Summary of Contents for Siemens SE25E259EU/39
- Page 1 HQ 2SHUDWLQJ LQVWUXFWLRQV 'LVKZDVKHU...
-
Page 3: Table Of Contents
en Table of contents Safety instructions ....4 Additional options ....16 Delivery . -
Page 4: Safety Instructions
– Do not add any solvents to the washing Safety instructions chamber. Danger of explosion! – Open the door carefully when the Delivery programme is still running. There is a – Check the packaging and dishwasher risk of hot water spraying out of the immediately for damage caused in appliance. -
Page 5: Door Lock
Childproof lock (door lock) * ã= Warning The description of the childproof lock is at Children could become locked in the the back in the envelope. appliance (risk of suffocation) or find * depending on model themselves in other dangerous situations. Therefore: Pull out the mains plug, sever Damage and dispose of the power cord. -
Page 6: Getting To Know Your Appliance
* depending on model Getting to know your *** The float 1J ensures that appliance the appliance interior is not overfilled. Only customer service may maintain, remove Diagrams of the control panel and the and install the float. interior of the appliance can be found in the envelope at the front. -
Page 7: Water Softening System
– Rotate the programme selector 8 Water softening system from the 12 o’clock position anti- clockwise by one notch. To ensure good washing results, the dishwasher requires soft water, i.e. containing low amounts of lime, otherwise white limescale will be deposited on the utensils and inner container. -
Page 8: Special Salt
Using detergents with salt Special salt $ component If combined detergents with a salt Using special salt component are used, salt can usually be Always refill with special salt immediately omitted up to a water hardness of 21° dH before switching on the appliance. This (37°... -
Page 9: Rinse Aid
Setting amount of rinse aid Rinse aid % The rinse aid dispensing rate can be adjusted steplessly. The clear rinse As soon as the rinse-aid refill controller was set to 4 at the factory. indicator ` is lit on the fascia, there Do not change the position of the rinse aid is still a rinse-aid reserve of 1–2 rinsing control unless there are streaks (rotate... -
Page 10: Utensils
Loading the dishwasher Utensils – Remove large food remnants. It is not necessary to prerinse utensils under Not suitable running water. – Cutlery and utensils made of wood. – Place the utensils so that – Delicate decorative glasses, craft and –... -
Page 11: Pans
Pans Folding spikes * Bottom basket 1R * depending on model The spikes can be folded down to improve arrangement of pans, bowls and glasses. Etagere * Lean long-stemmed and tall glasses along the edge of the etagere 1: (not against utensils). -
Page 12: Small Accessories Holder
Small accessories holder * Top basket with side levers – Pull out the top basket 1" out. * depending on model Light-weight plastic accessories, e.g. cups, – To lower the basket, press in the left lids, etc. can be held securely in the small and then the right accessories holder. -
Page 13: Detergent
Adding detergent Detergent – If the detergent dispenser 9* is still closed, press the lock 92 to open You can use tablets as well as powder the detergent dispenser. or liquid detergents for dishwashers, but Pour detergent into the dry detergent never use washing up liquid. -
Page 14: Combination Detergent
Combination detergent Apart from conventional detergents (Solo), a number of products are offered with additional functions. These products contain not only the detergent but also rinse-aid and salt replacement substances (3in1) and, depending on the combination (4in1, 5in1, etc.), additional components such as glass protection or stainless steel cleaner. -
Page 15: Overview Of Programmes
Overview of programmes The max. possible number of programmes is illustrated in this overview. The corresponding programmes and their arrangement can be found on the fascia. Type of utensils Type of soiling Programme Possible additional Programme sequence options Prerinse ² Clean 70°... -
Page 16: Additional Options
Additional options Basic functions Programme data * depending on model Additional options can be set with the The programme data (consumption buttons @. values) can be found in the summary of instructions. This data refers to normal Ÿ Express Wash * conditions and the water hardness set value 2. -
Page 17: Interrupting The Programme
Interrupting the programme Maintenance and care – Switch off the main switch (. The LEDs go out. The programme A regular inspection and maintenance of is saved. your machine will help to prevent faults. This saves time and prevents problems. If the door was opened on an appliance which has a warm water Overall condition of the machine... -
Page 18: Filters
Filters Spray arms The filters 1b keep large foreign Limescale and contaminants in the rinsing objects in the rinsing water away from water may block nozzles and bearings on the spray arms 12 the pump. These foreign objects may and 1B. occasionally block the filters. -
Page 19: Troubleshooting
– Using a spoon, prise off pump cover Troubleshooting (as illustrated) until it clicks, then grip the cover by the lug and pull it out The majority of faults which could occur in forwards. daily operation can be rectified by the user. -
Page 20: When The Appliance Is Switched On
... when the appliance is – Clean filter in the supply hose. switched on The appliance does not start. – The mains fuse has tripped. – The appliance plug has not been inserted. – The appliance door has not been shut properly. -
Page 21: On The Utensils
... on the utensils Dull, discoloured glasses, film cannot be washed off. Food residue on the utensils. – Unsuitable detergent. – Utensils placed too closely together, – Glasses not dishwasher-proof. utensils basket overfilled. Streaks on glasses and cutlery, glasses – Too little detergent. have metallic appearance. -
Page 22: Customer Service
Customer service Installation If the advice given does not resolve your The dishwasher must be connected problem, please contact your customer correctly, otherwise it will not function service. Contact details can be found on properly. The specifications for the inlet the back cover of this instruction manual and outlet as well as the electrical or in the enclosed customer service list. -
Page 23: Delivery
– After installing the appliance, ensure Installation that the plug is easily accessible. The required installation dimensions can – Some models: be found in the installation instructions. The plastic housing on the water Level the appliance with the aid of the connection contains an electric valve, height-adjustable feet. -
Page 24: Fresh Water Connection
Fresh water connection Removing the appliance – Connect the fresh-water connection to Also observe the sequence of worksteps the tap according to the installation here. instructions with the enclosed parts. – Disconnect the appliance from the Ensure that the fresh-water connection power supply. -
Page 25: Waste Disposal
Waste disposal Both the packaging of new appliances and the old appliances themselves contain valuable raw materials and recyclable materials. Please dispose of the individual parts separated according to type. Please ask your dealer or inquire at your local authority about current means of disposal. - Page 27 &KLOGSURRI ORFN GRRU ORFN $FWLYDWH WKH FKLOGSURRI ORFN $OZD\V FORVH WKH DSSOLDQFH GRRU FRPSOHWHO\ 2SHQ WKH GRRU ZLWK DFWLYDWHG ZKHQ \RX OHDYH WKH DSSOLDQFH FKLOGSURRI ORFN 7KLV LV WKH RQO\ ZD\ \RX FDQ SURWHFW \RXU 'HDFWLYDWH FKLOGSURRI ORFN FKLOGUHQ IURP SRWHQWLDO GDQJHUV %DNLQJ VKHHW VSUD\ KHDG /DUJH VKHHWV RU JULOOHV DQG SODWHV ZKLFK KDYH D GLDPHWHU JUHDWHU WKDQ FP JRXUPHW...
- Page 28 $48$6723 JXDUDQWHH GRHV QRW DSSO\ WR DSSOLDQFHV ZLWKRXW $TXD6WRS ,Q DGGLWLRQ WR ZDUUDQW\ FODLPV DJDLQVW WKH VHOOHU EDVHG RQ WKH SXUFKDVH FRQWUDFW DQG LQ DGGLWLRQ WR RXU DSSOLDQFH ZDUUDQW\ ZH ZLOO SD\ GDPDJHV XQGHU WKH IROORZLQJ FRQGLWLRQV ,I RXU $TXD6WRS V\VWHP LV GHIHFWLYH DQG FDXVHV ZDWHU GDPDJH ZH ZLOO PDNH JRRG WKH GDPDJH IRU SULYDWH XVHUV 7R HQVXUH ZDWHU GDPDJH SURWHFWLRQ WKH DSSOLDQFH PXVW EH FRQQHFWHGWR WKH SRZHU VXSSO\...
