All manuals and user guides at all-guides.com 1 Warning Caution: • Pb free solder has a higher melting point that standard solder; Typically the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder- ing iron, please be careful not to heat too long.
All manuals and user guides at all-guides.com 3 Troubleshooting Guide 3.1. Main unit and charging adaptor NOTE: Once taking the battery out, the shaver is RESET. The shaver must be charged for several seconds first. NOTE: Completely discharge and then fully charge before returning the shaver to the customer.
Page 4
All manuals and user guides at all-guides.com...
Page 5
All manuals and user guides at all-guides.com...
Page 6
All manuals and user guides at all-guides.com 3.2. Self-cleaning recharger (ES-LV95 only)
Page 7
All manuals and user guides at all-guides.com 3.3. Operation of self-cleaning recharger (ES-LV95 only)
All manuals and user guides at all-guides.com 4 Disassembly and Assembly Instructions 4.1. Disassembly instructions Follow the procedure below to disassemble the main unit. 1. Remove the cap, the outer foil with outer foil frame and 3. To remove the trimmer driving bar, finishing blade driving the inner blades.
Page 9
All manuals and user guides at all-guides.com 5. Take out the battery from the chassis. 7. Loosen two screws. 8. Move gently the linear motor assembly down and unhook it and remove the float springs from housing A. 6. Unsolder the lead wires from the module.
Page 10
All manuals and user guides at all-guides.com 4.2. Caution in assembly 4. Make sure that the lead wires set in position to avoid abnormal noise. Install (+) terminal of battery into the ter- NOTE: minal plate at the bottom cover side and firmly set the bat- When reassembling, replace the new waterproof seal.
Page 11
All manuals and user guides at all-guides.com 6. Tighten six screws and attach the rear panel firmly. 5. When putting the housing A and the housing B together, make sure if the waterproof seal must be fitted properly and no foreign substance sticking around.
Page 12
All manuals and user guides at all-guides.com 7. Attach the bottom cover and tighten a screw. 8. Set the trimmer driving bar, the finishing blade driving bar and the slit blade driving bar.
All manuals and user guides at all-guides.com 6 Exploded View and Replacement Parts List 6.1. Exploded View for ES-LV95...
Page 15
All manuals and user guides at all-guides.com 6.2. Replacement Parts List for ES-LV95 Safety Ref. No. Part No. Part Name & Description Quantity Remarks WESLV94X7158 PROTECTIVE CAP WESELV9S0047 FOIL FRAME WES9173P SYSTEM OUTER FOIL WES9170P INNER BLADE WESELV9L1007 LINEAR MOTOR ASSEMBLY...
Page 16
All manuals and user guides at all-guides.com 6.3. Exploded View for ES-LV65...
Page 17
All manuals and user guides at all-guides.com 6.4. Replacement Parts List for ES-LV65 Safety Ref. No. Part No. Part Name & Description Quantity Remarks WESLV94X7158 PROTECTIVE CAP WESELV8S0047 FOIL FRAME WES9173P SYSTEM OUTER FOIL WES9170P INNER BLADE WESELV9L1007 LINEAR MOTOR ASSEMBLY WESLV90L1077 SLIT BLADE DRIVING BAR WESLV90L0327...
