Page 1
OWNER’S MANUAL DVD Home Theater System Please read this manual carefully before operating your set and retain it for future reference. DH6635T (DH6635T, S63T2-S, S63S2-C, S63T4-W) DH6631T-FB_DKENHLK_ENG_6023.indd 1 2014-07-15 5:48:37...
Page 2
Getting Started Safety Information CAUTION CAUTION: This product employs a Laser System. RISK OF ELECTRIC SHOCK To ensure proper use of this product, please read DO NOT OPEN this owner’s manual carefully and retain it for future CAUTION: TO REDUCE THE RISK OF ELECTRIC reference.
Page 3
Getting Started This device is equipped with a portable battery or POWER: This unit operates on a mains supply accumulator. of 200-240V~, 50/60Hz. Safety way to remove the battery or the Wiring: This unit is supplied with a BS 1363 battery from the equipment: Remove the approved main plug.
Table of Contents Table of Contents System Setting Adjust the setup settings – OSD Initial language settings - Optional Getting Started – To display and exit the Setup menu – Language Safety Information – Display Unique Features – Audio – Portable In –...
Page 5
Table of Contents – Listening to music of a Bluetooth device – Listening to music on this unit using Bluetooth device Troubleshooting Troubleshooting Appendix Maintenance – Handling the Unit – Notes on Discs Area Code List Language code List Trademarks and Licenses Specifications DH6631T-FB_DKENHLK_ENG_6023.indd 5 2014-07-15...
Getting Started Unique Features Accessories Please check and identify the supplied accessories. Portable In Listen to music from your portable device. (MP3, Notebook, etc) USB Direct Recording Remote control (1) Battery (1) Records music from CD to your USB device. Full HD up-scaling Views Full HD picture quality with simple setup.
Getting Started Introduction Symbols Used in this Manual DVD-Video, DVD±R/RW in Video mode or VR mode and finalized Playable Discs Audio CDs This unit plays DVD±R/RW and CD-R/RW that contains audio titles, DivX, MP3, WMA and/or Video files contained in the JPEG files.
When setting the optin to Live File System, y Playable Audio format : “AC3”, “PCM”, “MP3”, “WMA”. you cannot use it on LG players. (mastered/Live y Sampling frequency : within 32 to 48 kHz (MP3), File System : Disc format sysyem for Windows...
- You can control the sound in the menu or exits the setup level, input source, and power menu. switching of LG TVs as well. Hold POWER (TV) and press PR/ TITLE: If the current DVD title has CH (W/S) button repeatedly a menu, the title menu appears until the TV turns on or off.
Getting Started Front panel a Disc Tray g I (STOP) Stops playback. b Display window h F (FUNCTION) Shows the current status of the unit. Changes the input source or function. c PORT. IN i -/ +(Volume) Connects to a portable player with audio outputs.
Getting Started Rear panel f VIDEO OUT a Power cord Connects to a TV with video inputs. b Speaker connectors Connects the speaker cables g HDMI OUT Connects to TV with HDMI inputs. c Cooling Fan (Interface for digital audio and video) d Antenna Connector h OPTICAL IN FM- Connects the FM wired antenna...
Connecting Assembling the 2. Draw the speaker cord through the hole on the base. speaker Preparation Pole Base Screw Speaker Speaker cables 1. Attach the pole to the base, then secure the connection with a supplied screw. Note Make sure speaker cable unfolded or in straght condition before insert it to the hole.
Page 13
Connecting 3. Attach the speakers to the speaker stands by 4. Connect the speaker wire to the terminal on rotating the screws. the speaker.Make sure the wire marked black goes in to the terminal marked “-”(minus) and the other wire goes in to the terminal marked “+”(plus) >...
Connecting Attaching the speakers Color Speaker Position to the unit Grey Rear Rear right Blue Rear Rear left Green Center Center 1. Connect the wires to the unit. Match each wire’s colored band to the same Orange Sub woofer Any front position colored connection terminal on the rear of the unit.
Connecting Positioning the system Front left speaker (L)/ Front right speaker (R): Place the front speakers to the sides of the monitor or screen and as flush with the screen The following illustration shows an example of surface as possible. positioning the system.
Connecting Connections to Your HDMI Out Connection If you have a HDMI TV or monitor, you can connect it to this unit using a HDMI cable (Type A, High Speed HDMI™ Cable). Connect the HDMI OUT jack on the unit to the Make one of the following connections, depending HDMI IN jack on a HDMI compatible TV or monitor.
Cable. Yellow Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc.
Connecting Video Output Resolution Setting Resolution The unit provides several output resolutions for HDMI OUT. You can change the resolution using [Setup] menu. Displayed resolution in display window and 1. Press n HOME. outputted resolution may different according to 2. Use A/D to select the [Setup] and press connection type.
Connecting Optional Equipment AUDIO (PORT. IN) In Connection Connection Connect an output of portable device (MP3 or PMP etc) to the AUDIO (PORT. IN) input connector. AUX In Connection Connect an Output of auxiliary device to the AUX (L/R) INPUT Connector. Unit MP3 player, etc...
Connecting USB Connection Compatible USB Devices y MP3 Player : Flash type MP3 player. Connect the USB port of USB Memory (or MP3 player, etc.) to the USB port on the front of the unit. y USB Flash Drive : Devices that support USB2.0 or USB1.1.
Connecting OPTICAL In connection Home theater speaker ez setup Connect an optical output of Unit (or Digital Device etc) to the OPTICAL IN connector. Listen to sound from TV, DVD and Digital Device with 5.1(2.1 or 2)ch mode. Even in power off mode, if you press OPTICAL, then power is on and automatically changed to AUX OPT mode.
Connecting Antenna Connection Connect the supplied FM antenna for listening to the radio. Connect the FM Wire antenna to the FM antenna connector. Note Be sure to fully extend the FM wire antenna. DH6631T-FB_DKENHLK_ENG_6023.indd 22 2014-07-15 5:48:43...
System Setting Adjust the setup To display and exit the Setup menu settings 1. Press n HOME. Displays the [Home Menu]. By using the Setup menu, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup menu, among other things.
System Setting Language Display Mode The Display Mode setting works only when the TV Aspect mode is set to 4:3. Menu Language Select a language for the Setup menu and then on [Letterbox] screen display. Displays a wide picture with bands on the upper and lower portions of the screen.
System Setting Audio [Speaker] Select a speaker that you want to adjust. 5.1 Speaker Setup Note Make the following settings for the built-in 5.1 Certain speaker settings are prohibited by channel surround decoder. the Dolby Digital licensing agreement. 1. Select [5.1 Speaker Setup] on the [Audio] menu. 2.
System Setting Lock (Parental Control) DRC (Dynamic Range Control) Make the sound clear when the volume is turned down (Dolby Digital only). Set to [On] for this effect. Initial Setting the Area Code: When you use this unit for the first time, you have Vocal to set the Area Code.
System Setting Others Password You can enter or change password. DivX(R) VOD 1. Select [Password] on the [Lock] menu and then press D. ABOUT DIVX VIDEO: DivX® is a digital video 2. Press b ENTER. format created by DivX, LLC, a subsidiary of Rovi Corporation.
Operating Using the Home Menu Basic Operations 1. Press n HOME. 1. Insert the disc by using the B OPEN/CLOSE or Displays the [Home Menu]. Connect the USB device to the USB port. 2. Press n HOME. Displays the [Home Menu]. 3.
Operating Other Operations Do this Press Z STOP. Stop Displaying Disc Information Press d PLAY, MONO/ Playback STEREO. on-screen Press M PAUSE/STEP. Pause You can display various information about the disc loaded on-screen. Press M PAUSE/STEP Frame-by- repeatedly to play title Frame- 1.
Operating To display the DVD Menu 3. Input the required start time in hours, minutes, and seconds from left to right. If you enter the wrong numbers, press CLEAR to remove the numbers you entered. Then input the correct When you play a DVD which contains several menu, numbers.
Operating Marked Playback To delete a Marker 1. Use to select the track that you wish to erase from the marked file. The mark function enables you to store your 2. Press MARKER. favourite files from any disc or USB device in the unit memory.
Operating Viewing a PHOTO file About help menu in the full screen Menu Buttons Operation This unit can play discs with photo files. Displaying the Option Menu INFO/ menu. 1. Select [Photo] on the [Home Menu] and press DISPLAY b ENTER. Moving to another file.
Operating Sleep Timer Setting System Select - Optional Press SLEEP one or more times to select delay time You must select the appropriate system mode for your TV system. Press and hold M PAUSE/STEP between 10 and 180 minutes, after the unit will turn off.
Operating Radio Operations Deleting a saved station 1. Press PRESET - / + to select a preset number you want to delete. Be sure that FM aerials are connected. (Refer to the page 22.) 2. Press CLEAR, the preset number will blink in the display window.
Operating Note Sound adjustment y In some of surround modes, some speakers, there’s no sound or low sound. It depends on the mode of surround and the source of Setting the surround mode audio, it is not defective. y You may need to reset the surround mode, This system has a number of pre-set surround after switching the input, sometimes even sound fields.
Operating Note Advanced Operations y You can check the recording percentage rate for the USB record on the screen during the recording. (Audio CD or MP3/ WMA CD Recording to USB only) y During recording MP3/WMA, there is no You can record music or sound souce to USB device sound.
Cascade if the connection was made via display depending on the type of Bluetooth Bluetooth® wireless technology. device.Your unit appears as “LG Audio”. Available Devices : Mobile phone, MP3, Laptop, 3. Enter the PIN code. PDA (This units be supported the Stereo Headset.) PIN code : 0000 4.
Operating Listening to music on this unit Operating with Bluetooth device using Bluetooth device You can operate a unit by connecting a Bluetooth device using AVRCP. For details about operation, refer to the Bluetooth device’s User Guide. Pairing your unit and Bluetooth Note device These operations may not be vailable for...
Page 39
Operating Note y This units dose not be supported the Mono Headset Profile (Hands Free Profile) y The sound may be interrupted when the connection interfered by the other electronic wave. y You cannot control the Bluetooth device with this unit. y Pairing is limited one Bluetooth device per one unit and multi-pairing is not supported.
Troubleshooting Troubleshooting PROBLEM CORRECTION No power Plug the power cord into the wall outlet securely. Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen. No picture Connect the video cables securely to both the TV and unit. Select the correct input mode of the unit so you can hear the sound from the unit.
Appendix Maintenance Notes on Discs Handling Discs Handling the Unit Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the When shipping the unit disc.
Appendix Area Code List Choose an area code from this list. Area Code Area Code Area Code Area Code Afghanistan Fiji Monaco Singapore Argentina Finland Mongolia Slovak Republic Australia France Morocco Slovenia Austria Germany Nepal South Africa Belgium Great Britain Netherlands South Korea Bhutan...
Appendix Language code List Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu]. Language Code Language Code Language Code Language Code Afar 6565 French 7082 Lithuanian 7684 Sindhi 8368 Afrikaans 6570 Frisian...
Bluetooth® wireless technology. The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners. DH6631T-FB_DKENHLK_ENG_6023.indd 44...
Appendix Specifications General Power requirements Refer to main label. Power consumption Refer to main label. Dimensions (W x H x D) (360 x 60.5 x 299) mm without foot Net Weight (Approx.) 2.66 kg Operating temperature 5 °C to 35 °C Operating humidity 5 % to 90 % Bus Power Supply (USB)
Page 46
Appendix Front Speaker Type 1 way 1 speaker Impedance Rated 3 Ω Input Power 167 W Max. Input Power 334 W Net Dimensions (W x H x D) (250 x 1150 x 250) mm Net Weight 3.7 kg Rear Speaker Type 1 way 1 speaker Impedance Rated...
