Discover your Lenovo computer ® Thank you for choosing a Lenovo computer! We are dedicated to delivering the best solution to you. Before starting your tour, please read the following information: • Illustrations in this documentation might look different from your product.
Features and specifications For detailed specifications of your computer, go to https://psref.lenovo.com • Width: 37 mm (1.5 inches) Dimensions • Height: 179 mm (7 inches) • Depth: 182.9 mm (7.2 inches) Weight (without packaging) Maximum configuration as shipped: 1.4 kg (3 lb) Type Device Manager in the Windows search box and then press Enter.
• Charge USB-C compatible devices with the output voltage and current of 5 V and 0.9 A. • Connect to USB-C accessories to help expand your computer functionality. To purchase USB-C accessories, go to https://www.lenovo.com/accessories • USB-C (3.2 Gen 1) connector • USB-C (3.2 Gen 2) connector...
1. Type Bluetooth in the Windows search box and then press Enter. 2. Turn on Bluetooth, if it is off. 3. Select a Bluetooth device, and then follow the on-screen instructions. Use with a Tiny-In-One monitor Note: When installing the computer to the TIO monitor, ensure that you use the ac power adapter that comes with the computer.
• ThinkCentre TIO24Gen3Touch • ThinkCentre 超级Q24Gen3Touch Purchase accessories Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your computer. Options include memory modules, storage devices, network cards, power adapters, keyboards, mice, and more. To shop at Lenovo, go to https://www.lenovo.com/accessories...
Chapter 4. Secure your computer and information Lock the computer Note: Lenovo makes no comments, judgments, or warranties about the function, quality, or performance of the locking device and security feature. You can purchase computer locks from Lenovo. Kensington-style cable lock Lock your computer to a desk, table, or other fixtures through a Kensington-style cable lock.
You should record your passwords and store them in a safe place. If you forget the passwords, contact a Lenovo-authorized service provider to have the passwords removed. Note: If the hard disk password is forgotten, Lenovo cannot remove the password or recover data from the storage drive.
2. The request data is displayed. Click Save to File to save the request data in a USB key and send the request data to IT admin by e-mail or phone. 3. Enter the unlock code provided by IT admin and click OK. Notes: •...
2. Select Security ➙ secure wipe ➙ Enabled. 3. Press F10 or Fn+F10 to save the changes and exit. 4. Restart the computer. When the logo screen is displayed, press F12 or Fn+F12. 5. Select App Menu ➙ secure wipe and press Enter. 6.
Page 21
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1. 2. Select Security ➙ Smart USB Protection and press Enter. 3. Select the desired setting and press Enter. 4. Press F10 or Fn+F10 to save the changes and exit. Chapter 4 Secure your computer and information...
Change the display mode of UEFI BIOS (for selected models) You can use UEFI BIOS in the graphic mode or the text mode according to your needs. The keys on the keyboard used to perform various tasks are displayed at the bottom of the screen. In addition to the keyboard, you also can use the mouse to make selections.
2. Restart the computer. When the logo screen is displayed, press F12 or Fn+F12. 3. Select the storage device as desired and press Enter. If you want to change the boot priority order permanently, select Enter Setup on Startup Device Menu and press Enter to enter the BIOS menu.
Open the Vantage app to check the available update packages. If the latest UEFI BIOS update package is available, follow the on-screen instructions to download and install the package. • From the Lenovo Support Web site: 1. Go to https://pcsupport.lenovo.com 2.
Recover from a BIOS update failure 1. Remove all media from the drives and turn off all connected devices. 2. Insert the BIOS update disc into the optical drive, and then turn off the computer. 3. Disconnect all power cords from electrical outlets. Then, remove any parts that impede access to the Clear CMOS/Recovery jumper.
Page 30
3. Select Intel (R) Rapid Storage Technology and press Enter. 4. Select Create RAID Volume and press Enter. 5. Select Name and press Enter. When prompted, type a proper RAID Volume name in the field. 6. Select RAID Level and press Enter. When prompted, select a RAID level in the field. 7.
If you are unable to isolate and resolve the problem after running the Vantage app, save and print the log files created by the program. You might need the log files when you speak to a Lenovo technical support representative.
If you intend on installing the CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You might be required to return the defective part that is replaced by the CRU.
• System fan • Wi-Fi card* • Wi-Fi card shield* * for selected models Remove or replace a CRU This section provides instructions on how to remove or replace a CRU. Power adapter and power cord Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, do the following: 1.
VESA mount bracket Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, do the following: 1. Turn off the computer and remove all connected devices and cables. 2. Disconnect the computer from ac power and all connected cables. Removal steps Vertical stand Prerequisite...
Removal step External Wi-Fi antenna Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, do the following: 1. Turn off the computer and remove all connected devices and cables. 2. Disconnect the computer from ac power and all connected cables. P360 Tiny User Guide...
Removal steps External optical drive box and external optical drive Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, do the following: 1. Turn off the computer and remove all connected devices and cables. 2.
Dust shield Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, do the following: 1. Turn off the computer and remove all connected devices and cables. 2. Disconnect the computer from ac power and all connected cables. Chapter 8 CRU replacement...
Removal step Computer cover Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Before you open the computer cover, turn off the computer and wait several minutes until the computer is cool. For access, do the following: 1.
Removal steps Internal speaker Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, do the following: 1. Remove the computer cover.See “Computer cover” on page 34. 2. Disconnect the internal speaker cable from the internal speaker connector on the system board. Removal steps •...
System fan Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, do the following: 1. Remove the computer cover. See “Computer cover” on page 34. 2. Remove the internal speaker. See “Internal speaker” on page 35. 3.
Replacement procedure Coin-cell battery Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Your computer has a special type of memory that maintains the date, time, and settings for built-in features, such as parallel connector assignments (configurations). A coin-cell battery keeps this information active when you turn off the computer.
• “System fan” on page 36 Note: Remove the battery protective cover when removing the battery. Removal steps Note: After installing a new coin-cell battery, reset the system date and time in the UEFI BIOS menu. PCIe card and PCIe converter Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions.
Page 45
• Type 2 1. For access, remove the following parts in order: – “Computer Cover” on page 34 – “System fan” on page 36 2. Replace the PCIe card and PCIe converter. Chapter 8 CRU replacement...
Wi-Fi card and Wi-Fi card shield Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, remove the following parts in order: • “Computer cover” on page 34 • “PCIe card and PCIe converter” on page 38 Chapter 8 CRU replacement...
Removal steps Bottom cover Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. For access, do the following: • Remove the computer cover.See “Computer cover” on page 34. • Turn over the computer so that the bottom cover is facing up. Replacement procedure P360 Tiny User Guide...
M.2 solid-state drive Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Attention: The M.2 solid-state drive is sensitive. Inappropriate handling might cause damage and permanent loss of data. When handling the M.2 solid-state drive, observe the following guidelines: •...
Memory module Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Ensure that you follow the installation order for memory modules shown in the following illustration. For access, remove the following parts in order: •...
How to access? • https://www.lenovo.com/tips Troubleshooting and frequently asked questions • https://forums.lenovo.com Accessibility information https://www.lenovo.com/accessibility • Use Lenovo recovery options. 1. Go to https://support.lenovo.com/ HowToCreateLenovoRecovery 2. Follow the on-screen instructions. • Use Windows recovery options. Reset or restore Windows 1. Go to https://pcsupport.lenovo.com...
Page 54
Resources How to access? Lenovo Support Web site with the latest support information of the following: • Drivers and software • Diagnostic solutions https://pcsupport.lenovo.com • Product and service warranty • Product and parts details • Knowledge base and frequently asked questions •...
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Prepare the following before you contact Lenovo: 1. Record the problem symptoms and details: •...
• Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service.
Page 57
4400 MT/s. • The microprocessor models supported in your computer might vary. For a list of supported microprocessor models, contact the Lenovo Customer Support Center. Refer to the following information about the system memory speed: • Memory module types: DDR5 non-ECC SODIMMs •...
Safety and Compliance Notices at https://pcsupport.lenovo.com/docs/generic_notices Certification-related information Product name: ThinkStation P360 Tiny Machine types: 30F8, 30F9, 30FA, 30FB, 30FC, 30FD, 30FE, 30FF, 30FG, 30FH, 30FJ, and 30FK Further compliance information related to your product is available at https://www.lenovo.com/compliance...
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
