AB300A Server Console Solution User Guide February 2004 (First Edition) Part Number AB300-90001 HP CONFIDENTIAL Codename: Part Number: AB300-90001 Last Saved On: 2/10/04 2:39 PM...
Page 2
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Warranty and Support ... 14 FRU Parts List... 14 Cables... 14 Thin Client ... 15 Monitors... 15 Keyboards ... 15 Miscellaneous Parts ... 16 AB300A Console User Guide HP CONFIDENTIAL Codename: Part Number: AB300-90001 Last Saved On: 2/10/04 2:39 PM Contents...
Abstract This guide provides instructions for using the HP AB300A Server Console Solution. This solution uses an HP Compaq Thin Client T5500 as a terminal emulator for the HP9000 and Integrity servers. The HP 9000 and Integrity servers use a character cell ("dumb") terminal over a serial RS232 connection to act as the console for the system.
DB9 Serial Cable (5184-1894) included in the server console solution bundle. NOTE: The HP Compaq Thin Client t5500 in the console bundle is a fully functional thin client and supports the full range of thin client connections. However, the AB300A console solution bundle is intended to provide RS-232 direct connect terminal emulation connection support only.
Creating a Terminal Emulator Session To create a terminal emulator session, perform the following steps: 1. Connect the HP Compaq Thin Client T5500 unit using the supplied DB9 Serial Cable (5184-1894) to the serial port of the HP9000 server. 2. Select Start > HP Connection Window.
Page 9
6. If selecting the VT100 emulation mode, click the Emulation dropdown list to select the VT100 emulation mode. Enter the required VT Terminal ID setting and click Next. 7. Select Serial option, and click the Configure button. AB300A Console User Guide HP CONFIDENTIAL Codename: Part Number: AB300-90001 Last Saved On: 2/10/04 2:39 PM...
Page 10
12. The Connection Wizard will create an icon with the same name you chose for the Connection Name. This icon will appear in the HP Connection window and on the desktop. Click this icon to launch the terminal emulation session.
10. Under Connection Options, select the Automatically Connect option. Under Windows Start Mode, select Kiosk. Click OK. 11. Reboot. The TEC session will launch at reboot. AB300A Console User Guide HP CONFIDENTIAL Codename: Part Number: AB300-90001 Last Saved On: 2/10/04 2:39 PM methods. Assign a name to the...
Page 12
Explorer. Manual: Automatically starts Windows Explorer and HPConnection Window. There is an HP Connection Administrator option in the Start menu and an HP Connection Administrator icon in the HP Connection Window that can be selected to run HP Connection Administrator.
Hardware Reference Guide: HP Compaq Thin Client t5000 Series Administrator’s Guide: Microsoft Windows CE .NET-based Thin Clients Additional information about the HP CRT Monitor s5500 can be found at http://www.hp.com/products/monitors/ AB300A Console User Guide HP CONFIDENTIAL Codename: Part Number: AB300-90001 Last Saved On: 2/10/04 2:39 PM...
AB300A bundle, contact your local HP9000 and Integrity Server support service center. NOTE: Please use your HP9000 or Integrity Server system information when calling the HP service center for AB300A support. FRU Parts List...
France-French UK English Finland-Finnish Italy-Italian Japan-English Brazil Mexico AB300A Console User Guide HP CONFIDENTIAL Codename: Part Number: AB300-90001 Last Saved On: 2/10/04 2:39 PM Replace FRU Part Exchange FRU Part Number Number 325698-001 Replace FRU Part Exchange FRU Part Number...
Miscellaneous Parts Table 8: Miscellaneous FRU Description Mouse Console (Thin Client) Adptr AC-DC 12V Ft Stand w/screws HP CONFIDENTIAL Codename: Part Number: AB300-90001 Last Saved On: 2/10/04 2:39 PM Replace FRU Part Exchange FRU Part Number Number 323615-001 325709-001 336604-001...
