DMH-W2770NEX
DMH-W2700NEX
RDS AV RECEIVER
Operation Manual
Important (Serial number)
The serial number is located on the bottom of this unit. For your own security and convenience, be
sure to record this number on the enclosed warranty card.

Advertisement

Table of Contents
loading

Related Manuals for Pioneer DMH-W2770NEX

Summary of Contents for Pioneer DMH-W2770NEX

  • Page 1 DMH-W2770NEX DMH-W2700NEX RDS AV RECEIVER Operation Manual Important (Serial number) The serial number is located on the bottom of this unit. For your own security and convenience, be sure to record this number on the enclosed warranty card.

  • Page 2: Table Of Contents

    Contents Thank you for buying this Pioneer product. Please read through these instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this document in a safe place for future reference.
  • Page 3 Camera settings ............................... 48 Phone Connectivity Settings........................51 ■ Other functions................. 52 ■ Appendix ................... 53 - 3 -...

  • Page 4: Precaution

    • If you notice smoke, a strange noise or odor from this product, or any other abnormal signs on the LCD screen, turn off the power immediately and consult your dealer or the nearest authorized Pioneer Service Station. Using this product in this condition may result in permanent damage to the system.
  • Page 5 If your vehicle has a compliant backup camera that displays the backup view through the factory receiver, do not use the Pioneer receiver unless it is connected to and displays the same view as the factory backup camera. Connection to the factory backup camera will require an adaptor, sold separately.
  • Page 6 • To prevent data loss and damage to the storage device, never remove it from this product while data is being transferred. • Pioneer cannot guarantee compatibility with all USB mass storage devices and assumes no responsibility for any loss of data on media players, iPhone, smartphone, or other devices while using this product.
  • Page 7 Failure to operate After-sales service for Pioneer products Please contact the dealer or distributor from which you purchased the product for after-sales service (including warranty conditions) or any other information. In case the necessary information is not available, please contact the companies listed below.
  • Page 8 Notes on internal memory • The information will be erased by disconnecting the yellow lead from the battery (or removing the battery itself ). • Some of the settings and recorded contents will not be reset. About this manual • This manual uses diagrams of actual screens to describe operations. However, the screens on some units may not match those shown in this manual depending on the model used.

  • Page 9: Parts And Controls

    Parts and controls Main unit Touch to turn off the display information. To turn on the display information, touch again. Touch and hold to power off. To power back on, touch again. If you power the unit off, you can turn off almost all functions. The unit turns on by operating the following functions: •...
  • Page 10 Remote control W2770NEX Volume (+/-) MODE Not used. Press to cycle through all the available sources. Press and hold to turn the power off. TOP MENU Not used. MENU Not used. Thumb pad Not used. MUTE AUDIO Not used. SUBTITLE ANGLE BAND/ESC Press to select the tuner band when tuner is selected as a source.

  • Page 11: Basic Operation

    Basic operation Resetting the microprocessor CAUTION • Pressing the RESET button restarts this product. In that case, some of the settings and recorded contents are reset to the factory settings. – Do not perform this operation when a device is connected to this product. •...
  • Page 12 Operating list screens video folder abcdefghi abcdefghi abcdefghi abcdefghi Touching an item on the list allows you to narrow down the options and proceed to the next operation. Appears when items cannot be displayed on a single page. Drag the side bar, the initial search bar or the list to view any hidden items. Operating the time bar 50:00 99:99...
  • Page 13 Source icons You can display the hidden source icon(s) by swiping left on the screen. Setting the clock display (page 52) Settings (page 44) Displays the connected devices. : lights up when Apple CarPlay is available. : lights up when Android Auto is available. : lights up when hands-free phoning via Bluetooth is available.

  • Page 14: Bluetooth

    Bluetooth® Bluetooth connection Turn on the Bluetooth function on the device. Display the connected Bluetooth device list screen on the device. Touch Touch The device search screen appears. Touch [Yes] to start searching. Touch if another device is already connected to the unit. Touch a desired device on the screen.
  • Page 15 Bluetooth Settings Touch Touch then [Bluetooth Settings]. CAUTION Never turn this product off and disconnect the device while the Bluetooth setting operation is being processed. Menu Item Description [Connection] Activate to connect the last connected Bluetooth device automatically. [Auto Answer] (page 17) [Search] Search for available devices.
  • Page 16 TIPS • on the top menu screen is not available while Android Auto is on. In that case, use the Android Auto phone function. • Confirm whether hands-free phoning via Bluetooth is activated if on the top menu screen is not available (page 13).
  • Page 17 Menu Item Description [Auto Answer] Activate to answer an incoming call automatically. Adjusting the other party’s listening volume This product can be adjusted to the other party’s listening volume. Touch to switch between the three volume levels. Notes for hands-free phoning ▶General notes •...
  • Page 18 • If the phone book in the phone contains image data, the phone book may not be transferred correctly. • Depending on the cellular phone, phone book transfer may not be available. Bluetooth audio Before using the Bluetooth audio player, register and connect the device to this product (page 14).
  • Page 19 Switches between playback and pause. Skips files forward or backward. Sets a repeat play range. Plays files in random order. - 19 -...

  • Page 20: Wi-Fi

    Wi-Fi® By connecting your Wi-Fi certified mobile device to this product via Wi-Fi connection, you can use Apple CarPlay or Android Auto wirelessly. Wi-Fi connection See the following chapters for the procedure on how to make a Wi-Fi connection for each application.

  • Page 21: Av Source

    AV source Supported AV source You can play or use the following sources with this product. • Radio • USB The following sources can be played back or used by connecting an auxiliary device. • iPhone • Bluetooth audio • SiriusXM Satellite Radio •...

  • Page 22: Radio

    Radio Starting procedure Press Touch [Radio]. The Radio screen appears. Basic operation Recalls the preset channel stored to a key from memory. XX.XX XX.XX Stores the current broadcast frequency to a key. Selects the FM1, FM2, FM3, AM1 or AM2 band. Performs BSM (best stations memory) function (page 23).
  • Page 23 Recall a preset channel in order and broadcast each channel for 10 seconds. Storing the strongest broadcast frequencies (BSM) The BSM (best stations memory) function automatically stores the six strongest broadcast frequencies under the preset channel keys [1] to [6]. NOTES •...

  • Page 24: Compressed Files

    Compressed files Plugging/unplugging a USB storage device You can play compressed audio, compressed video, or still image files stored in an external storage device. Plugging a USB storage device Pull out the plug from the USB port of the USB cable. Plug a USB storage device into the USB cable.
  • Page 25 You can also start this source by pressing then touching [USB]. Basic operation Audio source Switches between playback and pause. Skips files forward or backward. Performs fast forward or fast reverse. Sets a repeat play range for all files/the current folder/the current file. Plays files or does not play in random order.
  • Page 26 Video source CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the parking brake. Switches between playback and pause. Skips files forward or backward. Performs fast forward or fast reverse.
  • Page 27 Still image source Switches between playback and pause. Skips files forward or backward. Rotates the displayed picture 90° counterclockwise. Sets a repeat play range for all files/the current folder/the current file. Selects a file from the list. Touch a file on the list to playback. TIPS •...

  • Page 28: Iphone

    iPhone NOTE iPhone may be referred to as iPod in this manual. Connecting your iPhone When connecting an iPhone to this product, the settings are automatically configured according to the device to be connected. For details of the compatibility, refer to Compatible iPhone models (page 63).
  • Page 29 Skips files forward or backward. Sets a repeat play range for all in the selected list/the current song. Plays songs within the selected list/album randomly. Selects a song from the list. Touch the category then the title of the list to playback of the selected list. You can search a song in the songs list by dragging the initial search bar.

  • Page 30: Weblink

    Using WebLink Important • Pioneer is not responsible for content or functions accessed via WebLink, which are the responsibility of the application and content providers. • Availability of non-Pioneer content and services, including apps and connectivity, may change or discontinue without notice.
  • Page 31 NOTE For USB connection, refer to the Installation Manual. For smartphone (Android™) users System requirement Android 7.0 or higher NOTE The video playback capability depends on the connected Android device. Unlock your smartphone and connect it to this product via USB. You can start this source by touching , swiping left on the screen, and touching [WebLink] if the screen except for WebLink appears after the USB connection.

  • Page 32: Usb Mirroring

    Using USB Mirroring Important • Pioneer is not responsible for content or functions accessed via USB Mirroring, which are the responsibility of the application and content providers. • Availability of non-Pioneer content and services, including apps and connectivity, may change or discontinue without notice.

  • Page 33: Apple Carplay

    • Apple CarPlay allows access to applications other than those listed that are subject to limitations while driving. • PIONEER IS NOT RESPONSIBLE AND DISCLAIMS LIABILITY FOR THIRD PARTY (NON-PIONEER) APPS AND CONTENT, INCLUDING WITHOUT LIMITATION ANY INACCURACIES OR INCOMPLETE INFORMATION.
  • Page 34 Touch [Driving Position]. [Left] Select for a left-hand drive vehicle. [Right] Select for a right-hand drive vehicle. Starting procedure Wired connection Connect an Apple CarPlay compatible device to this product via USB. The application screen appears. You can start this source by touching then touching [Apple CarPlay] if the screen except for Apple CarPlay appears after the USB connection.
  • Page 35 Follow the on-screen instructions on the device to start the application. TIPS • When the USB connection with the other device has been made, the message that shows that the new device is available will appear. If you want to switch from the current device to the new one for use in the application, touch the pop-up message.

  • Page 36: Android Auto

    • Android Auto allows access to applications other than those listed that are subject to limitations while driving. • PIONEER IS NOT RESPONSIBLE AND DISCLAIMS LIABILITY FOR THIRD PARTY (NON-PIONEER) APPS AND CONTENT, INCLUDING WITHOUT LIMITATION ANY INACCURACIES OR INCOMPLETE INFORMATION.
  • Page 37 Touch Touch Touch [Phone Connectivity Settings]. Touch [Driving Position]. [Left] Select for a left-hand drive vehicle. [Right] Select for a right-hand drive vehicle. Starting procedure Wired connection Connect an Android Auto compatible device to this product via USB. The application screen appears. You can start this source by touching then touching [Android Auto] if the screen except for Android Auto appears after the USB connection.
  • Page 38 Touch [Start] to start Android Auto. The unit configures the connection then start the application. You can use voice recognition function by touching button once Android Auto is activated. NOTES • For details on USB connection, refer to the Installation Manual. •...

  • Page 39: Siriusxm® Satellite Radio

    SiriusXM® Satellite Radio SiriusXM is where moments happen. The widest, deepest variety of music, ad-free. More games, more sports, more coverage than anywhere. The most extensive entertainment, complete news coverage and every kind of comedy. Listen in your car, on your phone, online and at home.
  • Page 40 Listening to SiriusXM Touch Touch [SiriusXM]. Basic operation [RADIO ID] is displayed when Channel 0 is selected. Current channel display (Live broadcast mode) Tunes a channel directly. Recalls the preset channel stored to a key from the memory. Pre1 Pre6 Stores the current channel to a key.
  • Page 41 Selects a channel from the list. Scroll through the list of all channels then touch the desired channel to tune to that channel. When is selected, the channel list will be shown according to different categories. Touch to select other Category. NOTES •...

  • Page 42: Aux

    You can display the video image output by the device connected to video input. CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the parking brake. NOTE A Mini-jack AV cable (sold separately) is required for connection.

  • Page 43: Camera View

    Camera View You can display the video image output by the device connected to video or camera input. For details, refer to the Installation Manual. Starting procedure Touch then swipe left on the screen. Touch [Camera View] for connected camera view. The video image is displayed on the screen.

  • Page 44: Settings

    Settings You can adjust various settings in the main menu. Displaying the setting screen Touch Touch Touch one of the following categories, then select the options. System Settings (page 44) Display Settings (page 46) Audio & EQ Settings (page 47) Wi-Fi Settings (page 20) Bluetooth Settings (page 15) Camera settings (page 48)
  • Page 45 Menu Item Description [Factory Reset] Touch [OK] to restore the settings to the default settings. CAUTION Do not turn off the engine while restoring the settings. NOTES • This setting is available only when you stop your vehicle in a safe place and apply the parking brake.

  • Page 46: Display Settings

    Menu Item Description [System Information] Displaying and updating the firmware version. CAUTION • The USB storage device for updating must contain only the correct update file. • Never turn this product off, disconnect the USB storage device while the firmware is being updated. •...

  • Page 47: Audio & Eq Settings

    Menu Item Description [Wallpaper] Touch the wall paper from the preset items in this product or original pictures via the external device and touch [Apply]. The wall paper can be set from selections for the top menu screen and AV operation screen. Preset Display Select the desired preset background display.

  • Page 48: Camera Settings

    Menu Item Description [EQ] Select or customize the equalizer curve. [Super Bass] [Powerful] Select a curve that you want to use as the basis of [Natural] [Vocal] [Flat] customizing then touch the frequency that you want to [Custom] adjust. If you make adjustments when a curve [Super Bass], [Powerful], [Natural], [Vocal], or [Flat] is selected, the equalizer curve settings will be changed to [Custom] mandatorily.
  • Page 49 (page 49). CAUTION Pioneer recommends the use of a camera which outputs mirror reversed images, otherwise the screen image may appear reversed. • Immediately verify whether the display changes to the rear view camera image when the shift lever is moved to REVERSE (R) from another position.
  • Page 50 Menu Item Description [Parking Assist Guide Adjusting the guidelines by dragging or touching Adjust] on the screen. Touch [OK] to finish the settings. Touch [Reset] to reset the settings. CAUTION • When adjusting the guidelines, park the vehicle in a safe place and apply the parking brake;...

  • Page 51: Phone Connectivity Settings

    Menu Item Description [Contrast] Adjust the contrast. [-10] to [+10] [Color] Adjust the color saturation. [-10] to [+10] Phone Connectivity Settings Menu Item Description [Android Phone MSC] Set the USB connection mode for your smartphone (Android) to MSC (Mass Storage Class). NOTE This setting is not available when Android device or USB storage device is connected to this product via USB.

  • Page 52: Other Functions

    Other functions Setting the clock display You can set the time format, time zone, daylight saving, and the date format. However, the time and date are automatically adjusted by the GPS antenna and cannot be adjusted by the user. Touch the current time on the screen. Set the following items in the settings.

  • Page 53: Appendix

    – Park your vehicle in a safe place, and authorized Pioneer service facility. then turn off the ignition switch (ACC OFF). Subsequently, turn the ignition Common problems switch to on (ACC ON) again.
  • Page 54 If the error persists, record the error message and contact your – Perform the connection process. dealer or your nearest Pioneer service center. Problems with Application screen SiriusXM Satellite Radio A black screen is displayed.
  • Page 55 Pioneer www.siriusxm.ca or call 1-888-539- service center for assistance. 7474. No Signal Channel Locked Please Enter the Lock → The SiriusXM Connect Vehicle Tuner is Code → Locked by the radio Parental Control having difficulty receiving the SiriusXM satellite signal.
  • Page 56 Apple CarPlay Audio Format not supported → This type of file is not supported on this product. Connection failed. – Select a file that can be played. → Communication failed and the system is trying to connect. No Data → Wait for a while. Then, perform the →...
  • Page 57 your phone. When the related Android Auto has disconnected. information pops up on your phone, → Wi-Fi function on the device or the unit follow the pop-up message. is turned off. – Turn on the Wi-Fi function on the Others device and the unit when you use Android Auto (page 20).
  • Page 58 • The text information of some audio and Media compatibility chart video files may not be correctly displayed. General • File extensions must be used properly. • Maximum playback time of audio file • There may be a slight delay when starting stored on an USB storage device: 7.5 h playback of files on an USB storage (450 minutes)
  • Page 59 AAC compatibility .avi • This product plays back AAC files Compatible video codec MPEG4, H.264 encoded by iTunes. Maximum resolution 1 920 × 1 080 SAMPLING FREQUENCY 8 kHz to 48 kHz Maximum frame rate 30 fps TRANSMISSION RATE CBR (16 kbps to .mpg/.mpeg 320 kbps) Compatible video codec...
  • Page 60 • This product includes technology owned registered trademarks owned by Bluetooth SIG, by Microsoft Corporation and cannot be Inc. and any use of such marks by Pioneer used or distributed without a license Corporation is under license. Other trademarks from Microsoft Licensing, Inc.
  • Page 61 IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) • Pioneer accepts no responsibility for data ARISING IN ANY WAY OUT OF THE USE OF lost from an iPhone, even if that data is - 61 -...
  • Page 62 lost while using this product. Please back App Store up your iPhone data regularly. • Do not leave the iPhone in direct sunlight App Store is a service mark of Apple for extended amounts of time. Extended Inc., registered in the U.S. and other exposure to direct sunlight can result in countries.
  • Page 63 Using app-based connected Content application(s) or service by its provider. connected content • Pioneer is not liable for any issues that may arise from incorrect or flawed app- based content. Important • The content and functionality of the...
  • Page 64 App • Do not push the LCD screen with provider, and not determined by Pioneer. excessive force as this may scratch it. • USB Mirroring, WebLink, Apple CarPlay • Never touch the LCD screen with...
  • Page 65 4 Ω (4 Ω to 8 Ω allowable) visible. In that case, please consult your Preout output level (max): 2.0 V dealer or the nearest authorized Pioneer Equalizer (13-Band Graphic Equalizer): Service Station. Frequency:...
  • Page 66 AAC decoding format: Bluetooth MPEG-4 AAC (iTunes encoded only) (Ver. Version: 12.5 and earlier) Bluetooth 4.2 certified FLAC decoding format: Output power: Ver. 1.3.0 (Free Lossless Audio Codec) +4 dBm Max. (Power class 2) WAV signal format: Frequency band(s): Linear PCM 2 402.0 MHz to 2 480.0 MHz Sampling frequency: FM tuner...
  • Page 67 Frequency: Approx. once per second GPS antenna Antenna: Micro strip flat antenna/right-handed helical polarization Antenna cable: 3.55 m (11ft. 7in.) Dimensions (W × H × D): 47 mm × 16.2 mm × 55 mm (1-7/8 in. × 5/8 in. × 2-1/8 in.) Weight: 104.0 g (0.2 lbs) CTA2006 Specifications...
  • Page 68 © 2022 PIONEER CORPORATION <OPM_DMHW2700NEXUC_EN_A> UC...
