Sharp 29K-FD5RU Service Manual

Hide thumbs Also See for 29K-FD5RU:

Advertisement

Quick Links

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
Ë World Multi 28 System
Ë 100-CH Program Memory
Ë AV Mode (Standard / Dynamic /
Soft / Custom)
Ë CATV Hyper Band Ready
Ë 4 Line Digital Comb Filter
Ë Velocity Modulation
Ë Blue/Black Stretch Circuit
Ë Picture Noise Reduction
Ë White Temp. Select
Ë Aperture Control
Ë Gamma Correction
» SPECIFICATIONS ........................................... 2
» IMPORTANT SERVICE NOTES ...................... 2
» ADJUSTMENT PRECAUTIONS ..................... 3
» CHASSIS LAYOUT ........................................ 24
» BLOCK DIAGRAM ........................................ 26
» WAVEFORMS ............................................... 30
■ CRT UNIT ................................................. 32
The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and power
receptacle, when servicing this chassis. To prevent electric shock, do not remove cover. No user - serviceable
parts inside. Refer servicing to qualified service personnel.
SERVICE MANUAL
MODELS
FEATURES
Ë Multi Language OSD (English / Russian)
Ë On/Off/Reminder Timer (with Beep Sound)
Ë Comfy View
Ë Rear AV-IN 1 & 2, S-Video In, AV Output
(Monitor Out), Headphone and Front AV-IN 3
Ë AFT
Ë Component Input Terminal
Ë Multi Language TELE TEXT
Ë Surround Sound SRS 3D (for 29K-FD5RU
only)
Ë Base Emphasis (BBE) (for 29K-FD5RU only)
Ë NICAM/A2
CONTENTS
Page
WARNING
SHARP CORPORATION
1
COLOUR TELEVISION
Chassis No.GB-4
29K-FD5RU
29K-FG5RU
Ë Child Lock
Ë Dynamic Skin Tone
Ë Graphic Equalizer
Ë Clock
Ë Sound Mode (Music / Movie /
News / Custom)
Ë Hotel Mode
Ë 16 : 9 Mode
Ë PIP (for 29K-FD5RU only)
Ë Woofer (for 29K-FD5RU only)
Ë Tweeter (for 29K-FD5RU only)
■ PIP UNIT .................................................. 33
■ MAIN UNIT ............................................... 34
■ FRONT UNIT ............................................ 38
■ ELECTRICAL PARTS ............................... 47
■ MISCELLANEOUS PARTS ...................... 56
■ SUPPLIED ACCESSORIES ..................... 56
■ PACKING PARTS ..................................... 56
■ CABINET PARTS ..................................... 56
» PACKING OF THE SET ................................ 57
29K-FD5RU
29K-FG5RU
S95O229KFD5RU
Page

Advertisement

Table of Contents
loading

Summary of Contents for Sharp 29K-FD5RU

  • Page 1: Table Of Contents

    Ë Blue/Black Stretch Circuit Ë Multi Language TELE TEXT Ë 16 : 9 Mode Ë Picture Noise Reduction Ë Surround Sound SRS 3D (for 29K-FD5RU Ë PIP (for 29K-FD5RU only) Ë White Temp. Select Ë Woofer (for 29K-FD5RU only) only) Ë...
  • Page 19: Trouble Shooting Flowchart

    TROUBLE SHOOTING FLOWCHART TROUBLE SHOOTING FLOWCHART (Continued) NO RASTER NO LED LIGHT GREEN LED COLOUR ? Check F3700. Check F4701. Check CRT connector (KY), (H) bias GREEN Power on by R/C. (14V,120 V, 210 V line). Normal Blown out Normal Abnormal Does horizontal circuit Replace the Fuse.
  • Page 20 TROUBLE SHOOTING FLOWCHART (Continued) NO PICTURE Does the snow noise appear on the screen at maximum Snow noise increase. contrast and brightness ? Check the PC+5V line. Does 5V appear at pin 7 of TU 51 ? Does 31V appear at pin 9 of TU 51 ? Check +120V line at IC 753 and its related circuit.
  • Page 21 TROUBLE SHOOTING FLOWCHART (Continued) TROUBLE SHOOTING FLOWCHART (Continued) NO SPECIFIC COLOUR Is only RF signal's colour abnormal? No snow noise. COLOUR PRODUCED Check pin 104 & 105 of IC2100. Check tuner TU 51, NO COLOUR SF201and its related circuit. Normal Abnormal Set colour Adjust the colour control at the...
  • Page 22 TROUBLE SHOOTING FLOWCHART (Continued) Is some colours produced in the B/W broadcast reception ? Check IC 2100 & IC 851 and its Is the white balance properly Readjust the related circuit including the RGB adjusted ? white balance. input & output line. The picture The picture The picture...
  • Page 23: Solid State Device Base Diagram

    29K-FD5RU 29K-FG5RU SOLID STATE DEVICE BASE DIAGRAM TOP VIEW SDA9489X STV9380 PCF8563S FXA003W 2883E3 BR24L32 4 5 6 3 2 1 EX1394 KiA358P iP 0254 C7W66U RH-i XA972WJ iM Z1A iM X1C COLLEC TOR COLLEC TOR COLLEC TOR COLLEC TOR...
  • Page 24: Chassis Layout

    29K-FD5RU 29K-FG5RU CHASSIS LAYOUT (29K-FD5RU)
  • Page 25 29K-FD5RU 29K-FG5RU CHASSIS LAYOUT (29K-FG5RU)
  • Page 26: Block Diagram

    29K-FD5RU 29K-FG5RU BLOCK DIAGRAMS (29K-FD5RU)
  • Page 27 29K-FD5RU 29K-FG5RU...
  • Page 28 29K-FD5RU 29K-FG5RU BLOCK DIAGRAMS (29K-FG5RU)
  • Page 29 29K-FD5RU 29K-FG5RU...
  • Page 30: Waveforms

    29K-FD5RU 29K-FG5RU WAVEFORMS Horizontal Rate Vertical Rate Vertical Rate Horizontal Rate Pin 2 Vp-p = 1.30 V Pin 3 Vp-p = 2.26 V Pin 4 Vp-p = 2.40 V Pin 1 Vp-p = 2.02 V Vertical Rate Vertical Rate Vertical Rate Vertical Rate Pin 6 Vp-p = 29.40 V...
  • Page 31: Description Of Schematic Diagram

    29K-FD5RU 29K-FG5RU DESCRIPTION OF SCHEMATIC DIAGRAM SAFETY NOTES: NOTES: 1. The unit of resistance “ohm” is omitted. 1. DISCONNECT THE AC PLUG FROM THE AC OUTLET BEFORE REPLACING PARTS. (K = 1000 ohms, M = Meg ohm). 2. SEMICONDUCTOR HEAT SINKS SHOULD BE REGARDED AS 2.
  • Page 32: Schematic Diagram

    29K-FD5RU 29K-FG5RU SCHEMATIC DIAGRAM CRT UNIT...
  • Page 33: Pip Unit

    29K-FD5RU 29K-FG5RU PIP UNIT (29K-FD5RU ONLY)
  • Page 34 29K-FD5RU 29K-FG5RU MAIN UNIT (29K-FD5RU)
  • Page 35 29K-FD5RU 29K-FG5RU...
  • Page 36 29K-FD5RU 29K-FG5RU MAIN UNIT (29K-FG5RU)
  • Page 37 29K-FD5RU 29K-FG5RU...
  • Page 38 29K-FD5RU 29K-FG5RU FRONT UNIT...
  • Page 39 29K-FD5RU 29K-FG5RU...
  • Page 40: Main Unit

    VHD1SS133++-1Y R 1SS133 (29K-FD5RU) D520 RH-EX0609GEZZY R Zener Diode, EX0609GE AA (NOT REPLACEMENT ITEM) D521 VHD1SS133++-1Y R 1SS133 PWB-A DUNTKC516WEi6 – MAIN UNIT (29K-FD5RU) — D522 RH-EX0609GEZZY R Zener Diode, EX0609GE, 4.8V AA PWB-A DUNTKC516WEi4 – MAIN UNIT (29K-FG5RU) — D601 VHD1SS244//-1Y...
  • Page 41 C312 VCKYCY1HB104KY R 0.1 50V Ceramic L302 RCiLPA288WJZZ R Coil, 4.7µH C313 VCKYCY1HB153KY R 0.015 50V Ceramic L303 RCiLPA288WJZZ R Coil (29K-FD5RU) C314 VCKYCY1HB221KY R 220p 50V Ceramic L304 RCiLPA288WJZZ R Coil (29K-FD5RU) C315 VCKYTV1HF224ZY R 0.22 50V Ceramic L503...
  • Page 42 29K-FD5RU 29K-FG5RU ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code C348 VCKYTV1HF224ZY R 0.22 50V Ceramic C517 RC-FZ0272CEZZ+ R 0.39 100V M.Polypro. (29K-FD5RU) C518 VCEA0A1HW107M+R 100 50V Electrolytic C349 VCKYCY1HB104KY R 0.1 50V Ceramic C519 VCEA9M1HW474M+R 0.47...
  • Page 43 29K-FD5RU 29K-FG5RU ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code C757 VCEA0A1CW476M+R 47 16V Electrolytic C2017 VCKYCY1CF224ZY R 0.22 16V Ceramic (29K-FG5RU) C2018 VCKYCY1HB104KY R 0.1 50V Ceramic C758 RC-KZ0120GEZZ R 150 Ceramic C2019...
  • Page 44 29K-FD5RU 29K-FG5RU ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code R317 VRS-CY1JF562JY R 5.6k 1/16W Metal Oxide AA R524 VRD-RA2BE103JY R 10k 1/8W Carbon R318 VRS-CY1JF000JY R 0 1/16W Metal Oxide AA R525 VRD-RA2BE102JY R 1k...
  • Page 45 29K-FD5RU 29K-FG5RU ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code R923 VRS-CY1JF221JY R 220 1/16W Metal Oxide AA R2038 VRS-CY1JF333JY R 33k 1/16W Metal Oxide AA (29K-FD5RU) R2039 VRS-CY1JF101JY R 100 1/16W Metal Oxide AA...
  • Page 46 VHD1SS133++-1Y R 1SS133 (29K-FD5RU) D1507 VHD1SS133++-1Y R 1SS133 P301 QPLGN0461CEZZ R Plug, 4Pin(SP) D1508 RH-DX0487CEZZY R Diode, DX0487CE P303 QPLGN0361CEZZ R Plug (29K-FD5RU) D1509 RH-DX0487CEZZY R Diode, DXA006WJ P401 QPLGN0878GEZZ R Plug, 8Pin(KY) å P601 QPLGN0160FJZZ R Plug, 5Pin(K) CAPACITORS...
  • Page 47 29K-FD5RU 29K-FG5RU ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code COIL AND TRANSFORMERS R1511 VRD-RA2BE683JY R 68k 1/8W Carbon å L4701 RCiLFA106WJZZ R Coil R1512 VRD-RA2BE122JY R 1.2k 1/8W Carbon L4903 RCiLP0195CEZZ+ R Coil...
  • Page 48 29K-FD5RU 29K-FG5RU ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code MISCELLANEOUS PARTS RESISTORS å F4701 QFS-CA003WJZZ R Fuse, T5A, 250V R1624 VRD-RA2BE103JY R 10k 1/8W Carbon FB4701 RBLN-0094GEZZY R Balun, BLN-0094GE R1701 VRD-RA2BE101JY R 100 1/8W Carbon...
  • Page 49: Miscellaneous Parts

    Unit (29K-FD5RU) RRMCGA271WJSA R Infrared Remote Control Unit (29K-FG5RU) PACKING PARTS (NOT REPLACEMENT ITEM) SPAKCC093WJZZ – Packing Case — TLABZB009WJZZ – Case Label(29K-FD5RU) — TLABZB008WJZZ – Case Label(29K-FG5RU) — SPAKXA810WJZZ – Packing Add. — SPAKPA048WJZZ – Wrapping Sheet — 2-1 2...
  • Page 50 29K-FD5RU 29K-FG5RU COPYRIGHT © 2005 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

This manual is also suitable for:
