Write the model and serial number here:
Model # SHP-2100 & STR-2100
Serial #
THESE NUMBERS CAN BE FOUND INSIDE THE
REFRIGERATOR'S CABINET ON THE LEFT HAND SIDE.
OWNER'S MANUAL AND INSTALLATION
SETTING UP THE REFRIGERATOR.........................................................4
MAJOR FEATURES .....................................................................................4
CONTROL PANEL........................................................................................5
DIGITAL PANEL...........................................................................................6
TEMPERATURE CONTROL .......................................................................7
ICE and COLD WATER DISPENSER .........................................................7
SHELVES and BINS.....................................................................................8
FOOD STORAGE GUIDE ...........................................................................9
REMOVING THE FREEZER ACCESSORIES..........................................13
REMOVING THE REFRIGERATOR ACCESSORIES..............................13
CARE AND CLEANING .............................................................................14
CHANGING THE INTERIOR LIGHT .........................................................15
WATER FILTER ..........................................................................................16
DOORS.......................................................................................................16
INSTALLATION OF THE REFRIGERATOR .............................................17
REMOVING THE REFRIGERATOR DOORS ...........................................18
REATTACHING THE REFRIGERATOR DOORS......................................21
LEVELING THE REFRIGERATOR............................................................24
ADJUSTING THE CLEARANCE BETWEEN THE DOORS ....................25
CHECKING THE WATER DISPENSER LINE...........................................26
INSTALLATION OF THE WATER DISPENSER LINE...............................27
GENERAL INFORMATION ........................................................................32
VIEWS OF I.C.E. PAD AND TRANSMITTER............................................34
I.C.E. PAD POWER MANAGEMENT.........................................................37
HOW TO USE VIRTUAL KEYBOARD.......................................................39
USER INTERFACE ....................................................................................41
TROUBLESHOOTING ...............................................................................58
WARRANTY ...............................................................................................59
operation/performance, parts, accesories or service, call:
Register your product at www.samsung.com/global/register
I.C.E. PAD
(Interactive Control Entertainment)
REFRIGERATOR
RH269LBSH
CONTENTS
...............................................................2
........................................................4
Drawer GUIDE.............................................................11
................................................17
..............................31
....................................................................59
In the U.S. for questions about features,
1-800-726-7864 (1-800-SAMSUNG)
www.samsung.com
.......................57
DA99-01278D REV(0.0)
Advertisement
Table of Contents
Related Manuals for Samsung SHP-2100
Summary of Contents for Samsung SHP-2100
-
Page 1: Table Of Contents
Write the model and serial number here: I.C.E. PAD Model # SHP-2100 & STR-2100 (Interactive Control Entertainment) REFRIGERATOR Serial # RH269LBSH THESE NUMBERS CAN BE FOUND INSIDE THE REFRIGERATOR’S CABINET ON THE LEFT HAND SIDE. OWNER’S MANUAL AND INSTALLATION CONTENTS SAFETY WARNING SIGNS ...............2... - Page 2 FCC Radio Frequency Interference Requirements This product is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.
-
Page 3: Safety Warning Signs
SAFETY WARNING SIGNS • Before operating the appliance, please read and retain this manual thoroughly for your reference. • The appliance is not intended for use by children or infirm persons without adult supervision. • Children should be supervised to ensure that they do not play with the appliance. WARNING CAUTION/WARNINGS USED OTHER SIGNS USED... - Page 4 • Samsung does not recommend 3rd party modification, there- • You need to connect to the adapter or put the I.C.E. PAD in the fore Samsung is not responsible for safety issues that result docking station of the refrigerator door when the low battery from 3rd party modifications.
-
Page 5: Operating Instructions
SETTING UP THE REFRIGERATOR Once you have performed the following steps, your refrigerator should be fully operational. If not, check the power supply and electricity source. If you have any questions, contact your SAMSUNG service center. Place the refrigerator in an appropriate... -
Page 6: Control Panel
CONTROL PANEL FREEZER BUTTON To set the freezer temperature, press this FRIDGE BUTTON button repeatedly to change the set tem- To set the fridge temperature, press this button perature in sequence between repeatedly to change the set temperature in 8°F and -14°F. sequence between 34°F and 46°F. -
Page 7: Digital Panel
DIGITAL PANEL Freezer indicates the current freezer temperature. Fridge indicates the current refrigerator temperature. Quick Cool, Thaw, and Select show the status of the CoolSelect Zone Drawer Power Freeze • This light goes on when you press the Power Freeze button. Press this button to quickly return the freezer to its set temperature. -
Page 8: Temperature Control
TEMPERATURE CONTROL Freezer Refrigerator • The refrigerator temperature can be set between • The freezer temperature can be set between 46°F and 34°F. 8°F and -14°F. • Press the Fridge. button repeatedly until the desired • Press the Freezer. button repeatedly until the desired temperature is shown in the temperature display. -
Page 9: Shelves And Bins
SHELVES AND BINS Freezer Xtra Space Door Bin Ice Maker Light Ice Chute Glass Shelf Wire Shelf Light Switch Tilt Pockets Plastic Drawers Wire Drawers Front Leg Cover Refrigerator Dairy Compartment Water Filter Compartment Light (upper) Wine Shelf Spill-proof glass Shelf Gallon Door Bin Light Switch Foldable Shelf... -
Page 10: Food Storage Guide
FOOD STORAGE GUIDE FROZEN FOOD STORAGE IN FREEZER Ice chute Do not put your fingers, hands or any other unsuitable objects in the chute or ice-maker bucket, as this may result in personal injury or material damage. WARNING Door Bin •... - Page 11 FOOD STORAGE GUIDE CHILLED FOOD STORAGE IN REFRIGERATOR Wine Shelf • Place your wine bottles on the shelf to maintain their taste. Tempered Spill Proof Glass Shelf • Can be used to store all types of chilled food. • Safe and break resistant. •...
-
Page 12: Coolselect Zone
CoolSelect Zone Drawer GUIDE “Quick Cool” Button • You can use the Quick Cool feature with the CoolSelect Zone • “Quick Cool” allows 1~3 canned beverages to cool within 60 min. • To cancel this option, press the “Quick Cool” button again. CoolSelect Zone returns to the previous temperature. - Page 13 CoolSelect Zone Drawer GUIDE “Select” Button Soft Freeze • When “Soft Freeze” is selected, the temperature on the digital panel displays 23°F(-5 C), regardless of the set temperature of the refrigerator. • “Soft Freeze” temperature helps keep meat and fish fresh for longer.
-
Page 14: Removing The Freezer Accessories
REMOVING THE FREEZER ACCESSORIES Glass Shelf Ice Maker Bucket • Remove the bucket by lifting up and pulling out. • Pull the shelf out as far as it goes. Then lift it up and remove it. Door Bin Front Leg Cover •... -
Page 15: Care And Cleaning
CARE AND CLEANING Interior • Clean the accessories with a mild detergent, then wipe out with a dry cloth. • After washing the accessories, make sure that they are dry before using them again. Exterior • Wipe the digital panel and display panel with a clean cloth. •... -
Page 16: Changing The Interior Light
CARE AND CLEANING Twin Deodorizer • Remove the cover with a flat blade screw driver as shown. • Take out the cartridge from the cover and soak it in clean, warm water for at least 4 hrs. Completely dry out the cartridge in sunlight for at least 8 hrs in an open area. •... -
Page 17: Water Filter
Ordering replacement filters • To order more water filter cartridges, call 1-800-SAMSUNG and ask for accessory Part # DA29- 00003B or contact your authorized Samsung dealer. DOORS The refrigerator doors have a special door opening and closing feature to make sure that they close all the way and are securely sealed. -
Page 18: Installation Instructions
INSTALLATION OF THE REFRIGERATOR Checking the Dimensions of your Entrance Door Check the dimensions of your entrance door to determine whether the refrigerator can pass through it. 26.1 Capacity (Cu. Ft) Width 35.9" without Hinge 68.8" Case Height Dimension with Hinge 70"... -
Page 19: Removing The Refrigerator Doors
REMOVING THE REFRIGERATOR DOORS Removing the Front Leg Cover Open the freezer and refrigerator doors, and then take off the front leg cover by turning the three screws counter-clockwise. FRONT LEG COVER SCREW Separating the Water Supply Line from the Refrigerator 1) Remove the screw from clamp ( ). - Page 20 REMOVING THE REFRIGERATOR DOORS • Lift the door straight up. • Be careful not to pinch the water tubing and wire harness on the door. NOTE • Place doors on a protected surface. • Unplug the refrigerator from the power supply. Removing the Freezer Door 1) With the door closed, remove the upper hinge cover (➀) using a screwdriver, and then disconnect the wires (➁).
- Page 21 REMOVING THE REFRIGERATOR DOORS Removing the Refrigerator Door 1) With the door closed, remove the upper hinge cover (➀) using a screwdriver, and then disconnect the wires(➁). 2) Remove all hinge screws ( ) and ground screw ( ) counter-clockwise, and take off the upper hinge ( ) in the direction of the arrow ( ).
-
Page 22: Reattaching The Refrigerator Doors
REATTACHING THE REFRIGERATOR DOORS Reattaching the Freezer Door 1) Insert the lower hinge ( ➀ ) in the bracket (➁). 2) Before reattaching the freezer door, insert the hose ( ➂ ) in the lower side of the door into the hole in the lower hinge ( ➃... - Page 23 REATTACHING THE REFRIGERATOR DOORS Reattaching the Refrigerator Door 1) Insert the lower hinge ( ➀ ) in the bracket (➁). 2) Align the hole in the refrigerator door (➂) over the lower hinge and push down (➃). 3) Insert the upper hinge shaft (➄) into the hole at the top of the door(➅). After levelling between the upper hinge hole (➆) and cabinet hole (➇).
- Page 24 REATTACHING THE REFRIGERATOR DOORS Reattaching the Water Supply Line 1) While pressing the front face of coupler (➁), insert the water line (➀) in the coupler. 2) Tighten the screw on the clamp ( ). 1) Push the "A" collar to the "B" body and hold. Tube must be fully inserted to the marked line to avoid leaks.
-
Page 25: Leveling The Refrigerator
LEVELING THE REFRIGERATOR Make sure the refrigerator is level before adjusting its doors. The doors will be uneven if the refrigerator is not level. The front of refrigerator is adjustable. NOTE Insert a flat-blade screwdriver (-) ( ➀ ) into a slot of Case 1) Freezer door is lower than the control lever (➁), turn it clockwise and level the that of the refrigerator... -
Page 26: Adjusting The Clearance Between The Doors
ADJUSTING THE CLEARANCE BETWEEN THE DOORS Adjust Leveling first. NOTE Making small adjustments between doors. If the door of the freezer is lower than that of the If the door of freezer is higher than that of the refrigerator. refrigerator. Adjustment part Adjustment part Please open the doors and adjust them as follows:... -
Page 27: Checking The Water Dispenser Line
4) Ensure the water storage tank inside the refrigerator is properly filled initially. Push the water dis- penser lever until the water runs from the outlet. A Water line installation kit is available at extra cost from your dealer. Samsung recommends using a water supply kit containing copper tubing. -
Page 28: Installation Of The Water Dispenser Line
INSTALLATION OF THE WATER DISPENSER LINE Connect the water line to the refrigerator. 1) Slip the compression nut through the provided Refrigerator plastic tubing. Ferrule 2) Tighten the compression nut onto the 1/4” Compression Nut (1/4 (Purchased) compression fitting. (Provided) Do not overtighten the compression nut. - Page 29 INSTALLATION OF THE WATER DISPENSER LINE Remove any residual matter inside the water supply line after installing filter. 1) Turn on the main water supply & shut-off the valve of the water supply line. WATER 2) Run water through the dispenser until the water runs clear (6~7 minutes).
- Page 30 TROUBLESHOOTING The refrigerator does not work at all or it does not Ice is not dispensed chill sufficiently • Did you stop the ice making function? • Check that the power plug is properly connected. • Is there any ice in the ice storage unit? •...
- Page 31 MEMO...
-
Page 32: Operating Instructions(I.c.e. Pad)
I.C.E. PAD Owner s Manual... -
Page 33: General Information
GENERAL INFORMATION I.C.E. PAD Major Features. Function Description Processor Intel PXA255 400MHz NOR Flash:4MB NAND Flash : 128MB Memory SDRAM : 128MB Display 800x600 10.4” TFT LCD WinCE.Net 4.2 AC adapter output +14V DC 2.57A AC power adapter input 110~240V AC, 50/60Hz Battery 2400 mAH x 3 Cell Smart Battery Headphone port, AC Adaptor port... - Page 34 GENERAL INFORMATION I.C.E. PAD And Transmitter. I.C.E. PAD : This is a device that works with the Transmitter to provide convenient features including wireless TV, wireless radio, food reminder, family message, memo, scheduler and today functions. Food Family Management Message Scheduler Radio Memo...
-
Page 35: Views Of I.c.e. Pad And Transmitter
VIEW OF I.C.E. PAD/TRANSMITTER View of I.C.E. PAD. Front view Power Button : - Turns the system power on and off. Volume Control Button: - Controls the volume of the TV and Radio. Channel Control Button : - Controls the channel of the TV and Radio. LCD : - This displays touch screens. - Page 36 VIEW OF I.C.E. PAD/TRANSMITTER Rear view Stylus pen Stylus pen: - Use to touch the screen. Stand : - Allows you to stand the I.C.E. PAD on a desk. Battery Case : - Built-in battery case. A/S port : [Rear view ] - Service port (for service only).
- Page 37 VIEW OF I.C.E. PAD/TRANSMITTER View of Transmitter. Front view Status lamp : This displays the transmission status of the wireless signal. - If this lamp blinks, the Transmitter is sending a signal to the I.C.E. PAD. Power lamp : This displays the Transmitter power status. - On : The Transmitter is in power on mode.
-
Page 38: I.c.e. Pad Power Management
I.C.E. PAD POWER MANAGEMENT How to turn on the I.C.E. PAD. Press the power button on the front of the I.C.E. PAD. In power on mode, power lamp will be on. Food Family Management Message Scheduler Radio Memo How to turn off the I.C.E. PAD. Power off mode - In order to shut down the I.C.E. - Page 39 I.C.E. PAD POWER MANAGEMENT How to connect an adapter. Connect an adapter to the I.C.E. PAD. Connect the adapter's AC plug to a wall outlet. Do not connect an adapter to earphone port. - It may cause malfunction. CAUTION Battery Management. The amount of battery power remaining will be displayed with an icon( ) in the upper part of the screen.
-
Page 40: How To Use Virtual Keyboard
HOW TO USE VIRTUAL KEYBOARD How to use the virtual keyboard. You can use the on-screen keyboard to type in text on the screen. How to bring up the on-screen keyboard. - Food Management function : Choose the "memo" button( ) or written your memo. - Page 41 HOW TO USE VIRTUAL KEYBOARD In order to continue special characters mode, choose " " key. NOTE Handwriting mode This enables you to handwrite text using the stylus pen. Activates the basic Keyboard Recognizes numbers Recognizes special Characters Recognizes English Characters Activates the Spanish keyboard writing recognition mode...
-
Page 42: User Interface
USER INTERFACE How to control touch point. This setting helps to calibrate the I.C.E. PAD for use with the Stylus Pen. - Hold the stylus pen and press down lightly on the center of the "+" mark. - Repeat as the '+" mark moves on the screen. (refer to screen) - After finishing touch point setting, touch a screen within 30 seconds in order to apply setting. - Page 43 USER INTERFACE Food Management This feature helps you to keep track of food in the fridge and its expiration date. Food Family Management Message Scheduler Radio Memo [Main screen] [I.C.E. PAD front view] [Saved food display mode] [Select category mode] [Create new mode] [Monthly calendar] How to enter a new food item...
- Page 44 USER INTERFACE How to change food item. 1. [Saved food display mode] Choose the window containing the food item you previously entered. This window is directly above the calendar window. 2. [Edit mode] Change the contents using the screen keyboard and calendar.
- Page 45 USER INTERFACE [Daily mode ] [Input mode [Input mode 3. [Daily mode] Choose the "New" button( ), and then it will change to "Input mode". 4. [Input mode ] Type the content of your memo using the screen keyboard. If you choose the "Recent" button( ), you can see the contents that were input recently.
- Page 46 USER INTERFACE How to change your schedule. 1. [Daily mode] Choose the desired schedule to change. 2. [Edit mode] Change the information using the screen keyboard. - To save changes, press the "Save" button( - To cancel the changes, press the "Cancel" button( [Edit mode] How to delete your schedule.
- Page 47 USER INTERFACE Special Day(Birthday, Party, Wedding and Anniversary) Food Family Management Message Scheduler Radio Memo [Main screen] [I.C.E. PAD front view] [Monthly mode] How to enter new special day. 1. Choose the "Schedule" icon on the main screen or press the "Schedule" button on the I.C.E. PAD. 2.
- Page 48 USER INTERFACE How to change special day. 1. [Saved special day mode] Choose the desired special day to change. 2. [Edit mode] Change the information using the screen keyboard. - To save the changes, press the "Save" button( - To cancel the changes, press the "Cancel" button( [Edit mode] How to delete your special day.
- Page 49 USER INTERFACE 4. [Input memo] Press the "Screen", "Brush" and "Color" button, and then pop up window is displayed. Choose the desired background, pen thickness and pen color. - Eraser( ) : Select to erase the inputted memo in pen mode. - Pen( ) : Select to input a memo in pen mode.
- Page 50 USER INTERFACE Family Message. This mode enables you to leave a voice or text message for your family members or roomates. Food Family Management Message Scheduler Radio Memo [Main screen] [I.C.E. PAD front view] [Saved family message mode] How to leave a new voice message. 1.
- Page 51 USER INTERFACE How to leave new text message. 1. [Saved family message mode] Choose the "Write" button ( ), and then it will change to "Input mode". 2. [Input mode ] Choose the person that you want to receive the text message. Enter the text message using the stylus pen or screen keyboard.
- Page 52 USER INTERFACE Setting. Screen - This menu displays the I.C.E. PAD user screen properties including brightness, touch point settings and power saving time settings. [Main screen] [Setting-Screen mode] How to control screen brightness 1. Choose the "Settings" icon on the main screen, and then it will change to Screen. 2.
- Page 53 USER INTERFACE Sound - This menu enables you to set the I.C.E. PAD's sound properties including key volume, alarm volume and alarm sound settings. [Setting-Screen mode] [Setting-Sound mode] How to set the key volume. 1. Choose the "Sound" tab ( ) to bring up the sound mode.
- Page 54 USER INTERFACE Today. This menu displays food management, schedule and special day. [Main screen] [Today mode] How to use today. 1. Choose the "Today" button ( ) in the upper right corner of the screen to bring up the Today mode. 2.
- Page 55 USER INTERFACE How to connect the AM Antenna. The AM antenna can be : - Placed on a stable surface. - Fixed to the wall/base/floor, etc. (you must first remove/clean the base) To assemble the AM loop antenna. To connect the AM loop antenna cords. - Connect black cord to the black terminal, and the white cord to the white terminal.
- Page 56 USER INTERFACE How to watch TV. 1. Press the "TV" button on the I.C.E. PAD, and then the default TV mode will be shown. 2. In the default TV mode, a small TV screen and TV control section will be dis- played.
- Page 57 USER INTERFACE - To watch TV, you have to turn on the Transmitter and connect the TV antenna cable(sup- plied) to the ANT_IN port of the Transmitter and the other end to an Antenna/Cable TV. NOTE - If the TV cable is connected through external equipment (such as a set-top box), you can- not change channels.
-
Page 58: Installation Instructions(I.c.e. Pad)
HOW TO INSERT THE I.C.E. PAD IN THE DOCKING STATION OF THE REFRIGERATOR When you put I.C.E. PAD in the docking station of the refrigerator, make sure the I.C.E. PAD screen faces front. Do not drop the I.C.E. PAD. It may cause malfunction and personal injury. CAUTION After extensive use,the surface of the I.C.E pad may be hot. -
Page 59: Troubleshooting
TROUBLESHOOTING When the following message is displayed. "Battery is low. Please connect external power supply." • Save your data and recharge the battery with the AC adapter or the docking station of the refrigerator. When the following message is displayed. "Memory is full. -
Page 60: Consumer Support
SAMSUNG or SAMSUNG's authorized service center. SAMSUNG will repair or replace any part found to be defective, at our option and at no charge as stipulated herein, with new or reconditioned parts during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. - Page 61 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Samsung Electronics America, Inc. 105 Challenger Road Ridgefield Park, NJ 07660-0511 1-800-SAMSUNG(1-800-726-7864) www.samsung.com...
