Page 5
長者可能比年輕觀眾感受到較少 3D 效果。 請勿坐於 少於建議距離位置。 感覺因缺乏睡眠、過度工作或酒精飲用而引致疲勞 時,請勿觀看 3D 內容。 如出現此等癥狀時,停止觀看 3D 內容並進行足夠休 當使用 3D 眼鏡是請注意 息直至癥狀消退。 如癥狀持續請從速求醫。 癥狀可包括頭痛、眼球疼 確保使用的為 LG 的 3D 眼鏡。 否則,將不能正常觀 痛、眩暈、噁心、心悸、視力模糊及不適、重影、 看 3D 影片。 視力受阻或疲勞。 請勿使用普通眼鏡、太陽眼鏡或保護鏡而非 3D 眼 鏡。 使用已改造的 3D 眼鏡可導致因適應而產生之眼部不 適或影像變形。 請勿將 3D 眼鏡存放於過高或過低溫度。 將導致其變...
Page 16
確保所使用的螺絲及壁掛支架合符 VESA 標準。 壁掛支架 注意 的標準尺寸見下表。 先中斷電源線的連接,然後移動或安裝電視。 否 則,將可能導致觸電。 型號 32LA6200 42LA6200 若於天花或傾斜的牆面安裝電視,將可能跌落並導 VESA (A x B) 200 x 100 200 x 200 致嚴重受傷。 請使用授權 LG 壁掛支架並聯絡當地經銷商及合資格 人士。 請勿過度旋緊螺絲,否則會導致電視受損及保修失 效。 標準螺絲 使用符合 VESA 標準的螺絲和壁掛支架。 因誤用或 使用不當配件而造成的任何損壞或傷害並不包括在 螺絲數目 保養範圍內。 壁掛支架(選購) LSW130B LSW230B MSW240 注意...
Page 19
進行連線 DVI 至 HDMI 連接 將數字視頻信號從外部裝置傳輸至電視。 使用 DVI-HDMI 線連接外部裝置與電視,如下圖所示。 如需傳輸音頻訊號, 連接選購的音頻纜線。 注意 使用 HDMI/DVI 纜線時,僅支援單一連接。 選擇任何輸入 HDMI 輸入端口進行連接。 任何連連接端口均可使用。 (*不提供) 白 (*不提供) AUDIO OUT DVI OUT 紅 DVD / Blu-Ray / HD 收費電視機頂盒...
Page 26
進行連線 連接耳機 可使用耳機收聽聲音。 注意 當連接耳機後音效功能表選項將會被停用。 使用連接的耳機變更 AV 模式時,變更只會套用在視訊上,而不會套用在音訊上。 當連接耳機後光學數碼音效輸出便不能提供。 耳機阻抗:16 Ω 耳機最大音效輸出:10 mW 至 15 mW 耳機插頭尺寸:0.35 cm 耳機 (*不提供) H/P OUT 連接 USB 設備 將 USB 儲存裝置,如 USB 快閃記憶體、外置硬碟、或 USB 記憶卡讀取器連接至電視,然後進入 Smart Share 功能表即可使 用各種多媒體檔案。 注意 某些 USB 集線器可能不能運作。 如連接至 USB 集線器的 USB 裝置未能被探測,可直接將裝置連接至於電視上的 USB 端口。...
Page 27
遙控器 遙控器 本手冊的描述基於遙控器的按鍵而定。 請仔細閱讀本手冊並正確使用電視。 如需安裝電池,打開 電池蓋, 更換電池 (1.5 V AAA) 時配對電池格內的 及 端標籤,然後關上電池蓋。 如要移除 電池,以相反步驟執行動作。 注意 請勿混合使用新舊電池,否則遙控器可能受損。 某些遙控器按鍵於某些國家的類比模式電視有可能不能運作。 遙控器使用紅外線運作。 使用時應對準電視遙控感應器的方向。 (電源) 開啟或關閉電視。 (使用指南) 參閱使用指南。 RATIO INPUT RATIO TV / 重新調整圖像的大小。 INPUT 選擇外部輸入模式。 亦可將電視從待機狀狀態切換至開啟狀態。 TV/RAD 選擇電視頻道或廣播頻道。 數字按鈕 輸入數字。 LIST LIST Q.VIEW 進入已儲存頻道列表。...
Page 28
遙控器 RATIO INPUT TV / INFO 查看當前節目和屏幕信息。 SMART 進入 Smart Home 功能表。 MY APPS 顯示應用程式清單。 LIST Q.VIEW 導航按鍵 (上/下/左/右) 滾動閱覽菜單或選項。 OK ꔉ 選擇菜單或選項並確認輸入。 ꕣ BACK 返回至上一層。 MUTE GUIDE 節目播放時間將根據預定時間顯示。 INFO SMART MY APPS EXIT 清除所有畫面顯示並返回觀看電視。 顏色按鈕 訪問某些菜單中的特殊功能。 ( :紅、 :綠、 :黃、...
Page 29
To set TV lock options PROGRAMME Setting PICTURE, SOUND Setting To set language OPTION To set subtitle LG SMART Function Advanced Function Disabled Assistance Information Index Online User Guide (視乎國家而定) 顯示正觀看的視訊。 節目指南類別。 在目前類別中的一系列標題。 您可以使用導航鍵 鍵在頁面之間移動。 關鍵字索引列於使用指南中。 於已連接互聯網後可提供 LG Smart TV 功能的詳細 資訊。 (可能因應國家/語言而未能提供。)...
Page 30
操作溫度 0 °C ~ 40 °C 操作濕度 低於 80% 環境條件 儲存溫度 -20°C ~ 60 °C 儲存濕度 低於 85% 關於電源供應及耗電量,參閱於產品上的標籤。 32LA6200 42LA6200 型號 (32LA6200-CA) (42LA6200-CA) 含底座 733 x 499 x 242 (毫米) 964 x 631 x 294 (毫米) 尺寸(寬 x 高 x 深)...
Page 37
OWNER’S MANUAL LED TV* * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32LA6200 42LA6200 50LA6200 55LA6200 60LA6200 www.lg.com...
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS Please read these safety precautions carefully before using the product. WARNING Do not plug too many electrical devices into a single multiple electrical outlet. Otherwise, this may Do not place the TV and remote result in fire due to over-heating. control in the following environments: - A location exposed to direct sunlight - An area with high humidity such as...
Page 39
SAFETY INSTRUCTIONS Do not allow a impact shock or any If you intend to mount the product to a wall, attach VESA objects to fall into the product, and standard mounting interface (optional parts) to the back do not drop onto the screen with of the product.
Page 40
SAFETY INSTRUCTIONS Periodically examine the cord of your appliance, and if its Refer all servicing to qualified service appearance indicates damage or deterioration, unplug it, personnel. Servicing is required when discontinue use of the appliance, and have the cord replaced the apparatus has been damaged in with an exact replacement part by an authorized servicer.
3D Cautions when using the 3D glasses content. Make sure to use LG 3D glasses. Otherwise, you may not be able to view 3D videos properly. Symptoms which require discontinuation or Do not use 3D glasses instead of your normal refraining from watching 3D content glasses, sunglasses or protective goggles.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to ‘opensource@lge.com’. This offer...
TABLE OF CONTENTS TABLE OF CONTENTS SAFETY INSTRUCTIONS REMOTE CONTROL Viewing 3D Imaging (For 3D models) USING THE USER GUIDE LICENSES SPECIFICATIONS OPEN SOURCE SOFTWARE NOTICE EXTERNAL CONTROL DEVICE SETUP TABLE OF CONTENTS MAINTENANCE INSTALLATION PROCEDURE Cleaning Your TV - Screen, frame, cabinet and stand ASSEMBLING AND PREPARING - Power cord Unpacking...
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING INSTALLATION PROCEDURE Open the package and make sure all the accessories are included. Attach the stand to the TV set. Connect an external device to the TV set. Make sure the network connection is available. You can use the TV network functions only when the network connection is made.
Page 45
ASSEMBLING AND PREPARING Remote Control, Batteries (AAA) Owner’s Manual Cinema 3D Glasses (See p. 27) The number of 3D glasses may differ depending on the model or country. Stand Body, Stand Base Stand Screws Power Cord (See p. 13) 8 EA, M4 x 14 (See p.
Optional extras can be changed or modified for quality improvement without any notification. Contact your dealer for buying these items. These devices only work with certain models. The model name or design may be changed manufacturer’s circumstances or policies. AN-MR400 AN-VC4** LG Audio Device Magic Remote Video Call Camera AG-F*** AG-F***DP AN-WF100...
ASSEMBLING AND PREPARING Parts and Buttons Screen SETTINGS INPUT Buttons Speakers Remote Control Sensor Power Indicator Button Description (^ / v) Scrolls through the saved channels. Adjusts the volume level. (+ / -) (OK ⊙ ) Selects the highlighted menu option or confirms an input. Accesses the main menus, or saves your input and exits the menus.
ASSEMBLING AND PREPARING Lifting and moving the TV When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size. CAUTION Avoid touching the screen at all times, as this may result in damage to the screen.
ASSEMBLING AND PREPARING Setting up the TV You can mount your TV to a wall or attach the stand if you wish to place the TV on an entertainment center or other furniture. Attaching the stand If you are not mounting the TV to a wall, use the following instructions to attach the stand. CAUTION When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
ASSEMBLING AND PREPARING Mounting on a table Securing the TV to a table (For 32/42/50LA6200) Lift and tilt the TV into its upright position on a table. Fix the TV to a table to prevent from tilting forward, - Leave a 10 cm (minimum) space from the wall for damage, and potential injury.
ASSEMBLING AND PREPARING Securing the TV to a wall (optional) Using the Kensington security system (optional) (Depending on model) (Depending on model) The Kensington security system connector is located at the rear of the TV. For more information of installation and using, refer to the manual provided with the Kensington security system or visit http://www.kensington.com.
ASSEMBLING AND PREPARING Mounting on a wall Wall mount bracket (optional) LSW130B An optional wall mount can be used with your LG Television. Consult with your local dealer for a wall mount that supports the VESA standard used by your LSW230B TV model.
MAKING CONNECTIONS MAKING CONNECTIONS You can connect various external devices to the TV. Supported external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. For more information on external device’s connection, refer to the manual provided with each device. NOTE If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input cable to the TV through a DVD recorder or VCR.
MAKING CONNECTIONS Connecting to a HD receiver, DVD Player, or VCR Connect a HD receiver, DVD Player, or VCR to the TV and select an appropriate input mode. HDMI Connection HDMI is the best way to connect a device. Transmits the digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown in the following illustration.
MAKING CONNECTIONS DVI to HDMI Connection Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an audio cable. NOTE When using the HDMI/DVI cable, Single link is only supported.
MAKING CONNECTIONS Connecting to a mobile phone Mobile High-definition Link (MHL) is an interface for transmitting digital audiovisual signals from mobile phones to television sets. NOTE Connect the mobile phone to the HDMI IN 3 (MHL) port to view the phone screen on the TV. This only works for the MHL-enabled phone.
MAKING CONNECTIONS Component Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with a component cable as shown in the following illustration. NOTE If cables are installed incorrectly, it could cause the image to display in black and white or with distorted color. Check to ensure the cables are matched with the corresponding color connection.
MAKING CONNECTIONS Composite Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown in the following illustration. NOTE Check to ensure the cables are matched with the corresponding color connection. YELLOW WHITE VIDEO...
MAKING CONNECTIONS Connecting to a PC NOTE It is recommended to use an HDMI connection for the best image quality. Depending on the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use. In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness.
Page 60
MAKING CONNECTIONS Method B: DVI to HDMI Connection Choose any HDMI input port to connect. It does not matter which port you use. (*Not Provided) WHITE (*Not Provided) AUDIO OUT DVI OUT (PC) (PC) (RGB/HDMI-PC) (RGB/HDMI-PC) AUDIO AUDIO...
MAKING CONNECTIONS Connecting to an Audio System You may use an optional external audio system instead of the built-in speaker. Digital Optical Audio Connection Transmits a digital audio signal from the TV to an external device. Connect the external device and the TV with the optical audio cable as shown in the following illustration.
MAKING CONNECTIONS Connecting Headphones You listen to the sound using headphones. NOTE AUDIO menu options are disabled when headphones are connected. When changing AV MODE with headphones connected, the change is applied to video but not to audio. Optical Digital Audio Out is not available when headphones are connected. Headphone impedance: 16 Ω...
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To install batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover.
Page 64
REMOTE CONTROL RATIO INPUT TV / INFO Views the information of the current program and screen. SMART Accesses the Smart Home menu. MY APPS Shows the list of Apps. Navigation buttons (up/down/left/right) LIST Q.VIEW Scrolls through menus or options. OK ꔉ Selects menus or options and confirms your input.
An index of key words present in the User Guide. Provides the detailed information on the functions of LG Smart TV when the Internet is connected. (It may not be available depending on the country/ language.)
Storage Temperature -20°C to 60 °C Storage Humidity Less than 85 % For the power supply and power consumption, refer to the label attached to the product. 32LA6200 42LA6200 MODELS (32LA6200-CA) (42LA6200-CA) With stand 733 x 499 x 242 (mm)
Page 67
SPECIFICATIONS HDMI/DVI-DTV supported mode Component port connecting information Component ports on the Horizontal Vertical Resolution Frequency (kHz) Frequency (Hz) 640 x 480 31.469 / 31.5 59.94 / 60 720 x 480 31.469 / 31.5 59.94 / 60 Video output ports on DVD player 31.25 720 x 576...
Page 68
SPECIFICATIONS 3D supported mode Video, which is input as below media contents is switched into the 3D screen automatically. The method for 3D digital broadcast may differ depending on the signal environment. If video is not switched automatically into 3D, manually convert the settings to view 3D images. 3D supported mode automatically Horizontal Vertical Frequency...
1280 x 720p 30 / 60 2D to 3D, Side by Side(Half), Top & Bottom Miracast/Widi 1920 x 1080p 30 / 60 Others 2D to 3D EXTERNAL CONTROL DEVICE SETUP To obtain the external control device setup information, please visit ‘www.lg.com’.
MAINTENANCE / TROUBLESHOOTING MAINTENANCE Cleaning Your TV Clean your TV regularly to keep it at peak performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended or unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges.
Page 72
The model and serial number of the TV is located on the back and one side of the TV. Record it below should you ever need service. MODEL SERIAL...
