KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions----------------------------------------------- 4 16.5. Replacement Parts List--------------------------------- 76 1.1. For Service Technicians --------------------------------- 4 2 Warning -------------------------------------------------------------- 4 2.1. Battery Caution--------------------------------------------- 4 2.2. About Lead Free Solder (PbF: Pb free)-------------- 4 2.3. Discarding of P. C. Board-------------------------------- 5...
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 1 Safety Precautions 1.1. For Service Technicians • Repair service shall be provided in accordance with repair technology information such as service manual so as to prevent fires, injury or electric shock, which can be caused by improper repair work.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 2.2.1. Suggested PbF Solder There are several types of PbF solder available commercially. While this product is manufactured using Tin, Silver, and Copper (Sn+Ag+Cu), you can also use Tin and Copper (Sn+Cu), or Tin, Zinc, and Bismuth (Sn+Zn+Bi). Please check the manufacturer's specific instructions for the melting points of their products and any precautions for using their product with other materials.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 3 Specifications Note: • Design and specifications are subject to change without notice. Note for Service: • Operation range: Up to 300 m outdoors, Up to 50 m indoors, depending on the condition. • Analog telephone connection: Telephone Line...
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4 Technical Descriptions 4.1. US-DECT Description The frequency range of 1.91 GHz-1.93 GHz is used. Transmitting and receiving carrier between base unit and handset is same frequency. Refer to Frequency Table (P.53). 4.1.1. TDD Frame Format 4.1.2. TDMA system This system is the cycles of 10 ms, and has 6 duplex paths, but maximum duplex communication path is 5 because of dummy bearer use.
Page 8
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.1.3. Signal Flowchart in the Radio Parts Reception A voice signal from TEL line is encoded to digital data "TXDATA" by BBIC (IC501) in a base unit. Then TXDATA goes to RF PART and it's modulated to 1.9 GHz. The RF signal is amplified and fed to a selected antenna.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.4. Circuit Operation (Base Unit) General Description: (BBIC, EERROM) is a digital speech/signal processing system that implements all the functions of speech compression and memory management required in a digital telephone. The BBIC system is fully controlled by a host processor. The host processor provides activation and control of all that functions as follows.
Page 12
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.4.3. Power Supply Circuit/Reset Circuit The power supply voltage from AC adaptor is converted to VBAT (3.0V) in IC302. And +3.0V for peripherals and analog part is insulated from VBAT by Doubler of BBIC. Circuit Operation:...
Page 13
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.4.3.1. Charge Circuit The voltage from the AC adaptor is supplied to the charge circuits.
Page 14
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.4.4. Telephone Line Interface Telephone Line Interface Circuit: Function • Bell signal detection • ON/OFF hook and pulse dial circuit • Side tone circuit Bell signal detection and OFF HOOK circuit: In the idle mode, Q141 is open to cut the DC loop current and decrease the ring load. When ring voltage appears at the Tip (T) and Ring (R) leads (When the telephone rings), the AC ring voltage is transferred as follows: T →...
Page 15
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.4.5. Parallel Connection Detect Circuit/Auto Disconnect Circuit Function: In order to disable call waiting and stutter tone functions when using telephones connected in parallel, it is necessary to have a circuit that judges whether a telephone connected in parallel is in use or not. This circuit determines whether the telephone connected in parallel is on hook or off hook by detecting changes in the T/R voltage.
Page 16
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.4.6. Calling Line Identification (Caller ID) Function: Caller ID The caller ID is a chargeable ID which the user of a telephone circuit obtains by entering a contract with the telephone company to utilize a caller ID service. For this reason, the operation of this circuit assumes that a caller ID service contract has been entered for the circuit being used.
Page 17
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT Call Waiting Caller ID Calling Identity Delivery on Call Waiting (CIDCW) is a CLASS service that allows a customer, while off-hook on an existing call, to receive information about a calling party on a waited call. The transmission of the calling information takes place almost immediately after the customer is alerted to the new call so he/she can use this information to decide whether to take the new call.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.7. Circuit Operation (Handset) 4.7.1. Outline Handset consists of the following ICs as shown in Block Diagram (Handset) (P.18). • DECT BBIC (Base Band IC): IC1 - All data signals (forming/analyzing ACK or CMD signal) - All interfaces (ex: Key, Detector Circuit, Charge, DC/DC Converter, EEPROM, LCD, RF Power Amp.)
Page 21
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.7.3. Charge Circuit Circuit Operation: When charging the handset on the Base Unit, the charge current is as follows; DC+(6.5 V) → F301 → R371 → R372 →CHARGE+(Base) → CHARGE+(Handset) → Q4 → D7→ F1 → BATTERY+... Battery... BATTERY- → R45 → GND → CHARGE-(Handset)→ CHARGE-(Base) → GND → DC-(GND) In this way, the BBIC on Handset detects the fact that the battery is charged.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 4.8. Circuit Operation (Charger Unit) Charge control is executed at handset side so that the operation when using charger is also controlled by handset. Refer to Circuit Operation (Handset) (P.20) The route for this is as follows: DC+pin of J1(+) → F1 → R1 → CHARGE+pad → Handset → CHARGE-pad → DC-pin of J1(-).
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 5 Location of Controls and Components Refer to the Operating Instructions. Note: You can download and refer to the Operating Instructions (Instruction book) on TSN Server. 6 Installation Instructions Refer to the Operating Instructions. Note: You can download and refer to the Operating Instructions (Instruction book) on TSN Server.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 8 Test Mode 8.1. Engineering Mode 8.1.1. Base Unit...
Page 26
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT Frequently Used Items (Base Unit) ex.) Items Address Default Data New Data Remarks Frequency 00 07 / 00 08 00/01 Use these items in a READ-ONLY mode to confirm the contents. Careless rewriting may 00 02 ~ 00 06 Given value cause serious damage to the computer system.
Page 28
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT Frequently Used Items (Handset) ex.) Items Address Default Data New Data Possible Adjusted Possible Adjusted Remarks Value MAX (hex) Value MIN (hex) Battery Low 00 11 / 00 12 00 / 00 (*2) Frequency 00 07 / 00 08...
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 9 Service Mode 9.1. How to Clear User Setting (Handset Only) Handset Press simultaneously until a beep sound is heard. Then single handset is initialized. (The contents of user setting are reset to factory default) *Usage time is not cleared.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10 Troubleshooting Guide 10.1. Troubleshooting Flowchart Cross Reference: Check Power (P.31) Check Battery Charge (P.32) Check Link (P.33) Check the RF part (P.35) Check Handset Transmission (P.40) Check Handset Reception (P.40) Check Caller ID (P.40)
Page 31
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.1. Check Power 10.1.1.1. Base Unit Cross Reference: Note: Power Supply Circuit/Reset Circuit (P.12) BBIC is IC501. (*1) Refer to Specifications (P.6) for part number and supply voltage of AC adaptor. (*2) Refer to Circuit Board (Base Unit_Main) (P.67).
Page 32
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.2. Check Battery Charge 10.1.2.1. Base Unit Cross Reference: Charge Circuit (P.13) 10.1.2.2. Handset Cross Reference: Check Power (P.31) Charge Circuit (P.21) 10.1.2.3. Charger Unit Cross Reference: Charge Circuit (P.21)
Page 33
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.3. Check Link 10.1.3.1. Base Unit Cross Reference: Power Supply Circuit/Reset Circuit (P.12) Check the RF part (P.35) Note: *1 How to adjust +3.0V: Execute the command "VDA" Refer to Things to Do after Replacing IC or X'tal (P.51) for Base Unit.
Page 34
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.3.2. Handset Cross Reference: Power Supply Circuit/Reset Circuit (P.20) Check the RF part (P.35) Note: *1 How to adjust the frequency of X1: To see the frequency, execute the command “SFR“, then check the TP_CKM (IC1-46pin). To adjust frequency, send command “SFR “...
Page 35
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.4. Check the RF part 10.1.4.1. Finding out the Defective part After All the Checkings or Repairing 1. Re-register the checked handset to the checked base unit, and Regular HS to Regular BU. Note: (*1) HS: Handset (*2) BU: Base Unit...
Page 36
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.4.2. RF Check Flowchart Each item (1 ~ 6) of RF Check Flowchart corresponds to Check Table for RF part (P.37). Please refer to the each item. Note: (*1) Refer to Check Link (P.33).
Page 37
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.4.3. Check Table for RF part Item BU (Base Unit) Check HS (Handset) Check Link Confirmation Normal 1. Register Regular HS to BU (to be 1. Register HS (to be checked) to Regular checked). HS, BU Mode [Normal Mode] 2.
Page 38
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.4.4. TEST RANGE Check Circuit block which range is defective can be found by the following check. Item BU (Base Unit) Check HS (Handset) Check Range Confirmation TX TEST 1. Register Regular HS to BU (to be checked). 1. Register HS (to be checked) to Regular BU.
Page 39
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.5. Registering a Handset to the Base Unit 10.1.6. Deregistering a Handset 10.1.7. Deregistering All Handsets by the Base Unit...
Page 40
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 10.1.8. Check Handset Transmission Cross Reference: Signal Route (P.23) 10.1.9. Check Handset Reception Cross Reference: Signal Route (P.23) Note: When checking the RF part, Refer to Check the RF part (P.35). 10.1.10. Check Caller ID Cross Reference: Telephone Line Interface (P.14) Calling Line Identification (Caller ID) (P.16)
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 11.2. How to Replace the Handset LCD Note: The illustrations are simplified in this page. They may differ from the actual product.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 12 Measurements and Adjustments This chapter explains the measuring equipment, the JIG connection, and the PC setting method necessary for the measurement in Troubleshooting Guide (P.30) 12.1. Equipment Required • Digital multi-meter (DMM): it must be able to measure voltage and current.
Page 46
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 12.2.2. Connections (Handset) Connect the DC Power or Battery to BATT+ and BATT-. Connect the JIG cable GND (black) to GND. Connect the JIG cable UTX (yellow) to UTX and URX (red) to URX. Note: *: COM port names may vary depending on what your PC calls it.
Page 47
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 12.2.3. How to install Batch file into P.C. Note: • “*****” varies depending on the country or models. 12.2.4. Commands See the table below for frequently used commands. Command name Function Example rdeeprom Read the data of EEPROM Type “rdeeprom 00 00 FF”, and the data from address “00 00”...
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 12.3. Adjustment Standard (Base Unit) When connecting the simulator equipment for checking, please refer to below. 12.3.1. Bottom View Note: (*1) is referred to No.2 of Check Check Table for RF part (P.37) (*2) is referred to Power Supply Circuit/Reset Circuit (P.12)
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 12.4. Adjustment Standard (Charger Unit) When connecting the simulator equipment for checking, please refer to below. 12.4.1. Bottom View Digital Volt Meter /2 W DC POWER DC 6.5 V...
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 12.6. Things to Do after Replacing IC or X'tal If repairing or replacing EEPROM and X'tal, it is necessary to download the required data such as Programming data or adjustment data, etc. in memory. The set doesn't operate if it is not executed.
Page 52
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 12.6.1.2. Handset First, operate the PC setting according to The Setting Method of JIG(P.45). Then download the appropriate data according to the following procedures. Items How to download/Required adjustment EEPROM (IC3) Adjusted parameter data is 1) Default batch file: Execute the command “default.bat”.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 13 Miscellaneous 13.1. How to Replace the Flat Package IC Even if you do not have the special tools (for example, a spot heater) to remove the Flat IC, with some solder (large amount), a soldering iron and a cutter knife, you can easily remove the ICs that have more than 100 pins.
Page 55
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 13.1.3. How to Install the IC 1. Temporarily fix the FLAT PACKAGE IC, soldering the two marked pins. *Check the accuracy of the IC setting with the corresponding soldering foil. 2. Apply flux to all pins of the FLAT PACKAGE IC.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 13.2. How to Replace the Shield Case 13.2.1. Preparation • PbF (: Pb free) Solder • Soldering Iron Tip Temperature of 700°F ± 20°F (370°C ± 10°C) Note: We recommend a 30 to 40 Watt soldering iron. An expert may be able to use a 60 to 80 Watt iron where someone with less experience could overheat and damage the PCB foil.
Page 57
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 13.2.4. How to Install the Shield Case Note: • If you don’t have special tools (ex. Hot air disordering tool), conduct the following operations. • Shield case’s No. : PNMC1013Z 1. Put the shield case. 2. Solder the surroundings.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 13.3. How to Replace the LLP (Leadless Leadframe Package) IC Note: This description is only applied on the model with Shield case. 13.3.1. Preparation • PbF (: Pb free) Solder • Soldering Iron Tip Temperature of 700 °F ± 20 °F (370 °C ± 10 °C) Note: We recommend a 30 to 40 Watt soldering iron.
Page 59
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 13.3.4. How to Install the IC 1. Place the solder a little on the land where the radiation GND pad on IC bottom is to be attached. 2. Place the solder a little on the land where IC pins are to be attached, then place the IC.
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 14 Schematic Diagram 14.1. For Schematic Diagram 14.1.1. Base Unit (Schematic Diagram (Base Unit_Main)) 14.1.1.1. Acoustic Testing Mode Notes: 1. DC voltage measurements are taken with voltmeter from the negative voltage line. 2. The schematic diagrams may be modified at any time with the development of new technology.
Page 65
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT R807 W 0.15mm RXON L 20+/-2mm 3rd layer C827 L801 TP_ANT1 *C826 RX_RF C803 RF_RXn 1.5p DA801 BATTERY RF_RXp W 0.125mm L 7.6mm Gap 0.125mm W 0.15mm CP+3.0V W 0.15mm 1st layer L 5.0mm L 5.0mm 1st layer 1st layer...
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 16 Exploded View and Replacement Parts List 16.1. Cabinet and Electrical Parts (Base Unit) 7(*1) 7(*1) PCB1 Ref.No. Figure 2.6 8 mm Note: (*1) The SPACERs (No.7) are cut from the excess parts of SPACER (No.108) of Cabinet and Electrical Parts (Handset)
(*1) This cable is fixed by welding. Refer to How to Replace the Handset LCD (P.44). (*2) The rechargeable Ni-MH battery HHR-4DPA or HHR-4MRT is available through sales route of Panasonic. (*3) Attach the SPACER (No. 119) to the exact location described above.
Page 76
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT 16.5. Replacement Parts List 16.5.1.2. Main P.C. Board Parts Note: 1. RTL (Retention Time Limited) (*1) When replacing IC611 or X501, make the adjustment Note: using PNZZTG4011LA Refer to How to download the data The “RTL” marking indicates that its Retention Time is (P.51) of Things to Do after Replacing IC or X'tal.
Page 77
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R372 ERJ1TYJ5R6U C806 F1G1H2R7A480 2.7p R501 ERJ3GEYJ100 C810 F1G1H2R4A480 2.4p R502 ERJ2GEJ330 C811 F1G1H100A723 10p R505 ERJ2GEJ222 2.2k C812 F1G1HR90A480 0.9p...
Page 78
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks PNWIGA403LAR IC (EEPROM) (*2) R331 ERJ2GEJ273X IC801 C1CB00001842 IC R332 ERJ2GEJ273X (TRANSISTORS) R801 ERJ2GEJ122 1.2k B1ADGE000004 TRANSISTOR(SI) R802 ERJ2GEJ101 B1ADGE000004 TRANSISTOR(SI)
Page 79
KX-TG4011LAT/KX-TG4012LAT/KX-TG4013LAT/KX-TGA403LAT Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks E101 L5DYBYY00012 LIQUID CRYSTAL DISPLAY PQZZ430PIR TIP OF SOLDERING IRON (*3) (*2) E102 PNHR1247Z TRANSPARENT PLATE, LCD PMMA-HB PQZZ430PRB RUBBER OF SOLDERING IRON...
