RDS AV RECEIVER
Operation Manual
Important (Serial number)
The serial number is located on the bottom of this unit. For your own security and convenience, be
sure to record this number on the enclosed warranty card.

Advertisement

Table of Contents
loading

Related Manuals for Pioneer MVH-1400NEX

Summary of Contents for Pioneer MVH-1400NEX

  • Page 1 MVH-2400NEX MVH-2300NEX MVH-1400NEX RDS AV RECEIVER Operation Manual Important (Serial number) The serial number is located on the bottom of this unit. For your own security and convenience, be sure to record this number on the enclosed warranty card.

  • Page 2: Table Of Contents

    Contents ■ Bluetooth ......20 Thank you for buying this Pioneer product. Bluetooth connection ..........20 Please read through these instructions Bluetooth settings............. 20 so you will know how to operate your Switching the connected Bluetooth device ..21 model properly. After you have finished Hands-free phoning..........
  • Page 3 Basic operation ............50 Video settings ............. 92 ■ ■ Pandora®......54 Favorite menu....93 Listening to Pandora..........54 Creating a shortcut ........... 93 Basic operation ............55 Selecting a shortcut..........93 ■ Removing a shortcut ..........93 Spotify®......57 ■...
  • Page 4 Using app-based connected content ....117 Pandora®..............117 Spotify® ............... 117 Notice regarding video viewing ......117 Notice regarding MP3 file usage ....... 118 Using the LCD screen correctly ......118 Specifications............119 - 4 -...

  • Page 5: Precaution

    Precaution Information to user –MODEL NO.: MVH-2400NEX, MVH-2300NEX, MVH-1400NEX FCC ID: EW4C95 IC: 4250A-C95 –This device complies with Part 15 of FCC Rules and Innovation, Science, and Economic Development Canada licence-exempt RSSs. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

  • Page 6: Important Safety Information

    • If you notice smoke, a strange noise or odor from this product, or any other abnormal signs on the LCD screen, turn off the power immediately and consult your dealer or the nearest authorized Pioneer Service Station. Using this product in this condition may result in permanent damage to the system.

  • Page 7: Parking Brake Interlock

    Before using this product, be sure to read and fully understand the following safety information: • Do not operate this product, any applications, or the rear view camera option (if purchased) if doing so will divert your attention in any way from the safe operation of your vehicle.

  • Page 8: When Using A Display Connected To V Out

    • Do not take any steps to tamper with or disable the parking brake interlock system which is in place for your protection. Tampering with or disabling the parking brake interlock system could result in serious injury or death. • To avoid the risk of damage and injury and the potential violation of applicable laws, this product is not for use with a video image that is visible to the driver.

  • Page 9: Handling The Usb Connector

    • To prevent data loss and damage to the storage device, never remove it from this product while data is being transferred. • Pioneer cannot guarantee compatibility with all USB mass storage devices and assumes no responsibility for any loss of data on media players, iPhone, smartphone, or other devices while using this product.

  • Page 10: Notes On Internal Memory

    • To protect the LCD screen from damage, be sure to touch the touch panel keys only with your finger and do so gently. Notes on internal memory • The information will be erased by disconnecting the yellow lead from the battery (or removing the battery itself ).

  • Page 11: Parts And Controls

    Parts and controls Main unit 2400NEX 2300NEX 1400NEX NOTE For MVH-2400NEX/MVH-2300NEX, press buttons on the main unit, and for MVH-1400NEX, touch buttons on the main unit. LCD screen VOL (+/ - 11 -...

  • Page 12: Remote Control

    Press (touch) to switch between the Application screen and the AV operation screen. For MVH-2400NEX/MVH-2300NEX, press and hold to switch to the camera view mode, and for MVH-1400NEX, touch and hold to turn off the display. NOTE To activate the camera view mode with this button, set [Back Camera Input] to [On] (page 79).
  • Page 13 AUDIO Not used. SUBTITLE ANGLE BAND/ESC Press to select the tuner band when tuner is selected as a source. Press to cancel the control mode of functions. RETURN Press to return to the specified point and start playback from there. Press to pause or resume playback.

  • Page 14: Basic Operation

    Basic operation Resetting the microprocessor 2400NEX 2300NEX CAUTION • Pressing the RESET button resets settings and recorded contents to the factory settings. – Do not perform this operation when a device is connected to this product. – Some of the settings and recorded contents will not be reset. •...

  • Page 15: Starting Up The Unit

    death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.

  • Page 16: Using The Touch Panel

    4-speaker system with front and rear speakers, or a 6-speaker system with front and rear speakers and subwoofers. [Network Mode] 3-way system with a high range speaker, middle range speaker and subwoofer (low range speaker) for reproduction of high, middle and low frequencies (bands). WARNING Do not use the unit in standard mode when a speaker system for 3-way network mode is connected to the unit.
  • Page 17 Operating list screens Touching an item on the list allows you to narrow down the options and proceed to the next operation. Appears when all characters are not displayed on the display area. If you touch the key, the rests are scrolled for display. NOTE This function is available only when you stop your vehicle in a safe place and apply the parking brake.

  • Page 18: Top Menu Screen

    Switches the dimmer duration by day or night. NOTE When AppRadio Mode + is on, AppRadio Mode + SideControlBar is displayed. Switches between playback and pause. Skips files forward or backward. Performs fast reverse or fast forward. Displays setting menu screen (page 78). Closes the menu bar.
  • Page 19 Favorite source icons TIPS • When you connect the external navigation system to this unit, the navigation mode key is displayed at the middle of the right side of the display. • If you select [Power OFF], you can turn off almost all functions. –...

  • Page 20: Bluetooth

    Bluetooth Bluetooth connection Turn on the Bluetooth function on the device. Press (touch) Touch then The Bluetooth screen appears. Touch [Connection]. Touch The unit starts to search for available devices, then displays them in the device list. Touch the Bluetooth device name. After the device is successfully registered, a Bluetooth connection is established by the system.

  • Page 21: Switching The Connected Bluetooth Device

    CAUTION Never turn this product off and disconnect the device while the Bluetooth setting operation is being processed. Menu Item Description [Connection] Connect, disconnect, or delete registered Bluetooth device manually. Touch to delete registered device. To connect a registered Bluetooth device manually, touch the name of the device.

  • Page 22: Hands-Free Phoning

    registered devices are already connected, you can connect the remaining third device to use the audio function only from the switch devices key on the audio source screen. • The icon for the cellular phone currently being used is displayed on the Phone menu screen.
  • Page 23 The following items are displayed. • Name of the current cellular phone • List number of the current cellular phone • Reception status of the current cellular phone • Battery status of the current cellular phone If you connect two cellular phones to this product at the same time, you can switch between the cellular phones using the switch devices key.
  • Page 24 Touch Touch On the [Phone Book] screen, touch the desired name to display the contact’s phone number. Touch ▶Dialing from the preset dial list Touch Touch the desired entry on the list to make a call. The dial screen appears and dialing starts. ▶Deleting a phone number Press (touch) Touch...
  • Page 25 Press (touch) Touch Touch The voice recognition function launches and the voice control screen appears. TIPS • You can also launch the voice recognition function by pressing (touching) • If two cellular phones are automatically connected to this product with the Bluetooth device auto connect function, the voice recognition function (Siri Eyes Free Mode) will be set on the second phone.
  • Page 26 Touch to turn private mode on or off. NOTES • If two cellular phones are connected to this product and the first phone is set to private mode, you can receive incoming calls on the second phone while maintaining the call in progress on the first phone.

  • Page 27: Bluetooth Audio

    ▶The received call and dialed number histories • You cannot make a call to the entry of an unknown user (no phone number) in the received call history. • If calls are made by operating your cellular phone, no history data will be recorded in this product.
  • Page 28 The Bluetooth audio playback screen appears. Basic operation Bluetooth audio playback screen Track number indicator Switches between playback and pause. Skips files forward or backward. • By pressing (touching) then touch , you can also skip files forward or backward. •...

  • Page 29: Appradio Mode

    Using AppRadio Mode + Important • Pioneer is not liable for any issues that may arise from incorrect or flawed app-based content. • The content and functionality of the supported applications are the responsibility of the App providers.
  • Page 30 • If you connect your device to this product while an AppRadio Mode + compatible application is already running, the application operation screen will appear on this product. • The desired application is launched, and the application operation screen appears. •...

  • Page 31: Using The Keyboard

    For smartphone (Android) users NOTES • [USB MTP] is set to [Off] to use AppRadio Mode + (page 79). • The video playback capability depends on the connected Android device. Unlock your smartphone and connect it to this product via USB. Refer to the Installation Manual.
  • Page 32 The audio mix menu will be displayed on the screen. Touch to mute. Touch again to cancel mute. Adjusts the audio volume. The AV operation screen and the Application screen can be switched by pressing (touching) - 32 -...

  • Page 33: Av Source

    AV source Supported AV source You can play or use the following sources with this product. • Radio • USB The following sources can be played back or used by connecting an auxiliary device. • iPod • Spotify® • Pandora® •...

  • Page 34: Selecting A Source

    Selecting a source Source on the AV source selection screen Press (touch) then touch Touch the source icon. When you select [Source OFF], the AV source is turned off. Source on the source list Press (touch) then touch AV operation key. Touch Touch the source key.

  • Page 35: Adjusting The Range Of Favorite Source Icons Area

    Adjusting the range of favorite source icons area NOTE This function is available only when you stop your vehicle in a safe place and apply the parking brake. Press (touch) Touch and hold appears at the top left of the favorite source icons. Drag to the desired position.

  • Page 36: Ipod®/Iphone® Or Smartphone Connection For Av Source

    iPod®/iPhone® or smartphone connection for AV source When using an iPod/iPhone or a smartphone with this product, the settings are automatically configured according to the device to be connected. This section describes source compatibility for each device with the connection. NOTES •...

  • Page 37: Iphone With A 30-Pin Connector

    You can connect and control an iPod/iPhone compatible with this product by using separately sold connector cables. Connecting via Bluetooth The following sources are available when an iPod/iPhone is connected to the unit via Bluetooth. • iPod • Pandora • Spotify •...

  • Page 38: Smartphone (Android™ Device)

    • Connecting via CD-IU51* (page 38) * Sold separately Compatible iPhone model • iPhone 4s For details about iPhone compatibility with this product, refer to the information on our website. You can connect and control an iPhone compatible with this product by using separately sold connector cables.
  • Page 39 * Sold separately Compatible smartphones Compatibility with all smartphones is not guaranteed. For details about smartphone compatibility with this product, refer to the information on our website. Connecting via Bluetooth The following sources are available when a smartphone is connected to the unit via Bluetooth.

  • Page 40: Radio

    Radio Starting procedure Press (touch) then touch Touch [Radio]. The Radio screen appears. Basic operation Radio screen Recalls the preset channel stored to a key from memory. Stores the current broadcast frequency to a key. Displays the preset channel list. Select an item on the list ([1] to [6]) to switch to the preset channel.

  • Page 41: Storing The Strongest Broadcast Frequencies (Bsm)

    Manual tuning Seek tuning or non stop seek tuning Releasing the key in a few seconds skips to the nearest station from the current frequency. Keep holding the key for long seconds to perform, performs non stop seek tuning. TIPS •...
  • Page 42 Menu Item Description [Local] Local seek tuning allows you to only tune into [Off] radio stations with sufficiently strong signals. FM: [Level1] [Level2] [Level3] [Level4] NOTE AM: [Level1] [Level2] [Level4] for FM and [Level2] for AM are available only with the stations with the strongest signals. - 42 -...

  • Page 43: Compressed Files

    Compressed files Plugging/unplugging a USB storage device You can play compressed audio, compressed video, or still image files stored in an external storage device. Plugging a USB storage device Pull out the plug from the USB port of the USB cable. Plug a USB storage device into the USB cable.

  • Page 44: Basic Operation

    Plug the USB storage device into the USB cable (page 43). Touch [USB]. Playback is performed in order of folder numbers. Folders are skipped if they contain no playable files. Basic operation TIPS • By pressing (touching) then touch , you can also skip files/chapters forward or backward.
  • Page 45 Sets a repeat play range for all files/the current folder/the current file. Plays files or does not play in random order. Displays the hidden function bar. You can also display the hidden function bar by flicking the bar from the right to the left.
  • Page 46 Displays the hidden function bar. You can also display the hidden function bar by flicking the bar from the left to the right. Selects the previous folder or the next folder. Constructs the database for using the Music Browse mode (page 46). Switches the current music information display.
  • Page 47 Video source screen (Example: USB) Hides the touch panel keys. To display the keys again, touch anywhere on the screen. Switches between playback and pause. Performs fast reverse or fast forward. Touch again to change the playback speed. Stops playback. Performs frame-by-frame playback.
  • Page 48 Selects a file from the list. Touch a file on the list to playback. Touching a folder on the list shows its contents. You can play a file on the list by touching it. Skips files forward or backward. Still image source TIPS •...
  • Page 49 Saves the current images as the wallpaper. Touch the following items then touch [Yes] to overwrite the image. [As AVScreen]: Saves the image as the wallpaper for the AV screen. [As HomeScreen]: Saves the image as the wallpaper for the top menu screen. [As Both]: Saves the image as the wallpaper for both the AV screen and top menu screen.

  • Page 50: Ipod

    iPod Connecting your iPod When connecting an iPod to this product, the settings are automatically configured according to the device to be connected. For details of the available connection, refer to iPod®/iPhone® or smartphone connection for AV source (page 36). NOTES •...
  • Page 51 Displays the link search screen. Select a song from the list related to the song currently playing. If you touch the artwork, the list of songs in the album is displayed. NOTE This function is not available while playing Apple Music Radio. Switches between playback and pause.
  • Page 52 Audio source screen 2 Changes the audiobook speed. Normal—Fast—Slow Displays the hidden function bar. Apple Music® Radio source Important Apple Music Radio may not be available in your country or region. For details about Apple Music Radio, visit the following site: http://www.apple.com/music/ NOTE This function is only available when using the iPod function with an iPhone 7, iPhone 7 Plus, iPhone SE, iPhone 6s, iPhone 6s Plus, iPhone 6, iPhone 6 Plus, iPhone 5s, iPhone 5c, iPhone 5 or iPod touch (5th...
  • Page 53 Displays the pop-up menu for Apple Music Radio. • Touch [Play More Like This] to play back songs similar to the current song. • Touch [Play Less Like This] to set it not to play back the current song again. •...

  • Page 54: Pandora

    Pandora® Pandora internet radio is a music service not affiliated with Pioneer. More information is available at http://www.pandora.com. The Pandora mobile application is available for iPhone and smartphones. Please visit www.pandora.com/everywhere/mobile for the latest compatibility information. WARNING Certain uses of the iPhone or smartphone may not be legal while driving in your jurisdiction, so you must be aware of and obey any such restrictions.

  • Page 55: Basic Operation

    Touch [Pandora]. Launch the Pandora application on the mobile device and start playback. • For details on Bluetooth connection, see page 20. • For details on USB connection, refer to the Installation Manual. Basic operation Playback screen Recalls the preset station stored to a key from the memory. Stores the current station to a key.
  • Page 56 Adds information for the track currently playing to bookmarks. Switches among connected devices. Selects a Pandora station from the list. • : Switches to the station list. • : Switches to the genre list. • : Plays only one track based on particular musical characteristics from several shuffled stations.

  • Page 57: Spotify

    • Certain functions of the Spotify service are not available when accessing the service through Pioneer car audio/video products. • Spotify is a music service not affiliated with Pioneer. More information is available at https://support.spotify.com/. • The Spotify application is available for most iPhone and smartphone, please visit https://support.spotify.com/ for the latest compatibility information.

  • Page 58: Basic Operation

    Press (touch) Touch then Touch [AV Source Settings]. Confirm that [Spotify] is turned on. Press (touch) then touch Touch [Spotify]. NOTES • For details on Bluetooth connection, see page 20. • For details on USB connection for iPhone, refer to the Installation Manual. Basic operation Playback screen 1 (Track) Switches between playback and pause.
  • Page 59 Displays the hidden function bar. You can also display the hidden function bar by flicking the bar from the right to the left. Switches among connected devices. Selects a track or station from the list. Your Music: Selects a track or station from the list of saved song information. Browse: Selects a track from the category list.
  • Page 60 Playback screen 1 (Radio mode) Switches between playback and pause. Skips tracks forward or backward. By pressing (touching) then touch , you can skip songs forward. Starts new radio mode. Saves or deletes the current song information to or from Your Music. Displays the hidden function bar.
  • Page 61 Playback screen 2 (Radio mode) Displays the hidden function bar. You can also display the hidden function bar by flicking the bar from the left to the right. Gives a Thumbs Up to the playing track. Gives a Thumbs Down to the playing track and skips to the next track. - 61 -...

  • Page 62: Siriusxm® Satellite Radio

    SiriusXM® Satellite Radio Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the best sports, news, talk, comedy, and entertainment. Welcome to the world of satellite radio. A SiriusXM Connect Vehicle Tuner and Subscription are required.

  • Page 63: Listening To Siriusxm

    Listening to SiriusXM Press (touch) then touch Touch [SiriusXM]. Basic operation TIPS • By pressing (touching) then touch , you can move the preset channels up or down on the current channel screen, and skip files forward or backward on the play time indicator screen. •...
  • Page 64 Performs TuneScan™ (page 65). Switches TuneMix™ to on or off. You can use TuneMix™ from each of the music channels stored as presets on the current band. NOTES • When fewer than two music channels are stored as presets, you cannot use TuneMix™.

  • Page 65: Tunescan

    Selects a channel from the list. Select the category name or the list of all channels then touch the desired channel. To switch the display list, touch TIPS • The displayed list switches in the following order. Channel Name—Artist Name—Song Title—Content Info •...

  • Page 66: Sportsflash

    Touch to display the following display. Continues playing the current scanning song or channel. Skips to the previous/next song during TuneScan™ or to the previous/next channel during category scan. Cancels scan play and returns to the previous channel. SportsFlash™ SportsFlash™ will notify you when a big play happens during a game with one of your favorite sports teams.

  • Page 67: Parental Lock

    How to access When there is a Featured Favorite, access it with the band key. Touch the band key. SXM1—SXM2—SXM3—FF When there are multiple Featured Favorites, access them from the category list. It is displayed at the bottom of the category list (page 65). Parental lock The Parental Control feature allows you to limit access to any SiriusXM channels, including those with mature content.
  • Page 68 Menu Item Description [Featured Favorites] Set to [On] to allow you to discover new channels created by [On] [Off] the SiriusXM Programming department. NOTE If the Featured Favorite Band needs to update, the Featured Band Update message will appear. [Featured Band To be notified when the featured seasonal theme is updated.

  • Page 69: Aux

    You can display the video image output by the device connected to video input. CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the parking brake. NOTE A Mini-jack AV cable (CD-RM10) (sold separately) is required for connection.
  • Page 70 Hides the touch panel keys. To display the keys again, touch anywhere on the screen. You can set the screen size for the video image (page 94). Switches between the video input and audio input. - 70 -...

  • Page 71: Av Input

    AV input You can display the video image output by the device connected or the camera to video input. For details, refer to the Installation Manual. CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the parking brake.

  • Page 72: Mixtrax

    MIXTRAX MIXTRAX is an original technology for creating non-stop mixes of selections from your audio library, complete with DJ effects. MIXTRAX EZ operation You can use this unit to play USB audio files. MIXTRAX EZ is used to add a variety of sound effects between songs for arranging the pauses between songs.

  • Page 73: Mixtrax Settings

    MIXTRAX settings Press (touch) Touch then The system setting screen appears. Touch [AV Source Settings]. Touch [MIXTRAX Settings]. Menu Item Description [Short Playback Mode] Specify the playback portion. [Off] [60s] [90s] [120s] [150s] [180s] [Random] [Display Effect] Set the effect display for MIXTRAX. [On] [Off] [Cut-In Effect] Set the effect tone that sounds when you skip tracks...

  • Page 74: Idatalink

    iDatalink Using iDatalink You can access the satellite radio source provided for the vehicle. The vehicle information and many OEM systems such as steering wheel controls, warning chimes, driver safety systems, and etc. can be displayed on this product by connecting the optional iDatalink adapter.

  • Page 75: Starting Procedure

    NOTE When the serial number input is required, input the device number of this product. Install the vehicle/head unit specific firmware on your iDatalink Maestro module. Connect this product to iDatalink Maestro, and then install this product to the vehicle. The iDatalink function will be active.
  • Page 76 Displays the Climate screen. Displays the Parking Assist screen. Gauges screen Vehicle Information screen Climate screen - 76 -...

  • Page 77: Displaying Obstacle Detection Information

    Parking Assist screen Displaying obstacle detection information CAUTION This function is intended solely to assist the driver’s vision. It does not detect all dangers and obstacles and is not a substitute for your attentiveness, judgement, and care while parking your vehicle. NOTE This function is only available for vehicles equipped with a parking sensor system.

  • Page 78: Settings

    Settings You can adjust various settings in the main menu. Displaying the setting screen Press (touch) Touch Touch one of the following categories, then select the options. System settings (page 78) Theme settings (page 85) Audio settings (page 86) Video settings (page 92) Bluetooth settings (page 20) System settings The menu items vary according to the source.
  • Page 79 [Auto Mix] Menu Item Description [Auto Mix] Select whether to perform mixing the sound output from [On] [Off] AppRadio Mode + and AV source sound automatically. [Input/Output settings] Menu Item Description [USB MTP] Select whether or not to activate USB MTP (Media Transfer [On] [Off] Protocol) connection.
  • Page 80 (page 80). CAUTION Pioneer recommends the use of a camera which outputs mirror reversed images, otherwise the screen image may appear reversed. • Immediately verify whether the display changes to the rear view camera image when the shift lever is moved to REVERSE (R) from another position.
  • Page 81 [Restore Settings] Menu Item Description [All Settings] Touch [Restore] to restore the settings to the default settings. CAUTION Do not turn off the engine while restoring the settings. NOTES • This setting is available only when you stop your vehicle in a safe place and apply the parking brake.
  • Page 82 Menu Item Description [Touch panel calibration] Touch [Yes]. Touch two corners of the screen along the arrows then touch the centers of the two [+] marks at the same time twice. Press (touch) The adjustment results are saved. Press (touch) once again.
  • Page 83 Menu Item Description [Dimmer Duration] Adjust the time that the dimmer is turned on or off by dragging the cursors or touching You can use this function when [Dimmer Trigger] is set to [Time]. TIPS • Each touch of moves the cursor backward or forward in the 15 minute width.
  • Page 84 * With some pictures, you cannot adjust [Hue] and [Color]. NOTES • The adjustments of [Brightness], [Contrast], and [Dimmer] are stored separately when your vehicle's headlights are off (daytime) and on (nighttime). • [Brightness] and [Contrast] are switched automatically depending on the setting of [Dimmer Settings].

  • Page 85: Theme Settings

    [OEM Settings] Menu Item Description [OEM Settings] (page 77). [OEM Volume Settings] Menu Item Description [OEM Volume Settings] (page 77). Theme settings The menu items vary according to the source. Menu Item Description [Background] Select the wall paper from the preset items in this product [Home] [AV] or original pictures via the external device.

  • Page 86: Audio Settings

    Menu Item Description (off ) Hides the clock display. *1 Refer to Still image source (page 48). *2 You can preview the top menu screen or the AV operation screen by touching [Home] or [AV] respectively. Audio settings The menu items vary according to the source. Some of the menu items become unavailable when the volume is set to mute or the source is off.
  • Page 87 Menu Item Description [Off] The volume does not change. [Source Level Adjuster] Adjust the volume level of each source to prevent radical [-4] to [+4] changes in volume when switching between sources other than FM. Touch to adjust the source volume after comparing the FM tuner volume level with the level of the source.
  • Page 88 Menu Item Description [Time Alignment] Select or customize the time alignment settings to reflect [On] [Off] the distance between the listener’s position and each Listening position*1*2 speaker. You need to measure the distance between the [Off] [Front-L] [Front-R] head of the listener and each speaker unit. [Front] [All] Touch to select the listening position then...
  • Page 89 Menu Item Description [Automatic Level Control] Corrects automatically the audio level difference between the music files or the sources. [Off] Turns the auto level control setting off. [Mode1] Corrects a little the audio level difference between the music files or the sources (for the narrow dynamic range audio signal).
  • Page 90 ▶Before operating the Auto EQ function • Perform Auto EQ in a quiet place with the vehicle engine and air conditioning switched off. Also, cut the power of car phones or cellular phones in the vehicle, or remove them in advance. Surrounding sounds may prevent correct measurement of the vehicle’s acoustics.
  • Page 91 Disconnect the iPhone or smartphone device. Turn on the ignition switch (ACC ON). If the vehicle’s air conditioner or heater is turned on, turn it off. Switch the AV source to [Source OFF] (page 34). Press (touch) Touch then Touch [A-EQ&TA Measurement]. Connect the microphone for acoustical measurement (sold separately) with this product.

  • Page 92: Video Settings

    NOTE [Subwoofer Settings] is available only when [Subwoofer] is [On]. Press (touch) Touch then Touch [Crossover] or [Subwoofer Settings]. Touch to switch the speaker. Drag the graph line to set the cutoff position. Drag the lowest point of the graph to set the cutoff slope. The following items can also be set.

  • Page 93: Favorite Menu

    Favorite menu Registering your favorite menu items in shortcuts allows you to quickly jump to the registered menu screen by a simple touch on the [Favorites] screen. NOTE Up to 12 menu items can be registered in the favorite menu. Creating a shortcut Press (touch) then touch...

  • Page 94: Other Functions

    Other functions Setting the time and date Touch the current time on the screen. Touch to set the correct time and date. You can operate the following items: Year, month, date, hour, minute. TIPS • You can change the time display format to [12hour] or [24hour]. •...

  • Page 95: Restoring This Product To The Default Settings

    [Trimming] An image is displayed across the entire screen with the horizontal-to-vertical ratio left as is. If the screen ratio differs from the image, the image may be displayed partly cut off either at the top/bottom or sides. NOTE [Trimming] is for image files only. TIPS •...

  • Page 96: Apple Carplay

    • Apple CarPlay allows access to applications other than those listed that are subject to limitations while driving. • PIONEER IS NOT RESPONSIBLE AND DISCLAIMS LIABILITY FOR THIRD PARTY (NON-PIONEER) APPS AND CONTENT, INCLUDING WITHOUT LIMITATION ANY INACCURACIES OR INCOMPLETE INFORMATION.

  • Page 97: Starting Procedure

    Touch [Driving Position]. Touch the item. [Left] Select for a left-hand drive vehicle. [Right] Select for a right-hand drive vehicle. Starting procedure Connect an Apple CarPlay compatible device to this product via USB. Press (touch) Touch Touch [Apple CarPlay]. Touch Apple CarPlay icon in the tab. The application screen appears.
  • Page 98 Touch to mute. Touch again to cancel mute. Touch [+]/[-] to adjust the guidance volume. Displays the main sound volume. To adjust the main sound volume, press (touch) VOL (+/-) on the unit or touch [+]/[-]. NOTE The volume menu is displayed for four seconds. If the menu disappears, press (touch) VOL (+/-) again. The menu reappears.

  • Page 99: Android Auto

    • Android Auto allows access to applications other than those listed that are subject to limitations while driving. • PIONEER IS NOT RESPONSIBLE AND DISCLAIMS LIABILITY FOR THIRD PARTY (NON-PIONEER) APPS AND CONTENT, INCLUDING WITHOUT LIMITATION ANY INACCURACIES OR INCOMPLETE INFORMATION.

  • Page 100: Starting Procedure

    The system setting screen appears. Touch [Driving Position]. Touch the item. [Left] Select for a left-hand drive vehicle. [Right] Select for a right-hand drive vehicle. Starting procedure Connect an Android Auto™ compatible device to this product via USB. Press Touch Touch [Android Auto].

  • Page 101: Setting The Auto-Launch Function

    Touch to mute. Touch again to cancel mute. Touch [+]/[-] to adjust the guidance volume. Displays the main sound volume. To adjust the main sound volume, press VOL (+/-) on the unit or touch [+]/[-]. NOTE The volume menu is displayed for four seconds. If the menu disappears, press VOL (+/-) again. The menu reappears.

  • Page 102: Appendix For Apple Carplay And Android Auto

    If the error persists, – Restart the smartphone. record the error message and contact your – Turn the ignition switch to OFF and dealer or your nearest Pioneer service then to ON. center. If the error message is still displayed after...

  • Page 103: Detailed Information Regarding Connected Ipod Devices

    Lightning are trademarks of Apple Inc., devices registered in the U.S. and other countries. • Pioneer accepts no responsibility for data Apple CarPlay lost from an iPod, even if that data is lost while using this product. Please back up your iPod data regularly.
  • Page 104 Content application(s) or service by its provider. • Pioneer is not liable for any issues that may arise from incorrect or flawed app- based content. • The content and functionality of the supported applications are the responsibility of the App providers.

  • Page 105: Appendix

    → This product is not firmly secured. here, contact your dealer or the nearest – Secure this product firmly. authorized Pioneer service facility. No sounds are produced. The volume level will not rise. Common problems →...
  • Page 106 – Park your vehicle in a safe place, and Back image displayed when vehicle is not then turn off the ignition switch (ACC in reverse. OFF). Subsequently, turn the ignition → The camera polarity is not set properly switch to on (ACC ON) again. in the Camera settings menu.

  • Page 107: Error Messages

    → An error has occurred. dealer or your nearest Pioneer service – Park your vehicle in a safe place, and center. then turn off the ignition switch (ACC OFF).
  • Page 108 – Do not exceed the skip limit. your dealer or the nearest authorized – Spotify limits the total number of skips Pioneer service center for assistance. per hour. Check Tuner Check USB → The SiriusXM Connect Vehicle Tuner →...
  • Page 109 – Verify that your vehicle is outdoors Channel Locked Please Enter the Lock with a clear view of the southern sky. Code – Verify that the SiriusXM magnetic → Locked by the radio Parental Control mount antenna is mounted on a metal feature.
  • Page 110 memory into the unit. Please restart the Skipped unit. → The connected USB storage device → The USB connector or USB cable has contains DRM protected files. short-circuited. – The protected files are skipped. – Check that the USB connector or USB cable is not caught in something or Protect →...

  • Page 111: Detailed Information For Playable Media

    • Firmly secure the USB storage device contact your dealer or an authorized when driving. Do not let the USB storage Pioneer Service Station. device fall onto the floor, where it may become jammed under the brake or gas Detailed information pedal.
  • Page 112 • For details on the DivX video versions Media compatibility chart that can be played on this product, refer to Specifications (page 119). General • For more details about DivX, visit the • Maximum playback time of audio file following site: http://www.divx.com/ stored on an USB storage device: 7.5 h DivX subtitle files (450 minutes)
  • Page 113 AAC compatibility .avi Format: MPEG-4/DivX/H.264/H.263 • This product plays back AAC files Compatible video codec: MPEG-4 (Simple encoded by iTunes. Profile/Advanced Simple Profile)/DivX USB storage device (Home Theater Profile)/H.264 (Base Line File extension: .m4a Profile/Main Profile/High Profile)/H.263 Bit rate: 16 kbps to 320 kbps (CBR) (Baseline Profile 0/3) Sampling frequency: 8 kHz to 48 kHz Maximum resolution: 1 920 pixels ×...

  • Page 114: Bluetooth

    Bluetooth .asf SIG, Inc. and any use of such marks by PIONEER Format: VC-1 CORPORATION is under license. Other Compatible video codec: VC-1 (Simple trademarks and trade names are those of their Profile/Main Profile/Advanced Profile) respective owners.

  • Page 115: Siriusxm® Satellite Radio

    contributors may be used to endorse or SiriusXM® Satellite promote products derived from this Radio software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE...

  • Page 116: Aac

    MIXTRAX Please note that the use of this accessory with an Apple product may affect wireless performance. MIXTRAX is a trademark of the PIONEER iPhone, iPod, iPod nano, iPod touch, and CORPORATION. Lightning are trademarks of Apple Inc., registered in the U.S. and other countries.

  • Page 117: Using App-Based Connected Content

    Pandora Media, Inc. Used with • Latest version of the Pioneer compatible permission. connected content application(s) for the Pandora is only available in certain countries. smartphone, available from the service...

  • Page 118: Notice Regarding Mp3 File Usage

    may constitute an infringement on the • The LCD screen is exposed in order to author’s rights as protected by the increase its visibility within the vehicle. Copyright Law. Please do not press strongly on it as this may damage it. •...

  • Page 119: Specifications

    1 209 600 (2 520 × 480) visible. In that case, please consult your (MVH-1400NEX) dealer or the nearest authorized Pioneer 1 152 000 (2 400 × 480) Service Station. Display method:...
  • Page 120 HPF: kHz/4 kHz/5 kHz/6.3 kHz/8 kHz/10 kHz/ Frequency: 12.5 kHz 25 Hz/31.5 Hz/40 Hz/50 Hz/63 Hz/80 Slope: Hz/100 Hz/125 Hz/160 Hz/200 Hz/250 -6 dB/oct, -12 dB/oct, -18 dB/oct, -24 dB/oct, -30 dB/oct, -36 dB/oct, OFF Slope: Subwoofer: -6 dB/oct, -12 dB/oct, -18 dB/oct, -24 Frequency: dB/oct, OFF 25 Hz/31.5 Hz/40 Hz/50 Hz/63 Hz/80...
  • Page 121 Linear PCM: Usable sensitivity: 16 kHz/22.05 kHz/24 kHz/32 kHz/44.1 12 dBf (1.1 μV/75 Ω, mono, S/N: 30 dB) kHz/48 kHz Signal-to-noise ratio: <USB image> 72 dB (IHF-A network) JPEG decoding format (MSC Mode only): AM tuner .jpeg, .jpg, .jpe Frequency range: Pixel Sampling: 4:2:2, 4:2:0 530 kHz to 1 710 kHz Decode Size:...
  • Page 122 © 2017 PIONEER CORPORATION. All rights reserved. <CRI1019-D> UC...

This manual is also suitable for:

Mvh-2300nexMvh-2400nex

Table of Contents
