Specifications

Part numbers:
ICRXIBN7E000A
ICRXIBN7E001A
ICRXIBN7M000A
ICRXIBN7M001A
ICRXIBN0E000A
ICRXIBN0M000A
ICRXIACCBPL
IC690ACC001

General Specifications

Dimensions
Weight:
Processor
RAM
Floating point
Non-volatile storage
Time of day clock (RTC)
accuracy
Elapsed time clock (internal
timing) accuracy
Video
Maintenance ports
Power requirements
Serial Communications
Ethernet Communications
2
RXi Box IPC with Embedded 32GB mSATA SSD and Windows 7 Professional,
SP1 or later operating system
RXi Box IPC with Embedded 32GB mSATA SSD and Windows Embedded
Standard 7
RXi Box IPC with 250GB Magnetic SATA Hard Drive and Windows 7
Professional, SP1 or later operating system
RXi Box IPC with 250GB Magnetic SATA Hard Drive and Windows Embedded
Standard 7
RXi Box IPC with Embedded 32GB mSATA SSD
RXi Box IPC with 250GB Magnetic SATA Hard Drive
Optional Backplate for DIN rail mounting
Real Time Clock (RTC) battery, included with IPC
†
†
Intended only for temporary connection.
Introduction
IPC: 191.8mm x 115.6mm x 81.3mm
(7.55 in x 4.55 in. x 3.2 in)
Backplate: 226 mm x 137 mm x 12 mm
(8.90 in. x 5.39 in. x 0.47 in.)
IPC without Backplate 1.814 Kg (4 lbs)
Backplate 0.454 Kg (1 lb)
1.0 GHz VIA Eden dual core processor
4GB DDR3
64 bit
32GB mSATA SSD or 250GB SATA drive
Non-volatile storage (NVS) can retain data indefinitely without loss of
data integrity.
Maximum drift of ±2 seconds/day at 25°C.
± 0.01% maximum
Standard 15-pin VGA connector
Two Type A USB 2.0
SD standard card slot
Dual function Audio out/Microphone in jack (3.5mm four-pin TRRS)
1.8 A at 24 VDC (18–32 VDC)
LPS or Class 2 power supply required.
One RS-232 RJ-45 port
ICRXIBN7x000A-CA versions and earlier
ICRXIBN7x001A
Two Ethernet (10, 100, 1000 Mbit/s) RJ-45 ports
PACSystems* RXi Box IPC
COM2
COM1
