Washing Machine
This manual is made with 100% recycled paper.
DC68-03273N-01
F500S_W3050_DC68-03273N-01_EN.indd 1
user manual
imagine
the possibilities
Thank you for purchasing a Samsung
product.
To receive a more complete service, please
register your product at
www.samsung.com/register
WA90F5S2
WA10F5S2
WA11F5S2
WA12F5S2

Advertisement

Table of Contents
loading

Related Manuals for Samsung WA10F5S2

Summary of Contents for Samsung WA10F5S2

  • Page 1 WA10F5S2 WA11F5S2 WA12F5S2 Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register DC68-03273N-01 F500S_W3050_DC68-03273N-01_EN.indd 1...

  • Page 2: Table Of Contents

    contents SAFETY INSTRUCTIONS Important safety precautions SETTING UP YOUR WASHER Description of part Checking before washing and caring for garments How to wash automatically depends on the laundry Control Panel MANUAL FUNCTIONS Manual functions INSTALLATION & MAINTENANCE Environment Leveling Connecting the water supply hose Assembling the rat protection panel (option) How to connect the drain hose (option) Adding detergent...
  • Page 3 safety instructions_3 F700S_W3050_WA18F7-03271K_EN.indd Sec2:4 F700S_W3050_WA18F7-03271K_EN.indd Sec2:4 F700S_W3050_WA18F7-03271K-01_EN 2013-04-26 2013-04-26 25/02/2014 4:42:21 4:42:21...
  • Page 4 4_safety instructions F700S_W3050_WA18F7-03271K_EN.indd Sec2:5 F700S_W3050_WA18F7-03271K-01_EN 25/02/2014...
  • Page 5 safety instructions_5 F700S_W3050_WA18F7-03271K_EN.indd Sec2:6 F700S_W3050_WA18F7-03271K-01_EN 25/02/2014...

  • Page 6: Setting Up Your Washer

    setting up your washer DESCRIPTION OF PART The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. Water supply hose (Cold) Water supply hose (Hot) Be sure to keep the lid closed during washing and spinning.

  • Page 7: Checking Before Washing And Caring For Garments

    CHECKING BEFORE WASHING AND CARING FOR GARMENTS Must follow the checkpoints in order to avoid machine problems or damages on garments. • If the below problems are caused by customer’s faults, separate service fee will be charged. Checkpoints Before Starting Washing Check if the clothes are bleaching or not.
  • Page 8 setting up your washer CARING FOR CLOTHES BEFORE WASHING Take out personal belongings from pockets. • Caution, Check the pockets! Hairpins and coins cause damages to clothes and washing machine. They make noise and problems to the machine. Must check the pocket. If pants zippers are open while washing, the spin basket may be damaged.

  • Page 9: How To Wash Automatically Depends On The Laundry

    HOW TO WASH AUTOMATICALLY DEPENDS ON THE LAUNDRY Before starting washing, check the following; • Connect the water supply hose to the water tap. Leave a tap open. Plug the power cord in. Make sure to lay down the drain hose. Washing for the fi...

  • Page 10: Control Panel

    setting up your washer CONTROL PANEL For more details, see control panel of your washing machine. Displays the remaining wash time. Digital graphic Displays the error state if a problem occurs in the washing machine so that you display can take action. The water level is automatically adjusted.
  • Page 11 Fuzzy Selects the best washing program automatically. If you want to wash those frequently used towels or less dirty Quick laundry time. Because washing is speedy, it is good for light or less stained laundry. Delicate Washable sweater, cardigan, delicate clothes etc. Blanket Big volume laundry like blanket and bed cover sheets Jeans...

  • Page 12: Manual Functions

    manual functions Possible to select the function for each program. (Example) For a simple washing as the little dirt program : Power  Select the little dirt program  Wash  Start/Pause Press the Power button. WASH ONLY Press the Wash button. Press the Start/Pause button.

  • Page 13: Installation & Maintenance

    installation & maintenance The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. ENVIRONMENT Leave some space Maintain at least 10 cm between the washer and the wall. Place the washer on a sturdy fl at surface. If the washer is placed on an uneven or weak surface, noise or vibration occurs.

  • Page 14: Assembling The Rat Protection Panel (Option)

    installation & maintenance 4. Connect the water supply hose to the adaptor. Pull down the part (c) of the water supply hose. When the part (c) is released, the hose is automatically connected to the adaptor making a ‘click’ sound. 5.

  • Page 15: How To Connect The Drain Hose (Option)

    HOW TO CONNECT THE DRAIN HOSE (OPTION) IN CASE OF PUMP-DRAINED WASHER cap-hose Take out the cap-hose and connect the Be sure to join tightly the drain hose into the outlet-hose. drain outlet on the back of the machine. Drain hose Hose guide Be sure to join tightly the drain hose into the Install the drain hose in the position of about...

  • Page 16: Adding Detergent

    installation & maintenance CAUTIONS WHEN INSERTING THE DRAIN HOSE Less than 3 m 1. Don’t exceed more than 3 m when the 2. Be careful to drain water out at the end of drain hose is used by connecting with the drain hose.

  • Page 17: Water Supply Connector Filter

    WATER SUPPLY CONNECTOR FILTER 1. Pull out the fi lter and wash well. 2. Pull in the fi lter and connect the hose to the inlet water valve tightly. 3. Check if there is a leakage. Note to tighten up the connector. CLEANING THE FILTER Clean the filter net often to keep the washer clean.

  • Page 18: Troubleshooting

    troubleshooting PROBLEM CHECK Washing machine won’t work • Is the water tap opened? • Is the washer plugged in? • Is the power cut off? • Is there enough water? Water dose not drain • Is the drain hose down?(No pump) •...

  • Page 19: Washing Machine Won't Work

    washing machine won’t work? PROBLEM CHECK The power is cut off. Is the electric voltage normal? Is the washer plugged in? Plug in the electric cord.  Water does not drain. Is the drain hose down? Put the drain hose down. Is the drain hose folded? Unfold the drain hose.
  • Page 20 washing machine won’t work? PROBLEM CHECK When no water is extracted. Did you press the Start/Pause button after selecting the water supply?  If the Start/Pause button is not pressed, water is not supplied. Press the Start/Pause button. Is the faucet closed? ...

  • Page 21: Specification

    74 ℓ 65 ℓ STANDARD WATER LEVEL 51 ℓ 44 ℓ 34 ℓ ℓ WA10F5S2, WA12F5S2 POWER CONSUMPTION W680 x L670 x H983 (LOW BASE) DIMENSIONS(mm) W610 x L670 x H1003 (HIGH BASE) WEIGHT 41 kg 0.05~0.78 Mpa WATER PRESSURE (0.5 ~ 8.0 kg·f/cm2)
  • Page 22 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT www.samsung.com/ae/support (English) U.A.E 800-SAMSUNG (726-7864) www.samsung.com/ae_ar/support (Arabic) www.samsung.com/ae/support (English) KUWAIT 183-2255 (183-CALL) www.samsung.com/ae_ar/support (Arabic) 08000-726786 EGYPT www.samsung.com/eg/support 16580 NIGERIA 0800-726-7864 www.samsung.com/africa_en/support Code No. DC68-03273N-01_EN F500S_W3050_DC68-03273N-01_EN.indd Sec7:24...
  • Page 23 ‫ﺩﻟﻴﻞ ﺍﳌﺴﺘﺨﺪﻡ‬ .٪ ‫ﰎ ﺗﺼﻨﻴﻊ ﻫﺬﺍ ﺍﻟﺪﻟﻴﻞ ﻣﻦ ﻭﺭﻕ ﻣﻌﺎﺩ ﺗﺪﻭﻳﺮﻩ ﺑﻨﺴﺒﺔ‬ ‫ﻫﺎﺋﻠﺔ‬ ‫ﺇﻣﻜﺎﻧﺎﺕ‬ .Samsung ‫ﺷﻜﺮ ﺍ ﹰ ﻟﺸﺮﺍﺋﻚ ﺃﺣﺪ ﻣﻨﺘﺠﺎﺕ‬ ‫ﻟﻠﺤﺼﻮﻝ ﻋﻠﻰ ﺧﺪﻣﺔ ﺃﻛﺜﺮ ﺗﻜﺎﻣ ﻼ ﹰ ، ﺍﻟﺮﺟﺎﺀ ﺗﺴﺠﻴﻞ ﺍﳌﻨﺘﺞ ﻋﻠﻰ‬ ‫ﺍﳌﻮﻗﻊ‬ www.samsung.com/register DC68-03273N-01_AR ‫ﺭﻗﻢ ﺍﻟﻜﻮﺩ‬ F500S_W3050_WA10F5-03273N_AR.indd 1...
  • Page 24 ‫ﺍﶈﺘﻮﻳﺎﺕ‬ ‫ﺇﻋﺪﺍﺩ ﺍﻟﻐﺴﻻﺔ‬ ‫ﻭﺻﻒ ﺍﻷﺟﺰﺍﺀ‬ ‫ﺍﻟﺘﺤﻘﻖ ﻣﻦ ﺍﻟﺴﻼﻣﺔ ﻗﺒﻞ ﺍﻟﻐﺴﻴﻞ ﻭﺍﻻﻋﺘﻨﺎﺀ ﺑﺎﳌﻼﺑﺲ‬ ‫ﺗﻌﺘﻤﺪ ﻃﺮﻳﻘﺔ ﺍﻟﻐﺴﻞ ﺑﺸﻜﻞ ﺗﻠﻘﺎﺋﻲ ﻋﻠﻰ ﻧﻮﻋﻴﺔ ﺍﻟﻐﺴﻴﻞ‬ ‫ﻟﻮﺣﺔ ﺍﻟﺘﺤﻜﻢ‬ ‫ﺍﻟﻮﻇﺎﺋﻒ ﺍﻟﻴﺪﻭﻳﺔ‬ ‫ﺍﻟﻮﻇﺎﺋﻒ ﺍﻟﻴﺪﻭﻳﺔ‬ ‫ﺍﻟﺘﺮﻛﻴﺐ ﻭﺍﻟﺼﻴﺎﻧﺔ‬ ‫ﺍﻟﺒﻴﺌﺔ‬ ‫ﻭﺿﻊ ﺍﻟﻐﺴﻻﺔ ﻋﻠﻰ ﺳﻄﺢ ﻣﺴﺘﻮ ﹺ‬ ‫ﺗﻮﺻﻴﻞ ﺧﺮﻃﻮﻡ ﺗﺰﻭﻳﺪ ﺍﳌﺎﺀ‬ (‫ﺗﺮﻛﻴﺐ ﻟﻮﺣﺔ ﺍﳊﻤﺎﻳﺔ ﻣﻦ ﺍﻟﻔﺌﺮﺍﻥ )ﺍﺧﺘﻴﺎﺭﻱ‬ (‫ﻛﻴﻔﻴﺔ...
  • Page 25 ‫ﺇﺭﺷﺎﺩﺍﺕ ﺍﻟﺴﻼﻣﺔ‬ ‫ﺍﻟﺮﺟﺎﺀ ﻣﻼﺣﻈﺔ ﺃﻥ ﺍﻻﺣﺘﻴﺎﻃﺎﺕ ﺍﻟﺘﺎﻟﻴﺔ ﺗﻬﺪﻑ ﺇﻟﻰ ﲡﻨﺐ ﺍﻟﺘﻌﺮﺽ ﻟﻸﺧﻄﺎﺭ ﺃﻭ ﺍﻷﺿﺮﺍﺭ ﻏﻴﺮ ﺍﳌﺘﻮﻗﻌﺔ، ﻭﺫﻟﻚ ﻋﻦ ﻃﺮﻳﻖ ﺍﳌﺴﺎﻋﺪﺓ ﻓﻲ ﺍﻻﺳﺘﺨﺪﺍﻡ ﺍﳌﻼﺋﻢ ﻣﻦ ﺃﺟﻞ‬ .‫ﺍﻟﺴﻼﻣﺔ‬ .‫ﻋﻨﺪ ﺍﺳﺘﺨﺪﺍﻡ ﺍﳌﺎﺀ ﺍﻟﺴﺎﺧﻦ ﻓﻲ ﺍﻟﻐﺴﻞ، ﺍﻟﺮﺟﺎﺀ ﺍﻟﺘﺄﻛﺪ ﻣﻦ ﺃﻥ ﺩﺭﺟﺔ ﺣﺮﺍﺭﺓ ﺍﳌﺎﺀ ﻻ ﺗﺘﻌﺪﻯ ٠٥ ﺩﺭﺟﺔ ﻣﺌﻮﻳﺔ‬ .‫ﻗﺪ...
  • Page 26 ‫ﺇﺭﺷﺎﺩﺍﺕ ﺍﻟﺴﻼﻣﺔ‬ ‫ﺗﻨﺒﻴﻪ: ﻟﺘﺠﻨﺐ ﻭﺟﻮﺩ ﺧﻄﺮ ﺑﺴﺒﺐ ﺇﻋﺎﺩﺓ ﺍﻟﻀﺒﻂ ﻏﻴﺮ ﺍﳌﻘﺼﻮﺩ ﻟﻠﻘﺎﻃﻊ ﺍﳊﺮﺍﺭﻱ، ﻳﺠﺐ‬ ‫ﺃﻻ ﻳﺘﻢ ﺗﻮﺭﻳﺪ ﻫﺬﺍ ﺍﳉﻬﺎﺯ ﺑﺎﻟﻄﺎﻗﺔ ﻣﻦ ﺧﻼﻝ ﺟﻬﺎﺯ ﻓﺼﻞ ﻭﻭﺻﻞ ﺧﺎﺭﺟﻲ -ﻣﺜﻞ ﺍﳌﺆﻗﺖ- ﺃﻭ‬ ‫ﺗﻮﺻﻴﻠﻪ ﺑﺪﺍﺋﺮﺓ ﻛﻬﺮﺑﺎﺋﻴﺔ ﻳﺘﻢ ﺗﺸﻐﻴﻠﻬﺎ ﻭﺇﻳﻘﺎﻑ ﺗﺸﻐﻴﻠﻬﺎ ﺑﺼﻮﺭﺓ ﻣﻨﺘﻈﻤﺔ ﻣﻦ ﻗﺒﻞ‬ .‫ﻣﺮﻓﻖ...
  • Page 27 ‫ﻳ ﹸ ﻌﺪ ﺍﺳﺘﺨﺪﺍﻡ ﺍﳌﻨﺘﺞ ﻷﻏﺮﺍﺽ ﺍﻟﻌﻤﻞ ﺳﻮﺀ ﺍﺳﺘﺨﺪﺍﻡ ﻟﻪ. ﻭﻓﻲ ﻫﺬﻩ ﺍﳊﺎﻟﺔ، ﻻ ﺗﺘﻢ ﺗﻐﻄﻴﺔ ﺍﳌﻨﺘﺞ ﻣﻦ ﺧﻼﻝ ﺍﻟﻀﻤﺎﻥ ﺍﻷﺳﺎﺳﻲ ﺍﻟﺬﻱ‬ .‫ ﻻ ﺗﺘﺤﻤﻞ ﺃﻱ ﻣﺴﺌﻮﻟﻴﺔ ﻋﻦ ﺍﻷﻋﻄﺎﻝ ﺃﻭ ﺍﳋﺴﺎﺋﺮ ﺍﻟﺘﻲ ﺗﻨﺠﻢ ﻋﻦ ﺳﻮﺀ ﺍﻻﺳﺘﺨﺪﺍﻡ‬Samsung ‫، ﻛﻤﺎ ﺃﻥ ﺷﺮﻛﺔ‬Samsung ‫ﺗﻘﺪﻣﻪ ﺷﺮﻛﺔ‬...
  • Page 28 ‫ﺇﻋﺪﺍﺩ ﺍﻟﻐﺴﺎﻟﺔ‬ ‫ﻭﺻﻒ ﺍﻷﺟﺰﺍﺀ‬ .‫ﺩﻟﻴﻞ ﺍﳌﺴﺘﺨﺪﻡ ﻣﺨﺼﺺ ﻟﻼﺳﺘﺨﺪﺍﻡ ﺍﻟﻌﺎﻡ‬ .‫ﺍﺳﺘﻌﻦ ﺑﺪﻟﻴﻞ ﺍﳌﺴﺘﺨﺪﻡ ﺍﳋﺎﺹ ﺑﻄﺮﺍﺯ ﺍﻟﻐﺴﺎﻟﺔ‬ (‫ﺧﺮﻃﻮﻡ ﺗﺰﻭﻳﺪ ﺍﳌﺎﺀ )ﺍﻟﺒﺎﺭﺩ‬ ‫ﺍﻟﻐﻄﺎﺀ‬ ‫ﺗﺄﻛﺪ ﻣﻦ ﺇﻏﻼﻕ ﺍﻟﻐﻄﺎﺀ ﺃﺛﻨﺎﺀ ﻋﻤﻠﻴﺘﻲ‬ (‫ﺧﺮﻃﻮﻡ ﺗﺰﻭﻳﺪ ﺍﳌﺎﺀ )ﺍﻟﺴﺎﺧﻦ‬ .‫ﺍﻟﻐﺴﻞ ﻭﺍﻟﺘﻨﺸﻴﻒ‬ ‫ﺩﺭﺝ ﺍﳌﺴﺤﻮﻕ‬ ‫ﻣﻮ ﺯ ﹼ ﻉ ﻣﻨﻌ ﹼ ﻢ ﺍﻷﻗﻤﺸﺔ‬ ‫ﺍﳌﺼﻔﺎﺓ‬...
  • Page 29 ‫ﺍﻟﺘﺤﻘﻖ ﻣﻦ ﺍﻟﺴﻼﻣﺔ ﻗﺒﻞ ﺍﻟﻐﺴﻴﻞ ﻭﺍﻻﻋﺘﻨﺎﺀ ﺑﺎﳌﻼﺑﺲ‬ .‫ﻳﺠﺐ ﺇﺗﺒﺎﻉ ﺗﻌﻠﻴﻤﺎﺕ ﺍﻟﻔﺤﺺ ﻟﺘﺠﻨﺐ ﺍﳌﺸﺎﻛﻞ ﺍﻟﺘﻲ ﻗﺪ ﺗﻮﺍﺟﻬﻬﺎ ﺃﺛﻨﺎﺀ ﺍﺳﺘﺨﺪﺍﻡ ﺍﻟﻐﺴﺎﻟﺔ ﺃﻭ ﺍﻟﺘﻠﻔﻴﺎﺕ ﺍﻟﺘﻲ ﻗﺪ ﺗﺼﻴﺐ ﺍﳌﻼﺑﺲ‬ .‫ﺇﺫﺍ ﺣﺪﺛﺖ ﺍﳌﺸﺎﻛﻞ ﺍﳌﺬﻛﻮﺭﺓ ﺃﺩﻧﺎﻩ ﺑﺴﺒﺐ ﺃﺧﻄﺎﺀ ﻣﻦ ﻗﺒﻞ ﺍﻟﻌﻤﻴﻞ، ﻳﺘﻢ ﲢﺼﻴﻞ ﻣﺼﺎﺭﻳﻒ ﺧﺪﻣﺔ ﻣﻨﻔﺼﻠﺔ‬ •...
  • Page 30 ‫ﺇﻋﺪﺍﺩ ﺍﻟﻐﺴﺎﻟﺔ‬ ‫ﺍﻟﻌﻨﺎﻳﺔ ﺑﺎﳌﻼﺑﺲ ﻗﺒﻞ ﺍﻟﻐﺴﻴﻞ‬ .‫ﺃﺧﺮﺝ ﺍﳌﺘﻌﻠﻘﺎﺕ ﺍﻟﺸﺨﺼﻴﺔ ﻣﻦ ﺍﳉﻴﻮﺏ‬ ‫ﺗﻨﺒﻴﻪ، ﺍﻓﺤﺺ ﺍﳉﻴﻮﺏ! ﺗﺘﺴﺒﺐ ﺑﻨﺲ ﺍﻟﺸﻌﺮ ﻭﺍﻟﻌﻤﻼﺕ ﺍﳌﻌﺪﻧﻴﺔ ﻓﻲ ﺗﻠﻒ ﺍﳌﻼﺑﺲ ﻭﺍﻟﻐﺴﺎﻟﺔ. ﺣﻴﺚ‬ • .‫ﺃﻧﻬﺎ ﺗﺴﺒﺐ ﺿﻮﺿﺎﺀ ﻭﻣﺸﺎﻛﻞ ﻟﻠﻐﺴﺎﻟﺔ. ﻟﺬﺍ، ﻳﺠﺐ ﻓﺤﺺ ﺍﳉﻴﻮﺏ‬ ‫ﻔﻒ. ﻳﺠﺐ‬‫ﺇﺫﺍ ﺗ ﹸ ﺮﻛﺖ ﺳ ﹶ ﺤ ﱠ ﺎﺑﺎﺕ ﺍﻟﺴﺮﺍﻭﻳﻞ ﻣﻔﺘﻮﺣﺔ ﺃﺛﻨﺎﺀ ﺍﻟﻐﺴﻴﻞ، ﻓﺈﻥ ﻫﺬﺍ ﻗﺪ ﻳﺘﺴﺒﺐ ﻓﻲ ﺗﻠﻒ ﺍ‬ .‫ﻏﻠﻖ...
  • Page 31 ‫ﺗﻌﺘﻤﺪ ﻃﺮﻳﻘﺔ ﺍﻟﻐﺴﻞ ﺑﺸﻜﻞ ﺗﻠﻘﺎﺋﻲ ﻋﻠﻰ ﻧﻮﻋﻴﺔ ﺍﻟﻐﺴﻴﻞ‬ ‫ﻗﺒﻞ ﺑﺪﺀ ﻋﻤﻠﻴﺔ ﺍﻟﻐﺴﻞ، ﲢﻘﻖ ﳑﺎ ﻳﻠﻲ؛‬ ‫ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﺧﺮﻃﻮﻡ ﺗﺰﻭﻳﺪ ﺍﳌﺎﺀ ﺑﺼﻨﺒﻮﺭ ﺍﳌﺎﺀ. ﺍﺗﺮﻙ ﺍﻟﺼﻨﺒﻮﺭ ﻣﻔﺘﻮ ﺣ ﹰ ﺎ. ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﺳﻠﻚ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﻲ ﻭﺗﺄﻛﺪ ﺃﻥ ﺧﺮﻃﻮﻡ ﺍﻟﺘﺼﺮﻳﻒ ﻣﺘﺠﻪ‬ • .‫ﻷﺳﻔﻞ‬ ‫ﺍﻟﻐﺴﻞ...
  • Page 32 ‫ﺇﻋﺪﺍﺩ ﺍﻟﻐﺴﺎﻟﺔ‬ ‫ﻟﻮﺣﺔ ﺍﻟﺘﺤﻜﻢ‬ .‫ﻟﻠﺤﺼﻮﻝ ﻋﻠﻰ ﻣﺰﻳﺪ ﻣﻦ ﺍﻟﺘﻔﺎﺻﻴﻞ، ﺭﺍﺟﻊ ﻟﻮﺣﺔ ﺍﻟﺘﺤﻜﻢ ﺍﳋﺎﺻﺔ ﺑﺎﻟﻐﺴﺎﻟﺔ‬ ١ ٧ ٢ ٣ ٤ ٥ ٦ ٨ ٩ .‫ﻋﺮﺽ ﺍﻟﻮﻗﺖ ﺍﳌﺘﺒﻘﻲ ﻟﻠﻐﺴﻞ‬ ‫ﻟﻮﺣﺔ ﺍﻟﻌﺮﺽ ﺍﻟﺮﺳﻮﻣﻴﺔ‬ ١ ‫ﺍﻟﺮﻗﻤﻴﺔ‬ .‫ﻋﺮﺽ ﺣﺎﻟﺔ ﺍﳋﻄﺄ ﺇﺫﺍ ﺣﺪﺛﺖ ﻣﺸﻜﻠﺔ ﻓﻲ ﺍﻟﻐﺴﺎﻟﺔ ﻟﺘﺘﻤﻜﻦ ﻣﻦ ﺍﺗﺨﺎﺫ ﺍﻹﺟﺮﺍﺀ ﺍﻟﻼﺯﻡ‬ .‫ﻳﺘﻢ...
  • Page 33 . ‫ﲢﺪﻳﺪ ﺩﻭﺭﺓ ﺍﻟﻐﺴﻴﻞ ﺍﳌﺜﻠﻰ ﺗﻠﻘﺎﺋﻴ ﺎ ﹰ‬ (‫ )ﺭﻗﻤﻲ‬Fuzzy ‫ﺗﺴﺘﺨﺪﻡ ﻫﺬﻩ ﺍﻟﺪﻭﺭﺓ ﻋﻨﺪﻣﺎ ﺗﺮﻳﺪ ﻏﺴﻞ ﺍﳌﻨﺎﺷﻒ ﺍﻟﺘﻲ ﺗﺴﺘﺨﺪﻡ ﺑﺸﻜﻞ‬ ،‫ﻣﺘﻜﺮﺭ ﺃﻭ ﺍﻟﻐﺴﻴﻞ ﻗﻠﻴﻞ ﺍﻻﺗﺴﺎﺥ. ﲟﺎ ﺃﻥ ﻋﻤﻠﻴﺔ ﺍﻟﻐﺴﻴﻞ ﺗﻜﻮﻥ ﺳﺮﻳﻌﺔ‬ (‫ )ﺳﺮﻳﻊ‬Quick .‫ﻳ ﹸ ﻔﻀﻞ ﺍﺳﺘﺨﺪﺍﻡ ﻫﺬﻩ ﺍﻟﺪﻭﺭﺓ ﻟﻠﻐﺴﻴﻞ ﺍﳌﺘﺴﺦ ﺍﺗﺴﺎ ﺧ ﹰ ﺎ ﺧﻔﻴﻔﹰ ﺎ ﺃﻭ ﺃﻗﻞ‬ ‫ﻳ...
  • Page 34 ‫ﺍﻟﻮﻇﺎﺋﻒ ﺍﻟﻴﺪﻭﻳﺔ‬ .‫ﳝﻜﻦ ﲢﺪﻳﺪ ﺍﻟﻮﻇﻴﻔﺔ ﻟﻜﻞ ﺑﺮﻧﺎﻣﺞ‬ : ‫)ﻣﺜﺎﻝ( ﻟﻠﻐﺴﻴﻞ ﺍﻟﺒﺴﻴﻂ ﻛﻤﺎ ﻓﻲ ﺩﻭﺭﺓ ﺍﻷﻭﺳﺎﺥ ﺍﻟﻘﻠﻴﻠﺔ‬ (‫ )ﺗﺸﻐﻴﻞ/ﺗﻮﻗﻒ‬Start/Pause  (‫ )ﻏﺴﻴﻞ‬Wash  ‫ ﲢﺪﻳﺪ ﺑﺮﻧﺎﻣﺞ ﺍﻷﻭﺳﺎﺥ ﺍﻟﻘﻠﻴﻠﺔ‬ (‫ )ﺍﻟﻄﺎﻗﺔ‬Power .(‫ )ﺍﻟﻄﺎﻗﺔ‬Power ‫ﺍﺿﻐﻂ ﻋﻠﻰ ﺍﻟﺰﺭ‬ ‫ﺍﻟﻐﺴﻴﻞ ﻓﻘﻂ‬ .(‫ )ﻏﺴﻴﻞ‬Wash ‫ﺍﺿﻐﻂ ﻋﻠﻰ ﺍﻟﺰﺭ‬ .(‫...
  • Page 35 ‫ﺍﻟﺘﺮﻛﻴﺐ ﻭﺍﻟﺼﻴﺎﻧﺔ‬ .‫ﺩﻟﻴﻞ ﺍﳌﺴﺘﺨﺪﻡ ﻣﺨﺼﺺ ﻟﻼﺳﺘﺨﺪﺍﻡ ﺍﻟﻌﺎﻡ‬ .‫ﺍﺳﺘﻌﻦ ﺑﺪﻟﻴﻞ ﺍﳌﺴﺘﺨﺪﻡ ﺍﳋﺎﺹ ﺑﻄﺮﺍﺯ ﺍﻟﻐﺴﺎﻟﺔ‬ ‫ﺍﻟﺒﻴﺌﺔ‬ ‫ﺍﺗﺮﻙ ﻣﺴﺎﺣﺔ‬ .‫ﺍﺗﺮﻙ ﻣﺴﺎﻓﺔ ٠١ ﺳﻢ ﻋﻠﻰ ﺍﻷﻗﻞ ﺑﲔ ﺍﻟﻐﺴﺎﻟﺔ ﻭﺍﳊﺎﺋﻂ‬ .‫ﺿﻊ ﺍﻟﻐﺴﺎﻟﺔ ﻋﻠﻰ ﺃﺭﺽ ﺛﺎﺑﺘﺔ ﻭﻣﺴﺘﻮﻳﺔ‬ (‫ﺇﺫﺍ ﰎ ﻭﺿﻊ ﺍﻟﻐﺴﺎﻟﺔ ﻋﻠﻰ ﺳﻄﺢ ﻏﻴﺮ ﻣﺴﺘﻮ ﺃﻭ ﺿﻌﻴﻒ ﺳﻴﺆﺩﻱ ﻫﺬﺍ ﺇﻟﻰ ﺍﺭﺗﻔﺎﻉ ﺻﻮﺕ ﺍﻟﻐﺴﺎﻟﺔ ﺃﻭ ﺍﻫﺘﺰﺍﺯﻫﺎ ﺃﺛﻨﺎﺀ ﺍﻟﺘﺸﻐﻴﻞ. )ﺍﳌﺴﺎﻓﺔ ﺍﳌﺴﻤﻮﺡ ﺑﻬﺎ ١ ﻳﺎﺭﺩﺓ‬ .‫ﻗﻢ...
  • Page 36 ‫ﺍﻟﺘﺮﻛﻴﺐ ﻭﺍﻟﺼﻴﺎﻧﺔ‬ ‫٤. ﻭﺻ ﹼ ﻞ ﺧﺮﻃﻮﻡ ﺍﻟﺘﺰ ﻭ ﹼ ﺩ ﺑﺎﳌﺎﺀ ﺑﺎﶈﻮ ﹼ ﻝ. ﺍﺳﺤﺐ ﺍﳉﺰﺀ )ﺝ( ﻣﻦ ﺧﺮﻃﻮﻡ ﺗﻮﺭﻳﺪ ﺍﳌﺎﺀ ﻷﺳﻔﻞ. ﻋﻨﺪ‬ ."‫ﺇﺭﺧﺎﺀ ﺍﳉﺰﺀ )ﺝ(، ﻳﺘﺼﻞ ﺍﳋﺮﻃﻮﻡ ﺑﺎﶈﻮ ﹼ ﻝ ﺗﻠﻘﺎﺋﻴ ﺎ ﹰ ﻣﺤﺪﺛ ﺎ ﹰ ﺻﻮﺕ "ﻧﻘﺮﺓ‬ ‫ﺝ‬...
  • Page 37 (‫ﻛﻴﻔﻴﺔ ﺗﻮﺻﻴﻞ ﺧﺮﻃﻮﻡ ﺍﻟﺘﺼﺮﻳﻒ )ﺍﺧﺘﻴﺎﺭﻱ‬ ‫ﻓﻲ ﺣﺎﻟﺔ ﺍﺳﺘﺨﺪﺍﻡ ﻏﺴﺎﻟﺔ ﺫﺍﺕ ﻣﻀﺨﺔ ﺗﺼﺮﻳﻒ‬ ‫ﻏﻄﺎﺀ ﺍﳋﺮﻃﻮﻡ‬ ‫ﺗﺄﻛﺪ ﻣﻦ ﺗﻮﺻﻴﻞ ﺧﺮﻃﻮﻡ ﺗﺼﺮﻳﻒ ﺍﳌﺎﺀ ﺑﺈﺣﻜﺎﻡ ﲟﺨﺮﺝ ﺍﻟﺘﺼﺮﻳﻒ‬ .‫ﺍﻧﺰﻉ ﻏﻄﺎﺀ ﺍﳋﺮﻃﻮﻡ ﻭﺻﻞ ﺧﺮﻃﻮﻡ ﺍﻟﺼﺮﻑ‬ .‫ﺍﳌﻮﺟﻮﺩ ﺑﺎﳉﺰﺀ ﺍﳋﻠﻔﻲ ﻣﻦ ﺍﻟﻐﺴﺎﻟﺔ‬ ‫ﺧﺮﻃﻮﻡ ﺍﻟﺼﺮﻑ‬ ‫ﺣﺎﻣﻞ ﺍﳋﺮﻃﻮﻡ‬ ‫ﺛﺒﺖ ﺧﺮﻃﻮﻡ ﺗﺼﺮﻳﻒ ﺍﳌﺎﺀ ﻋﻠﻰ ﺑﻌﺪ ﻳﻘﺪﺭ ﺑﻨﺤﻮ ٠٩~٠٠١ﺳﻢ ﻋﻦ‬ ‫ﺗﺄﻛﺪ...
  • Page 38 ‫ﺍﻟﺘﺮﻛﻴﺐ ﻭﺍﻟﺼﻴﺎﻧﺔ‬ ‫ﺗﻨﺒﻴﻬﺎﺕ ﺣﻮﻝ ﺇﺩﺧﺎﻝ ﺧﺮﻃﻮﻡ ﺗﺼﺮﻳﻒ ﺍﳌﺎﺀ‬ ‫ﺃﻗﻞ ﻣﻦ ٣ ﻣﺘﺮ‬ .‫٢. ﻛﻦ ﺣﺬﺭ ﺍ ﹰ ﻓﻲ ﺗﺼﺮﻳﻒ ﺍﳌﺎﺀ ﺣﺘﻰ ﻧﻬﺎﻳﺔ ﺧﺮﻃﻮﻡ ﺍﻟﺘﺼﺮﻳﻒ‬ ‫١. ﻳﺠﺐ ﺃﻻ ﻳﺰﻳﺪ ﻃﻮﻝ ﺧﺮﻃﻮﻡ ﺍﻟﺘﺼﺮﻳﻒ ﻋﻦ ٣ ﻣﺘﺮ ﺃﺛﻨﺎﺀ‬ .‫ﺍﺳﺘﺨﺪﺍﻣﻪ ﻣﻊ ﺗﻮﺻﻴﻠﻪ ﺑﺨﺮﺍﻃﻴﻢ ﺃﺧﺮﻯ‬ ‫ﺃﻗﻞ...
  • Page 39 ‫ﻣﺼﻔﺎﺓ ﻭﺻﻠﺔ ﺍﻟﺘﺰ ﻭ ﹼ ﺩ ﺑﺎﳌﺎﺀ‬ . ‫١. ﺍﻧﺰﻉ ﺍﳌﺼﻔﺎﺓ ﻭﺍﻏﺴﻠﻬﺎ ﺟﻴﺪ ﺍ ﹰ‬ .‫٢. ﺍﺩﻓﻊ ﺍﳌﺼﻔﺎﺓ ﻭﺻﻞ ﺍﳋﺮﻃﻮﻡ ﺑﺼﻤﺎﻡ ﺍﻟﺘﺰ ﻭ ﹼ ﺩ ﺑﺎﳌﺎﺀ ﺑﺈﺣﻜﺎﻡ‬ .‫٣. ﲢﻘﻖ ﻣﻦ ﻋﺪﻡ ﻭﺟﻮﺩ ﺗﺴﺮﺏ‬ .‫ﺍﻧﺘﺒﻪ ﺇﻟﻰ ﺇﺣﻜﺎﻡ ﺭﺑﻂ ﺍﻟﻮﺻﻠﺔ‬ ‫ﺗﻨﻈﻴﻒ ﺍﳌﺼﻔﺎﺓ‬ .‫ﻗﻢ...
  • Page 40 ‫ﺍﺳﺘﻜﺸﺎﻑ ﺍﳌﺸﺎﻛﻞ ﻭﺣﻠﻬﺎ‬ ‫ﺍﻟﻔﺤﺺ‬ ‫ﺍﳌﺸﻜﻠﺔ‬ ‫• ﻫﻞ ﺻﻨﺒﻮﺭ ﺍﳌﺎﺀ ﻣﻔﺘﻮﺡ؟‬ ‫ﺍﻟﻐﺴﻻﺔ ﻻ ﺗﻌﻤﻞ‬ ‫• ﻫﻞ ﺍﻟﻐﺴﻻﺔ ﻣﺘﺼﻠﺔ ﲟﺼﺪﺭ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﻲ؟‬ ‫• ﻫﻞ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﺎﺋﻲ ﻣﻘﻄﻮﻉ؟‬ ‫• ﻫﻞ ﺿﻐﻂ ﺍﳌﺎﺀ ﻛﺎﻓﻲ؟‬ (‫• ﻫﻞ ﺧﺮﻃﻮﻡ ﺍﻟﺘﺼﺮﻳﻒ ﻣﻮﺿﻮﻉ ﻷﺳﻔﻞ؟ )ﺑﺪﻭﻥ ﻣﻀﺨﺔ‬ ‫ﻻ ﻳﺘﻢ ﺗﺼﺮﻳﻒ ﺍﳌﺎﺀ‬ ‫•...
  • Page 41 ‫ﺍﻟﻐﺴﺎﻟﺔ ﻻ ﺗﻌﻤﻞ؟‬ ‫ﺍﻟﻔﺤﺺ‬ ‫ﺍﳌﺸﻜﻠﺔ‬ ‫ﻫﻞ ﺍﳉﻬﺪ ﺍﻟﻜﻬﺮﺑﻲ ﻃﺒﻴﻌﻲ؟‬ .‫ﺍﻧﻘﻄﺎﻉ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﻲ‬ .‫ﻫﻞ ﺍﻟﻐﺴﻻﺔ ﻣﺘﺼﻠﺔ ﲟﺼﺪﺭ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﻲ؟ ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﺳﻠﻚ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﻲ‬ .‫ ﻻ ﻳﺘﻢ ﺗﺼﺮﻳﻒ ﺍﳌﺎﺀ‬ .‫ﻫﻞ ﺧﺮﻃﻮﻡ ﺍﻟﺘﺼﺮﻳﻒ ﻣﺘﺠﻪ ﻷﺳﻔﻞ؟ ﺍﺟﻌﻞ ﺧﺮﻃﻮﻡ ﺍﻟﺘﺼﺮﻳﻒ ﻣﺘﺠﻬ ﺎ ﹰ ﻷﺳﻔﻞ‬ .‫ﻫﻞ...
  • Page 42 ‫ﺍﻟﻐﺴﺎﻟﺔ ﻻ ﺗﻌﻤﻞ؟‬ ‫ﺍﻟﻔﺤﺺ‬ ‫ﺍﳌﺸﻜﻠﺔ‬ ‫ )ﺗﺸﻐﻴﻞ/ﺗﻮﻗﻒ( ﺑﻌﺪ ﲢﺪﻳﺪ ﺗﺰﻭﻳﺪ ﺍﳌﺎﺀ؟‬Start/Pause ‫ﻫﻞ ﻗﻤﺖ ﺑﺎﻟﻀﻐﻂ ﻋﻠﻰ ﺍﻟﺰﺭ‬ .‫ﻳﺘﺴﺮﺏ ﺍﳌﺎﺀ ﻣﻦ ﻭﺻﻠﺔ ﺧﺮﻃﻮﻡ ﺗﻮﺭﻳﺪ ﺍﳌﺎﺀ‬ .‫ )ﺗﺸﻐﻴﻞ/ﺗﻮﻗﻒ(، ﻓﻠﻦ ﻳﺘﻢ ﺗﺰﻭﻳﺪ ﺍﳌﺎﺀ‬Start/Pause ‫ ﻓﻲ ﺣﺎﻟﺔ ﻋﺪﻡ ﺍﻟﻀﻐﻂ ﻋﻠﻰ ﺍﻟﺰﺭ‬ .(‫ )ﺗﺸﻐﻴﻞ/ﺗﻮﻗﻒ‬Start/Pause ‫ﺍﺿﻐﻂ ﻋﻠﻰ ﺍﻟﺰﺭ‬ ‫ﻫﻞ...
  • Page 43 ‫٤٤ ﻟﺘﺮ ﹰ ﺍ‬ ٢ ‫٤٤ ﻟﺘﺮ ﹰ ﺍ‬ ١ ‫ﻟﺘﺮ ﹰ ﺍ‬ ‫ﺍﺳﺘﻬﻼﻙ ﺍﳌﺎﺀ‬ ‫٠٠٧ ﺩﻭﺭﺓ ﻓﻲ ﺍﻟﺪﻗﻴﻘﺔ‬ ‫ﺳﺮﻋﺔ ﺍﻟﺘﻨﺸﻴﻒ‬ WA12F5S2 ‫ ﻭ‬WA10F5S2 ‫٠٨٤ ﻭﺍﻁ‬ ‫ﻏﺴﻞ‬ ‫ﺍﺳﺘﻬﻼﻙ‬ ‫ﺍﻟﻄﺎﻗﺔ‬ ‫٠٨٢ ﻭﺍﻁ‬ ‫ﺗﻨﺸﻴﻒ‬ (‫ﺍﻟﻌﺮﺽ ٠١٦ × ﺍﻟﻌﻤﻖ ٠٧٦ × ﺍﻻﺭﺗﻔﺎﻉ ٣٨٩ )ﺑﻘﺎﻋﺪﺓ ﻣﻨﺨﻔﻀﺔ‬...
  • Page 44 ‫ﻫﻞ ﻟﺪﻳﻚ ﺃﻱ ﺃﺳﺌﻠﺔ ﺃﻭ ﺗﻌﻠﻴﻘﺎﺕ؟‬ ‫ﺃﻭ ﻗﻢ ﺑﺰﻳﺎﺭﺓ ﻣﻮﻗﻌﻨﺎ ﻋﻠﻰ ﺍﻹﻧﺘﺮﻧﺖ‬ ‫ﺍﺗﺼﻞ‬ ‫ﺍﻟﺒﻠﺪ‬ www.samsung.com/ae/support (English) 800-SAMSUNG (726-7864) U.A.E www.samsung.com/ae_ar/support (Arabic) www.samsung.com/ae/support (English) 183-2255 (183-CALL) KUWAIT www.samsung.com/ae_ar/support (Arabic) 08000-726786 www.samsung.com/eg/support EGYPT 16580 www.samsung.com/africa_en/support 0800-726-7864 NIGERIA DC68-03273N-01_AR ‫ﺭﻗﻢ ﺍﻟﻜﻮﺩ‬ F500S_W3050_DC68-03273N-01_AR.indd Sec8:24...
