English TABLE OF CONTENTS Table of contents..............Safety Information..............Getting Started................ Features................What's Included..............Parts Descriptions..............Front Panel................Rear Panel................Remote Control..............Installation................Mounting the Main Unit ............ Installing the Remote Control Battery......... Installing the Wireless Subwoofer........Pairing the Wireless Subwoofer With the Main Unit... Positioning the Soundbar System ........
English SAFETY INFORMATION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR CAUTION BACK). NO USER SERVICEABLE PARTS RISK OF ELECTRIC SHOCK INSIDE. PLEASE REFER SERVICING TO DO NOT OPEN QUALIFIED PERSONNEL. This lightning bolt with the arrowhead within the triangle is intended to alert the user to the presence of dangerous, uninsulated voltage in the enclosure of the product which may be powerful enough to pose a risk of electric shock.
Page 4
English 13 Unplug this apparatus during lightning storms or when unused for long periods of time. 14 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Page 5
Clean the system with a soft dry cloth. Do not use any type of abrasive pad, scouring powder or solvents such as alcohol or benzine. SAVE THESE INSTRUCTIONS HOUSEHOLD USE ONLY Thank you for purchasing our Haier Model number product. This easy-to-use...
English GETTING STARTED Features 2.1 Channel Built-In Digital Amplifer Easier Installation, More Vivid sound and image ••HDMI input for easy setup with your TV Stylish and Skinny Style ••Soundbar system in a stylish integrated single-unit design ••Slim design that matches any flat TV ••Wall mountable to maximize space Enhanced Wireless Active Subwoofer ••Class-D digital amplifier with Texas Instruments PurePath...
English What's Included Main Unit Subwoofer Remote Control Battery (1 ea) Wall Mount Cradle Stand (1 ea) Brackets(2 ea) (2 ea) AC Power Wall Mount HDMI Cable DC Power User Manual Cord Sheet (1 ea) (1 ea) Supply (2 ea) (1 ea) (2 ea)
English PARTS DESCRIPTIONS Front Panel Display Window Shows the current status of the main unit. Remote Sensor Point the remote control towards this point.
English Rear Panel 11 10 9 8 7 6 LINE IN Input Jack WOOFER Connect to the line out jack of Turns the subwoofer on or off. your portable audio player. MODE Selects a sound mode from S/PDIF Input Jack MUSIC, MOVIE, SURROUND, Connect to the S/PDIF output jack or NEWS.
English Remote Control Turns the main unit on or off. VOL - / VOL + Adjusts the volume. MUTE Mutes the sound. MODE Selects a sound mode from MUSIC, MOVIE, SURROUND, or NEWS. LINE IN / S/PDIF / HDMI 1 / HDMI 2 Chooses the corresponding input mode you want to use.
English INSTALLATION Mounting the Main Unit On a Shelf You can use the cradle stand to install the main unit on a shelf. Insert the head of the cradle stand into the slots in the soundbar. Place the assembled main unit on a flat surface.
Page 12
English On the Wall You can mount the main unit on a wall. Attach the supplied wall mount sheet to the wall as horizontally as possible. Align the bracket with the points on the sheet as shown below. Secure the bracket with 4 screws at the marked points. Screws (not supplied) Remove the sheet from the wall.
English Caution! • Do not hang onto the installed main unit and avoid any impact to the main unit. • Secure the main unit firmly to the wall so that it does not fall off. If the main unit falls off, it may result in an injury, or in damage to the product. •...
English Installing the Wireless Subwoofer Connect the power cord with the main unit DC IN jack and then plug it into a power outlet. Connect the DC power supply into the subwoofer. DC Power Supply Plug the AC power cord of the subwoofer into a power outlet.
English Pairing the Wireless Subwoofer With the Main Unit When the soundbar system is manufactured, the pairing is preset. Please pair the subwoofer with the main unit by following the procedure below if interference occurs or if pairing is interrupted. Pairing Button Press CONNECT on the back of the subwoofer.
English Positioning the Soundbar System Place the main unit at a height that is closest to ear-level in the listening area. Position the main unit so that it is parallel to the listening area. Place the subwoofer in the corner of the room or at least one meter away from the TV.
English CONNECTIONS Connection Overview You can enjoy music or movies with one of the following connections. Find an external device you want to connect to the main unit as shown in the following images. Check the connection type of the external device. Find the appropriate image and check the connection details.
English Connecting Audio and Video With HDMI HDMI Connection You can connect external devices like a gaming device, Blu-ray player, etc to the main unit using an HDMI cable (Type A, Version 1.3). With HDMI, you can enjoy high quality sound on the main unit and high quality images on an HDMI compatible TV or monitor.
English Note: • Before connecting to an external device, make sure to turn the main unit off. • If there is noise or lines on the screen, please check the HDMI cable (length is generally limited to 4.5 m and use a high speed HDMI cable (version 1.3)). •...
Page 20
English Note: • The S/PDIF cable is not supplied. • When you connect S/PDIF, make sure to set the source device output mode to PCM. Refer to the the user manual of the source device for more detailed information about the audio output settings. LINE IN Connection You can enjoy the sound from your portable audio player through the main unit.
English OPERATION Setting the Sound Mode You can select a suitable sound mode for the connected device by using MODE. Press MODE repeatedly to select MUSIC, MOVIE, SURROUND, or NEWS. ••MUSIC This sound mode is the best for listening to music, as you can enjoy the high fidelity sound experience.
English Selecting a Soundbar Input Mode Your soundbar acts as a device for switching between all the input sources that are plugged into it. ••On the main unit Press INPUT repeatedly to select a soundbar input source. The corresponding input source will then be activated. ••On the remote control When one of the source buttons on the remote control is pressed, the corresponding input will be activated.
English TROUBLESHOOTING Check the list below when your soundbar does not function properly. If the problem you are experiencing is not listed below or if the instructions do not help, turn off the main unit, disconnect the power cord, and contact the nearest authorized dealer.
Page 24
English SYMPTOM CHECK ••Check that the TV is selected correctly. ••Set the TV to the appropriate input mode. ••The system may not work correctly if you Screen There is no picture select a device that is not compatible with Image on the TV screen.
English SPECIFICATIONS General Dimensions (W x H X D) 39.4 x 3.7 x 1.1inch Net Weight (Approx.) 5.25 lbs Operating Temperature 5 °C - 35 °C (41 °F to 95 °F) Operating Humidity 5 % - 80 % Frequency Response 200 Hz - 20 kHz Power Source DC 24V...
Haier be liable, or in any way responsible for The warranty commences on the date the incidental or consequential economic or item was purchased and the original property damage.
Page 28
No Devuelva Este Producto al Establecimiento Compra. Si tiene problemas con este producto, por favor póngase en contacto con el “Centro Haier de Atención al Cliente” en el 1-877-337-3639. PARA EL SERVICIO DE GARANTÍA SE REQUIERE PRUEBA DE COMPRA, FECHADA, No.
