Panasonic TH-43FS432M Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. LED TV
  5. TH-43FS432M
  6. Service manual

Panasonic TH-43FS432M Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TH-43FS432M
7N07T

Advertisement

loading

Related Manuals for Panasonic TH-43FS432M

Summary of Contents for Panasonic TH-43FS432M

  • Page 1 TH-43FS432M 7N07T...

  • Page 6: Table Of Contents

    CONTENT CONTENT-----------------------------2 Technical Specification------------3-14 Block Diagram ----------------------15 List of key parts-------------------16 IC BLOCK Diagram--------------------17-21 MAIN PCB-TOP------------------------22 Circuit Diagrams--------------------24...

  • Page 7: Technical Specification

    Technical Specification 1. Application Area: This product standard is use for LED 7N07T 43PE2A chassis. 2. Specification: All the standard are measured under following conditions without other specification. 2.1 Ambient Temperature: 20+/-5℃ 2.2 Relative Humidity: 65+-10％ 2.3 Power Supply Voltage: Standard Input Voltage(100～240V AC 50/60HZ) 2.4 Adjust after 20 minutes warm-up.
  • Page 8 CB Compliance 5. Video Item Unit Remark Linearity Distortion, Vertical ％ Linearity Distortion, Horizontal ％ Trapezoidal Distortion, Vertical ％ Trapezoidal Distortion, Horizontal ％ Over scan, Vertical ％ Over scan, Horizontal ％ Brightness Maximum Nit(s) Video Noise Limited dBuV Sensitivity(@S/N=30dB) VHF Video Noise Limited dBuV Sensitivity(@S/N=30dB) UHF...
  • Page 9 Audio ouput,L/R,at 10％ THD Audio ouput,Center Stereo Separation Speaker Impedance Speaker Power rating 8. Power Item Unit Remark DC Voltage, Audio DC Voltage, Tuner 9. External Interface Item Unit Remark Video Input Level 75 ohm Video Input Frequency Response Video Input S/N Audio Input Level Vrms Audio Input Frequency Response...
  • Page 10 sensitivity,Straight REMOCON Working sensitivity,T/B/L/R Close caption sensitivity dBuV Teletext sensitivity Resonance of unit(sweep freq:50~1000) 11. Customer Menu Setup(as shipped condition) Item Specification Remark Standard Standard Volume Mute Input Mode RF-Air Customer menu language English Based on different order Sleep Timer Auto sleep Surround Noise Reduction...
  • Page 11 picture Brief Information Product Name 43PE2A Chassis Name 7N07T Key functions SMART TV Target Market INDIA Product Category Product Positioning Product size 43" Panel Specification Model Number 3.1.1 Panel Manufacturer Skyworth 3.1.2 Model Number 7626-T4300L-T211 Mechanical 3.2.1 Panel Size 43" 3.2.2 Dimension 3.2.3...
  • Page 12 Receiving System 4.1.1 PAL BG/I/DK/ + NTSC-M PAL/SECAM BG/DK/I + SECAM 4..1.2 PAL/SECAM BG/DK/I L/L" 4.1.3 PAL M/N + NTSC-M Receiving System 4.2.1 ISDB-T/ISDB-S/SBTVD-T 4.2.2 ATSC 4.2.3 DTMB 4.2.4 DVB-T 4.2.5 DVB-T2 4.2.6 DVB-C 4.2.7 DVB-S 4.2.8 DVB-S2 DVB-CI(*Not a system, but 4.2.9 important to indicate the type of DTV)
  • Page 13 External Signal Receiving System Composite 4.4.1 PAL 50Hz/60Hz Input 4.4.2 SECAM 4.4.3 NTSC 3.58 4.4.4 NTSC4.43 Component 480i /480p/720p/1080i 4.4.5 Input (60Hz) 576i /576p/720p/1080i 4.4.6 (50Hz) 1080P 4.4.7 24Hz/25Hz/30Hz/50Hz/60Hz 4.4.8 PC Input VGA (640 x 480) 4.4.9 S-VGA (800 x 600) 4.4.10 XGA (1024 x 768) 4.4.11...
  • Page 14 4.4.23 Media player formats Refer to sheet "Mediaplayer Formats" Features Picture 5.1.1 Picture Mode Standard/Soft/Vivid/User 5.1.2 Picture Size 16:9/4:3/Zoom1/Zoom2/Just Scan/Panorama/Auto 5.1.3 Picture Freeze 5.1.4 Back light Adjust 5.1.5 Auto Format 5.1.6 3:2 Pull Down 5.1.7 4:3 Stretch 5.1.8 Comb filter 5.1.9 PIP(Single tuner) 5.1.10...
  • Page 15 5.4.4 Subtitle 5.4.5 5.4.6 Channel list 5.4.7 Favorite Channel List 5.4.8 Channel Editor 5.4.9 Sleep Timer 5.4.10 On/Off timer 5.4.11 Channel Swap timer 5.4.12 Blue Screen AC Input 5.5.1 AC Input Range 100-240V AC (-10%,+10%) 5.5.2 AC Plug Type 5.5.3 AC Cable Length 1.5m 5.5.4...
  • Page 16 5.10.1 FAT16 5.10.2 FAT32 5.10.3 NTFS Yes(Only read) 5.11 Middle Ware 5.11.1 MHEG5 5.11.2 Ginga 5.11.3 5.11.4 HbbTV 5.12 Wifi 5.12.1 Wifi Dongle 5.12.2 Wifl Built in Terminals Configuratio Terminal Direction (Side and Side and Rear Bottom & Side and Rear) Input 6.2.1...
  • Page 17 Digital Audio Output (Coaxial 6.3.3 1 ( Coaxial, Rear) & Optical) 6.3.4 Earphone 1 (Side) Diagram of Terminal Configuration Mechanical Spec Cabinet 7.1.1 Cabinet color For front back stand Operation 7.1.2 Keys / Touch 5 in 1, Keys outside sensor AC Power 7.1.3 Mechanical power switch...
  • Page 18 Loading quantity 7.2.7 (20GP/40GP/40GP) without pallet Stand build in Packing Box 7.2.8 (together or separately ) Accessories Remote Controller 8.1.1 Type No. PANASONIC 8.1.2 Battery Option Instruction Manual 8.2.1 Paper size 8.2.2 Printing Color Languages (Refer to Sales 8.2.3 Country Sheet) 8.2.4...

  • Page 19: Block Diagram

    9.11 DviX HD 9.12 DviX+HD 9.13 Optional 9.14 DLNA Optional 9.15 9.16 Energy Star 9.17 Block Diagram List of key parts -15-...

  • Page 20: Ic Block Diagram

    Spec. name position model MODULE IR RECEVIER M0K1 SDR138 5300-147438-0S00 38KHZ SPEAKER SPEAKER SL411-08E 53FJ-3932E2-0020 OHM 8W MAX CRYSTAL X2T1 49S-16.000-20-30/A 16MHz 4900-127053-R000 NT72563BG-AC SMD IC 475V-N72561-4240 NOVATEK H5TQ2G63GFR-RDC SMD IC 4711-H5T2G6-0960 HYNIX H5TQ4G63CFR-RDC SMD IC 4711-H5T4G7-0960 HYNIX MX25L1606EM2I-12G U0M1 SMD IC 16MB SPI FLASH 47F2-G25161-0080...
  • Page 21 3.TAS5707PHPR -17-...
  • Page 22 NT72563M2 NT72561M2 CI/TS VER1 GPC_0/STSIN0_CLK/INT_1/I2C_MB_SDA CI_A0 R1C14 56Ω VER2 GPB_2/CI_HA0/CI_ALE0/ARM_UART_D_RX/I2C_MF_SDA/I2S_IN_WS/NAND_D0 GPC_1/STSIN0_VALID/INT_2/I2C_MB_SCL CI_A1 13/18V_SW R1C15 56Ω GPB_3/CI_HA1/CI_ALE/I2S_IN_BCLK/NAND_D1 GPC_2/STSIN0_START/INT_3/I2C_MC_SDA 13/18V_SW CI_A2 LNB_EN R1C12 56Ω GPB_4/CI_HA2/USB2_PWEN/NAND_D2 GPC_3/STSIN0_DATA/INT_4/I2C_MC_SCL LNB_EN CI_A3 R1C16 56Ω C0C8 NC/10pF GPB_5/CI_HA3/USB3_PWEN/NAND_D3 CI_A4 R1C10 56Ω CI_A5 GPB_6/CI_HA4/FRC_Dimming1/DSU_BRE/leonDSU_BRE/oproc_DSU_BRE/NAND_D4 CI_VCC R1C11 56Ω CI_A6 GPB_7/CI_HA5/FRC_Dimming2/DSU_ACT/leonDSU_ACT/NAND_D5 GPA_0/TSI1_ERR/STSI0_ERR/I2C_MA_SDA R1C13...
  • Page 23 +12V_PWR to 5VSTB +12V_PWR to 3V3STB +12V_PWR to 3V3STB （DC - DC 价 格0. 0 7 8 U S D 规 格 标 称 最 大 3 A 5 8 0 K H Z 输入 电 压 范 围 4 . 5 V- 1 7 V 轻 载 高 效 　 优 选 ） （DC - DC 价...
  • Page 24 C3D1 470pF R3D4 R3D5 R3D6 R3D7 R3D8 R3D9 R3D41 R3D42 R3D43 R3D44 R3D45 R3D46 20KΩ 20KΩ 20KΩ 20KΩ 20KΩ 20KΩ 20KΩ 20KΩ 20KΩ 20KΩ 20KΩ 20KΩ R3D2 R3D1 R3D3 DANGER1 C2D3 R2D10 D2D4 D2D3 FB1D1 48Ω/100MHz 100Ω 100Ω 100Ω D1D0 D1D2 3.9nF 100KΩ...
  • Page 25 R4B36 33Ω L4B1 R4B37 33Ω 90uH LED+ C4B1 220pF +42V D4B1 R4B32 LV10T100D 470KΩ C4B5 100nF D4B2 Q4B1 100V L4B2 1N4148W ME15N10-G/TO252 R4B33 R4B1 100uH 470KΩ 200KΩ 100V 100V C4B2 C4B3 R4B2 R4B3 R4B4 R4B26 100uF 100uF +12V_PWR 51Ω 51Ω 51Ω...
  • Page 26 Amplifier Circuits TAS5707 FB0A4 60Ω/100MHz 22.1KΩ R5A8 R5A9 R6A0 470Ω 470Ω 60Ω/100MHz FB0A3 C7A8 C7A9 C7A7 NC/2.2nF MAIN3V3 +3.3V_AMP 4.7nF 4.7nF C8A1 C8A2 C8A0 1uF F0A3 47nF 47nF SPEAKER_L- 5A/32V +12V_NOR VDD_AMP C8A3 33nF L0A7 22uH R6A1 22Ω C8A4 VDD_AMP C8A8 CE0A7 330pF...
  • Page 27 16MB SPI NOR FLASH 4GB Toshiba eMMC THGBMBG5D1KBALL STBC3V3 R0M1 4.7KΩ U0M1 SPI_CS0 SPI_DI R0M2 0Ω C0M1 SPI_CLK /HOLD SPI_WP# R0M3 22Ω SPI_DO SCLK U0M2 100nF eMMC_D0 MX25L1606EM2I-12G R0M4 R1M4 0Ω eMMC_D1 DAT0 NC32 4.7KΩ R1M5 0Ω eMMC_D2 DAT1 NC33 R1M6 0Ω...
  • Page 28 Tuner circuits MXL661 for ATV, DVB-C/T/T2 MXL661-----双 头 +3.3V_TUNER R1T13 470KΩ VDD1V8 靠 近 IC 引 脚 22放 置 C2T09 1uF C1T84 10nF T_RST R1T96 NC/0Ω TU_RST X0T5 L5T6 Tuner Reset By GPIO 16MHz 33nH 地 面 接收 如 D V B - T 2 ， I S D B - T 在 东 南 亚 ， 非 洲， C2T52 5.6pF 要...
  • Page 29 HDMI Interfaces Interfaces for VGA, RCA and YPbPr from NT72562 RCA Interface NT72563M2 HDMI_SOURCE2_WITH CEC & ARC & POH Close to SoC VGA_R JA1J3 HD_AV_L R3J4 C4J1 4.7uF HD_AV_L0 VGA_G TVDAC_OUT FB0J2 60Ω/100MHz 10KΩ STBC5V HDMI_PWR HD_AV_L0 YELLOW HD_AV_R 6.3V SOC_SC_R SOG_1 FB0J1...
  • Page 30 LED Control Power Enable/BL Enable/PWM Adjust Interfaces of IR/KEY/Indicator/Light Sensor Light Sensor In Power Enable STBC3V3 R0S3 LIGHT_SEN LIGHT LIGHT_SEN NC/100Ω R0S3 for TOSHIBA R0S4 STBC3V3 1KΩ R0S5 STANDBY IR/KEY Connector Compatible Indicator on Board STANDBY 100Ω R0S16 LED0S1 4.7KΩ R0S2 STBC3V3 CN0S1...
  • Page 31 DRAM1V5 NT72563M2 DDR_MA0 DDRA_DQL0 DDR_MA1 DQ16 DDRA_DQL1 DQ17 DDR_MA2 DDRA_DQL2 DQ18 DDR_MA3 DDRA_DQL3 DQ19 DDR_MA4 DDRA_DQL4 DQ20 DDR_MA5 DDRA_DQL5 DQ21 DDR_MA6 DDRA_DQL6 DQ22 DDR_MA7 DDRA_DQL7 DQ23 DDR_MA0 DDRA_DMU DDR_MA8 DDR_MA1 DDRA_DQSU DDR_MA9 DDRA_DQU0 DQSU DQ24 DDR_MA2 DDRA_DQSUn DDR_MA10 DDRA_DQU1 /DQSU MA10 DQ25 DDR_MA3...
  • Page 32 1、 删 除 D VB- S2 L NB Po w e r C i rc ui t s 3、 删 除 I S DB Co m p a ti b l e 9 、其他电路修改 删 除 : R4 T 4 删...
  • Page 33 12V/1A ME9435 VCC_Pannel 12V/2A TAS5707 12V/500mA LNB power AOZ1236 MAIN1V1/6A MP1495 MAIN3V3/3A MP1495 DRAM1V5/3A NTD72562 +12V_NORMAL LDO(reserved) +3.3V_TUNER ME4953 +5V_NORMAL 5V_USB/1A & MHL/1A SWITCH 5V_MHL/1A 5V/500MA PCMCIA POWER IN +5V_STB +3V3_STB MP1495 eMMC_1V8 Power Tree ME9435A +12V_Panel PANEL_LVDS VDD_AMP TAS5707PHPR STANDBY SIGNAL +12V_PWR...
  • Page 34 Power for panel LVDS Signals Interface +12V_Panel CN-F FB0L1 31Ω/100MHz U0L1 +12V_NOR PANEL-GND R0L9 C0L2 4.7KΩ R3L3 NC/0Ω RP0L6 0Ω X 4 AMP_SCL RP0L1 0Ω X 4 C0L3 C0L4 220nF C0L6 C0L1 R3L4 NC/0Ω AMP_SCL LVDS_A1+ LVDS_B1+ AMP_SDA LVA1P1 LVB1P1 R0L1 22uF R3L5...
  • Page 35 SOC Reset STBC3V3 STBC3V3 NT72563M2 USB_DP0 DP0: USB1 USB_DM0 USB0_D+ ARM_TXB R289 4.7KΩ MAIN3V3 USB0_D- GPC_4/ARM_UART_B_TX/INT_5/ARM_UART_A_TX ARM_RXB R290 4.7KΩ R219 NC/10KΩ R220 10KΩ DP1: BT USB_DP1 GPC_5/ARM_UART_B_RX/INT_6/ARM_UART_A_RX USB_DM1 USB1_D+ USBx4 USB1_D- DP2: USB2 R285 1.5KΩ MAIN3V3 USB_DP2 GPC_16/I2C_MD_SDA R286 1.5KΩ R231 NC/10KΩ...
  • Page 36 VDD15_MMU CORE-1V HDMI AUDIO LVDS TVDAC DEMOD TVADC NT72561M2 STBC_VCC VDD33_STBC VDD33_ETHERNET VDD33_XTAL POWER/GND C305 10uF VDD10_STBC 6.3V AC22 C306 100nF VDD_eMMC eMMC_1V8 C307 100nF NT72563M2 60Ω/100MHz STBC_VCC STBC3V3 STBC3V3 MAIN3V3 VDD33_USB C220 R581 0Ω 2.2uF C221 R582 0Ω NC/40Ω/100MHz 100nF HEAT SINK AO3401A...

  • Page 37: Main Pcb-Top

    MAIN PCB 1.TOP 2、BOTTOM -18-...
  • Page 38 -19-...
  • Page 39 43 INCH TV 8518290000 AC LINE CORD 1500MM 0.75*2 VDE PLUG(BEND 5942-A15203-1080 Power Cord TH-43FS432M 43 INCH TV 8544422900 HANDSET ASS'Y HS-0404J-00 "Panasonic TV" 539C-260404-W000 Remote TH-43FS432M 43 INCH TV 8543709990 FFC 51 PINS P=0.5MM L=729MM(60+300+165+1 5900-F72130-5100 LVDS Cable TH-43FS432M...
  • Page 40 BOM LIST 编号 物料描述 数量 单位 207N-07TQPE2AX01 7N07T-43PE2A PANEL BOM 7N07T-43PE2A00-00 ELE. BOM 7N07T-43PE2A FWBX-QPE2AAB7N07T MKD STR.LED BOM 7N07T-43PE2A(PANASONIC) ZL00-N72563-03 PATENT COMPONENTS NT72563C 7N07T-43PE2A 2043-T7N07TX-K0 ELE.SCREEN ASS'Y(7626-T4300L-K101)7N07T- 7N07G-01SB0W-00 (TI) MAIN MATCH SCREEN ASS'Y(7618-T4000Q 168P-G3U03C-W7 LED POWER ASS'Y 75W FUJI(FA8A00N) INPUT 7626-T4300L-K101 43"...
  • Page 41 6463-011600-T0 SMD FERRITE BEAD (1.6 X 0.8MM) TAPE TYPE 431R-NF180C-T5 SMD NPO CERAMIC CHIP CAPACITOR 18PF 50V 4311-CA475D-T2 SMD CERAMIC CAPACITOR 4.7UF 6.3V +/-10%( 411Q-CA2200-T0 SMD RESISTOR 22 OHM 1/10W +/-5% (1.6X0.8 431R-CF1030-7200 SMD X7R CERAMIC CHIP CAPACITOR 10NF 50V 4897-S11000-AS80 SMD POWER INDUCTORS 10UH +/-20% 3.0A(6.0 4311-CC225D-T1...
  • Page 42 411Q-CA1020-2200 SMD RESISTOR 1K OHM 1/16W +/-1% (1.0 X0. 411Q-CA2231-2200 SMD RESISTOR 22K1 OHM 1/16W +/-1% (1.0*0 4391-CT1020-7500 SMD X7R MLCC 1000PF 2KV +/-10% (3.2*1.6M 4661-T39060-T0 SMD TRANSISTOR LMBT3906LT1G PNPPACKAGE ( 482J-S082D0-4200 SMD CHIP COIL 8.2NH +/-3% 380mA (1.0*0.5 4722-T61380-0140 SMD IC TPA6138A2PWR TI(HEADPHONES DRIVE) 4393-CF224E-T2 SMD CERAMIC CHIP CAPACITOR 0.22UF 50V +/...
  • Page 43 614G-150010-1910 SMD HDMI SOCKET BLACK V-TYPE 19PIN 4311-CD1050-7300 SMD X5R CERAMIC CHIP CAP. 1UF 25V +/-10% 4876-2833C0-5200 SMD RF CERAMIC INDUCTOR 33NH +/-5% 200MA 484G-S222A0-AS00 SMD MOLDED INDUCTOR 2.2UH ±20% 10A (6.6* 431R-NF6800-5200 SMD NPO MLCC 68PF 50V +/-5% (1.0*0.5MM) 6008-500429-T0 SMD FUSE 5A/32V FAST TIME-TO-TRIP UL/CSA 411Q-CA0000-T0...
  • Page 44 431R-NF8200-5200 SMD C0G CERAMIC CHIP CAPACITOR 82PF 50V 431R-CF102D-T5 SMD CERAMIC CHIP CAPACITOR 0.001UF 50V + 411Q-CA5130-2200 SMD RESISTOR 51K OHM 1/16W +/-1% (1.0*0. 6136-080010-0600 USB SOCKET (180*D PLUG BLACK) 6146-089110-0410 USB(AF) SOCKET H-TYPE 4 PINS (13.9*13*12 544N-921120-0810 WAFER(M) P=2.0MM H-TYPE SINGLE ROW 8 PIN 614P-090020-0810 NETWORK CONNECTIONS SOCKET RJ45 V-TYPE 8 1505-M0610410-0302 HEAT SINK 2-110A# L61.2*W41.5*H5.4...
  • Page 45 4143-CA5130-T0 SMD RESISTOR 51K OHM 1/10W +/-5% (1.6x0. 4143-CB1000-T0 SMD RESISTOR 10 OHM 1/8W +/-5% (0805 TYP 4143-CB1010-T0 SMD RESISTOR 100 OHM 1/8W +/-5% (0805 TY 4143-CB1020-T0 SMD RESISTOR 1K OHM 1/8W +/-5% (0805 TYP 4143-CB1030-T1 SMD RESISTOR 10K OHM 1/8W +/-1% (0805 TY 4143-CB1230-2400 SMD RESISTOR 12K OHM 1/8W +/-1% (2.0 X 1 4143-CB2240-T0...
  • Page 46 4876-S11000-ASJ0 SMD POWER INDUCTORS 10UH ±20% 770mA 3.0* 4143-CB5600-T0 SMD RESISTOR 56 OHM 1/8W +/-5% (2 X 1.25 4628-J12N65-0S00 SMD TRANSISTOR JCS12N65T (650V/12A 250W 4300-CF473D-T1 SMD CERAMIC CHIP CAPACITOR 0.047UF 50V + 4144-CB2230-T0 SMD RESISTOR 22K OHM 1/8W +/-5% 2012 TAP 4348-AR1010-7T00 CER CAP 100PF 1KV +/-10% P=5MM TAPE 434B-AR221D-T0...
  • Page 47 1305-L0554001-0112 BLACK ACETATE CLOTH 55*40*0.18MM（AC323B) 1320-R4303300-0112 FU SPONGE ON DOWN FRAME 43E3 MODULE 1320-R4304501-0112 FU SPONGE FOR 43U67 MODULE 1509-R4300800-0225 DOWN BEZEL FOR 43TE3B CKD MODULE 1810-06003000-0004 ELECTRIC FABRIC W6*L30*T0.085MM MODULE 26SM-02506020-NH04 SCREW M2.5*6.0 (D=6，T=0.6) 26SM-02508020-NH04 SCREW SM2.5*8 1018 PLUS HARD 26TT-03008020-BH01 SCREW TT3*8 BLACK HARDEN 5926-F25130-5000 FFC 50 PINS P=0.5MM L=254M(29+200+25MM)
  • Page 48 433V-NF101C-T5 SMD NPO CERAMIC CHIP CAPACITOR 100PF 50V 433V-NF220C-T5 SMD NPO CERAMIC CHIP CAPACITOR 22PF 50V 4393-CC104D-T5 SMD CERAMIC CHIP CAPACITOR 0.1UF 16V +/- 474Z-R81880-0460 SMD IC RTL8188ETV-CG REALTEK(1T1R WLAN C 47J5-A24080-0050 SMD IC APS2408ES5-ADJ CHIPOWN (STEP-DOWN 482J-2830D0-M200 SMD RF CERAMIC INDUCTOR 3NH +/-0.3NH 100 482J-S010C0-5220 SMD CHIP COIL 10NH +/-5% 300mA(1.0*0.5MM 482J-S027D0-M210...
  • Page 50 Factory Manual 1 、How to enter and exit factory mode 1.1.1 Press Source button, and then press digital button “3”, “1”, “9”, “5” in turns to enter the factory menu. Press  and  button to choose the item ，press OK button to enter the submenu and press ...
  • Page 51 the product line. 2、In YPBPR channel ,must adjust the SD and HD two modes. 2.2 W/B ADJUST Enter factory mode, select W/B ADJUST, go to the “MODE” item to select the channel which you want to adjust then select the color temperature (Medium, Warm, Favorite,Cool). Then press  Key to go to these items you want to adjust: R Gain G Gain...
  • Page 52 3.3、press “Read” to choose the “merge.bin” file . 3.4、Press “Auto”, set parameter。...
  • Page 53 3.5、press “Run”。...
  • Page 54 4、Update software (by USB): Copy the new software (name by “MERGE.bin”) to the root directory of USB drive. Plug the drive to the USB socket (if there are two USB socket, make sure you use the socket 1). Enter MENU and select SETUP item , select “Software Upgrade(USB)” item and press OK button to begin update.
