Page 1
IN, ENG (2) 6. Number of pages “This part contains Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level, Details should be followed Eco-SCM management standard[LG(56)-A-2524]. Especially, Part should be followed and controlled the following specification.
Page 2
Part number MFL68140504 Pagination sheet Total pages 88 pages Front Back (IN) P/No. … … … blank Front Back (Eng) P/No. … … … blank...
Page 3
BUKU PANDUAN TV LED * Pernyataan TV LED LG menggunakan layar LCD dengan lampu latar LED. Klik! Panduan Pengguna Baca panduan ini dengan baik sebelum mengoperasikan TV Simpanlah sebagai pegangan selanjutnya. 65UB98** 49UC97** 105UC9* 49UB85** 65UB93** 79UB98** 55UC97** 55UB85** 84UB98**...
Page 4
DAFTAR ISI DAFTAR ISI LISENSI REMOTE KONTROL DOKUMENTASI BEBAS FUNGSI REMOTE KONTROL AJAIB PERANGKAT LUNAK Registrasi Remote Ajaib Cara Menggunakan Remote Ajaib PENGATURAN PERANGKAT Himbauan Ketika Menggunakan KONTROL EKSTERNAL Remote Kontrol Ajaib MENGGUNAKAN PANDUAN PETUNJUK KEAMANAN PENGGUNA Menonton Gambar 3D (Hanya model TV 3D) PERAWATAN CARA PEMASANGAN PRODUK Membersihkan TV Anda...
Page 5
Selain itu untuk kode lisensi, semua persyaratan lisensi yang dimaksud , peraturan garansi dan pernyataan hak cipta tersedia untuk di-unduh. LG Electronics juga akan memberikan kode lisensi bebas dalam CD-ROM Anda, dengan biaya yang dikenakan untuk proses pendistribusian (seperti biaya dari media, penanganan dan pengiriman), kirim- kan email ke opensource@lge.com.
Page 6
PETUNJUK KEAMANAN PETUNJUK KEAMANAN Bacalah petunjuk keamanan ini dengan teliti sebelum menggunakan produk PERINGATAN y Pastikan kabel daya sudahterhubung pada soket yang sudah dihubungkan pada ground. yy Jangan menempatkan TV dan remote (Kecuali untuk perangkat yang tidak ada kontrol di lingkungan berikut: groundnya.) Anda dapat tersengat listrik -y Lokasi yang terkena sinar matahari langsung atau cedera.
Page 7
PETUNJUK KEAMANAN y Saat memasang TV di dinding pastikan kabel yy Buanglah baterai yang sudah tidak digunakan dan kabel sinyal tidak tergantung di belakang dengan hati-hati untuk melindungi anak dan kabel sinyal tidak tergantungdi belakang menelannya. Jika mereka memakannya, TV. Ini dapat menyebabkan kebakaran dan bawalah ke dokter segera.
Page 8
PETUNJUK KEAMANAN y Jika Anda berniat untuk tidak menggunakan y Jangan biarkan produk terguncang atau benda jatuh mengenai produk, dan jangan memben- produk dalam waktu yang lama, cabutlah kabel turkan sesuatu ke layar. Anda mungkin bisa daya dari produk. Debu yang menutupi produk terluka atau dapat merusak produk.
Page 9
PETUNJUK KEAMANAN y Jika Anda memasang produk pada dudukan, y Jangan meletakan baterai non-rechargeable Anda perlu mengambil tindakan untuk men- di perangkat pengisian. cegah produk terbalik. Karena produk mungkin bisa terjatuh, yang dapat me- y Pastikan tidak ada benda antara remote nyebabkan cedera kontrol dan sensor.
Page 10
PETUNJUK KEAMANAN y Jangan menyentuh lubang ventilasi saat TV y Saat membersihkan produk an komponennya, dihidupkan. Lubang ventilasi mungkin cabut kabel daya, dan gunakan kain lembut sangat panas. Hal ini tidak berpengaruh pada untuk membersihkan. Jangan terlalu keras, pengoperasian atau tampilan TV. dapat menyebabkan goresan, atau luntur.
Page 11
PETUNJUK KEAMANAN y Hubungi pusat layanan setahun sekali y Anda mungkin menemukan perbedaan kecerahan dan warna pada panel, tergan- untuk membersihkan bagian dalam TV. tung posisi layar pandang(kiri/kanan/atas/ Debu yang mengumpul, dapat menye- bawah). babkan kerusakan mekanis. Fenomena ini terjadi karena karakteristik panel.
Page 12
Perhatian saat menggunakan kacamata 3d Jika kemampuan penglihatan mata kiri dan Pastikan menggunakan kacamata 3D LG. Jika kanan Anda berbeda, periksa dan perbaiki tidak, anda mungkin tidak dapat melihat konten 3D. terlebih dahulu sebelum menonton konten 3D.
Page 13
CARA PEMASANGAN PRODUK / PERISAPAN DAN PERAKITAN CATATAN Gambar yang ditampilkan mungkin berbeda dari TV Anda. OSD TV Anda (On Screen Display) mungkin sedikit berbeda dari yang ditampilkan di manual ini. Menu-menu yang tersedia dan pilihan mungkin berbeda dari sumber masukan atau model produk yang Anda gunakan.
Page 14
PERSIAPAN DAN PERAKITAN ENERGY AV MODE INPUT ENERGY AV MODE INPUT SAVING SAVING FLASHBK FLASHBK LIST LIST MARK MARK MUTE MUTE MENU INFO Q.MENU INFO MENU Q.MENU ENTER ENTER BACK EXIT L/R SELECT BACK EXIT L/R SELECT FREEZE FREEZE RATIO RATIO Remote Kontrol Ajaib, Baterai Remote Kontrol, Baterai...
Page 15
PERSIAPAN DAN PERAKITAN Badan Penyangga / Kabel Gender Komponen Kabel Gender Komposit Dudukan Penyangga (Lihat h.29) (Lihat h.29, 30) (Hanya UB85**, UB93**, UB95**) (Lihat h.20) Kacamata sinema 3D Inti Ferrite Pengatur Kabel Jumlah kacamata 3D (Tergantung model) (Hanya UB85**, UB93**, dapat berbeda, tergantung (Lihat h.14) UB95**)
Page 16
PERSIAPAN DAN PERAKITAN CATATAN y Item-item yang disediakan bersama produk Anda bervariasi tergantung pada model. y Spesifikasi produk atau isi pada manual ini bisa berubah tanpa pemberitahuan untuk meningkatkan fungsi produk. y Untuk koneksi yang optimal, kabel HDMI dan perangkat USB harus memiliki tebal kurang dari 10 mm dan lebar kurang dari 18 mm.
Page 17
Hubungi penyalur(dealer) Anda untuk membeli item ini. Perangkat ini hanya bekerja dengan model yang sesuai. AG-F***DP AG-F*** AN-MR500 Kacamata Dual play Kacamata sinema 3D Remote ajaib AN-VC5** Kamera video call Perangkat audio LG Tag on UB85** UB98** Kompabilitas UB93** UB95** UC9* UC97** AG-F***DP •...
Page 18
Speaker Sensor remote kontrol Sensor remote kontrol dan Sensor Cerdas Tombol Joystick dan Sensor Cerdas Tombol Joystick Indikator Daya Lampu logo LG Tipe B : UB93**, UB95** Tipe D : 79UB98** Layar Kamera integral Layar Speaker Speaker Sensor remote kontrol...
Page 19
Tipe E : 84UB98** Kamera integral Layar Speaker Sensor remote kontrol dan Sensor Cerdas Tombol Joystick Lampu logo LG Tipe F : UC9* Kamera integral Layar Speaker Tombol Joystick 1 Sensor Cerdas - Mengatur kualitas gambar dan kecerahan sesuai kondisi ruangan/lingkungan.
Page 20
PERSIAPAN DAN PERAKITAN CATATAN y Anda dapat mengatur mati atau menyala nya lampu Logo LG dan indikator daya melalui UMUM pada menu utama. Menggunakan tombol joystick Anda dapat mengoperasikan TV dengan menekan tombol atau memindahkan joystick ke kiri, kanan, atas, atau bawah...
Page 21
PERSIAPAN DAN PERAKITAN Mengangkat dan Memindahkan TV y Saat memindahkan TV ukuran besar, harus dilakukan setidaknya oleh 2 orang. y Saat memindahkan TV dengan tangan, Saat mengangkat atau memindahkan TV, baca hal pegang TV seperti ilustrasi berikut. berikut untuk mencegah TV tergores atau rusak dan untuk keamanan yang sesuai dengan jenis dan ukurannya.
Page 22
PERSIAPAN DAN PERAKITAN Merakit TV Gambar mungkin berbeda dengan TV anda. Memasang Dudukan UB85**, UB93**, UB95** Badan Penyangga (L) Badan Penyangga (R) Dudukan Penyangga Pasang dudukan ke TV cocokkan dengan lubang pengunci atas pada bagian belakang TV. Pasang dudukan ke TV cocokkan dengan konektor bawah pada bagian belakang TV.
Page 23
PERSIAPAN DAN PERAKITAN UB98** (Hanya 84UB98**) Dudukan Penyangga Kunci Pas M6 x L50 (Penyangga Insulasi) PERHATIAN (Hanya 65/79UB98**) y Pastikan untuk mengencangkan sekrup dengan baik. (Jika pemasangan sekrup tidak cukup kencang, TV dapat miring ke depan saat dipasang.) Kunci Pas (Hanya 65UB98**) M6 x L45 (Hanya 79UB98**)
Page 24
PERSIAPAN DAN PERAKITAN Memasang TV pada Meja PERHATIAN Angkat dan atur TV ke posisi yang sesuai y Saat memasang penyangga pada TV, pada meja. letakkan layar menghadap bawah, pada - Beri jarak 10 cm (minimal) dari dinding permukaan yang halus dan rata untuk untuk ventilasi yang baik.
Page 25
Saat memasang TV di material dinding yang lain, harap hubungi orang yang berpengalaman. LG menyarankan pemasangan TV di dinding dilakukan oleh orang yang profesional. Saat anda tidak menggunakan braket penyangga dinding LG, harap gunakan braket penyangga...
Page 26
Jika Anda memasang TV pada langit-langit Jumlah atau dinding miring, TV dapat terjatuh dan sekrup melukai. Gunakan braket penyangga resmi LSW440B LSW440B LG dan hubungi penyalur lokal atau orang Braket yang berpengalaman(profesional). Penyangga MSW240 Jangan memasang sekrup terlalu kencang Model...
Page 27
PERSIAPAN DAN PERAKITAN Merapikan Kabel Menggunakan Kamera Integral (Hanya UB98**, UC9*) Gambar yang ditampilkan mungkin berbeda. Anda dapat melakukan panggilan video Skype (Hanya UB98**) atau menggunakan fungsi pengenal gerakan 1 Gabung dan ikat kabel menggunakan dengan kamera yang integral pada TV. Pengikat Kabel.
Page 28
PERSIAPAN DAN PERAKITAN Pengaturan Kamera Integral 3 Tekan kamera ke arah bawah jika tidak digunakan. 1 Dorong tuas geser pada bagian belakang TV ke atas. Pengatur sudut Tuas Geser Bagian-bagian Kamera Integral Lapisan Pelindung Mikrofon Lensa kamera CATATAN y Lepaskan lapisan pelindung sebelum menggunakan kamera.
Page 29
PERANGKAT Hubungkan TV ke soket antena dinding dengan menggunakan kabel RF (75 Ω). Dibagian MENGHUBUNGKAN PERANGKAT ini menggunakan diagram model 65UB980T . Menghubungkan berbagai perangkat ke TV dan mengganti mode masukan untuk memilih perangkat. Untuk informasi rinci koneksi perangkat eksternal lihat panduan yang disertakan pada perangkat tersebut.
Page 30
MENGHUBUNGKAN PERANGKAT Menghubungkan HDMI 1) Spesifikasi HDMI dapat berbeda di masing- masing terminal masukan, jadi pastikan anda Menghubungkan sinyal audio dan video dari mengecek spesifikasi perangkat terlebih dahulu PC anda ke TV. Hubungkan PC dengan TV sebelum menghubungkan.) menggunakan kabel HDMI seperti terlihat 2) Hubungi layanan pelanggan untuk informasi lebih pada ilustrasi beriku.
Page 31
MENGHUBUNGKAN PERANGKAT Menghubungkan DVI ke HDMI Menghubungkan Komponen Menghubungkan sinyal video digital dari pe- Mengirimkan video analog dan sinyal audio dari rangkat eksternal ke TV menggunakan kabel perangkat eksternal ke TV. Hubungkan perangkat DVI-HDMI seperti terlihat pada ilustrasi berikut. eksternal dan TV dengan kabel Komponen seperti Untuk menghubungkan sinyal audio, gunakan yang ditunjukkan pada ilustrasi berikut.
Page 32
MENGHUBUNGKAN PERANGKAT Menghubungkan Audio Menghubungkan Komposit Anda dapat menggunakan sistem audio eksternal Mengirimkan sinyal audio dan video analog dari untuk menggantikan speaker TV yang telah ada. perangkat eksternal ke TV. Hubungkan perangkat eksternal dan TV menggunakan kabel Komposit seperti yang ditunjukkan pada ilustrasi berikut. Menghubungkan Digital Audio Optik Menghubungkan sinyal audio digital dari TV ke perangkat eksternal.
Page 33
MENGHUBUNGKAN PERANGKAT Menghubungkan Headphone Menghubungkan USB Mengirimkan sinyal headphone dari TV ke perangkat Menghubungkan perangkat USB seperti USB eksternal. Hubungkan perangkat eksternal head- flash memory, hard drive eksternal atau USB phone dengan TV seperti yang ditampilkan pada card reader ke TV dan mengakses menu gambar.
Page 34
MENGHUBUNGKAN PERANGKAT Menghubungkan MHL Mobile High-definition Link (MHL) adalah koneksi untuk mentransmisikan sinyal audio-visual digital dari ponsel ke TV. Kabel MHL Pasif (*Tidak Disediakan) Telepon Selular CATATAN y Hubungkan ponsel ke terminal HDMI (4K@60Hz)/DVI IN 4 (MHL) untuk melihat tampilan layar ponsel di TV. Kabel MHL Pasif diperlukan untuk menghubungkan TV dan telepon seluler.
Page 35
REMOTE KONTROL REMOTE KONTROL Deskripsi pada manual ini berdasarkan pada tombol-tombol yang terdapat pada remote kontrol. Baca panduan ini dengan baik dan gunakan TV dengan benar. Untuk mengganti baterai buka penutupnya, dan pasangkan baterai (1.5 V AAA) sesuai tanda yang terdapat pada tempat baterai, kemudian tutup kembali.
Page 36
FUNGSI REMOTE KONTROL AJAIB FUNGSI REMOTE KONTROL AJAIB Saat pesan “Baterai Remote Kontrol Ajaib Habis. Ganti Baterai.” ditampilkan, gantilah baterainya. Untuk mengganti baterai, buka penutup baterai, ganti baterai (1.5 V AA) sesuaikan dengan petunjuk yang terdapat pada tempat baterai, dan tutup kembali. Pastikan untuk mengarahkan remote kontrol pada sensor remote kontrol pada TV.
Page 37
FUNGSI REMOTE KONTROL AJAIB Cara Menggunakan Remote Ajaib Pengenal suara (Tergantung model) Koneksi jaringan dibutuhkan untuk menggu- Gerakkan Remote Ajaib secara nakan fungsi pengenal suara. perlahan ke kiri dan ke kanan 1 Tekan tombol pengenal suara. atau tekan tombol (home), , tombol untuk 2 Bicaralah saat tampilan window suara...
Page 38
FUNGSI REMOTE KONTROL AJAIB / MENGGUNAKAN PANDUAN PENGGUNA MENGGUNAKAN PANDUAN Himbauan Ketika Menggunakan Remote Kontrol Ajaib PENGGUNA Gunakan Remote Kontrol Ajaib dalam jarak Panduan pengguna memungkinkan Anda untuk komunikasi maksimal (10 m). lebih mudah mengakses detil informasi TV. Penggunaan Remote Kontrol Ajaib melewati jarak ini, atau terdapat benda yang mengha 1 Tekan tombol (Home) untuk mengakses...
Page 39
PERAWATAN / PENYELESAIAN MASALAH PERAWATAN Membersihkan TV Anda Bersihkan TV Anda secara teratur untuk menjaga performa terbaik dan memperpanjang usia. PERHATIAN y Matikan daya, cabut kabel daya dan semua kabel terlebih dahulu sebelum membersihkan. y Jika TV tidak digunakan untuk waktu yang lama, cabut kabel daya dari terminal dinding untuk mencegah kemungkinan kerusakan akibat petir atau atau kenaikan tegangan.
Page 40
INFORMASI LINGKUNGAN INFORMASI LINGKUNGAN (Hanya India) WEEE Pembuangan peralatan Anda yang sudah lama 1. Ketika ada simbol tempat sampah disilang tertera pada produk, itu berarti bahwa produk itu tercakup oleh aturan e-waste (Manajemen dan Penanganan), 2011. 2. Semua produk kelistrikan dan elektronik harus dibuang secara terpisah dari aliran limbah kotamelalui fasilitas yang ditunjuk oleh pemerintah atau pihak berwenang setempat.
Page 41
SPESIFIKASI SPESIFIKASI (Hanya UB98**, UC9*) Spesifikasi Modul Nirkabel (LGSWF41) Standar IEEE 802.11a/b/g/n/ac 2400 hingga 2483.5MHz Jangkauan Frekuensi 5150 hingga 5250 MHz 5725 hingga 5850 MHz(Selain EU) 802.11a: 14.5 dBm 802.11b: 16 dBm 802.11g: 13.5 dBm Daya Keluaran(Maks.) 802.11n - 2.4GHz: 14 dBm 802.11n - 5GHz: 15.5 dBm 802.11ac - 5GHz : 16 dBm y Karena pita saluran pada tiap negara mungkin berbeda, Pengguna tidak dapat mengganti atau...
Page 42
SPESIFIKASI (Hanya UB85**, UB93**, UB95**, UC97**) Spesifikasi Modul Nirkabel (LGSBW41) LAN Nirkabel Bluetooth Standar IEEE 802.11a/b/g/n Standar Versi Bluetooth 3.0 2400 hingga 2483.5 MHz Jangkauan Jangkauan 5150 hingga 5250 MHz 2400 hingga 2483.5 MHz Frekuensi Frekuensi 5725 to 5850 MHz (selain EU) 802.11a: 13 dBm 802.11b: 15 dBm Daya Keluaran...
Page 43
23.1 33.7 Tanpa Dudukan (kg) Kebutuhan Daya AC 100-240 V~ 50 / 60 Hz AC 100-240 V~ 50 / 60 Hz AC 100-240 V~ 50 / 60 Hz 65UB98** 79UB98** 84UB98** 65UB980T-TA 79UB980T-TA 84UB980T-TA MODEL 65UB980Y-TA 79UB980Y-TA 84UB989Y-TA 65UB980T-TB 79UB980T-TB...
Page 44
CATATAN Data video yang dibuat dari beberapa encoder mungkin tidak dapat diputar. TV ULTRA HD LG mungkin tidak kompatibel dengan beberapa konten codec tipe HEVC. File video dengan format selain dari yang tertera pada tabel diatas mungkin tidak dapat diputar.
Page 47
OWNER’S MANUAL LED TV * Disclaimer LG LED TV applies LCD screen with LED backlights. Click! User Guide Please read this manual carefully before operating your set and retain it for future reference. 65UB98** 49UC97** 105UC9* 49UB85** 65UB93** 79UB98** 55UC97**...
TABLE OF CONTENTS TABLE OF CONTENTS LICENSES REMOTE CONTROL OPEN SOURCE SOFTWARE MAGIC REMOTE FUNCTIONS NOTICE Registering Magic Remote How to use Magic Remote Precautions to Take when Using the EXTERNAL CONTROL DEVICE Magic Remote SETUP USING THE USER GUIDE SAFETY INSTRUCTIONS Viewing 3D Imaging MAINTENANCE...
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com.
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS Please read these safety precautions carefully before using the product. WARNING y Make sure to connect Mains cable to y Do not place the TV and/or remote control compliant AC mains socket with Grounded in the following environments: earth pin.
Page 51
SAFETY INSTRUCTIONS y When mounting TV onto wall make sure to neatly install and isolate cabling from rear of TV as to not create possibility of electric shock /fire hazard. y Do not insert any metal objects/conductors (like a metal chopstick/cutlery/screwdriver) between power cable plug and input Wall Socket while it is connected to the input terminal on the wall.
Page 52
SAFETY INSTRUCTIONS y Unplug the TV from AC mains wall socket if you y Do not allow any impact, shock or any do not intend to use the TV for a long period of objects to fall into the unit, and do not time.
Page 53
SAFETY INSTRUCTIONS y If you install the TV on a stand, you need y Do not place non-rechargeable batteries to take actions to prevent the product from in charging device. overturning. Otherwise, the product may y Make sure there are no objects between fall over, which may cause injury.
Page 54
SAFETY INSTRUCTIONS y Take care not to touch the ventilation y When cleaning the product and its openings when watching the TV for long components, unplug the power first periods as the ventilation openings may and wipe it with a soft cloth. Applying become hot.
Page 55
SAFETY INSTRUCTIONS y Contact the service centre once a year to y You may find different brightness and clean the internal parts of the product. colour of the panel depending on your Accumulated dust can cause mechanical viewing position(left/right/top/down). failure. This phenomenon occurs due to the characteristic of the panel.
3D contents. distance. Cautions when using the 3D glasses Symptoms which require discontinuation y Make sure to use LG 3D glasses. Otherwise, you may not be able to view 3D videos or refraining from watching 3D contents properly. y Do not watch 3D contents when you feel...
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING NOTE y Image shown may differ from your TV. y Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. y The available menus and options may differ from the input source or product model that you are using.
Page 58
ASSEMBLING AND PREPARING ENERGY AV MODE INPUT ENERGY AV MODE INPUT SAVING SAVING FLASHBK FLASHBK LIST LIST MARK MARK MUTE MUTE MENU INFO Q.MENU INFO MENU Q.MENU ENTER ENTER BACK EXIT L/R SELECT BACK EXIT L/R SELECT FREEZE FREEZE RATIO RATIO Magic remote, Batteries Remote control, Batteries...
Page 59
ASSEMBLING AND PREPARING Stand Body / Stand Base Component gender cable Composite gender cable (Only UB85**, UB93**, (See p.29) (See p.29, 30) UB95**) (See p.20) Cable Managements Cinema 3D Glasses Ferrite core The number of 3D glasses (Depending on model) (Only UB85**, UB93**, may differ depending on the (See p.14)
Page 60
ASSEMBLING AND PREPARING NOTE y The items supplied with your product may vary depending on the model. y Product specifications or contents of this manual may be changed without prior notice due to upgrade of product functions. y For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick and 18 mm width.
Contact your dealer to buy these items. These devices only work with certain models. AG-F***DP AG-F*** AN-MR500 Dual Play Glasses Cinema 3D Glasses Magic Remote AN-VC5** LG Audio Device Tag on Video Call Camera UB85** UB98** Compatibility UB93** UB95** UC9*...
Speakers Remote control and Remote control and Joystick Button Intelligent sensors Intelligent sensors Joystick Button Power Indicator LG Logo light B Type : UB93**, UB95** D Type : 79UB98** Screen Built-in Camera Screen Speakers Speakers Remote control and Intelligent sensors...
Page 63
Built-in Camera Screen Speakers Remote control and Intelligent sensors Joystick Button LG Logo light F Type : UC9* Built-in Camera Screen Speakers Joystick Button 1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment. 2 Joystick Button - This button is located behind the TV screen.
ASSEMBLING AND PREPARING NOTE y You can set the LG Logo Light or power indicator light to on or off by selecting GENERAL in the main menus. Using the joystick button You can operate the TV by pressing the button or moving the joystick left, right, up, or down.
ASSEMBLING AND PREPARING Lifting and moving the TV y When transporting a large TV, there should be at least 2 people. y When transporting the TV by hand, hold the Please note the following advice to prevent the TV as shown in the following illustration. TV from being scratched or damaged and for safe transportation regardless of its type and size.
ASSEMBLING AND PREPARING Setting up the TV Image shown may differ from your TV. Attaching the stand UB85**, UB93**, UB95** Stand Body (L) Stand Body (R) Stand Base 1 Attach the stand to the TV using the upper mounting hole on the back of the TV. 2 Attach the stand to the TV using the lower connection on the back of the TV.
Page 67
ASSEMBLING AND PREPARING UB98** (Only 84UB98**) Stand Base Wrench M6 x L50 (Insulation Holders) CAUTION (Only 65/79UB98**) y Make sure that the screws are fastened completely. (If they are not fastened securely enough, the TV may tilt forward after being installed.) Wrench (Only 65UB98**) M6 x L45...
ASSEMBLING AND PREPARING Mounting on a table CAUTION 1 Lift and tilt the TV into its upright position on a y When attaching the stand to the TV table. set, place the screen facing down on a - Leave a 10 cm (minimum) space from cushioned table or flat surface to protect the the wall for proper ventilation.
We recommend the use of LG’s wall mount bracket. When you do not use LG’s wall mount bracket, please use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices.
Page 70
If you install the TV on a ceiling or slanted Number of wall, it may fall and result in severe injury. screws Use an authorised LG wall mount and contact the local dealer or qualified personnel. LSW440B LSW440B Wall mount...
ASSEMBLING AND PREPARING Tidying cables Using Built-in Camera Image shown may differ from your TV. (Only UB98**, UC9*) (Only UB98**) You can make a Skype video call or use the 1 Gather and bind the cables with the Cable motion recognition function using the built-in Holder.
ASSEMBLING AND PREPARING Preparing Built-in Camera 3 Push down the built-in camera when you are not using it. 1 Pull up the slide at the back of the TV. Angle Adjustment Lever Slide Name of Parts of Built-in Camera Protective film Microphone Camera Lens NOTE...
Connect the TV to a wall antenna socket with an RF cable (75 Ω). This section on MAKING CONNECTIONS mainly uses diagrams for the 65UB980T models. Connect various external devices to the TV and switch input modes to select an external device.
MAKING CONNECTIONS HDMI connection 1) HDMI specifications may be different for each input port, so make sure to check the device specifications before connecting. Transmits the digital video and audio signals from an external device to the TV. Connect the 2) Contact customer service for more information external device and the TV with the HDMI cable on the HDMI specifications of each input port.
MAKING CONNECTIONS DVI to HDMI connection Component connection Transmits the digital video signal from an Transmits analog video and audio signals external device to the TV. Connect the external from an external device to the TV. Connect the device and the TV with the DVI-HDMI cable as external device and the TV with a component shown.
MAKING CONNECTIONS Composite connection Audio connection Transmits analog video and audio signals You may use an optional external audio system from an external device to the TV. Connect the instead of the built-in speaker. external device and the TV with the composite cable as shown.
MAKING CONNECTIONS Headphone connection USB connection Transmits the headphone signal from the TV to Connect a USB storage device such as a USB an external device. Connect the external device flash memory, external hard drive, or a USB and the TV with the headphone as shown. memory card reader to the TV and access the SmartShare menu to use various multimedia files.
MAKING CONNECTIONS MHL connection Mobile High-definition Link (MHL) is an interface for transmitting digital audiovisual signals from mobile phones to television sets. MHL passive cable (*Not Provided) Mobile phone NOTE y Connect the mobile phone to the HDMI(4K@60Hz)/DVI IN 4 (MHL) port to view the phone screen on the TV.
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover.
MAGIC REMOTE FUNCTIONS MAGIC REMOTE FUNCTIONS When the message “Magic Remote battery is low. Change the battery.” is displayed, replace the battery. To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching ends to the label inside the compartment, and close the battery cover.
MAGIC REMOTE FUNCTIONS How to use Magic Remote Voice recognition (Depending on model) Network connection is required to use the y Shake the Magic Remote voice recognition function. slightly to the right and left 1 Press the Voice recognition button. or press (Home), 2 Speak when the voice display window...
MAGIC REMOTE FUNCTIONS / USING THE USER GUIDE USING THE USER GUIDE Precautions to Take when Using the Magic Remote y Use the Magic Remote within the User Guide allows you to more easily access the maximum communication distance (10 detailed TV information.
MAINTENANCE / TROUBLESHOOTING MAINTENANCE Cleaning your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION y Make sure to turn the power off and disconnect the power cord and all other cables first. y When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges.
ENVIRONMENTAL INFORMATION ENVIRONMENTAL INFORMATION (Only India) WEEE Disposal of your old appliance 1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the e-waste (Management and Handling) Rules, 2011. 2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.
SPECIFICATIONS SPECIFICATIONS (Only UB98**, UC9*) Wireless module(LGSWF41)Specifications Standard IEEE 802.11a/b/g/n/ac 2400 to 2483.5MHz Frequency Range 5150 to 5250 MHz 5725 to 5850 MHz(for Non EU) 802.11a: 14.5 dBm 802.11b: 16 dBm 802.11g: 13.5 dBm Output Power (Max.) 802.11n - 2.4GHz: 14 dBm 802.11n - 5GHz: 15.5 dBm 802.11ac - 5GHz : 16 dBm y Because band channel used by the country could be different, the user can not change or...
Page 86
SPECIFICATIONS (Only UB85**, UB93**, UB95**, UC97**) Wireless module(LGSBW41)Specifications Wireless LAN Bluetooth Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 3.0 2400 to 2483.5MHz Frequency ragne 5150 to 5250 MHz Frequency ragne 2400 to 2483.5MHz 5725 to 5850 MHz (for Non EU) 802.11a: 13 dBm 802.11b: 15 dBm Output Output...
Page 87
Without stand (kg) 33.7 23.1 33.7 Power requirement AC 100-240 V~ 50 / 60 Hz AC 100-240 V~ 50 / 60 Hz AC 100-240 V~ 50 / 60 Hz 65UB98** 79UB98** 84UB98** 65UB980T-TA 79UB980T-TA 84UB980T-TA MODELS 65UB980Y-TA 79UB980Y-TA 84UB989Y-TA 65UB980T-TB 79UB980T-TB...
Video files created by some encoders may not be played back. y LG ULTRA HD TV may not be compatible with certain types of HEVC codec contents. y Video files in formats other than the ones specified here may not be played back.
Page 90
PT. LG ELECTRONICS INDONESIA Kawasan Industri MM2100 Blok G Cikarang Barat, Bekasi, Jawa Barat 17520 INDONESIA TANDA PENDAF TARAN PETUNJUK PENGGUNAAN (MANUAL) DAN KARTU JAMINAN/GARANSI PURNA JUAL DALAM BAHASA INDONESIA BAGI PRODUK TELEMATIKA DAN ELEKTRONIKA NOMOR : (Hanya DTV) Catat nomor model dan nomor seri TV.
