  • Page 1 Digital Signage Media Player NC1000 WARNING -This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Temporary noise is normal when powering ON or OFF this device.

  • Page 2: Table Of Contents

    Contents Digital Signage Media Player Introduction of SuperSign ...1 Characteristics of the product (What is SuperSign?) ...1 Minimum System Requirement ...1 Files supported by SuperSign ...2 Product Specifications ...2 Composition of SuperSign ...4 Parts ...4 Name of each part ...5 Installation procedure of the product ...6 Cable connection procedure of the product ...7 Usage of the SuperSign Manager Software ...8...
  • Page 3 UPDATE ...31 Massage ...33 Log Report ...33 E-mail Configuration ...34 File Menu ...35 Edit Menu ...35 View Menu...35 Option Menu ...36 Setup Menu ...36 Help Menu ...36 Player Menu usage of SuperSign ...37 Login Screen ...37 Network ...38 Display ...40 Password ...41 EWF ...42 Initialize ...42...

  • Page 4: Introduction Of Supersign

    Introduction of SuperSign Characteristics of the product (What is SuperSign?) LG SuperSign is a solution to allow users to transmit media and information files stored on a computer installed with SuperSign Software using LAN. Differentiated special feature VAR(SI: System Integration), a software that can be easily used by system operators as well as private users.

  • Page 5: Files Supported By Supersign

    Introduction of SuperSign Installation of universal codec and S/W 1. Microsoft Office - To support Microsoft Office Word, PowerPoint or Excel documents, MS Office (2000, XP, 2003, 2007) must be installed on the Manager and Player. - Slide show viewing is possible if ‘Show’ configuration is configured on the Microsoft PowerPoint document.
  • Page 6 Introduction of SuperSign Multi I/O Port Chip Set Nvidia MCP7A-ION One external RS-232 Serial port Serial Port Hi-Speed USB 2.0 port 480 Mbps rate (x 5) USB Port LAN Port Realtek RTL8103E 10/100 Mbyte Ethernet controller Nvidia MCP7A-ION integrated Graphic chipset VGA / HDMI 4-in-1 Card Secure Digital(SD) / MultiMedia Card(MMC/MMC4.0) / Memory...

  • Page 7: Composition Of Supersign

    Composition of SuperSign Parts !!! Thank you very much for purchasing our product !!! Case Power Cable Handle x 2 NOTE Parts may look different than the pictures shown here. Make inquiries to the purchased store or purchase from electronics store or online shopping malls for purchase of accessories Setup program/ User Manual...

  • Page 8: Name Of Each Part

    Composition of SuperSign Name of each part Power cable input terminal Power Switch RS-232C output terminal USB input terminal Operation and program installation can be carried out using USB Memory, USB Hard-disk, USB CD-ROM, Keyboard (wired/wireless), Mouse (wired/ wireless), etc. HDMI output terminal LAN/USB connection terminal 4 IN 1 Multi-card Slot...

  • Page 9: Installation Procedure Of The Product

    Composition of SuperSign Installation procedure of the product 1. Please insert the handle into the groove on the side of product as shown in the picture. 3. Please insert rails into the groove on the side of the product. 4. Please attach Box Guide on four hole on the back of monitor as shown in the diagram using screws.

  • Page 10: Cable Connection Procedure Of The Product

    Please set the SET ID of the display connected Player to 1. NOTE Display Device whitch does not use LG RS23C Protocol can not be controlled and monitored on SuperSign Manager HDMI Cable...

  • Page 11: Usage Of The Supersign Manager Software

    Usage of the SuperSign Manager Software In order to use SuperSign program, install the SuperSign Manager Software from the included CD and connect to user’s monitor and SuperSign. Installation of SuperSign program <Auto Installation Steps> 1. Installation window appears automatically when you click on ‘SuperSign Manager’ from main screen of the CD Please Install SuperSign Manager Software in the order shown below.
  • Page 12 Usage of the SuperSign Manager Software <Manual Installation Steps> Install SuperSign Manager Software in the order shown below. *My Computer > SuperSign > SuperSign > SuperSign Software > Application > SuperSign Manager > SuperSignManager_setup.exe Finish Next - Add to quick launch : Creation of Quick Launch Icon - Add to desktop : Creation of Shortcut Icon on the Desktop Install...

  • Page 13: Removing Supersign Software

    Usage of the SuperSign Manager Software 1. It is registered to Start menu after program installation automatically. 2. Remove Supersign Manager : Removal of installed SuperSign Manager Software. 3. Supersign Manager : SuperSign Manager Software is operated. Removing SuperSign Software Select remove Supersign Manager removal of installed SuperSign Manager Software.

  • Page 14: Usage Of Each Item On Supersign Manager Software

    Usage of each item on SuperSign Manager Software SuperSign Login 1. Following login window appears when SuperSign Manager Software is executed. 2. Default ID is “Administrator”. ID and password is stored as the values input during initial login. Password can be changed from File Menu. ID is fixed as value input during initial login and it cannot be changed.

  • Page 15: Canvas Setting

    Usage of each item on SuperSign Manager Software Canvas Setting 2. Select “OK” after selecting desired template and layout 1. Select “OK” after selecting desired resolution. setting. 3. Move to Edit screen...

  • Page 16: Contents Edit Menu

    Usage of each item on SuperSign Manager Software CONTENTS EDIT MENU Main Window Time Line is closed when Property screen of each Zone appears when Media Library * Media Library : Desired video, image, sound, flash and documents can be imported. : Import files by clicking on the icons.) * Canvas : Zone of respective files are created when files registered on Media Library dragged and dropped on Canvas or Time Line.
  • Page 17 Usage of each item on SuperSign Manager Software 1. Preview : Previews the contents of current Canvas. 2. Save : Creates Contents by storing details of current Canvas. 3. Send To Player : A function to play current contents of the Player by immediately distributing them.

  • Page 18: Registering Media Library

    Registering Media Library 1. Click on Media icon on “Library tab " to open the popup window. 2. Select the file to upload from the popup window. 3. “File Uploading” popup window will be displayed while the file is being uploaded, and it will automatically disappear when the upload is completed.

  • Page 19: Creation Of Contents

    Creation of Contents 1. Zone of respective file is created when a file registered on Media Library is dragged and dropped on Canvas or Time Line. * It is added to one single Zone if several files are selected, dragged and dropped simultaneously. 2.

  • Page 20: Configuration Of Timeline

    Configuration of TimeLine 1. Gap of time axis on Time Line can be adjusted. Intervals are 1,10,30 minutes and ‘upper time limit’ is 12 hours. : Function to display/hide each color properties and icon information from the screen for classification of Zones. 3.

  • Page 21: Contents Properties

    Contents Properties Media File <When background is selected> <Photo> Displays connected Player or group information. Nothing is displayed when there is no connected Player. Resolution information Background Color assignment. Background Picture assignment. (Limited to pictures registered on the Media Library) <When Zone is created>...
  • Page 22 Displays connected Player or group information. Nothing is displayed when there is no connected Player. It shows media information selected. Name, size, play time Set media play time selected Within the set media play time, the repeating play of the file setting. Volume Control <Sound>...
  • Page 23 Usage of each item on SuperSign Manager Software Service <Web> <RSS> Displays connected Player or group information. Nothing is displayed when there is no connected Player. Information of URL to be linked. Set media play time selected. URL to be linked can be changed.
  • Page 24 Usage of each item on SuperSign Manager Software <Date> <Widget> Displays connected Player or group information. Nothing is displayed when there is no connected Player. Set media play time selected. Setting for text condition. Font : text form Size : text size Color : text color Style : Bold, Italic, Underline Configuration of...

  • Page 25: Configuration Of Service Function

    Configuration of service function 1. URL : Add = Web Zone is created when clicked after entering a URL. Reset = Stored URL disappears. 2. RSS Feed Add = RSS Zone is created when clicked after entering a URL. Reset = Stored URL disappears. 3.

  • Page 26: Plan Menu

    Usage of each item on SuperSign Manager Software PLAN MENU Main Plan Window 1. Information of connected Player can be viewed. 2. List of created contents and media files can be viewed from ‘Contents edit’. 3. Units of displayed time can be selected. (10minutes/ 30minutes/ 1hour are supported.) 4.

  • Page 27: Plan Configuration

    Usage of each item on SuperSign Manager Software Plan configuration 1. Create Time Cell by drag & drop after selecting contents or media files. Play back time of Time Cell can be adjust by selecting a Time Cell and dragging each corner of the Time Cell.

  • Page 28: Contents Copy

    Usage of each item on SuperSign Manager Software Contents Copy 1. Select a Time Cell 2. Shape of mouse point is changed and enters into copy mode when Ctr l + C is pressed. 3. Paste copied Time Cell by clicking on desired location. 4.

  • Page 29: Management Menu

    Usage of each item on SuperSign Manager Software MANAGEMENT MENU Main Management Screen 1. Shows currently connected Players. 2. Contents and media file lists created from ‘Contents Edit’ can be viewed. 3. Information and Control function. However, information is not shown in case of a group. : Group : Player 4.

  • Page 30: Management Configuration

    NOTE Some Management functions on Display Device may not work because SuperSign Player is not fully compatible with all of LG Display Device in terms of LG Protocol. 1. Select a Player. 2. Drag & drop by selecting contents or media files.

  • Page 31: Tile Mode Control Cable

    Usage of each item on SuperSign Manager Software Tile Mode Control Cable 1. Tile mode can be configured when several monitors are connected to one SuperSign 2. Connect ‘RS232C Out’ of SuperSign to ‘RS232C In’ of the monitor. 3. For connection between monitors, connect ‘RS232C In’ and ‘RS232C Out’ as shown in 4.

  • Page 32: Control Tile Configuration

    Usage of each item on SuperSign Manager Software Control Tile Configuration Please execute the “Display Search for Daisy Chain” of option in advance when you configure the Tile Mode. A tab to configure Tile Mode of the display connected to a Player. Display is arranged by configured Tile Size Selected button is activated in white color when each display is selected.
  • Page 33 Usage of each item on SuperSign Manager Software After selecting display areas to be set as a tile, you can select the input source Monitor location can be configured by Drag & Drop. Shows the configured Tile image. * Attention If select input source after selecting one display, the display sets its tile size as 1x1.

  • Page 34: Option

    Usage of each item on SuperSign Manager Software OPTION 1. When Display is searched manually after connecting a monitor with RS232C cable, select Player and use ‘Display Search Control’ from "Control -> Option -> Daisy Chain Display". 2. When ‘Search’ button is clicked after selecting Daisy Chain, the Display is found and added. UPDATE It is a function to remotely update SuperSign Player Software of the selected Player.
  • Page 35 Usage of each item on SuperSign Manager Software Select SuperSign Player installation file downloaded from SuperSign website (www.lge.com) by pressing on ‘Open’ button. Execute update function of the selected Player by pressing on ‘Update Now’ button. Player on the remote site executes update with installation file selected by the user and automatically reboots once the update is completed.

  • Page 36: Massage

    Usage of each item on SuperSign Manager Software Massage A function to display messages in cases of situations such as notice, information and emergency. 1. It changes text attributes (size,color,etc). 2. It changes text messages to be displayed. 3. It adjust a message location to send. 4.

  • Page 37: E-Mail Configuration

    Usage of each item on SuperSign Manager Software E-mail Configuration Log report can be sent by e-mail if you follow the procedure as below. 1) To set e-mail configuration, select ‘File menu>Option>Management‘ as shown. E-mail configuration menu 2) Pop-up window appears. Input an e-mail address and outgoing mail server in ‘Admin email’ and ‘SMTP Server’ textbox respectively.

  • Page 38: File Menu

    Usage of each item on SuperSign Manager Software File Menu Edit Menu View Menu...

  • Page 39: Option Menu

    Usage of each item on SuperSign Manager Software Option Menu Setup Menu Help Menu...

  • Page 40: Player Menu Usage Of Supersign

    Player Menu usage of SuperSign ※ You can enter the SuperSign Player Menu by selecting the Setup menu from the SuperSign Player TrayIcon menu from the desktop. (Refer to the screen on page 43 for location of Tray Icon). ※ When you press the ESC button from the SuperSign Player standby screen, you can exit to the desktop.

  • Page 41: Network

    Network Player IP Mode : A menu to configure network connection related information. Initial condition is Dynamic IP. When setting as Dynamic IP, IP assigns automatically. Player Name can be put in Dynamic IP Other items be arrangement disable state. Player Name is able to put by number/English/special characters.
  • Page 42 Player Menu usage of SuperSign Manager Discovery : Menu for setting server IP. Initial condition is Auto Discovery. IP assigns to Auto Discovery automatically. Click “Save”, setting condition is saved. “Manual Discovery” is a menu for setting server IP directly. Default value of IP Address is "0.0.0.0"...

  • Page 43: Display

    Player Menu usage of SuperSign Display Menu for setting display form. Submenu is Landscape and Portrait. Initial condition is Landscape. <Landscape> <Portrait>...

  • Page 44: Password

    Player Menu usage of SuperSign Password Setting Change * Screen that appears in case of password change error. <When nothing is entered> A function to configure password input requirement at initial entrance. Submenu is ‘Disable’ and ‘Enable’ It is saved when each category is selected. Initial condition is ' E nable' It is a menu to change password.

  • Page 45: Ewf

    It is a function to protect the product and file systems. When EWF is in Enable status, data saved on C drive is deleted when the system restart. Initialize Initial condition is ' E nable' . System must be restart after changes are made to settings from the menu.

  • Page 46: Others

    Player Menu usage of SuperSign Others Composition of SuperSign Player Tray Icon Menu Open exported file : Exported canvas can be selected by creating a file open window. (Identical function when tray icon is double clicked) Play schedule : Returns to Signage mode and if a schedule exists, it is played according to preexisting schedule.

  • Page 47: Setting Regional And Language Options

    Player Menu usage of SuperSign Setting Regional and Language Options Set the Windows Language to the SuperSign Manager and SuperSign Player by using the Regional and Language Options menu from Windows Control Panel. Windows language on SuperSign Manager should be identical to SuperSign Player. * How to change the Windows Language setting 1.

  • Page 48: Program Restriction Items

    Program Restriction items Installation / Removal - All previously input data by the user are deleted during program removal. - Data preservation or initialization can be selected when the program is reinstalled without removal. - In the case of Windows Vista OS, approaching user system with administrator’s authority must be allowed during installation/ execution.

  • Page 49: Plan Manager

    Program Restriction items Plan Manager - During transmission of prepared schedule through ‘Send to Player’, it may take some time depending of network status, and it can be stopped during transmission using ‘Cancel’ button. In this case, download of stopped contents cannot be resumed, and overwrite is carried out during retransmission.

  • Page 50: Preview Player Manager

    Program Restriction items Preview Player Manager - When different codec is installed on the Manager and the Player, the Player may not play. (Install same type and version of codec on both the Manager and the Player.) - Install same version of Microsoft Office on both the Manager and the Player. Play form maybe displayed differently. (It is supported from MS OFFICE 2000, XP, 2003, 2007) - In the case of Office files, please close the office program before preview.

  • Page 51: Q & A

    - Password cannot be recovered if forgotten. Manager account has to be initialized. Please input "1234567890init" on password input field for initialize the manager account. * How can I get SuperSign Player program or driver files? - Those are provided "SuperSign\SuperSign Software\Application\SuperSign Player" or "SuperSign\SuperSign Software\System\SuperSign Driver" in bundle CD of NC1000.
  • Page 52 Q & A ※ They are information pop-up used in the Manager. Please use as “Solution Methods” Details The file is not supported. The file is not supported. The file is not supported. The video file is invalid or its codec is not available. Please install Adobe Reader version 8.1 or later.

  • Page 53: Supersign Network Connection Guide

    SuperSign network connection guide 1. Simple network connection (LAN) <When the SuperSign manager and Supersign player are connected to the same network> - Same network refers to the case of using the same Gateway and Subnet Address in IP communications. - SuperSign manager can find the SuperSign player in the same network through the scan function.

  • Page 54: Hierarchical Network Connection (Internet)

    SuperSign network connection guide 2. Hierarchical network connection (Internet) <When SuperSign manager and Supersign player are connected through a different network> - SuperSign manager cannot find the SuperSign player in a different network through the scan function. - SuperSign player can connect to the SuperSign manager on another network using the manual discovery mode.

  • Page 55: Wireless Network Connection

    SuperSign network connection guide 3. Wireless network connection - SuperSign manager and Supersign player supports both wired and wireless network connections. - SuperSign player may not work properly when both the wireless and wired network devices are used simultaneously. - When connecting to SuperSign manager using the wireless network, unplug the LAN cable. When connecting to the SuperSign manager using the wired network, do not connect the wireless network device.

  • Page 56: Limitation Of Windows Embedded

    Limitation of Windows embedded Microsoft Windows Embedded Standard limited element - When you run Full Screen (Alt+Enter) from the DOS window, the font can be broken. - When saving the file with a different name from the Print window, the name of the menu window is displayed in English - When moving to the detail menu item of Control panel etc., some menus are displayed in English (HyperTerminal, Language setting by country etc.)

  • Page 57: Restrictions Of Nvidia Graphic Chipset

    Restrictions of Nvidia Graphic chipset ※ Nvidia Graphic chipset included to NC1000 does not support change in main/sub screen of monitors from Display properties. ※ Main/sub screen of monitors can be changed from Control Panel/NVDIA Control Panel Menu.
