Fujitsu LifeBook N Series BIOS Guide LifeBook N Series Models: N6000 Document Date: 11/11/04 Document Part Number: FPC58-1268-01 F U J I T S U C O M P U T E R S Y S T E M S...
To enter the BIOS Setup Utility do the following: 1. Turn on or restart your notebook. 2. Press the [F2] key once the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.
Page 3
3. If an error message is displayed on the screen, and you want to enter the setup utility, press the [F2] key. 4. When the setup utility starts with a fault present, the system displays the following message: Warning! Error message [Continue] 5.
MS- DOS prompt. PhoenixBIOS Setup Utility Security Boot Info Exit [14:57:01] [11/11/2004] Adjust calendar clock. <Tab>, <Shift-Tab>, or [FUJITSU MHT2060H-(PM)] <Enter> selects field. [DV-W28E-(SM)] [English (US)] -/Space Change Values Enter Select Sub-Menu Figure 1. Main Menu Default Description –—...
Page 5
Table 1: Fields, Options and Defaults for the Main Menu Note that the parameters listed in the following table may vary depending upon your system’s configuration. Menu Field Options Primary Master: Selects Primary Master submenu Secondary Master Selects Secondary Master submenu ■...
Page 6
L i f e B o o k N S e r i e s N o t e b o o k B I O S Primary Master Submenu of the Main Menu The Primary Master submenu identifies what ATA devices are installed. Main Primary Master [FUJITSU MHT2060AH-(PM)] Type: Total Sectors: Maximum Capacity:...
Page 7
Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu Menu Field Options ■ Heads: A number between 1 and 16 ■ Sectors: A number between 0 and 63 ■ Maximum Display only Capacity: LBA and CHS ■...
Page 8
L i f e B o o k N S e r i e s N o t e b o o k B I O S Secondary Master Submenu of the Main Menu The Secondary Master submenu allows you to configure secondary ATA devices. Main Secondary Master [TOSHIBA DVD-ROM SD-R2412] Type:...
Page 9
Table 3: Fields, Options and Defaults for the Secondary Master Submenu of the Main Menu Menu Field Options ■ Maximum Display only Capacity: ■ Multi-Sector Disabled Transfers: ■ 2 Sectors ■ 4 Sectors ■ 8 Sectors ■ 16 Sectors ■ LBA Mode Disabled Control:...
L i f e B o o k N S e r i e s N o t e b o o k B I O S ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS The Advanced Menu allows you to: Set the I/O addresses for the serial and parallel ports.
Page 11
Table 4: Fields, Options and Defaults for the Advanced Menu Menu Field Description USB Features When selected, opens the USB Features submenu to allow you to enable or disable the legacy support and SCSI SubClass support (e.g., floppy disk drive, external optical drive). Miscellaneous When selected, opens the Miscellaneous Configurations submenu to allow you to enable or disable the power Configurations...
Page 12
L i f e B o o k N S e r i e s N o t e b o o k B I O S Keyboard Features Submenu of the Advanced Menu The Keyboard Features submenu is for enabling or disabling the NumLock feature. Main Advanced Keyboard Features...
Video Features Submenu of the Advanced Menu The Video Features Submenu is for setting the display parameters. Main Advanced Video Features Display: Compensation: Help Select Item Exit Select Menu Table 6: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu Menu Field Options ■...
L i f e B o o k N S e r i e s N o t e b o o k B I O S Internal Device Configurations Submenu of the Advanced Menu The Internal Device Configuration submenu allows the user to configure other internal devices. Main Advanced Internal Devices Configurations...
CPU Features Submenu of the Advanced Menu The CPU Features Submenu provides options for enabling or disabling the Hyper-Threading (HT) Technology feature. Main Advanced CPU Features HT Technology: Power Management: [Enabled] Help Select Item Exit Select Menu Table 8: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu Menu Field Options ■...
L i f e B o o k N S e r i e s N o t e b o o k B I O S USB Features Submenu of the Advanced Menu The USB Features Submenu provides options for enabling or disabling the USB Floppy Disk Drive. Main Advanced USB Features...
Miscellaneous Configurations Submenu of the Advanced Menu The Miscellaneous Configurations Submenu provides options for enabling or disabling the power button and the Wake Up On LAN feature, and for enabling or disabling the system beep. Main Advanced Miscellaneous Configurations Power Button: Wake up on LAN: System Beep: Instant MyMedia:...
L i f e B o o k N S e r i e s N o t e b o o k B I O S Event Logging Submenu of the Advanced Menu The Event Logging Submenu configures event logging features for DMI events. Main Advanced Event Logging...
SECURITY MENU – SETTING THE SECURITY FEATURES The Security menu allows you to set up the data security features of your notebook to fit your operating needs and to view the current security configuration. Follow the instructions for Navigating Through the Setup Utility to make any changes.
Hard Disk Security Submenu of the Security Menu The Hard Disk Security Submenu is for configuring hard disk security features. Main Advanced Hard Disk Security Primary Master Password Is: Set Primary Master Password: Password Entry on Boot: Help Select Item Exit Select Menu Table 13: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu...
L i f e B o o k N S e r i e s N o t e b o o k B I O S Owner Information Submenu of the Security Menu The Owner Information Submenu is for setting owner information. Note that the owner information cannot be set without having entered a Supervisor password.
Turns on and off booting with a truncated set of Power On Self Test. (Fewer tests mean faster turn on.) [Disabled] Turns on and off display of test results instead of Fujitsu logo screen during Power On Self Test. [Enabled] This field is not active unless the Supervisor’s Password has...
L i f e B o o k N S e r i e s N o t e b o o k B I O S Boot Device Priority Submenu of the Boot Menu The Boot Device Priority Submenu is for setting the order of checking of sources for the operating system. Main Advanced Boot Device Priority...
INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION The Info menu is a display only screens that provides the configuration information for your notebook. The following table shows the names of the menu fields for the Info menu and the information displayed in those fields.
L i f e B o o k N S e r i e s N o t e b o o k B I O S EXIT MENU – LEAVING THE SETUP UTILITY The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating Through the Setup Utility to make any changes.
