D-Link DFB-H7 Quick Installation Manual

7-port usb 2.0/firewire combo hub

Download this manual

This product can be used with the

following operating systems:

Windows XP, Me, 2000, 98SE,

Mac OS 10.1 and above

Before You Begin

You must have at least the following:

•

Pentium 233 MHz or faster with 64MB RAM

•

Available USB 2.0 Port

•

Available Firewire Port

•

Windows XP, 2000, Me, 98SE, or Mac OS 10.1 and above for both

USB 2.0 and Firewire Operation

Check Your Package Contents

These are the items included with your purchase:

If any of the below items are missing, please contact your reseller.

their respective holders. Software and specifications subject to change without notice. DFB-H7.08192003

• DFB-H7 7-Port USB 2.0/Firewire

Combo Hub

• USB 2.0 Cable

• 1394 Firewire Cable (6-pin to 6-pin)

• Power Adapter

(5V 2.5A)

DFB-H7

7-Port USB 2.0/

Firewire Combo Hub

Page 1 • 1394 Firewire Cable (6-pin to 6-pin) • Power Adapter (5V 2.5A) ©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DFB-H7.08192003 DFB-H7...
Page 2 Your computer will automatically detect and install the DFB-H7. Your installation is now complete! You may now connect USB 2.0 or USB 1.1 devices and/or Firewire devices to an available USB port or Firewire port on the front of the DFB-H7. Type B Type A...
Page 3 • If you wish to use only the USB ports on the DFB-H7, the Firewire port located on the back of the DFB-H7 does not need to be connected to your host computer or hub.
Page 4 Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link Technical Support through our website, or by phone.
