Page 1
PRODUCT NO. BASE MODEL NO. FFU11FK1CW0 FFU11FK1CW MARKET North America WIRING DIAGRAM - # 216857600 OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216795201 SERVICE DATA SHEET - # 216857600 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
Page 2
Publication No FFU11FK1CW0 5995385902 DOOR 02/03...
Page 3
POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFU11FK1CW0 DOOR PART NO DESCRIPTION 216522303 Gasket-door,white 216527402 Panel-inner door,frzr 216565401 Panel-outer door,white 216892800 Nameplate 08016354 Door Stop 5303313518 Washer,sealing 08005520 Screw,door stop mtg ,4.0 x 0.7-19.7 ,flat hd,metric 216443600...
Page 4
Publication No FFU11FK1CW0 5995385902 CABINET 02/03...
Page 5
POS. NO 21 # # = Fast-moving Parts * = Non-Illustrated Parts FFU11FK1CW0 CABINET PART NO DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 216604400 Breaker Kit w/corners 216603400 Breaker Kit w/corners,22.13" long ,top or bottom 216822500 Motor,evaporator fan ,115 V 216707200...
Page 6
Publication No FFU11FK1CW0 5995385902 SYSTEM 02/03...
Page 7
POS. NO 23 # 30 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FFU11FK1CW0 SYSTEM PART NO DESCRIPTION 5300123788 Condenser 5308000110 Strap-evap/heater,aluminum ,(2) 216634500 Drier-filter 216898900 Harness-main 216740000 Heater-defrost 216737400 Evaporator 216565700 Heat Exchanger 216727600 Insulator-evap,styrofoam 216727700...
