4. RAIN SHOWER

Please follow the instructions given by symbol

5. PARTS IDENTIFICATION

Home Shower Set:
ON/OFF DP (double pole) Switch
Earth
Miniature Circuit Breaker (MCB)
Upper Rail Holder
Shower Plate (Ag+Crystal-
Antibacterial Shower Plate)
Shower Select Button
Shower Head
Shower Hanger
Shower Hanger Knob
Sliding Rail
Lower Rail Holder
Shower Hose
View from the bottom
ELB Reset Lever
Air Hose (For DH-3ND1)
Outlet
Rain Shower:
Rain Shower Head
before using DH-3NDP1 (with Rain Shower).
Parts not included
Built in Electric Leakage Breaker (ELB)
Health
Hot
Cool
Normal
PM
-
e-Cycle
ELB Test
Push On -Off
ELB Reset
Push Up
ELB Test Button
Shower Pipe Holder
Shower Head
Shower Hanger
Shower Hose A
- 23 -
Back Plate
Front Plate
LCD Display &
Control Panel
Safe
o
C
Bubble
Max
Beat
Level
Set + e-Hybrid
Push On-Off Lever
Filter Body Assembly
Inlet
Upper Shower Pipe
Upper Bracket
Adjustable Lock
Lower Shower Pipe
Shower Hanger Button
Diverter
Lower Bracket
Shower Hose B
Bath Room
Water Volume Knob
FILTER
CLEANING
Filter Knob
Parts not included
Water Inlet
Main Water Valve
DH-3NDP1
(with Rain Shower)
