Acer T230H Service Manual

Bmidh wide touch screen display
Hide thumbs Also See for T230H:

Advertisement

Table of Contents

See also: User Manual
Acer T230H
Service Guide
Service guide files and updates are available on the CSD web: for
more information,
Please refer to
http://csd.acer.com.tw/
100% Recycled Paper

Advertisement

Table of Contents
loading

Related Manuals for Acer T230H

Summary of Contents for Acer T230H

  • Page 1 Acer T230H Service Guide Service guide files and updates are available on the CSD web: for more information, Please refer to http://csd.acer.com.tw/ 100% Recycled Paper...
  • Page 2 Copyright Copyright © 2003 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 3 Conventions The following conventions are used in this manual: Screen messages Note Warning Caution Important Denotes actual messages that appear on screen Gives bits and pieces of additional information related to the current topic. Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 4 DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and Service of customer machines.
  • Page 5 WARNING: (FOR FCC CERTIFIED MODELS) NOTE: this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 6 PRECAUTIONS Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, Swimming pool or in a wet basement. Do not place the monitor on an unstable trolley, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance.

  • Page 7: Special Notes On Lcd Monitors

    SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. NOTES Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. You may find slightly uneven brightness in the screen depending on the desktop pattern you use.

  • Page 8: Table Of Contents

    Table of contents Chapter 1 MONITOR FEATURE…………………………………………………………………… 9-26 Chapter 2 OPERATING INSTRUTION ……………………………………………………… 27-32 Chapter 3 MACHINE ASSEMBLY……………………………………………………………….. 33-38 Chapter 4 TROUBLE SHOOTING………………………………………………………………….39-47 Chapter 5 CONNECTOR INFORMATION………………………………………………….. 48-50 Chapter 6 FRU LIST……………………………………………………………………………………. 51-56 Chapter 7 SCHEMATIC DIAGRAM ……………………………………………………………...57-78...

  • Page 9: Chapter 1 Monitor Feature

    Monitor Feature Driving system Size Pixel pitch Viewable angle Brightness Contrast Ratio LCD Panel Response time Video Input Separate Sync H-Frequency V-Frequency Display Color Maximum Dot Clock ® Max Resolution Plug & Play ON Mode EPA ENERGY STAR OFF Mode Audio output Input Connector Input Video Signal...
  • Page 10 Switch External Controls : Regulatory Compliance * Power Switch * MENU / ENTER / Volume / Volume * AUTO / EXIT * e-Color * Contrast/brightness * Focus * Clock * H.Position * W.Position * Language * OSD Color temperature * OSD Position & Timeout * Auto Config * Input * Information...
  • Page 11 Timings The product has 34 memory modes in total. 26 modes are preset and 8 modes are user definable. MODE NO. RESOLUTION 720 x 400 Dot clock(MHz) 28.321 31.469kHz H-Total ( us ) 31.78(900dots) H-Sync ( us ) 3.813(108dots) H-B-P ( us ) 1.907(54dots) H-Active ( us ) 25.42(720dots)
  • Page 12 MODE NO. RESOLUTION 800 x 600 Dot clock(MHz) 35.16kHz H-Total ( us ) 28.44(1024 dots) H-Sync ( us ) 2.00(72 dots) H-B-P ( us ) 3.56(128 dots) H-Active ( us ) 22.22(800 dots) H-F-P ( us ) 0.67(24 dots) 56.25 V-Total (ms ) 17.78(625 lines) V-Sync ( ms )
  • Page 13 MODE NO. RESOLUTION 1024 x 768 Dot clock(MHz) 48.363kHz H-Total ( us ) 20.677(1344 dots) H-Sync ( us ) 2.092(136 dots) H-B-P ( us ) 2.462(160 dots) H-Active ( us ) 15.754(1024 dots) H-F-P ( us ) 0.369(24 dots) 60.004Hz V-Total (ms ) 16.666(806 lines) V-Sync ( ms )
  • Page 14 MODE NO. RESOLUTION 1280 x 1024 Dot clock(MHz) 63.981kHz H-Total ( us ) 15.630 (1688 dots) H-Sync ( us ) 1.037 (112 dots) H-B-P ( us ) 2.296 (248 dots) H-Active ( us ) 11.852 (1280 dots) H-F-P ( us ) 0.444 (48 dots) 60.020Hz V-Total (ms )
  • Page 15 MODE NO. RESOLUTION 1440 x 900 Dot clock(MHz) 106.5 55.935 H-Total ( us ) 17.878 (1904 dots) H-Sync ( us ) 1.417 (152 dots) H-B-P ( us ) 2.178 (232 dots) H-Active ( us ) 13.521 (1440 dots) H-F-P ( us ) 0.751 (80 dots) 60Hz V-Total (ms )
  • Page 16 MODE NO. RESOLUTION 1920 x 1080 Dot clock(MHz) 148.5 67.5 H-Total ( us ) 14.815 (2200 dots) H-Sync ( us ) 0.296 (44 dots) H-B-P ( us ) 0.997 (148 dots) H-Active ( us ) 12.929 (1920 dots) H-F-P ( us ) 0.593 (88 dots) 60Hz V-Total (ms )

  • Page 17: Monitor Block Diagram

    Monitor Block Diagram DVI_INPUT DVI-D DVI_IIC EEPROM EDID 24C02 D_SUB15_INPUT(R/G/B/HS/VS/SOG) D-SUB15 D-SUB15_IIC EEPROM EDID 24C02 HDMI_INPUT HDMI_IIC HDMI EEPROM EDID 24C02 5DVCC TO 3.3V POWER BOARD TO 1.2V SCALER RTD2482RD AUDIO OUTPUT V33S INPUT AUDIO V12S TO PANEL PANEL CONNETER EEPROM 24C16 SERIAL...
  • Page 18 PCB CONDUCTOR VIEW Button Board...
  • Page 19 Main board...
  • Page 20 Power board...
  • Page 21 ARM Board Top-Side...
  • Page 22 ARM Board Bot-Side...
  • Page 23 Camera L-Board Top-Side...
  • Page 24 Camera L-Board Bot-Side...
  • Page 25 Camera R-Board Top-Side...
  • Page 26 Camera R-Board Bot-Side...

  • Page 27: Chapter 2 Operating Instrution

    Right / MINUS POWER Press “e” can have the mode for acer e Color management. If OSD is active, press to enter a selection in OSD. If OSD is inactive, press and the monitor will automatically optimize the position, focus and clock of your display.
  • Page 28 OSD menu Acer eColor Management: Brightness and Contrast adjusted by Acer eColor Management. User: Brightness and Contrast adjusted by User mode. Focus: This removes any horizontal distortion and makes the picture clear and sharp. Clock: If there are any vertical stripes seen on the background of the screen, this renders them less noticeable by minimizing their size.
  • Page 29 Language for Asia: Select the OSD menu language. Select from English, German, Spanish, Simplified Chinese, Traditional Chinese, French, Italian, and Japanese. OSD Settings: This changes the position of the OSD window on the screen and the staying time. Input signal: Select either Analog Input or Digital Input video.
  • Page 30 This page only be visible in factory mode R,G,B OFFSET : Adjust current RGB cut off level R,G,B GAIN : Adjust current RGB Driver value. SPREAD : Adjust chip set internal frequency spread effect for EMI testing. This page only be visible in factory mode AUTO BURN : Use the chip set internal pattern for hot running monitor panel and inverter.

  • Page 31: Led Definition

    LED Definition The system equips one dual color (blue/amber) led to indict system status and defined as bellows: LED Color Blue Amber Dark LOGO: When the monitor is power on, the LOGO will be showed in the center, and disappear slowly. HOW TO OPTIMIZE THE DOS-MODE Plug and play Plug &...
  • Page 32 SIGNAL. This monitor meets the Green monitor standards as set by the Video Electronics Standards Association(VESA) and/or the United States Environmental Protection Agency (EPA) and The Swedish Confederation Employees (NUTEK). This feature is designed to conserve electrical energy by reducing power consumption when there is no video-input signal present.

  • Page 33: Chapter 3 Machine Assembly

    Machine disassembly This chapter contains step-by-step procedures on how to disassemble the monitor for maintenance and trouble shooting NOTE: 1. The screws for the different components vary in size. During the disassembly process, group the screws with the corresponding to avoid mismatch when putting back the components. 2.
  • Page 34 Rear View: Top View:...
  • Page 35 Side View: (unit: mm)
  • Page 36 DISASSEMBLE PROCEDURE 1.Remove 4pcs screws from stand neck and take off 3. Remove 1pcs screw for back cover and take off back cover. 5.Take off the 1pcs yellow type for button/B cable and speaker cable. 2.Take off the screw and separate the base and stand. 4.Take off the lamp cable from power board.
  • Page 37 7. Take off the AL-Foil for LVDS cable and shielding. 9.Take off the LVDS cable from panel. 11. Remove 1pcs yellow type for Button/B cable. 8. Take off the yellow type for LVDS connector . 10. Remove 1pcs of Al-foil and 2pcs of yellow type for camera cable L&R and take off the camera cable.
  • Page 38 13. Take off Button/B from Bezel and take off bezel from panel. 15.Remove total 4pcs of screw for BKT-L&R. 17.Remove 9pcs screws for PCBA and take off of them from shielding. 19.Disconnet the camera cable L&R from ARM board. 14.Take off Button/B cable from Button/B. 16.Remove 5pcs screws for the DVI,VGA,HDMI joint.

  • Page 39: Chapter 4 Trouble Shooting

    TROUBLE SHOOTING 1. No Power Change Power Board Check Short Of Main Board Change U1,Q7,Q8,Q9, Change Y1 Change U3 Change U3 RU Software Check Bottom Board Chapter 4 No Power Check CN1 Check U1=3.3V Q7,Q8,Q9,Q13= 1.8V==1.8V Check Y1=24MHz Check U3 Pin 15,16 Clock Check U3 Pin 24 level...
  • Page 40 2. Missing Color Change Cable Change M/B Change U7 or CN8 Cable or Panel Adjustment R/G/B Color Missing Color Check VGA Cable Check R70~R80 Check CN8 LVDS Signal Check OSD R/G/B Gain Change Panel...
  • Page 41 3. Always show “NO SIGNEL” Change Cable “NO SIGNEL” Check VGA Cable VGA Check R70~R80,C2 9,C30 Change M/B Change M/B...
  • Page 42 4. NO Touch Function “No Touch Function” Change Cable Check Internal CCD Cable Change ARM Module or CCD Module...
  • Page 43 RTD Tool Only ISP Basic operations Before write 1. Please connect LPT cord to PC LPT Port. 2. The correct connection ISP tool to LPT Cord as below: When write BIOS, Need connect VGA Cord to ISP tool Double Click “RTDTOOL ONLY ISP” procedure。...
  • Page 44 Pop out the follow operation surface Click 64K, choose the first bios file (bios file is chosen from the local hard disk)
  • Page 45 Click 64K~96K,choose the second bios file（the first and the second files are saved together） The properties of setup files: “Main” means the main writing file. “Second” means the second writing file. “Both” means both files writing together. “1 TO 4 writer” means 4pcs main boards writing together at the same time.
  • Page 46 “Auto” means the PC writing automatically. “Erase” means procedure erased the former bios of monitor. When write Acer model bios, if two files used, set up the file properties as fellow: 1. Within 64K option, choose the bios file without “ext”;...
  • Page 47 Before writing, please make sure that the monitor must be turned on. During writing, it can’t work if power cutting off, and VGA cord falling off After writing OK, it will display “CRC OK”. Notices: When writing was interrupted, the message will show “MCU link error”. Analysis: Check: 1.

  • Page 48: Chapter 5 Connector Information

    Connector Information Phone jack stereo PIN1. AC power cord: CEE22 typed connector PIN2. Audio cable PIN3. Audio: Line-in receptacle 15 pin mini D-Sub connector The PIN assignment of the 15 pin mini D-SUB connector / cable is as follows: Signal Green Blue No Pin...
  • Page 49 DVI-D connector The PIN assignment of the 24 pin DVI-D connector / cable is as follows: Signal TMDS data2- TMDS data2+ TMDS data2 shield DDC clock DDC data Not connected TMDS data1- TMDS data1+ TMDS data1 shield Detection (return for +5 V and H/V sync) Hot plug detect TMDS data0-...
  • Page 50 HDMI connector The PIN assignment of the 14 pin HDMI connector / cable is as follows Pinout of HDMI connector: TMDS Data 2+ TMDS Data 2 shield TMDS Data 2- TMDS Data 1+ TMDS Data 1 Shield TMDS Data1- TMDS Data 0+ TMDS Data 0 Shield TMDS data 0- TMDS clk+...
  • Page 51 Acer office to order FRU parts repair and service of customer machines. NOTE: To scrap or to return the defective parts, you should follow the local government ordinance or regulations on how best to dispose it, or follow the rules set by your regional Acer office on how to return it.
  • Page 52 EXPLODED DRAWING...
  • Page 53 WIRE ASSY(6/5P F/F 45CM P1/1)W/S JXWCT906015 TP ADHESIVE 288*5.5*0.15(JXWCT906,3A)OTM JXWCT905019 TP ADHESIVE 56*5.5*0.15(JXWCT905,3A)OTM FBWCT905018 BKT-R WCT9-M1(FBWCT905,R3A)OTM FBWCT906014 BKT-T WCT9-M1(FBWCT906,R3A)OTM AA230HT0009 LCD 23"LTM230HT01(1920*1080,5MS)ACER CON DEFC1639122 CABLE FFC(30P,163,,.W)WDZT PTI AS56B4DCB04 PI 55W 4L(175*140,W/O SW)AIP-0191A ATHWCT9M106 WCT9-M1 HUB MODULE(QCI CON) 21WC82RAF28 WCT9-M1 M/B ASSY(DUAL+A+HDMI RTD2482RD) UNIT...

  • Page 54: Chapter 6 Fru List

    LCD PANEL SAMSUNG LTM230HT01 LCD BEZEL ASSY BACK COVER PART NAME W0T9-A1 BUTTON/B ASSY PI 55W 4L(175*140,W/O SW)AIP-0191A WCT9-M1 M/B ASSY(DUAL+A+HDMI RTD2482RD) 23"LTM230HT01(1920*1080,5MS)ACER WCT9-M1 LCD BEZEL SUB ASSY(OTM) 60.LHS0E.005 REAR COVER WCT9- M1(EAWCT909,R3A)OTM ACER PART NO. 55.LE80E.001 55.LHS0E.001 55.LHS0E.002 LK.23006.002 60.LHS0E.006...
  • Page 55 PART NAME STAND KIT ASSY WCT9- M1(KNWCT902,R3A)OTM BASE KIT ASSY WCT9- M1(KNWCT903,R3A)OTM WCT9-M1 PCB SHIELDING ASSY(OTM) 60.LHS0E.009 HINGE COVER-L WCT9- M1(EBWCT911,R3A)OTM HINGE COVER-R WCT9- M1(EBWCT910,R3A)OTM WCT9-M1 OTM MODULE ASSY BKT-R WCT9-M1(FBWCT905,R3A)OTM 60.LHS0E.003 ACER PART NO. 60.LHS0E.007 60.LHS0E.008 60.LHS0E.002 60.LHS0E.001 47.LHS0E.001...
  • Page 56 FRU list CATEGORY BRACKET -L SPEAKER ASSY PART NAME BKT-L WCT9-M1(FBWCT906,R3A)OTM SPEAKER(4,2W,62.3*16*11)L22,R44 P2 ACER PART NO. 60.LHS0E.004 23.LFR0E.001...

  • Page 57: Chapter 7 Schematic Diagram

    MENU AUTO POWER E COLOR RIGHT LEFT GREEN AMBER D2/NC D2/NC DIODE DIAC DIODE DIAC 4401-E10-10P-R 4401-E10-10P-R D1/NC D1/NC DIODE DIAC DIODE DIAC SCHEMATIC DIAGRAM Button board LED1 LED1 LED Dual LED Dual Chapter 7 MENU/SELECT HDK632A HDK632A AUTO/EXIT HDK632A HDK632A POWER HDK632A...

  • Page 58: Main Board

    01/06 HDMI Pin11 Add Cable Detect Function 此料需自己備料 HD5V HD5V HDMI HDMI TMDS_D2+ TMDS_D2+ HDMI_22+ TMDS_GND TMDS_GND TMDS_D2- TMDS_D2- HDMI_22- TMDS_D1+ TMDS_D1+ HDMI_11+ TMDS_GND TMDS_GND TMDS_D1- TMDS_D1- HDMI_11- TMDS_D0+ TMDS_D0+ HDMI_00+ TMDS_GND TMDS_GND TMDS_D0- TMDS_D0- HDMI_00- TMDS_CK+ TMDS_CK+ HDMI_CKK+ TMDS_GND TMDS_GND TMDS_CK- TMDS_CK-...
  • Page 59 PAGE1 VGA INPUT RED+IN RED-IN DDC_SDA GREEN+IN GREEN-IN IN-H BLUE+IN BLUE-IN IN-V DDC_SCL DGND 2007.12.07 change for EMI 5DVCC DAN217K/NC DAN217K/NC DAN217K/NC DAN217K/NC DAN217K/NC DAN217K/NC RED+IN GREEN+IN BLUE+IN IN-H IN-V TX00- 10K/6 10K/6 2007.12.07 change for EMI RX2- RX2+ RX4- RX4+ DDC2_SCL DDC2_SCL...
  • Page 60 V33S V33S 0.1uF/6 0.1uF/6 4.7K/6 4.7K/6 Shielding WP_PRO 100/6 100/6 EESCL 100/6 100/6 EESDA 24LC16BT-I/SNG/RoHS 24LC16BT-I/SNG/RoHS For HDCP 0309 V33S 0.1uF/6/NC 0.1uF/6/NC NC/24LC04BT-I/SN NC/24LC04BT-I/SN NC/3.9K/6 NC/3.9K/6 Shielding HDCP_SCL NC/0/6 NC/0/6 NC/0/6 NC/0/6 HDCP_SDA Pin 119 Pull up- normal mode Pull down- scan mode Pin 110, F/W 一般設定為-pull up Hot_Plug Should...
  • Page 61 V33S R106 R106 R107 R107 10K/6 10K/6 10K/6 10K/6 LED_G R108 R108 4.7K/6 4.7K/6 LED_G MMBT3906 MMBT3906 LED_R R109 4.7K/6 R109 4.7K/6 LED_R MMBT3906 MMBT3906 V33S R112 R112 R113 R113 R114 R114 R115 R115 4.7K/6 4.7K/6 4.7K/6 4.7K/6 4.7K/6 4.7K/6 4.7K/6 4.7K/6 HOTKEY_M...
  • Page 62 CONN 6P2R MV(DFHD06MV001) CONN 6P2R MV(DFHD06MV001) 修改Pull high電壓 V33S 1K/6 1K/6 10K/6 10K/6 0 ohm-->10k 修改Pull high電壓 V33S 1K/6 1K/6 1U/6/NC 1U/6/NC DTC144EUA DTC144EUA BAT54C/NC BAT54C/NC DSUB_5V HD5V BAT54C/NC BAT54C/NC Bus_Power Pi3.3v=440mA x 3.3=1.452w U1與U1-1共同layout 120/CX201209813/8 120/CX201209813/8 BL_EN BL_ADJ SMB/NC SMB/NC SMB/NC SMB/NC...
  • Page 63 1W=913mA 120/CX201209813/8 120/CX201209813/8 120/CX201209813/8 120/CX201209813/8 10K/6/NC 10K/6/NC 4.7K/6/NC 4.7K/6/NC 2K2/6/NC 2K2/6/NC AUDIO_PWR 2N3904/NC 2N3904/NC 100/6/NC 100/6/NC AGND 22/6 22/6 SHUTDOWN 2u2F/8 2u2F/8 0.47uF/6 0.47uF/6 AUDIO_R AUDIO_R AC10 0.47uF/6 AC10 0.47uF/6 AUDIO_L AUDIO_L 10K/6 10K/6 VOL_ADJ AC11 AC11 1uF/6 1uF/6 10K/6 10K/6 AGND AGND...
  • Page 64 POWER BOARD_1...
  • Page 65 POWER BOARD_2...
  • Page 66 Camera L Sensor USB Bridge PAS6312 PAP7701 ARM9 control board NOR Flash DC- DC Power 5V to 3.3V DC- DC Power 5V to 1.2V ARM BOARD Sensor PAS6312 USB signal USB signal ISP1760 Memory Bus ARM9 LPC3230 USB Bridge MAX3420 USB Bus USB connector TO PC...
  • Page 67 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 4.7uF/10V/0603 4.7uF/10V/0603 3.3V 12MHz_3.2x2.5 12MHz_3.2x2.5 XTAL1 C0201/10pF/50V C0201/10pF/50V 1M/0201 1M/0201 XTAL2 C0201/10pF/50V C0201/10pF/50V 3.3V CLKIN TEST1 OC1_N OC1_N PSW1_N PSW1_N 3.3V OC2_N OC2_N PSW2_N PSW2_N 10K/0201 10K/0201 10K/0201 10K/0201 10K/0201 10K/0201 10K/0201 10K/0201 3.3V OC3_N PSW3_N BAT_ON_N SUSPEND/WAKEUP_N TEST3...
  • Page 68 FLASH_RESET C0201/10pF/50V C0201/10pF/50V 1M/0201 1M/0201 13MHz_3.2x2.5 13MHz_3.2x2.5 C0201/10pF/50V C0201/10pF/50V A[0:15] A[0:15] R27 22/0402 R27 22/0402 EMC_A[00]/P1.0 R19 22/0402 R19 22/0402 EMC_A[01]/P1.1 R29 22/0402 R29 22/0402 EMC_A[02]/P1.2 R28 22/0402 R28 22/0402 EMC_A[03]/P1.3 R30 22/0402 R30 22/0402 EMC_A[04]/P1.4 R31 22/0402 R31 22/0402 EMC_A[05]/P1.5 R20 22/0402 R20 22/0402...
  • Page 69 A[0:18] A[0:18] OE_N OE_N WR_N WR_N FLASH_RESET FLASH_RESET 10K/0201 10K/0201 3.3V OE_N WR_N FLASH_RESET 3.3V 10K/0201 10K/0201 DATA[0:15] DATA[0:15] 2,3 DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 S29AL008D S29AL008D 8 Megabit 8 Megabit DATA7 (x8/x16) (x8/x16) DATA8 DATA9 DATA10 DQ10 FBGA48 FBGA48 DATA11...
  • Page 70 VBUS 600 ohm Bead/0603 600 ohm Bead/0603 USBi_D- VBUS USBi_D+ HCB2012KF-330T40 HCB2012KF-330T40 22uF/10V/1210 22uF/10V/1210 CASE CASE USB-B/UBR44-4K5C10 USB-B/UBR44-4K5C10 *0/0805 *0/0805 R108 R108 33/0201 33/0201 3.3V 3.3V 1uF/10V/0402 1uF/10V/0402 3.3V 0.1uF/6.3V/0201 0.1uF/6.3V/0201 1uF/10V/0402 1uF/10V/0402 1M/0201 1M/0201 *0/0805 *0/0805 12MHz_3.2x2.5 12MHz_3.2x2.5 WCM-2012-900T WCM-2012-900T C0201/10pF/50V C0201/10pF/50V...
  • Page 71 4PIN/88291-04001 4PIN/88291-04001 0.1uF/6.3V/0201 0.1uF/6.3V/0201 150uF/6.3V/3.5*2.8(POSCAP) 150uF/6.3V/3.5*2.8(POSCAP) 330/0402 330/0402 Vi = 5V LED1 LED1 KPHHS-1005PBC-A KPHHS-1005PBC-A 0.1uF/10V/0402 0.1uF/10V/0402 10uF/10V/0805 10uF/10V/0805 Vi = 5V 0.1uF/10V/0402 0.1uF/10V/0402 10uF/10V/0805 10uF/10V/0805 R103 R103 *0/0402 *0/0402 R104 R104 VBUS 0/0402 0/0402 U11 AP1533 U11 AP1533 47uH/0403 47uH/0403 OCSET 5.6K/0201...
  • Page 72 Camera L-Board 3.3V 0.1uF/6.3V/0201 0.1uF/6.3V/0201 3.3V 10uF/10V/0805 10uF/10V/0805 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 3.3V 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 1.2V 0.1uF/6.3V/0201 0.1uF/6.3V/0201 10uF/10V/0805 10uF/10V/0805 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 1.2V 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 1.2V 0.1uF/6.3V/0201...
  • Page 73 VSYNC BAT54APT BAT54APT P3V3 1K/0201 1% 1K/0201 1% 74LVC2G74DC 74LVC2G74DC P3V3 LTE-S008X LTE-S008X MMBT2222AT MMBT2222AT sot523_123-1_6-1 sot523_123-1_6-1 10K/0201 1% 10K/0201 1% 60.4/0402 1% 60.4/0402 1% PROJECT PROJECT PROJECT Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Size Size Size...
  • Page 74 PXCLK PXCLK VSYNC VSYNC HSYNC HSYNC SYSCLK SYSCLK P3V3 0.1uF/6.3V/0201 0.1uF/6.3V/0201 P3V3 SYSCLK SYSCLK 0.1uF/6.3V/0201 0.1uF/6.3V/0201 SEN_RESET RESET VSSD PAS6311LT PAS6311LT 100K/0201 100K/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 P2V5 VDDA VSSA 0.1uF/6.3V/0201 0.1uF/6.3V/0201 PROJECT PROJECT PROJECT Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/...
  • Page 75 HCB1608KF-601T10 HCB1608KF-601T10 FILTER-CL-2M2012-4P FILTER-CL-2M2012-4P WCM2012F2SF-900T04 WCM2012F2SF-900T04 CON5_0/87213-0500G CON5_0/87213-0500G 0/0603 0/0603 PBY160808T-330Y-N PBY160808T-330Y-N VDD5MV PBY160808T-330Y-N PBY160808T-330Y-N VDD5MD 10uF/10V/0805 10uF/10V/0805 0.1uF/10V0402 0.1uF/10V0402 0.1uF/10V0402 0.1uF/10V0402 0.1uF/10V0402 0.1uF/10V0402 P3V3 300K/0201 300K/0201 1uF/10V/0402 1uF/10V/0402 P3V3 EPR_CSB EPR_SO EPR_HOLD# HOLD# EPR_SCK EPR_SI *0.1uF/10V/0603 *0.1uF/10V/0603 AT25F512AN-10SU AT25F512AN-10SU P3V3 100K/0201 100K/0201...
  • Page 76 Camera R-Board VSYNC BAT54APT BAT54APT P3V3 1K/0201 1% 1K/0201 1% 74LVC2G74DC 74LVC2G74DC P3V3 LTE-S008X LTE-S008X MMBT2222AT MMBT2222AT sot523_123-1_6-1 sot523_123-1_6-1 10K/0201 1% 10K/0201 1% 60.4/0402 1% 60.4/0402 1% PROJECT PROJECT PROJECT Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Size...
  • Page 77 PXCLK PXCLK VSYNC VSYNC HSYNC HSYNC SYSCLK SYSCLK P3V3 0.1uF/6.3V/0201 0.1uF/6.3V/0201 P3V3 SYSCLK SYSCLK 0.1uF/6.3V/0201 0.1uF/6.3V/0201 SEN_RESET RESET VSSD PAS6311LT PAS6311LT 100K/0201 100K/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 0.1uF/6.3V/0201 P2V5 VDDA VSSA 0.1uF/6.3V/0201 0.1uF/6.3V/0201 PROJECT PROJECT PROJECT Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/ Rvboub!Dpnqvufs!Jod/...
  • Page 78 HCB1608KF-601T10 HCB1608KF-601T10 FILTER-CL-2M2012-4P FILTER-CL-2M2012-4P WCM2012F2SF-900T04 WCM2012F2SF-900T04 CON5_0/87213-0500G CON5_0/87213-0500G 0/0603 0/0603 PBY160808T-330Y-N PBY160808T-330Y-N VDD5MV PBY160808T-330Y-N PBY160808T-330Y-N VDD5MD 10uF/10V/0805 10uF/10V/0805 0.1uF/10V0402 0.1uF/10V0402 0.1uF/10V0402 0.1uF/10V0402 0.1uF/10V0402 0.1uF/10V0402 P3V3 300K/0201 300K/0201 1uF/10V/0402 1uF/10V/0402 P3V3 EPR_CSB EPR_SO EPR_HOLD# HOLD# EPR_SCK EPR_SI *0.1uF/10V/0603 *0.1uF/10V/0603 AT25F512AN-10SU AT25F512AN-10SU P3V3 100K/0201 100K/0201...
