door Gasket Detergent Dispenser 1. Remove the door. 2. Place the door on a protected surface to prevent damage. 3. Slide the gasket either direction to remove. The door does not need to be separated. -
Page 54: Door Strike
Detergent Module Diagnosing 6. The detergent module can now be removed from the inner door panel. 1. Remove power to dishwasher. 2. Remove toe kick panel. 3. Disconnect door harness. 4. Remove and separate the door. 5. The inner panel may be set into the dishwasher and latched in the closed position. -
Page 55: Error Mode
Error Mode To Enter Error Mode Start LED Fault Fault Description Blinks Code Wake up the control by opening and closing the door for all models. F153 Door latch failure. Temperature sensor For Models with 1 or 2 Pads high. Wake up the control. -
Page 56: Service Mode
Service Mode Service Mode can only be entered during For Models with 3 or More Pads Error Mode. Press and hold the furthest most pad on the left NOTE: Entering Service Mode resets the CSM. for 5 seconds. Pressing the furthest most pad on the left will select the test. -
Page 57: Critical Faults
Critical Faults Critical faults will shut the dishwasher down. The Start LED then will blink according to the fault. This will be displayed to the consumer and will allow the technician to properly diagnose a critical issue without having to enter Service Mode. Start LED Error Name Action Item... -
Page 58: Fault Codes
Fault Codes Fault Load to Control Action Items Code Communication Error with UI Verify harness connections between User Interface (UI) Board board and Main Control (MC) board. High Water Temperature Check thermistor, harness and connectors. Check to see if pressure sensor is plugged in. If so, then most likely pressure sensor is out of range, thus Water Level Sensor Invalid replace pressure sensor. -
Page 59: Demo Mode
Fault Load to Control Action Items Code The control has detected the pressure sensor at a flood F151 Continuous Flow Fault stage. Check for stuck open water valve or continuous voltage to the valve. The control has detected a stuck heater relay. Cycle F152 Continuous Heater Power. -
Page 60: Wiring Diagram
Wiring Diagram Solid Colors Stripe Colors Color Designator Color Designator Black Black White Brown Yellow Green Orange Blue Grey Orange Dark Blue (Navy) Grey Brown Purple Purple White Green Yellow Lt Blue (Aqua) None Pink Wire color indicated by two-character code. Example: BW is black with white stripe. -
Page 61: Index
