Operating Instructions for advanced features Digital Camera DMC-XS1 Model No. DMC-FS50 DMC-XS1 DMC-FS50 Please read these instructions carefully before using this product, and save this manual for future use. VQT4P63 F1212HH0...
Contents Before Use Care of the camera ...................... 5 Standard Accessories....................6 Names and Functions of Main Parts................7 Preparation Charging the Battery....................11 • Inserting the Battery.................... 12 • Charging ......................13 • Approximate operating time and number of recordable pictures ......16 Inserting and Removing the Card (optional) ............
Page 3
• Digital Zoom......................49 Taking Pictures Using the Built-in Flash..............50 • Switching to the appropriate flash setting ............50 Taking Pictures with the Self-timer................54 Compensating the Exposure..................55 Taking Pictures with different image effects (Creative Control Mode) (DMC-XS1) ................. 56 •...
Page 4
• [Stabilizer] ......................79 • [Date Stamp] ....................... 80 • [Clock Set] ......................80 Using the [Motion Picture] Menu ................81 • [Rec Quality] ....................... 81 • [Continuous AF] ....................81 Playback/Editing Various methods of playback................... 82 • [Slide Show]......................83 •...
Before Use Care of the camera Do not subject to strong vibration, shock, or pressure. • The lens, LCD monitor, or external case may be damaged if used in the following conditions. It may also malfunction or image may not be recorded if you: –...
The card is optional. You can record or play back pictures on the built-in memory when you are not using a card. • Consult the dealer or Panasonic if you lose the supplied accessories. (You can purchase the accessories separately.) - 6 -...
Before Use Names and Functions of Main Parts (DMC-XS1) Flash (P50) Self-timer indicator (P54) Lens (P5, 110) LCD monitor (P45, 107, 110) [MODE] button (P25, Charging lamp (P13) Zoom button (P47) Motion picture button (P32) [MENU/SET] button (P38) 10 [(] (Playback) button (P34) 11 [ ] (Delete/Cancel) button...
Page 8
Before Use 13 Speaker (P41) • Be careful not to cover the speaker with your finger. Doing so may make sound difficult to hear. 14 Lens barrel 15 Strap eyelet (P24) • Be sure to attach the strap when using the camera to ensure that you will not drop it.
Page 10
Before Use 13 Speaker (P41) • Be careful not to cover the speaker with your finger. Doing so may make sound difficult to hear. 14 Lens barrel 15 Strap eyelet (P24) • Be sure to attach the strap when using the camera to ensure that you will not drop it.
Please be advised that we are not liable for any accident or failure occurring as a result of use of a counterfeit battery pack. To ensure that safe products are used, we recommend that a genuine Panasonic battery pack is used.
Slide the release lever in the direction of the arrow and open the card/battery door. • Always use genuine Panasonic batteries. • If you use other batteries, we cannot guarantee the quality of this product. Being careful about the battery...
Preparation Charging • Charge the battery in areas with an ambient temperature, between 10 oC and 30 oC (50 oF and 86 oF) (same as the battery temperature), is recommended. Check that this unit is turned off. A To power outlet B AC adaptor (supplied) C PC (Turned on) D USB connection cable (supplied)
Page 14
Preparation (Charging from a computer) Connect the computer and this camera with the USB connection cable (supplied). • Charging may not be possible depending on computer specifications. • If the computer enters a suspended state while charging the battery, charging will stop. •...
Page 15
Otherwise, a fire and/or electric shocks may be caused by short-circuiting or the resulting heat generated. • Do not use any other USB connection cables except the supplied one or a genuine Panasonic USB connection cable (DMW-USBC1: optional). • Do not use any other AC adaptors except the supplied one.
CIPA is an abbreviation of [Camera & Imaging Products Association]. • Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is on. • Using a Panasonic microSDHC Memory Card (16 GB). • Using the supplied battery. • Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabiliser function is set to [ON].)
Page 17
Preparation Playback ∫ Playback time Approx. 240 min • The operating times and number of recordable pictures will differ according to the environment and the operating conditions. For example, in the following cases, the operating times will shorten and the number of recordable pictures is reduced: –...
Inserting and Removing the Card (optional) • Check that this unit is turned off. • We recommend using a Panasonic card. Slide the release lever in the direction of the arrow and open the card/battery door. Push it securely all the way until you hear a “click”...
Only the cards with capacity listed left can be used. ¢ SD Speed Class is the speed standard regarding continuous writing. Check via the label on the card, etc. e.g.: • Please confirm the latest information on the following website. http://panasonic.jp/support/global/cs/dsc/ (This site is English only.) - 19 -...
Page 20
Preparation • During access (image writing, reading and deleting, formatting etc.), do not turn this unit off, remove the battery, card or disconnect the AC adaptor (supplied). Furthermore, do not subject the camera to vibration, impact or static electricity. The card or the data on the card may be damaged, and this unit may no longer operate normally.
Preparation Approximate number of recordable pictures and available recording time About the display of the number of recordable pictures and available recording time ∫ • Switch the display (number of recordable pictures, available recording time, etc.) by pressing 4. (P45) A Number of recordable pictures MJPEG MJPEG...
Preparation Setting Date/Time (Clock Set) • The clock is not set when the camera is shipped. Press camera [ON/OFF] button. • If the language select screen is not displayed, proceed to step Press [MENU/SET]. Press 3/4 to select the language, and press [MENU/SET]. Press [MENU/SET].
Preparation Changing the Clock Setting Select [Clock Set] in the [Rec] or [Setup] menu, and press [MENU/SET]. (P38) • The clock can be reset as shown in steps • The clock setting is maintained for about 20 hours using the built-in clock battery even without the battery.
Preparation Tips for taking good pictures Fit the strap and hold the camera carefully Hold the camera gently with both hands, keep your arms still at your side and stand with your feet slightly apart. • To prevent dropping, be sure to attach the supplied strap and fit it to your wrist. (P8) •...
Basic Selecting the Recording Mode Press [MODE]. Press 3/4/2/1 to select the Recording Mode. Press [MENU/SET]. List of Recording Modes ∫ Intelligent Auto Mode (P26) ¦ The subjects are recorded using settings automatically selected by the camera. Normal Picture Mode (P29) The subjects are recorded using your own settings.
Basic Taking pictures using the automatic function (Intelligent Auto Mode) Recording Mode: The camera will set the most appropriate settings to match the subject and the recording conditions so we recommend this mode for beginners or those who want to leave the settings to the camera and take pictures easily.
Page 27
Basic Scene Detection When the camera identifies the optimum scene, the icon of the scene concerned is displayed in blue for 2 seconds, after which its colour changes to the usual red. When taking pictures > [i-Portrait] [i-Scenery] ¦ [i-Macro] [i-Night Portrait] ¢...
Basic Changing the settings Following menus can be set. Menu Item ¢ ¢ ¢ [Rec] [Picture Size] /[Burst] /[Color Mode] [Motion Picture] [Rec Quality] [Setup] [Clock Set]/[World Time]/[Beep]/[Language]/[Stabilizer Demo.] • Menu items other than those listed above are not displayed, but you can set them in other Recording Modes.
Basic Taking pictures with your favourite settings (Normal Picture Mode) Recording Mode: The camera automatically sets the shutter speed and the aperture value according to the brightness of the subject. You can take pictures with greater freedom by changing various settings in the [Rec] menu. Press [MODE].
Basic Focusing Aim the AF area at the subject, and then press the shutter button halfway. F2.8 F2.8 F2.8 1/60 1/60 1/60 When the subject is focused When the subject is not Focus focused Focus indication A Blinks AF area B White>Green White>Red Sound...
Page 31
Basic When the subject is not in focus (such as when it is not in the centre of the ∫ composition of the picture you want to take) Aim the AF area at the subject, and press the shutter button half way to fix the focus and exposure.
Basic Recording Motion Pictures Applicable modes: (DMC-XS1) (DMC-FS50) This unit can record motion pictures in QuickTime Motion JPEG format. Start recording by pressing the motion picture button. A Available recording time B Elapsed recording time • You can record motion pictures fitting each Recording Mode. •...
Page 33
Basic • When recording to the built-in memory, [Rec Quality] is fixed to [QVGA]. • The available recording time displayed on the screen may not decrease regularly. • Depending on the type of the card, the card access indication may appear for a while after recording motion pictures.
Basic Playing Back Press [(]. Press 2/1 to select pictures. A File number 100-0001 100-0001 100-0001 B Picture number • If you press and hold 2/1, you can play back the pictures in succession. • Speed of picture Forwarding/Rewinding changes depending on the playback status.
Page 35
Basic • This camera complies with the DCF standard “Design rule for Camera File system” established by JEITA “Japan Electronics and Information Technology Industries Association” and with Exif “Exchangeable Image File Format”. Files that do not comply with the DCF standard cannot be played back.
Basic Displaying Multiple Screens (Multi Playback) Press [W] of the zoom button. 1/26 1 screen>12 screens>30 screens>Calendar screen display A Number of the selected picture and the total number of recorded pictures • Press [T] of the zoom button to return to the previous screen. •...
Basic Deleting Pictures Once deleted, pictures cannot be recovered. • Pictures on the built-in memory or the card that are being played back will be deleted. • Pictures that are not in the DCF standard or those that are protected cannot be deleted. To delete a single picture Select the picture to be deleted, and then press [...
Basic Setting the Menu The camera comes with menus that allow you to choose the settings for taking pictures and playing them back just as you like and menus that enable you to have more fun with the camera and use it more easily. In particular, the [Setup] menu contains some important settings relating to the camera’s clock and power.
Page 39
Basic Press 3/4 to select the menu item and then press [MENU/SET]. A Menu screen page • It will switch to the next page when you reach the bottom. (It will also switch by pressing the zoom button) Press 3/4 to select the setting and then press [MENU/SET].
Basic About the Setup Menu For details on how to select the [Setup] menu settings, refer to P38. • [Clock Set], [Auto Power Off] and [Auto Review] are important items. Check their settings before using them. • In Intelligent Auto Mode, only [Clock Set], [World Time], [Beep], [Language], [Stabilizer Demo.] can be set.
Page 41
Basic Adjusts the volume of the operating sound. ([Low]) r [Beep] ([High]) ([OFF]) • Changing the settings for the operating sound will change the shutter sound. Adjust the volume of the speaker to any of the 7 levels. u [Speaker Volume] •...
Page 42
Basic The camera is automatically turned off if the camera has not been used for the time selected on the setting. [2MIN.] p [Auto Power Off] [5MIN.] [10MIN.] [OFF] • [Auto Power Off] is set to [5MIN.] in the Intelligent Auto Mode. •...
Page 43
Basic Set to match the colour television system in each country or the type of [|] ([Video Out]): [NTSC]: Video output is set to NTSC system. [PAL]: | [Output] Video output is set to PAL system. ] ( [TV Aspect]): [W]: When connecting to a 16:9 screen TV.
Page 44
If the card has been formatted on a PC or other equipment, format it on the camera again. • It may take longer to format the built-in memory than the card. • If you cannot format, contact the dealer or Panasonic. Set the language displayed on the screen. ~ [Language] •...
Recording About the LCD Monitor Press 4 to change. 1 LCD monitor • During motion picture playback, panorama playback or a slideshow, you can only select “Normal Display E” or “No Display G”. In Recording Mode A Normal display MJPEG MJPEG QVGA QVGA...
Page 46
Recording Recording guideline ∫ This is used as a reference of composition, such as balance, while taking a picture. • In the following cases, the guidelines are not displayed: – Panorama Shot Mode – [Photo Frame] (Scene Mode) - 46 -...
Recording Using the Zoom Applicable modes: (DMC-XS1) (DMC-FS50) You can zoom in to make people and objects appear closer or zoom out to record landscapes in wide angle. To make subjects appear further away use (Wide) Press [W] of the zoom button. To make subjects appear closer use (Tele) Press [T] of the zoom button.
Recording Extra Optical Zoom (EZ) This function works when any of the picture sizes (P69) indicated with is selected. You can zoom in further than you can with the Optical Zoom without deteriorating the image quality. Maximum magnification: 11.3k (This includes the optical zoom magnification. The magnification level differs depending on [Picture Size] setting.) •...
Recording Digital Zoom This function works when [Digital Zoom] (P75) in the [Rec] menu is set to [ON]. Although the image quality deteriorates every time you zoom in further, you can zoom in up to four times the original zoom magnification. •...
Recording Taking Pictures Using the Built-in Flash Applicable modes: (DMC-XS1) (DMC-FS50) A Flash Do not cover it with your fingers or other objects. Switching to the appropriate flash setting Set the flash to match the recording. Press 1 [‰]. - 50 -...
Page 51
Recording Press 3/4 to select the item and then press [MENU/SET]. Item Description of settings [‡] ([Auto]) The flash is automatically activated when the recording conditions make it necessary. ¢1 ([iAuto]) The flash is automatically activated when the recording conditions make it necessary.
Page 52
Recording Available Flash Settings in Recording Mode ∫ The available flash settings depend on the Recording Mode. (±: Available, —: Not available, ¥: Scene Mode initial setting) ‡ ‰ Œ ¢ — — — ± ± ± ± ± — ±...
Page 53
Recording The available flash range ∫ • The available flash range is an approximation. Wide Tele In [ ] in 40 cm (1.3 feet) to 4.4 m (14 feet) 1.0 m (3.3 feet) to 1.7 m (5.6 feet) [Sensitivity] Shutter speed for each flash setting ∫...
Recording Taking Pictures with the Self-timer Applicable modes: (DMC-XS1) (DMC-FS50) Press 2 [ë]. Press 3/4 to select the item and then press [MENU/SET]. Item Description of settings Picture is taken 10 seconds after shutter is pressed. ([10sec.]) Picture is taken 2 seconds after shutter is pressed. •...
Recording Compensating the Exposure Applicable modes: (DMC-XS1) (DMC-FS50) Use this function when you cannot achieve appropriate exposure due to the difference in brightness between the subject and the background. Underexposed Properly exposed Overexposed Compensate the exposure Compensate the exposure towards positive. towards negative.
Recording Taking Pictures with different image effects (Creative Control Mode) (DMC-XS1) Recording Mode: (DMC-XS1) This mode records with additional image effects. You can set the effects to add by selecting example images and checking them on the screen. Press [MODE]. Press 3/4/2/1 to select [Creative Control], and then press [MENU/ SET].
Recording ¢ These pictures are examples to show the effect. [Expressive] This effect emphasises the colour to make a pop art picture. [Retro] This effect gives a faded image. [High Key] This effect adds a bright, airy and soft feel to the overall image. •...
Recording [Sepia] This effect creates a sepia image. [Dynamic Monochrome] This effect gives a higher contrast to create an impressive black and white picture. [Impressive Art] This effect gives your photo a dramatic contrast look. • If you select this effect with Panorama Shot Mode, seams between pictures may become noticeable.
Recording [Cross Process] This effect gives your photo a dramatic colour look. Items that can be set Green tone/Blue tone/Yellow tone/Red tone Colour • Press 2/1 to select the colour to enhance, and press [MENU/SET]. [Toy Effect] This effect reduces peripheral brightness to give the impression of a toy camera.
Recording [Soft Focus] This effect blurs the overall image to produce a soft feel. • Display of the recording screen will be delayed more than usual and the screen will look as if frames are dropping. [One Point Color] This effect leaves one selected colour to emphasise impressiveness. Set the colour to leave in ∫...
Recording Taking panorama pictures (Panorama Shot Mode) Recording Mode: Pictures are recorded continuously while moving the camera horizontally or vertically, and are combined to make a single panorama picture. Press [MODE]. Press 3/4/2/1 to select [Panorama Shot], and then press [MENU/SET]. Press 3/4 to select the recording direction and then press [MENU/SET].
Page 62
Recording Press the shutter button fully and record a picture while moving the camera in a small circle in the direction selected in Step Recording from left to right Trace a half-circle with the camera, taking about 4 seconds. • Move the camera at a constant speed.
Page 63
Recording • The zoom position is fixed to Wide. • The focus, white balance, and exposure are fixed at the optimum values for the first picture. As a result, if the focus or brightness changes substantially during recording, the entire panorama picture may not be recorded at the suitable focus or brightness.
Recording Taking pictures that match the scene being recorded (Scene Mode) Recording Mode: When you select a Scene Mode to match the subject and recording situation, the camera sets the optimal exposure and hue to obtain the desired picture. Press [MODE]. Press 3/4/2/1 to select [Scene Mode], and then press [MENU/SET].
Recording [Portrait] When taking pictures of people outdoors during the daytime, this mode allows you to improve the appearance and make their skin tones look healthier. Technique for Portrait Mode ∫ To make this mode more effective: 1 Press and hold down the zoom button as far as possible to Tele. 2 Move close to the subject to make this mode more effective.
Recording [Sports] Setting for when you want to take pictures of sports scenes or other fast-moving events. • Shutter speed may slow down up to 1 second. • This mode is suitable for taking pictures of subjects at distances of 5 m (16 feet) or more. [Night Portrait] This allows you to take pictures of a person and the background with near real-life brightness.
Recording [Baby1]/[Baby2] This takes pictures of a baby with a healthy complexion. When you use the flash, the light from it is weaker than usual. It is possible to set different birthdays for [Baby1] and [Baby2]. You can display those during playback.
Recording [Starry Sky] This mode allows you to take vivid pictures of a starry sky or a dark subject. Setting the shutter speed ∫ Select a shutter speed of [15 sec.], [30 sec.] or [60 sec.]. • Press the shutter button fully to display the countdown screen. Do not move the camera after this screen is displayed.
Recording Using the [Rec] Menu For details on [Rec] menu settings, refer to P38. [Picture Size] Applicable modes: (DMC-XS1) (DMC-FS50) Set the number of pixels. The higher the numbers of pixels, the finer the detail of the pictures will appear even when they are printed onto large sheets. Settings Picture Size 4608k3456...
Recording [Sensitivity] Applicable modes: (DMC-XS1) (DMC-FS50) This allows the Sensitivity to light (ISO sensitivity) to be set. Setting to a higher figure enables pictures to be taken even in dark places without the resulting pictures coming out dark. Settings Description of settings The ISO sensitivity is adjusted according to the movement of the subject and the brightness.
Recording [White Balance] Applicable modes: (DMC-XS1) (DMC-FS50) In sunlight, under incandescent lights or in other such conditions where the colour of white takes on a reddish or bluish tinge, this item adjusts to the colour of white which is closest to what is seen by the eye in accordance with the light source.
Page 72
Recording Auto White Balance ∫ Depending on the conditions prevailing when pictures are taken, the pictures may take on a reddish or bluish tinge. Furthermore, when a multiple number of light sources are being used or there is nothing with a colour close to white, Auto White Balance may not function properly. In this case, set the White Balance to a mode other than [AWB].
Recording [AF Mode] Applicable modes: (DMC-XS1) (DMC-FS50) This allows the focusing method that suits the positions and number of the subjects to be selected. Settings Description of settings The camera automatically detects the person’s face. (max. 12 areas) ([Face The focus and exposure can then be adjusted to fit that face no [š] Detection]) ¢...
Page 74
Recording About [š] ([Face Detection]) ∫ The following AF area frames are displayed when the camera detects the faces. Yellow: When the shutter button is pressed halfway, the frame turns green when the camera is focused. White: Displayed when more than one face is detected. Other faces that are the same distance away as the faces within the yellow AF areas are also brought into focus.
Recording [i.Exposure] Applicable modes: (DMC-XS1) (DMC-FS50) Contrast and exposure will be adjusted automatically when there is a big difference in brightness between the background and subject, to bring the image close to real life. Settings: [ON]/[OFF] • ] in the screen turns yellow when [i.Exposure] is in effect. •...
Recording [Burst] Applicable modes: (DMC-XS1) (DMC-FS50) Pictures are taken continuously while the shutter button is pressed. Settings Description of settings Burst speed approx. 1.0 pictures/second • You can take pictures until the capacity of the built-in memory or the card is full.
Page 77
Recording • Depending on the operating conditions, it may take time to take the next picture if you repeat the recording of pictures. • It may take time to save pictures taken in Burst Mode on the card. If you take pictures continuously while saving, the maximum number of recordable pictures decreases.
Recording [Color Mode] Applicable modes: (DMC-XS1) (DMC-FS50) Sets various colour effects, including making the picture sharper, brighter, or applying a sepia tone. Settings Description of settings This is the standard setting. [STANDARD] [Happy] ¢1 Image with enhanced brightness and vividness. The picture becomes sharper.
Recording [Red-Eye Removal] Applicable modes: (DMC-XS1) (DMC-FS50) When Red-Eye Reduction ([ ], [ ]) is selected, Red-Eye Removal is performed whenever the flash is used. The camera automatically detects red-eye and corrects the picture. Settings: [ON]/[OFF] • Only available when [AF Mode] is set to [š] and Face Detection is active. •...
Recording [Date Stamp] Applicable modes: (DMC-XS1) (DMC-FS50) You can take a picture with date and time of recording. Settings Description of settings Stamp the year, month, and day. [W/O TIME] Stamp the year, month, day, hour, and minutes. [WITH TIME] [OFF] —...
Recording Using the [Motion Picture] Menu For details on [Motion Picture] menu settings, refer to P38. [Rec Quality] Applicable modes: (DMC-XS1) (DMC-FS50) This sets up the picture quality of motion pictures. Settings Picture size Aspect ratio [HD] 1280k720 pixels 16:9 [VGA] 640k480 pixels [QVGA]...
Playback/Editing Various methods of playback You can play back the recorded pictures in various methods. Press [(]. Press [MODE]. Press 3/4/2/1 to select item, and then press [MENU/SET]. • Following items can be selected. ] ([All]) (P34) ] ([Slide Show]) (P83) ] ([Filtering Play]) (P85)
Playback/Editing [Slide Show] You can play back the pictures you have taken in synchronisation with music, and you can do this in sequence while leaving a fixed interval between each of the pictures. You can also play back images that have been sorted by category, images that have been set as favourites, etc.
Page 84
Playback/Editing To filter images for slide show playback ∫ You can filter images and play them back in a slide show by selecting [Filtering] on the slide show menu screen. • If you select [All], you can play back all images in a slide show. You can also filter images by using the same setting as [Filtering Play].
Playback/Editing [Filtering Play] The images sorted into the category or images set as favourite are played back. Settings Description of settings [Picture Only] Only still pictures are played back. [Video Only] Only motion pictures are played back. This mode allows you to search images by Scene Mode or other categories (such [Category as [Portrait], [Scenery] or [Night Scenery]) and sort the pictures into each of the Selection]...
Page 86
Playback/Editing You can play back pictures taken on each date Press 3/4 to select [Select Date] and then press [MENU/SET]. Press 3/4/2/1 to select the date to be played back, and then press [MENU/SET]. MON TUE WED THU FRI SAT •...
Playback/Editing [Calendar] You can search for images by recorded date. Press 3/4/2/1 to select the date you want to search. MON TUE WED THU FRI SAT • If there were no pictures recorded during a month, that month is not displayed.
Playback/Editing Having Fun with Recorded Pictures (Retouch) You can adjust the colour tone of the pictures taken, or add your preferred effects. • The processed pictures are newly generated, so be sure that you have enough space in the built-in memory or on the card.
Page 89
Playback/Editing (DMC-FS50) Press 2/1 to select a picture, and then press 3. • If you have filtered images for playback by using [Slide Show] (P83) or [Filtering Play] (P85), the selection screen appears. You can proceed to step by selecting [Auto Retouch] with 3/4, and then pressing [MENU/SET], •...
Playback/Editing [Creative Retouch] (DMC-XS1) You can add your desired effects to the pictures that you have taken. Press 2/1 to select a picture, and then press 3. • If you have filtered images for playback by using [Slide Show] (P83) or [Filtering Play] (P85), the selection screen appears.
Playback/Editing Using the [Playback] Menu • With [Retouch] (DMC-XS1), [Auto Retouch] (DMC-FS50) or [Resize], a new edited picture is created. A new picture cannot be created if there is no free space on the built-in memory or the card so we recommend checking that there is free space and then editing the picture.
Page 92
Playback/Editing [MULTI] setting Press 3/4 to select the size, and then press [MENU/SET]. Press 3/4/2/1 to select the picture, and then press [MENU/SET]. (repeat this step) • If you press [MENU/SET] again, the setting is cancelled. • Select [OK] with 2, and then press [MENU/SET] to set. •...
Playback/Editing [Favorite] You can do the following if a mark has been added to pictures and they have been set as favourites. • Play back only the pictures set as favourites. ([Favorite] in [Filtering Play]) • Play back the pictures set as favourites only as a Slide Show. •...
Playback/Editing [Protect] You can set protection for pictures you do not want to be deleted by mistake. Select [Protect] on the [Playback] menu. Press 3/4 to select [SINGLE] or [MULTI] and then press [MENU/SET]. [SINGLE] [MULTI] Select the picture, and then press [MENU/SET].
Playback/Editing [Copy] You can copy the data of the pictures you have taken from the built-in memory to a card or from a card to the built-in memory. Select [Copy] on the [Playback] menu. Press 3/4 to select the copy destination and then press [MENU/SET]. ] ([IN>SD]): All the picture data in the built-in memory are copied onto the card at one time.
Check the directions of the connectors, and plug them straight in or unplug them straight out. (Otherwise the connectors may bend out of shape, which may cause malfunction.) • Always use a genuine Panasonic AV cable (DMW-AVC1: optional). A Yellow: to the video input socket C AV cable (optional) B White: to the audio input socket D Align the marks, and insert.
Page 97
Connecting to other equipment If the TV, Blu-ray disc recorder, DVD recorder or other equipment has an SD card slot ∫ Insert the card into the SD card slot. (Always connect the dedicated adaptor. The device will not operate properly if only the adaptor is inserted. Always insert the card into the adaptor before use.) •...
Connecting to other equipment Saving still pictures and motion pictures on your You can transfer the pictures in the camera to a PC by connecting the camera and the PC. • Some PCs can read directly from the card removed from the camera. For details, refer to the operating instructions of your PC.
Page 99
Connecting to other equipment Installing supplied software ∫ • Before inserting the CD-ROM, close all running applications. Check the environment of your PC. • Operating environment of “PHOTOfunSTUDIO 9.0 LE” – Windows XP (32bit) SP3, Windows Vista (32bit) SP2, Windows 7 (32bit/64bit) or SP1 Windows 8 (32bit/64bit)
Page 100
(Otherwise the connectors may bend out of shape, which may cause malfunction.) • Do not use any other USB connection cables except the supplied one or a genuine Panasonic USB connection cable (DMW-USBC1: optional). A USB connection cable (supplied) B Align the marks, and insert.
Page 101
Connecting to other equipment Copying to a PC without using “PHOTOfunSTUDIO” ∫ If the installation of “PHOTOfunSTUDIO” fails, you can copy files and folders to your PC by dragging and dropping them from the camera after connecting to your PC. Directory structure of built-in memory/card of this unit is shown by the figure below.
(Otherwise the connectors may bend out of shape, which may cause malfunction.) • Do not use any other USB connection cables except the supplied one or a genuine Panasonic USB connection cable (DMW-USBC1: optional). A USB connection cable (supplied) B Align the marks, and insert.
Connecting to other equipment Selecting a single picture and printing it PictBridge Press 2/1 to select the picture and then press [MENU/ SET]. Press 3 to select [Print start] and then press [MENU/ SET]. • Refer to P104 for the items which can be set before starting to print the pictures.
Connecting to other equipment Print Settings Select and set the items both on the screen in step of the “Selecting a single picture and printing it” and in step of the “Selecting multiple pictures and printing them” procedures. • When you want to print pictures in a paper size or a layout which is not supported by the camera, set [Paper Size] or [Page Layout] to [{] and then set the paper size or the layout on the printer.
Page 105
Connecting to other equipment [Paper Size] Item Description of settings Settings on the printer are prioritised. [L/3.5qk5q] 89 mmk127 mm [2L/5qk7q] 127 mmk178 mm [POSTCARD] 100 mmk148 mm [16:9] 101.6 mmk180.6 mm [A4] 210 mmk297 mm [A3] 297 mmk420 mm [10k15cm] 100 mmk150 mm [4qk6q]...
Page 106
Connecting to other equipment [Page Layout] (Layouts for printing that can be set with this unit) Item Description of settings Settings on the printer are prioritised. 1 picture with no frame on 1 page á 1 picture with a frame on 1 page â...
Others Cautions for Use Optimal use of the camera Keep this unit as far away as possible from electromagnetic equipment (such as microwave ovens, TVs, video games etc.). • If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be disrupted by electromagnetic wave radiation.
Page 110
Others Cleaning Before cleaning the camera, remove the battery or disconnect the power plug from the outlet. Then wipe the camera with a dry, soft cloth. • When the camera is soiled badly, it can be cleaned by wiping the dirt off with a wrung wet cloth, and then with a dry cloth.
Page 111
Others Battery The battery is a rechargeable lithium ion battery. Its ability to generate power comes from the chemical reaction that takes place inside it. This reaction is susceptible to the surrounding temperature and humidity. If the temperature is too high or too low, the operating time of the battery will become shorter.
Page 112
Information including personal information may be altered or vanish due to erroneous operation, effect of static electricity, accident, malfunction, repair, or other handlings. Please note in advance that Panasonic is not liable in any way for any direct or indirect damage from the alteration or vanishing of information or personal information.
Page 113
About the picture data Recorded data may be damaged or lost if the camera breaks down due to inappropriate handling. Panasonic will not be liable for any damage suffered due to loss of recorded data. About tripods or unipods •...
[Please turn camera off and then on again]/[System Error] • This is displayed when the lens has stopped operating normally due to being pressed on by a hand etc. > Turn the camera off and on. If the message persists, contact the dealer or Panasonic. - 114 -...
Page 115
102) [This battery cannot be used] • Use a genuine Panasonic battery. If this message is displayed even when a genuine Panasonic battery is used, contact the dealer or Panasonic. • If the battery terminal is dirty, clean it and remove any objects.
Others Troubleshooting First, try out the following procedures (P116–125). If the problem is not resolved, it may be improved by selecting [Reset] (P42) on the [Setup] menu. Battery and power source The charging lamp has gone off but the unit has not been charged. Or the charging lamp blinks.
Page 117
Others Recording The picture cannot be recorded. • Is there any memory remaining on the built-in memory or the card? > Delete the pictures which are not necessary to increase available space in the memory. (P37) • You may not be able to record for a short while after turning this unit on when using a large capacity card.
Page 118
Others The recorded picture looks rough. Noise appears on the picture. • Is the ISO sensitivity high or the shutter speed slow? (ISO sensitivity is set to [ ] when the camera is shipped. Therefore, when taking pictures indoors etc. noise will appear.) >...
Page 119
Others LCD monitor The LCD monitor becomes darker or brighter for a moment. • This phenomenon appears when you press the shutter button halfway to set the aperture value and does not affect the recorded pictures. • This phenomenon also appears when the brightness changes when the camera is zoomed or when the camera is moved.
Page 120
Others Flash The flash is not activated. • Is the flash setting set to [Œ]? > Change the flash setting. (P50) • The flash cannot be used in the following cases: – Creative Control Mode (P56) (DMC-XS1) – Panorama Shot Mode (P61) –...
Page 121
• Playback of motion pictures recorded with this unit may not be possible with other companies’ digital ¢ cameras. Also, Panasonic’s digital cameras (LUMIX) may also not be able to play them back. ¢ Introduced prior to December 2008, and FS and LS series introduced in 2009.
Page 122
Others TV, PC and printer The picture does not appear on the television. • Is the camera connected to the TV correctly? > Set the TV input to External Input Mode. The display areas on the TV screen and the camera’s LCD monitor are different. •...
Page 123
Others The picture cannot be printed when the camera is connected to a printer. • Pictures cannot be printed using a printer that does not support PictBridge. > Select [PictBridge(PTP)] when connecting. (P102) The ends of the pictures are cut at printing. >...
Page 124
Others Others An unreadable language was selected by mistake. > Press [MENU/SET], select the [Setup] menu icon [ ]. Then press [MENU/SET], and then select the [~] icon to set the desired language. (P44) The camera becomes warm. • The surface of the camera may become warm during use. This does not affect the performance or quality of the camera.
Page 125
Others The file numbers are not recorded consecutively. • When you perform an operation after taking a certain action, the pictures may be recorded in folders with different numbers from the ones used prior to the operation. The file numbers are recorded with previously used numbers. •...
Page 126
• microSDHC Logo is a trademark of SD-3C, LLC. • QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Inc., used under license therefrom. • Mac and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.
