Page 1 CC-Link IE Field Network Basic Remote I/O Module User's Manual -NZ2MFB2-16A -NZ2MF2S2-16A -NZ2MFB1-32D -NZ2MF2S1-32D -NZ2MFB2-16R -NZ2MF2S2-16R -NZ2MFB1-32T -NZ2MF2S1-32T -NZ2MFB1-32TE1 -NZ2MF2S1-32TE1 -NZ2MFB1-32DT -NZ2MF2S1-32DT -NZ2MFB1-32DTE1 -NZ2MF2S1-32DTE1...
Page 3: Safety Precautions
SAFETY PRECAUTIONS (Read these precautions before using this product.) Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle the product correctly. The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable controller system, refer to the user's manual for the CPU module used.
Page 4 [Security Precautions] WARNING ● To maintain the security (confidentiality, integrity, and availability) of the programmable controller and the system against unauthorized access, denial-of-service (DoS) attacks, computer viruses, and other cyberattacks from external devices via the network, take appropriate measures such as firewalls, virtual private networks (VPNs), and antivirus solutions.
Page 5 To prevent this, configure an external safety circuit, such as a fuse. ● Mitsubishi Electric programmable controllers must be installed in control panels. Wiring and replacement of a module must be performed by qualified maintenance personnel with knowledge of protection against electric shock.
Page 6 [Startup and Maintenance Precautions] WARNING ● Do not touch any terminal while power is on. Doing so will cause electric shock or malfunction. ● Shut off the external power supply (all phases) used in the system before cleaning the module or retightening the terminal block screws or connector screws.
Page 7: Conditions Of Use For The Product
CONDITIONS OF USE FOR THE PRODUCT (1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions; i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident; ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.
Page 8: Introduction
When applying the program and circuit examples provided in this manual to an actual system, ensure the applicability and confirm that it will not cause system control problems. Please make sure that the end users read this manual. Relevant products NZ2MFB2-16A, NZ2MF2S2-16A, NZ2MFB1-32D, NZ2MF2S1-32D, NZ2MFB2-16R, NZ2MF2S2-16R, NZ2MFB1-32T, NZ2MF2S1-32T, NZ2MFB1-32TE1, NZ2MF2S1-32TE1, NZ2MFB1-32DT, NZ2MF2S1-32DT, NZ2MFB1-32DTE1, NZ2MF2S1-32DTE1 MELIPC...
Page 9: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ..............1 CONDITIONS OF USE FOR THE PRODUCT .
Page 10 CHAPTER 8 FUNCTIONS Input Response Time Setting Function............90 Output HOLD/CLEAR Setting Function.
Page 11: Relevant Manuals
[SH-080779ENG] configuration, parameter settings, and online operations of GX Works2 e-Manual e-Manual refers to the Mitsubishi Electric FA electronic book manuals that can be browsed using a dedicated tool. e-Manual has the following features: • Required information can be cross-searched in multiple manuals.
Page 12: Terms
TERMS Unless otherwise specified, this manual uses the following terms. Term Description Cyclic transmission A function by which data are periodically exchanged among stations on the same network using link devices Link device A device (RX, RY, RWr, RWw) in a CPU module and a MELIPC that is used for communications with a slave station Master station A station that controls the entire CC-Link IE Field Network Basic.
Page 13: Chapter 1 Product Lineup
100 to 120VAC, 16 points 16A AC input module Page 19 Spring clamp terminal block 64mA 0.26kg NZ2MF2S2-16A 100 to 120VAC, 16 points NZ2MF2S2-16A AC input module DC input module Positive common/ Screw terminal block 71mA 0.30kg NZ2MFB1-32D Page 22 NZ2MFB1-...
Page 14: I/O Combined Module
I/O Combined Module Module name Input specifications, output Module Weight Model Reference specifications power supply current DC input/transistor Input part: Positive Screw terminal block 79mA 0.30kg NZ2MFB1-32DT Page 46 NZ2MFB1- output module common type 24VDC, 16 points 32DT DC input/transistor output module Output part: Sink Screw terminal block...
Page 15: Chapter 2 Part Names
PART NAMES This chapter describes part names of the I/O module. • Screw terminal block type • Spring clamp terminal block type Name Application Ethernet port Port connector for network connection. Connect an Ethernet cable. For wiring method and precautions, refer to the following. Page 83 Wiring of Ethernet cable 100M LED Indicates the link status.
Page 16 Name Application X0 LED to XF LED Indicates the ON/OFF status of the inputs. On: Input ON Off: Input OFF Y10 LED to Y1F LED Indicates the ON/OFF status of the outputs. On: Output ON Off: Output OFF I/O PW LED Indicates the status of the power supply from the external power supply.
Page 17: Chapter 3 Specifications
SPECIFICATIONS This chapter describes the specifications of the I/O module. General Specifications Item Specifications Operating ambient temperature 0 to 55 Storage ambient temperature -25 to 75 Operating ambient humidity 5 to 95%RH, non-condensing Storage ambient humidity Vibration resistance Compliant with JIS ...
Page 18: Performance Specifications
Performance Specifications Input module NZ2MFB2-16A AC input module Item NZ2MFB2-16A Station type Slave station Number of input points 16 points Rated input voltage/rated frequency 100 to 120VAC (+10%/-15%), 50/60Hz (3Hz) Rated input current 8.2mA (100VAC, 60Hz), 6.8mA (100VAC, 50Hz) Inrush current 200mA maximum within 1ms Input voltage distortion ratio Within 5%...
Page 19 ■External connection Terminal block for module power supply and FG UNIT POWER Signal name Non-insulated CABLE +24V Module power supply Terminal block for input COM B COM B COM B COM B COM B COM B COM B COM B COM B COM B COM B...
Page 20 ■Terminal block for input 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 21 NZ2MF2S2-16A AC input module Item NZ2MF2S2-16A Station type Slave station Number of input points 16 points Rated input voltage/rated frequency 100 to 120VAC (+10%/-15%), 50/60Hz (3Hz) Rated input current 8.2mA (100VAC, 60Hz), 6.8mA (100VAC, 50Hz) Inrush current 200mA maximum within 1ms...
Page 22 ■External connection Terminal block for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for input COM B COM B COM B COM B COM B COM B COM B COM B COM B COM B COM B...
Page 23 ■Terminal block for input 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 24 NZ2MFB1-32D DC input module Item NZ2MFB1-32D Station type Slave station Number of input points 32 points Rated input voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Rated input current 6.0mA TYP. (for 24VDC) Isolation method Photocoupler isolation Max.
Page 25 ■External connection Terminal block for module power supply and FG UNIT POWER Signal name Non-insulated CABLE +24V Module power supply Terminal block for input *1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG. Multiple wires cannot be connected to a terminal.
Page 26 ■Terminal block for input 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 27 NZ2MF2S1-32D DC input module Item NZ2MF2S1-32D Station type Slave station Number of input points 32 points Rated input voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Rated input current 6.0mA TYP. (for 24VDC) Isolation method Photocoupler isolation Max.
Page 28 ■External connection Terminal block for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for input *1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG or the terminal block for input. Multiple wires cannot be connected to a terminal.
Page 29 ■Terminal block for input 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 30: Output Module
Output module NZ2MFB2-16R contact output module Item NZ2MFB2-16R Station type Slave station Number of output points 16 points Rated switching voltage/current 24VDC 2A (resistance load)/point, 8A/common 240VAC 2A (COS = 1)/point, 8A/common Minimum switching load 5VDC 1mA Maximum switching load 264VAC 125VDC Output response time OFFON...
Page 31 ■External connection Terminal block for module power supply and FG UNIT POWER Signal name Non-insulated CABLE +24V Module power supply Terminal block for output Load COM B COM B COM B COM B COM B COM B COM B COM B COM B COM B COM B...
Page 32 ■Terminal block for output 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 33 NZ2MF2S2-16R contact output module Item NZ2MF2S2-16R Station type Slave station Number of output points 16 points Rated switching voltage/current 24VDC 2A (resistance load)/point, 8A/common 240VAC 2A (COS = 1)/point, 8A/common Minimum switching load 5VDC 1mA Maximum switching load 264VAC 125VDC Output response time OFFON 10ms or less...
Page 34 ■External connection Terminal block for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for output Load COM B COM B COM B COM B COM B COM B COM B COM B COM B COM B COM B...
Page 35 ■Terminal block for output 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 36 NZ2MFB1-32T transistor output module Item NZ2MFB1-32T Station type Slave station Number of output points 32 points Rated load voltage 12/24VDC (ripple rate: 5% or less) (Allowable voltage range: 10.2 to 28.8VDC) Max. load current 0.5A/point, 5A/common Isolation method Photocoupler isolation Max.
Page 37 ■External connection Terminal block for module power supply and FG UNIT POWER Signal name Non-insulated CABLE +24V Module power supply Terminal block for output Load External power supply for the output part Load CTL+ COM- Constant-voltage circuit Load power supply Load External power supply for the output part and load power supply (common)
Page 38 ■Terminal block for output 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 39 NZ2MF2S1-32T transistor output module Item NZ2MF2S1-32T Station type Slave station Number of output points 32 points Rated load voltage 12/24VDC (ripple rate: 5% or less) (Allowable voltage range: 10.2 to 28.8VDC) Max. load current 0.5A/point, 5A/common Isolation method Photocoupler isolation Max.
Page 40 ■External connection Terminal block for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for output Load External power supply for the output part Load CTL+ COM- Constant-voltage circuit Load power supply Load External power supply for the output part and load power supply (common)
Page 41 ■Terminal block for output 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 42 NZ2MFB1-32TE1 transistor output module Item NZ2MFB1-32TE1 Station type Slave station Number of output points 32 points Rated load voltage 12/24VDC (ripple rate: 5% or less) (Allowable voltage range: 10.2 to 28.8VDC) Max. load current 0.1A/point, 2A/common Isolation method Photocoupler isolation Max.
Page 43 ■External connection Terminal block for module power supply and FG UNIT POWER Signal name Non-insulated CABLE +24V Module power supply Terminal block for output Load Load COM+ CTL- Constant-voltage External power supply for circuit the output part and load power supply (common) *1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG.
Page 44 ■Terminal block for output 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 45 NZ2MF2S1-32TE1 transistor output module Item NZ2MF2S1-32TE1 Station type Slave station Number of output points 32 points Rated load voltage 12/24VDC (ripple rate: 5% or less) (Allowable voltage range: 10.2 to 28.8VDC) Max. load current 0.1A/point, 2A/common Isolation method Photocoupler isolation Max.
Page 46 ■External connection Terminal block for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for output Load Load COM+ CTL- Constant-voltage External power supply for circuit the output part and load power supply (common) *1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG or the terminal block for output.
Page 47 ■Terminal block for output 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name...
Page 48: I/O Combined Module
I/O combined module NZ2MFB1-32DT DC input/transistor output module Item NZ2MFB1-32DT Input specifications Output specifications Station type Slave station  Number of input points 16 points Rated input voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Rated input current 6.0mA TYP.
Page 49 Item NZ2MFB1-32DT Input specifications Output specifications Applicable solderless Terminal block for module Page 81 Applicable solderless terminal terminal power supply and FG Page 84 Applicable solderless terminal I/O terminal block Number of occupied stations One station Reference response time Communication cable An Ethernet cable that meets the 100BASE-TX standard For details, refer to the following.
Page 50 ■External connection Connector for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for I/O Load Load COM+ COM- Constant-voltage Load power circuit supply External power supply for the output part Load External power supply for the output part and load power supply (common) COM+...
Page 51 ■I/O terminal block 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name ...
Page 52 NZ2MF2S1-32DT DC input/transistor output module Item NZ2MF2S1-32DT Input specifications Output specifications Station type Slave station  Number of input points 16 points Rated input voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Rated input current 6.0mA TYP.
Page 53 Item NZ2MF2S1-32DT Input specifications Output specifications Communication cable An Ethernet cable that meets the 100BASE-TX standard For details, refer to the following.  CC-Link IE Field Network Basic Reference Manual Module power supply Voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Current 79mA or less (24VDC, all points ON) Weight...
Page 54 ■External connection Connector for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for I/O Load Load COM+ COM- Constant-voltage Load power circuit supply External power supply for the output part Load External power supply for the output part and load power supply (common) COM+...
Page 55 ■I/O terminal block 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name ...
Page 56 NZ2MFB1-32DTE1 DC input/transistor output module Item NZ2MFB1-32DTE1 Input specifications Output specifications Station type Slave station  Number of input points 16 points Rated input voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Rated input current 6.0mA TYP.
Page 57 Item NZ2MFB1-32DTE1 Input specifications Output specifications Reference response time Communication cable An Ethernet cable that meets the 100BASE-TX standard For details, refer to the following.  CC-Link IE Field Network Basic Reference Manual Module power supply Voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Current 79mA or less (24VDC, all points ON) Weight...
Page 58 ■External connection Connector for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for I/O Load Load COM+ COM- Constant-voltage External power supply for circuit the output part and load power supply (common) *1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG.
Page 59 ■I/O terminal block 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name ...
Page 60 NZ2MF2S1-32DTE1 DC input/transistor output module Item NZ2MF2S1-32DTE1 Input specifications Output specifications Station type Slave station  Number of input points 16 points Rated input voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Rated input current 6.0mA TYP.
Page 61 Item NZ2MF2S1-32DTE1 Input specifications Output specifications Communication cable An Ethernet cable that meets the 100BASE-TX standard For details, refer to the following.  CC-Link IE Field Network Basic Reference Manual Module power supply Voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC) Current 79mA or less (24VDC, all points ON) Weight...
Page 62 ■External connection Connector for module power supply and FG UNIT POWER Non-insulated Signal name CABLE +24V Module power supply Terminal block for I/O Load Load COM+ COM- Constant-voltage External power supply for circuit the output part and load power supply (common) *1 Only one wire can be connected to a terminal of the terminal block for module power supply and FG or the I/O terminal block.
Page 63 ■I/O terminal block 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Pin number Signal name Pin number Signal name ...
Page 64: Function List
Input response Output HOLD/ Protection SLMP time setting CLEAR setting function communication function function function NZ2MFB2-16A       NZ2MF2S2-16A       NZ2MFB1-32D          ...
Page 65: Chapter 4 Procedures Before Operation
PROCEDURES BEFORE OPERATION This chapter describes the procedures before operation. IP address setting switch setting Set the fourth octet of IP address of I/O module. Page 73 IP address setting switch setting Function setting switch setting Set the input response time setting and output HOLD/CLEAR setting of the I/O module. Page 76 Function setting switch setting Connection Mount the I/O module on the DIN rail.
Page 66 MEMO 4 PROCEDURES BEFORE OPERATION...
Page 67: Chapter 5 System Configuration
SYSTEM CONFIGURATION Applicable master station For the CPU module that can be used as the master station of CC-Link IE Field Network Basic, refer to the following.  CC-Link IE Field Network Basic Reference Manual Compatible software version For the compatible software version, always keep the configuration tool of the master station up to date. When the latest software version is necessary, please consult your local Mitsubishi representative.
Page 68 MEMO 5 SYSTEM CONFIGURATION...
Page 69: Chapter 6 Installation And Wiring
INSTALLATION AND WIRING This chapter describes the installation and wiring of the I/O module. Before Using the I/O Modules Input modules Precautions common to all input modules ■Number of simultaneous ON points The number of input points that can be turned on at the same time varies depending on the input voltage and ambient temperature.
Page 70: Output Module
Output module Precautions common to all output modules ■Maximum switching frequency when load is driven The maximum switching frequency imposes a limit on the use; an ON state or an OFF state must not be changed without an interval of at least one second. ■Load to be connected When connecting a counter or timer utilizing a DC/DC converter as a load of the output module, select an output module whose maximum load current is higher than the inrush current of a load to be connected.
Page 71 Precautions when using the contact output module When using the contact output module, carefully consider the following points: • Relay life (contact switching life) • Influence on the relay life by a connected load • Measures against back EMF ■Relay life (contact switching life) Applicable module: NZ2MFB2-16R, NZ2MF2S2-16R The relay life varies depending on the environment where a module is used.
Page 72 Influence on the relay life by a connected load An actual relay life can be substantially shorter than the relay life curve depending on the type of a connected load and the characteristics of its inrush current. ( Page 69 Relay life (contact switching life)) The inrush current generated by a connected load can lead to contact welding of the module.
Page 73 *1 A typical discharge lamp circuit is configured with a combination of discharge tubes, transformers, choke coils, capacitors and others. Because of this, be especially careful of the case of a high power factor and a low power supply impedance, where the inrush current flowing into the output module can be 20 to 40 times as high as the rated current.
Page 74 Precautions when using the transistor output module ■Measures against reverse current In the following connections, a reverse current flows to the output element, which can cause failure. When wiring, set up diodes as the following figures show: • When connecting transistor output modules in parallel Sink type Source type Load...
Page 75: Setting Switch
Setting Switch IP address setting switch setting Set the fourth octet of IP address using the IP address setting switch on the front of I/O module. The setting of IP address setting switch is enabled when the I/O module is powered on. Thus, set this function when the module is powered off.
Page 76 Automatic setting of the first to third octet of IP address The first to third octet of IP address is automatically set by the I/O module according to the settings of the master station. (The factory default setting is 192.168.3.) ■When there is one master station: Receives the information of network configuration setting from the master station.
Page 77 • Automatic setting of the first to third octet of IP address is executed only once during the initial communication with the master station after the I/O module is powered on. When the IP address of the I/O module in the network parameter at the master station is changed while the data link between the I/O module and master station is established, power off and on the I/O module as well after the parameter of master station is reflected.
Page 78: Function Setting Switch Setting
Function setting switch setting Set the input response time setting and output HOLD/CLEAR setting using the function setting switch on the front of I/O module. Switch name Function to be used Setting details Function setting switch 1 to 3 Input response time setting Set the input response time.
Page 79: Installation Environment And Installation Position
Installation Environment and Installation Position Installation environment Installation location Do not install the I/O module to the place where: • Ambient temperature is outside the range of 0 to 55; • Ambient humidity is outside the range of 5 to 95%RH; •...
Page 80: Installation Direction
Installation direction The I/O module can be installed in six directions. Use the DIN rail (1) to install the module. (1) DIN rail (2) Horizontal installation (3) Downward installation (4) Vertical installation (5) Upward installation (6) Horizontal installation (upside down) 6 INSTALLATION AND WIRING 6.3 Installation Environment and Installation Position...
Page 81: Installation
Installation Mounting the module on a DIN rail An example of the use of the DIN rail stopper is described in the following procedure. Fix the module according to the manual of the DIN rail stopper used. Mounting procedure Pull down all DIN rail hooks on the back of the module. The hooks should be pulled down until they click.
Page 82 Slide the DIN rail stopper up to the left side of the module. Hold the DIN rail stopper in the direction opposite to the arrow on the stopper and tighten the screw with a driver. Install the DIN rail stopper on the right side of the module in the same procedure.
Page 83: Wiring
Wiring Wiring of terminal block for module power supply and FG Wiring of spring clamp terminal block ■Tightening torque Tighten the terminal block mounting screw within the following specified torque range. Tightening the screw too much may damage the module case. Screw type Tightening torque range Terminal block mounting screw (M2.5 screw)
Page 84 ■Connecting and disconnecting the cable To connect the cable, fully insert a wire having a bar solderless terminal into a wire insertion opening. After inserting the wire, pull it lightly to check that it is securely clamped. Continuity can be checked with test terminal (1). To disconnect the cable, push in the open/close button with a Phillips screwdriver or flathead screwdriver.
Page 85: Wiring Of Ethernet Cable
Wiring of Ethernet cable Wiring method ■Installation method Power off the power supplies of the I/O module and the external device. Push the Ethernet cable connector into the I/O module until it clicks. Pay attention to the connector's direction. Power on the module power supply of the I/O module. Power on the external device.
Page 86: Wiring Of External Device And I/O Terminal Block
Wiring of external device and I/O terminal block Wiring of screw terminal block ■Tightening torque Tighten the terminal screw within the following specified torque range. Tightening the screw too much may damage the module case. Screw type Tightening torque range Terminal screw (M3 ...
Page 87 Wiring of spring clamp terminal block ■Wire to be used The following table describes the wire to be connected to the spring clamp terminal block. Diameter Type Material Temperature rating 22 to 16 AWG Stranded Copper 75 or more ■Applicable solderless terminal The following table lists the applicable solderless terminal.
Page 88 The terminal block can be inserted with the lever locations other than the lock lever position. After insertion, confirm that the lever is in the lock lever position. 6 INSTALLATION AND WIRING 6.5 Wiring...
Page 89 ■Signal name and wiring For the signal names of the terminal block and wiring of the external device, refer to the specifications of each module. Incorrect wiring can cause malfunction of or damage on the module. Page 16 Performance Specifications ■Wiring method •...
Page 90: Chapter 7 Parameter Setting
PARAMETER SETTING Network Configuration Setting Write the network configuration setting into the master station before starting the operation of I/O module. For how to set the network configuration of the master station, refer to the following.  CC-Link IE Field Network Basic Reference Manual Setting procedure Display the network configuration setting window.
Page 91 Close the network configuration setting window. [Network Configuration Settings]  [Close with Reflecting the Setting] Write the set parameter to the CPU module of the master station and reset the CPU module, or turn off and on the power supply. [Online] ...
Page 92: Chapter 8 Functions
FUNCTIONS This chapter describes the details of the functions available in the I/O module, and the setting method for those functions. Input Response Time Setting Function This function prevents an incorrect input due to noise by setting the response time until the module recognizes an actual input as the X signal.
Page 93: Output Hold/Clear Setting Function
Output HOLD/CLEAR Setting Function When the I/O module is disconnected from data link, or the CPU module operating status is STOP, whether to hold or clear the last output value can be set by this function. Output HOLD/CLEAR setting and its operation When HOLD or CLEAR is set for an output, the output is turned on or off as follows.
Page 94: Protection Function
Protection Function The overload protection function and overheat protection function protect the internal circuit from overcurrent and its heat. Overload protection function If the transistor output module and I/O combined module (transistor output part) detect overcurrent, the module performs the current limiting operation (that imposes a limit on the output current to a constant value and keeps the output).
Page 95: Slmp Communication Function
SLMP communication function SLMP can be used to communicate with the I/O module. For details on SLMP, refer to the following.  SLMP Reference Manual Available command Item Command Subcommand Description Type Operation Remote Control Remote Reset 1006 0000 Executes the remote RESET for I/O module. Communication setting If I/O module and SLMP are used for communication, use the following settings.
Page 96: Chapter 9 Programming
PROGRAMMING This chapter describes the programming of the I/O module. Precautions for Programming Cyclic transmission program To create a cyclic transmission program, configure an interlock so that the process is executed while the cyclic transmission is normally performed between the master station and slave station. For the interlock program of cyclic transmission, refer to the following.
Page 97: Program Example
Program Example System configuration (1) Master station • Power supply module: R62P • CPU module: R04CPU (2) Slave station (station number: 1, IP address setting switch: 1) • I/O combined module: NZ2MFB1-32DT (3) X0 input signal (pressing button) (4) Y10 output signal (lamp) The setting procedure assumes the use of GX Works3.
Page 98 ■Assignment of link devices X1000 · · · X100F RX0F RX0F X1010 RX10 RX10 · · · X103F RX3F RX3F Y1000 · · · Y100F RY0F RY0F Y1010 RY10 RY10 · · · Y101F RY1F RY1F Y1020 RY20 RY20 · ·...
Page 99 Label to be used ■Module label Use the following module labels. Module label Description Device RCPU.stSM.bSts_CyclicTransmission Cyclic transmission status SM1536 RCPU.stSD.bnSts_CyclicTransmission_Station[1] Cyclic transmission status of each station (station SD1536.0 number 1) ■Label to be defined Define the global labels as follows. Setting procedure Create a project with the contents below.
Page 100 Display the refresh setting window and configure the setting as follows. [Navigation window]  [Parameter]  [CPU module model name]  [Module Parameter]  [Basic Settings]  [Refresh Settings] After the parameter setting, click the [Apply] button. Write the set parameter to the CPU module of the master station and reset the CPU module, or turn off and on the power supply.
Page 101: Chapter 10 Maintenance And Inspection
MAINTENANCE AND INSPECTION The I/O module has no special item to be inspected. However, to maintain the best condition of the system, perform the inspection in accordance with the items described in the user's manual of the CPU module used. 10 MAINTENANCE AND INSPECTION...
Page 102 MEMO 10 MAINTENANCE AND INSPECTION...
Page 103: Chapter 11 Troubleshooting
TROUBLESHOOTING This chapter describes error contents that may occur while the I/O module is used and those troubleshooting. 11.1 Checking the LEDs This section describes how to troubleshoot the system by the LEDs. Determine the status of module error Error status can be determined by the On/Off status of RUN LED and ERR. LED as follows. RUN LED ERR.
Page 104 When the D LINK LED flashes Check item Action Does the IP address setting of I/O module match the IP address of I/O The IP address of I/O module must match the IP address specified in the module specified in the configuration setting of master station? configuration setting of master station.
Page 105: Cc-Link Ie Field Network Basic Diagnostics
11.2 CC-Link IE Field Network Basic Diagnostics Check the network status or error definition of I/O module to perform troubleshooting by executing the CC-Link IE Field Network Basic diagnostics. How to use For how to use the CC-Link IE Field Network Basic diagnostics, refer to the following. ...
Page 106: Troubleshooting By Symptom
11.3 Troubleshooting by Symptom Perform troubleshooting by symptom when the I/O module does not operate properly with no error. Check the following items in the order from the top. When the ON/OFF status of an external input cannot be read Check item Action Is the corresponding LED (X0 LED to X1F LED) of the input module and I/O...
Page 107: Examples Of Troubles With The I/O Module
11.4 Examples of Troubles with the I/O Module Troubleshooting for input circuit An input signal does not turn off No.1 ■Cause There is a leakage current from the input switch (driven by a contactless switch and others). AC input Leakage Input module current Power supply...
Page 108 An input signal does not turn off No.3 ■Cause There is a leakage current due to the line capacity of the wiring cables. (The line capacity, C, of a twisted pair cable is as follows: C = approx. 100pF/m.) AC input Leakage Input module current...
Page 109 ■Calculation example If the switch with LED indicator with maximum leakage current of 3mA when 24VDC is supplied to the NZ2MFB1-32D is connected Leakage current 3mA Input module 24VDC The OFF current of NZ2MFB1-32D is not 1.7mA or lower. Therefore, connect a resistor as shown below. Iz = 1.7mA = 1.3mA Resistor...
Page 110 An input signal does not turn off No.5 ■Cause By using two power supplies, a sneak path is configured. DC input Input module E1 > E2 ■Action • Use one power supply. • To prevent the sneak path, connect a diode as shown below. DC input Input module 11 TROUBLESHOOTING...
Page 111 An input signal does not turn on (AC input module). ■Cause Around the zero cross voltage (1) of the input signal (AC), there are step-like deformations as shown below: ■Action Improve the input signal waveform by using an on-line type UPS and others. A signal incorrectly inputs data ■Cause Noise is taken as input data.
Page 112: Troubleshooting For Output Circuit
Troubleshooting for output circuit A load momentarily turns on when the external power supply is powered on ■Cause An incorrect output occurs due to the stray capacitance (C) between collector and emitter of a photocoupler. There is no problem with the normal load. When a high sensitivity load (such as solid state relay) is used, however, this incorrect output may occur.
Page 113 ■Action Before turning on or off the external power supply, check that the rise time of the external power supply is 10ms or more. Then, install a switch (SW1) to the primary side of the external power supply. Primary side Secondary side External power supply Output module...
Page 114 A load momentarily turns on from off when the system is powered off ■Cause When an inductive load is connected, [2] Load may turn on from off due to a sneak current of back EMF at [1] Shutoff. Output module + Back electromotive force - [3] Sink output Load...
Page 115 ■Action Take either of the following two actions: • Action 1: To suppress the back EMF, connect a diode parallel to the load where back EMF is generated in [3]. Sink output Source output + Back electromotive force - - Back electromotive force + Load Load •...
Page 116 When the output module is off, the LED connected as a load dimly turns on ■Cause The load operates by the leakage current when the output module is off. Output module Countermeasure Sink output 24VDC COM- ■Action Connect a resistor of 5 to 50k in parallel with the LED load. When a digital display unit is connected as a load, the display may not be normal ■Cause The load operates by the leakage current when the output module is off.
Page 117 When output is turned on, load connected to other outputs is turned on simultaneously ■Cause When a non-wiring state occurs due to, for example, a shutoff or disconnection between 0V of the external power supply and the common of a load, a current flows across the load that is off through an unexpected circuit of the output element that is off. Output module Source output Output control...
Page 118: Method For Checking Errors
11.5 Method for Checking Errors The errors for the I/O module can be classified into the following three categories. The checking methods for each error are as follows. Classification Checking method I/O module specific error • CC-Link IE Field Network Basic diagnostics Page 103 CC-Link IE Field Network Basic Diagnostics •...
Page 119: Error Code List
11.6 Error Code List I/O module specific error I/O module specific error codes are as follows. Error code Error type Error name Description and cause Action 0010H Major error Hardware error Module hardware error Power off and on the module power supply. If this error persists, the module may be in failure.
Page 120: Appendices
APPENDICES Appendix 1 Remote I/O Signal List of remote I/O signals This section lists I/O signals for a master station. Remote input (RX) indicates the input signal from the I/O module to the master station. Remote output (RY) indicates the output signal from the master station to the I/O module. Do not use any "Use prohibited"...
Page 121 ■32-point module Remote input Remote output Signal direction: Input module  Master station Signal direction: Master station  Input module Device number Description Device number Description External input signal X0 Use prohibited External input signal X1 External input signal X2 External input signal X3 External input signal X4 External input signal X5...
Page 122 Output module ■16-point module Remote input Remote output Signal direction: Output module  Master station Signal direction: Master station  Output module Device number Description Device number Description Use prohibited External output signal Y0 External output signal Y1 External output signal Y2 External output signal Y3 External output signal Y4 External output signal Y5...
Page 123 ■32-point module Remote input Remote output Signal direction: Output module  Master station Signal direction: Master station  Output module Device number Description Device number Description Use prohibited External output signal Y0 External output signal Y1 External output signal Y2 External output signal Y3 External output signal Y4 External output signal Y5...
Page 124 I/O combined module ■32-point module Remote input Remote output Signal direction: I/O combined module  Master station Signal direction: Master station  I/O combined module Device number Description Device number Description External input signal X0 Use prohibited External input signal X1 External input signal X2 External input signal X3 External input signal X4...
Page 125: Details Of Remote Input Signals
Details of remote input signals The following describes the details of the remote input signals for the master station. External input signal (RX0 to RX1F) This signal shows the on/off status of the external input of input module and I/O combined module. Details of remote output signals The following describes the details of the remote output signals for the master station.
Page 126: Appendix 2 Remote Register
Appendix 2 Remote Register List of remote register Use of the remote register is prohibited. Do not read or write the data from/to any "Use prohibited" remote register areas. Doing so may result in an accident due to an incorrect output or malfunction. Remote register (RWr) Remote register (RWw) Signal direction: I/O module ...
Page 127: Appendix 3 Setting Ip Addresses And Subnet Masks
Appendix 3 Setting IP Addresses and Subnet Masks This section describes the setting procedure of IP addresses and subnet masks. This setting is required when changing IP addresses and subnet masks to specific values. This setting is not required if these values need not be changed.
Page 128 • Set the IP address in the range between 0.0.0.1 and 223.255.255.254. • Set the subnet mask in the range between 192.0.0.0 and 255.255.255.252. • If the IP address setting switch is not 0, the setting is not reflected. • Settings other than the IP address and subnet mask are not reflected. •...
Page 129: Appendix 4 Diagnostic Information Of Slave Station
Appendix 4 Diagnostic Information of Slave Station Diagnostic information list This section shows the list of diagnostic information of slave station that can be checked in the special register (SD) or buffer memory of master station. Note that the information shown here are diagnostic information 2 only. For other diagnostic information, refer to the following.
Page 130: Diagnostic Information Details
Manufacturer code 0000H (fixed) (manufacturer code for I/O module) is stored. Model code Model code for I/O module is stored. Model name Model code (upper) Model code (lower) NZ2MFB2-16A 0000H 3006H NZ2MF2S2-16A 0000H 300DH NZ2MFB1-32D 0000H 3001H NZ2MF2S1-32D 0000H 3008H NZ2MFB2-16R...
Page 131 Detailed module information (upper) The function setting status of I/O module is stored. ■bit0 to bit2 (input response time setting status) The setting status of input response time setting is stored. The input response time setting is determined depending on the status of the function setting switch 1 to 3 when the module power supply is on.
Page 132 ■bit3 (output HOLD/CLEAR setting status) The setting status of output HOLD/CLEAR setting is stored. The output HOLD/CLEAR setting is determined depending on the status of the function setting switch 4 when the module power supply is on. Stored value Output HOLD/CLEAR setting bit3 CLEAR HOLD...
Page 133: Appendix 5 Processing Time
Appendix 5 Processing Time For the processing time of CC-Link IE Field Network Basic, refer to the following.  CC-Link IE Field Network Basic Reference Manual Response processing time of slave station This section shows the response processing time of slave station. ■Input reflection processing time of slave station (input) The input reflection processing time of the slave station (input) = Input response time + Internal processing time (0.2ms)
Page 134: Appendix 6 Emc And Low Voltage Directives
EMC and Low Voltage Directives, their manufacturers are required to declare compliance and affix the CE marking. Sales representative in EU member states The sales representative in EU member states is: Company: MITSUBISHI ELECTRIC EUROPE B.V. Address: Mitsubishi-Electric-Platz 1, 40882 Ratingen, Germany Measures to comply with the EMC Directive The EMC Directive sets requirements for emission (conducted and radiated electromagnetic interference emitted by a product) and immunity (the ability of a product not to be influenced by externally generated electromagnetic interference).
Page 135 EMC Directive related standards ■Emission requirements Standard Test item Test details Standard value EN61131-2: 2007 CISPR16-2-3 Radio waves from the product are • 30M-230MHz QP: 40dBV/m (10m in measurement range) Radiated emission measured. • 230M-1000MHz QP: 47dBV/m (10m in measurement range) CISPR16-2-1, Noise from the product to the power •...
Page 136 Installation in a control panel The module is open type devices and must be installed inside a control panel. This ensures safety as well as effective shielding of programmable controller-generated electromagnetic noise. ■Control panel • Use a conductive control panel. •...
Page 137 Cables extended out of the control panel Use a shielded cable for a cable extended out of the control panel such as an I/O signal line (including a common line) and cable for communications. If a shielded cable is not used or not grounded correctly, the noise immunity will not meet the specified value. ■Grounding a shielded cable •...
Page 138 Use shielded cables for external wiring and ground the shields of the external wiring cables to the control panel with the AD75CK cable clamp (manufactured by Mitsubishi Electric Corporation). (Ground the shield section 20 to 30cm away from the module.)
Page 139 For the FG terminal on a module that is connected to the external power supply, and the Ethernet cable, attach a ferrite core 4cm away from the module. (Ferrite core used for the tests conducted by Mitsubishi Electric Corporation: NEC TOKIN ESD-SR-250, TDK ZCAT3035- 1330) Attachment ■Noise filter (power supply line filter)
Page 140: Requirements To Compliance With The Low Voltage Directive
Requirements to compliance with the Low Voltage Directive I/O modules with their rated input/output voltages being 100VAC and 200VAC systems have a dangerous voltage inside (a peak voltage of 42.4V or higher). Therefore, for CE-marked I/O modules, reinforced insulation is applied between the primary and secondary circuits.
Page 141: Appendix 7 How To Check Serial Number And Function Version
Appendix 7 How to Check Serial Number and Function Version The serial number and function version of the I/O module can be checked on the rating plate. PASSED MODEL SERIAL 000000000000000-A TOKYO 100-8310, JAPAN MADE IN JAPAN (1) MAC address (2) Relevant standard symbol (3) Serial number (4) Function version...
Page 142: Appendix 8 External Dimensions
Appendix 8 External Dimensions Screw terminal block type (Unit: mm) (1) Center of DIN rail Spring clamp terminal block type (Unit: mm) (1) Center of DIN rail APPX Appendix 8 External Dimensions...
Page 143 MEMO APPX Appendix 8 External Dimensions...
Page 144: Index
INDEX ....65 Applicable master station ..... . . 65 Applicable profile .
Page 145 MEMO...
Page 146: Revisions
Japanese manual number: SH-081762-F This manual confers no industrial property rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.
Page 147: Warranty
WARRANTY Please confirm the following product warranty details before using this product. 1. Gratis Warranty Term and Gratis Warranty Range If any faults or defects (hereinafter "Failure") found to be the responsibility of Mitsubishi occurs during use of the product within the gratis warranty term, the product shall be repaired at no cost via the sales representative or Mitsubishi Service Company.
Page 148: Trademarks
TRADEMARKS The company names, system names and product names mentioned in this manual are either registered trademarks or trademarks of their respective companies.   In some cases, trademark symbols such as ' ' or ' ' are not specified in this manual. SH(NA)-081763ENG-F...
Page 150 SH(NA)-081763ENG-F(2104)MEE MODEL: CCIEFB-IO-U-E MODEL CODE: 13JX73 HEAD OFFICE : TOKYO BUILDING, 2-7-3 MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN NAGOYA WORKS : 1-14 , YADA-MINAMI 5-CHOME , HIGASHI-KU, NAGOYA , JAPAN When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission.

This manual is also suitable for:

Nz2mfb2-16a Nz2mfb1-32d Nz2mf2s1-32d Nz2mfb2-16r Nz2mf2s2-16r Nz2mfb1-32t ... Show all

Mitsubishi Electric NZ2MF2S2-16A User Manual

Chapter 1 Product Lineup

Chapter 2 Part Names

Chapter 3 Specifications

Chapter 4 Procedures before Operation

Chapter 5 System Configuration

Chapter 6 Installation and Wiring

Chapter 7 Parameter Setting

Chapter 8 Functions

Chapter 9 Programming

Chapter 10 Maintenance and Inspection

Chapter 11 Troubleshooting

Appendix 1 Remote I/O Signal

Appendix 2 Remote Register

Appendix 3 Setting IP Addresses and Subnet Masks

Appendix 4 Diagnostic Information of Slave Station

Appendix 5 Processing Time

Appendix 6 EMC and Low Voltage Directives

Appendix 7 How to Check Serial Number and Function Version

Appendix 8 External Dimensions

Quick Links

Troubleshooting

Related Manuals for Mitsubishi Electric NZ2MF2S2-16A

Summary of Contents for Mitsubishi Electric NZ2MF2S2-16A

This manual is also suitable for:

Table of Contents
