OWNER'S MANUAL
AIR
CONDITIONER
Please read this manual carefully before operating
your set and retain it for future reference.
TYPE : WALL MOUNTED
MODELS : SS-H106T4A1
SS-H126T4A1
SS-H186T4A1
SS-H246T4A1
The equipment complies with requirements of the Technical Regulation,
in terms of restrictions for the use of certain dangerous substances in
electrical and electronic equipment.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG SS-H106T4A1
Summary of Contents for LG SS-H106T4A1
- Page 1 OWNER’S MANUAL CONDITIONER Please read this manual carefully before operating your set and retain it for future reference. TYPE : WALL MOUNTED MODELS : SS-H106T4A1 SS-H126T4A1 SS-H186T4A1 SS-H246T4A1 The equipment complies with requirements of the Technical Regulation, in terms of restrictions for the use of certain dangerous substances in electrical and electronic equipment.
- Page 2 TIPS FOR SAVING ENERGY TIPS FOR SAVING ENERGY Here are some tips that will help you minimize the power consumption when you use the air conditioner. You can use your air conditioner more efficiently by referring to the instructions below: •...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product WARNING It can result in serious injury or death when the directions are ignored CAUTION It can result in minor injury or product damage when the directions are ignored WARNING... - Page 4 IMPORTANT SAFETY INSTRUCTIONS • Do not install the air conditioner on an unstable surface or where there may be a danger of it falling. It may result in death, serious injury, or product failure. • Use inflammable gas (nitrogen) to inspect leak and to purge air, using compressed air or flam- mable gas may cause fire or explosion.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS CAUTION Installation • Make sure to check if there is a refrigerant leak after you install or repair the air conditioner. Failure to do so may result in product failure. • Install the drain hose properly for smooth drainage of condensed water. Failure to do so may result in product failure.
-
Page 6: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS TIPS FOR SAVING ADVANCED FUNCTIONS ENERGY Operating the air conditioner without the remote control Restarting the air conditioner automatically IMPORTANT SAFETY INSTRUCTIONS MAINTENANCE Cleaning the Air filter BEFORE USE Components TROUBLESHOOTING Using the remote control Self-diagnosis function Before requesting service BASIC FUNCTIONS... -
Page 7: Before Use
BEFORE USE BEFORE USE Components Indoor unit Air inlet Reset switch Front grille Air filter Vertical louver & Horizontal vane Air outlet * Please keep the protective film of reset switch. It is used to protect the PCB from ESD damage. * The feature can be changed according to type of model. -
Page 8: Using The Remote Control
BEFORE USE Using the remote control You can operate the air conditioner more conveniently with the remote control. You will find the buttons for the additional functions under the cover of the remote control. Wireless remote control Control Display Description panel screen Sleep mode auto button*: SLEEP indi-... - Page 9 BEFORE USE Inserting batteries Fix the holder by fastening the 2 screws firmly with a screwdriver. Insert batteries before using the remote control. The battery type used is AAA (1.5 V) Remove the battery cover. Type “B” screw Slide the remote control into the holder. Insert the new batteries and make sure that the + and - terminals of the batteries are installed correctly.
-
Page 10: Basic Functions
BASIC FUNCTIONS BASIC FUNCTIONS Cooling your room Removing humidity (Cooling operation) (Dehumidifying operation) Press to turn on the power. This mode removes excess moisture from an environment with high humidity or in the rainy Press repeatedly to select the cooling season, in order to prevent mold from setting operation. -
Page 11: Airing Your Room
BASIC FUNCTIONS Airing your room Adjusting the air flow (Air Circulation operation) direction This mode only circulates the indoor air To adjust the direction of the air flow horizon- tally, press repeatedly and select the de- without changing the room temperature. sired direction. -
Page 12: Turning On The Air Conditioner Automatically At A Set Time
BASIC FUNCTIONS Turning on the air conditioner Turning off the air conditioner automatically at a set time automatically at a set time To activate the time on, the air conditioner To activate the time off, the air conditioner should be off. should be on. -
Page 13: Advanced Functions
ADVANCED FUNCTIONS ADVANCED FUNCTIONS Restarting the air conditioner The air conditioner offers some additional ad- vanced functions. automatically When the air conditioner is turned on again Operating the air conditioner after a power failure, this function restores without the remote control the previous settings. -
Page 14: Maintenance
MAINTENANCE MAINTENANCE Clean the product regularly to maintain optimal performance and to prevent possible breakdown. * This may not be provided, depending on the model. Air filter * The feature can be changed according to type of model. Item Cleaning interval Cleaning method Air filter 2 weeks... -
Page 15: Cleaning The Air Filter
MAINTENANCE Cleaning the Air filter Clean the Air filter once every 2 weeks or more if necessary. Turn off the power and unplug the power cord. Open the front cover. - Lift up both sides of the cover slightly. * The feature can be changed according to type of model. -
Page 16: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Self-diagnosis function In case of error, the display on the indoor unit shown the folloing error codes: Code RUN lamp Description of the trouble Flashes once The fault of indoor temperature sensor Flashes twice The fault of indoor pipe temperature sensor Flashes 6 times Malfunction of indoor fan motor Before requesting service... -
Page 17: Operation Ranges
TROUBLESHOOTING Problem Possible causes Corrective action Make sure that there are no curtains, Air is not circulating blinds or furniture blocking the front of the properly. air conditioner. Clean the air filter once every 2 weeks. The Air filter is dirty. See “Cleaning Air filter”...
