Sharp LC-32DH500 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

DVB-T (HDTV), PAL
ELECTRICAL SPECIFICATIONS .............................................................................. 2
IMPORTANT SERVICE SAFETY PRECAUTIONS...................................................... 3
OPERATION MANUAL ............................................................................................... 6
DIMENSIONS ......................................................................................................... 10
REMOVING OF MAJOR PARTS ..................................................................................... 11
SERVICE ADJUSTMENTS ..................................................................................... 16
SOFTWARE UPDATING .................................................................................... 28
MAJOR ICs INFORMATION ..................................................................................... 29
SOURCE OF DOCUMENTATION ..................................................................................... 39
CHASSIS LAYOUT .................................................................................................. 40
BLOCK DIAGRAMS ......................................................................................... 43
WIRING DIAGRAMS ......................................................................................... 44
SCHEMATIC DIAGRAMS ......................................................................................... 45
PRINTED WIRING BOARDS ..................................................................................... 60
REPLACEMENT PARTS LIST .................................................................................. 64
CABINET AND MECHANICAL PARTS .......................................................................... 72
PACKING OF THE SET ........................................................................................... 73
1st Edition
/ SECAM
B/G, I
B/G, D/K, L/L'
In the interests of user safety (required by safety
regulations in some countries) the set should be re-
stored to its original condition and only parts identical
to those specifi ed should be used.
CONTENTS
SHARP CORPORATION
SERVICE MANUAL
LCD
COLOUR TELEVISION
SYSTEM COLOUR TELEVISION
MODELS
LC-32DH500E/RU/S
1
LC-32DH500
SE00LC32DH5FE
th
Issued: 28
This document has been published to
be used for after sales service only.
The contents are subject to chage without notice.
Oct. 2009

Advertisement

Table of Contents
loading

Related Manuals for Sharp LC-32DH500

Summary of Contents for Sharp LC-32DH500

  • Page 1: Table Of Contents

    LC-32DH500 1st Edition SERVICE MANUAL SE00LC32DH5FE Issued: 28 Oct. 2009 COLOUR TELEVISION DVB-T (HDTV), PAL / SECAM SYSTEM COLOUR TELEVISION B/G, I B/G, D/K, L/L’ MODELS LC-32DH500E/RU/S In the interests of user safety (required by safety regulations in some countries) the set should be re- stored to its original condition and only parts identical to those specifi...

  • Page 2: Electrical Specifications

    Cautions regarding use in high and low temperature environments • As a part of our policy of continuous im- provement, SHARP reserves the right to • When the unit is used in a low temperature space (e.g. room, offi ce), the make design and specifi...

  • Page 3: Important Service Safety Precautions

    LC-32DH500 IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualifi ed service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING 1. For continued safety, no modifi cation of any circuit should be attempted.
  • Page 4 LC-32DH500 PRECAUTIONS FOR USING LEAD-FREE SOLDER 1 Employing lead-free solder “ALL PWB” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.
  • Page 5 If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities.

  • Page 6: Operation Manual

    LC-32DH500 OPERATION MANUAL...
  • Page 7 LC-32DH500 Operation Manual (Continued)
  • Page 8 LC-32DH500 Operation Manual (Continued)
  • Page 9 LC-32DH500 Operation Manual (Continued)

  • Page 10: Dimensions

    LC-32DH500 DIMENSIONS 53.3 94.9 775.5 699.2 361.2 200.0...

  • Page 11: Removing Of Major Parts

    LC-32DH500 REMOVING OF MAJOR PARTS [1] REMOVING OF MAJOR PARTS 1. Remove the 4 lock screws and detach the Stand. 2. Remove the 8 lock screws , 1 lock screws , 1 lock screw and detach the Rear Cabinet. Rear Cabinet...
  • Page 12 LC-32DH500 Removing of major parts (Continued) 3. Disconnect all the connectors from all the PWBs. 4. Remove the KEY Unit Ass'y Operation Button 5 KEY Unit [KM] [PD] [LA] [KM] [LV] [RA] [SP] SP-R SP-L...
  • Page 13 LC-32DH500 Removing of major parts (Continued) 5. Remove the Speaker (R) , (L) 6. Remove the 4 lock screws and detach the POWER Unit. 7. Remove the 4 lock screws , and detach the MAIN Unit. 8. Remove the 2 lock screws and detach the MINI AV Cover.
  • Page 14 LC-32DH500 Removing of major parts (Continued) 9.Remove the 2 lock screws , 2 lock screws and detach the Stand Bracket set. 10.Remove the R/C, LED Unit R/C,LED Unit Stand Bracket set...
  • Page 15 LC-32DH500 Removing of major parts (Continued) 11.Remove the 2 lock screws and detach the Bracket set. Bracket set...

  • Page 16: Service Adjustments

    2. Press and hold “V-” and “b” keys, simultaneously, and then plug the AC power cord. 3. “K” appears on the screen. 4. Press and hold “V-” and “P-” keys, simultaneously. 5. “SHARP FACTORY MENU” appears (see Figure 1). 6. Unplug the AC power cord to exit of adjustments process. 2. By own R/C 1.
  • Page 17 Function Cursor (▼/▲ ) Moving an item (line) by one (up/down) on “Sharp Factory Menu” or submenus. Selecting a submenu on lines 5 to 12 of “Sharp Factory Menu” or executing a function. Cursor (◄/►) V (+/-) Changing a selected item setting value.
  • Page 18 ← I2C OFF ← I2C BUS status. On: free BUS. Off: Normal. ← ← ← Remote Control Protocol. On: SHARP Off: MSTAR. ← ← Sharp protocol …0: off. 1: White 100%. 2: White 50%. 3: Red 100% 4: Green 100%. 5: Blue 100%. 6: Black 0%.
  • Page 19 LC-32DH500 5. Adjustment process mode menu (continued) Figure 5: PUBLIC MODE Menu 1/2 PUBLIC MODE ◄ ► Power On fi xed Variable ← Press “ ← ← ” or “ ” to change Variable/Fixed. Maximum volume ◄ ► ← Press “...
  • Page 20 LC-32DH500 5. Adjustment process mode menu (continued) Figure 8: ADC ADJUST Menu ADC ADJUST ◄ ► ← Press “ ← ← ” or “ ” to change RGB/YPbPr(SD)/ YPbPr(HD). MODE ◄ ► ← Press “ ← ← ” or “...
  • Page 21 LC-32DH500 5. Adjustment process mode menu (continued) Figure 11: GAMMA Menu 3/3 GAMMA MGAMMA R4 ← W/B adjustment, gradation 4R adjustment value. ← ← MGAMMA G4 ← W/B adjustment, gradation 4G adjustment value. ← ← MGAMMA B4 ← W/B adjustment, gradation 4B adjustment value.
  • Page 22 LC-32DH500 6. Video Signal Adjustment Procedure 6.1. RGB SCART ADC 1. Enter in Service mode. 2. Press “▼” until selecting “ADC ADJUST” option. 3. Press “OK”. 4. “ADC ADJUST” menu appears. Fig. 7. 5. Press “▼” until selecting “ADJUST” option.
  • Page 23 LC-32DH500 7. White Balance Adjustment Condition: AV MODE= Dynamic (backlight at max.). • Adjustments reference device: Minolta CA-210 • Adjustments target: x=0.272, y=0.277 High: adjustments spec ±0.001, inspection spec: ±0.002 Low: adjustments spec ±0.002, inspection spec: ±0.004 1. Press “▼” until selecting “GAMMA” option.
  • Page 24 LC-32DH500 8. Initialization to factory setting Caution: When the factory settings have been made, all user setting data, including the channel settings, are initialized. (The adjustments done in the adjustment process mode are not initialized.) Keep this in mind when initializing these settings.
  • Page 25 LC-32DH500 9. Lamp error detection 1. Function description This LCD colour television has a function (lamp error detection) to be turned OFF the TV set automatically for safety criteria when the lamp or lamp circuit is abnormal. If the lamp or lamp circuit is abnormal, or some other errors happen, and the lamp error detection is executed, the following occurs: a.
  • Page 26 LC-32DH500 10. Public Mode (Hotel mode) 1. How to Enter in the Public Mode (Hotel Mode). There are three following ways to display the Public Mode setting screen. Method 1: Turn on the power and enter in the Service mode as usual and select line 8 [PUBLIC MODE].
  • Page 27 LC-32DH500 10. Public Mode (Hotel mode) (continued) 8. ON SCREEN DISPLAY [On Off] If “NO” has been selected, the On Screen Display does not appear. 9. INPUT MODE START [NORMAL → TV → SCART1 → SCART2 → COMPONENTS → HDMI1 → HDMI2 →...

  • Page 28: Software Updating

    2. Press “MENU”. • “PICTURE” menu appears on screen. 3. Press “►” until selecting “OPTION” menu. 4. Press “▼” until selecting “Software update (USB) Sharp v*.*”. • The current software version is displayed. 5. Press “OK” • “Are you sure? Yes - No” message is displayed.

  • Page 29: Major Ics Information

    It contains a signal processor to offer high quality reception of analog terrestrial multistandard signal. • IC 306: Audio power IC Part number: MSH 9000-LF Sharp code : RH-IXC867WJQZY 10W-Ch audio power class-D operation for driving bridged-tied stereo speakers. • IC 309: Headphones amplifi er.
  • Page 30 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) 2.1. IC201 (MSB1220LQFP) 2.1.1. Block Diagram RF_AGC RF/IF MPEG TS Out IF_AGC DVBT DEMOD ZIF_I 11-bit ZIF_Q ADC x 2 Video SAW VIF DBB DEMOD Front End Tuner MPEG Audio SAW SSIFO...
  • Page 31 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) (continued) 2.1. IC201 (MSB1220LQFP) 2.1.2. Pin Description (continued) Analog Interface Pin Name Pin Type Function SSIFO Analog output SSIF Output CVBSOUT Analog output CVBS Output CLKO Analog output Clock Output VR27 Analog output...
  • Page 32 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) (continued) 2.2. IC 306 ( MSH 9000-LF ) 2.2.1. Functional Block Diagram FBPL HVDDL VIPL Output Driver OUTPL Modulator VINL OUTNL HVSSL FBNL FBPR HVDDR VIPR Output Driver OUTPR Modulator VINR OUTNR...
  • Page 33 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) (continued) 2.2. IC 306 ( MSH 9000-LF ) 2.2.2. Pin Description Analog Interface Pin Name Pin Type Function VIPL Analog Input Left channel P side audio input VINL Analog Input Left channel N side audio input...
  • Page 34 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) (continued) 2.3. IC 1001 (MSD3303GX) 2.3.1. Key Features • Master CPU with MMU. • DRAM controller supporting up to two 16-bit DDR2 interface. • Power control module with ultra low power MCU available in stand by mode.
  • Page 35 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) (continued) 2.3. IC 1001 (MSD3303GX) 2.3.3. Pin Description Analog Interface Pin Name Pin Type Function VCLAMP CVBS/YC Mode Clamp Voltage Bypass REFP Internal ADC Top De-coupling Pin REFM Internal ADC Bottom De-coupling Pin...
  • Page 36 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) (continued) 2.3. IC 1001 (MSD3303GX) 2.3.3. Pin Description (continued) Analog Audio Input/Output Interface Pin Name Pin Type Function SIF0P Analog Input SIF Audio Input Channel 0 SIF0M Analog Input Reference Ground for SIF Audio Input Channel 0...
  • Page 37 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) (continued) 2.3. IC 1001 (MSD3303GX) 2.3.3. Pin Description (continued) Common Interface Pin Name Pin Type Function PCMDATA[7:0]/ PCMCIA Data[7:0] / AE14, AD14, CI_DATA[7:0] Common Interface Data[7:0] AC14, AB14, AA14, AB20, AC20, AD20...
  • Page 38 LC-32DH500 2. Detailed ICs Information, DUNTKF261WE (Main Unit) (continued) 2.3. IC 1001 (MSD3303GX) 2.3.3. Pin Description (continued) DVI/HDMI Interface Pin Name Pin Type Function RXACKN DVI/HDMI Input Negative DVI/HDMI Input for A Link Clock Channel RXACKP DVI/HDMI Input Positive DVI/HDMI Input for A Link Clock Channel...

  • Page 39: Source Of Documentation

    LC-32DH500 SOURCE OF DOCUMENTATION IC201 (MSB1210) MSTAR Semiconductor: Preliminary Data Sheet. Version 0.2. Digital DVBT / VIF Demodulator. Doc. No.: MSB1210_ds_v02. August 2009. IC 306 (MSH 9000-LF) MSTAR Semiconductor; Preliminary Product Brief Version 0.3. Power Management IC. Doc. No.: MSH9000_pb_v03. April 2009.

  • Page 40: Chassis Layout

    LC-32DH500 CHASSIS LAYOUT Main Unit Layout LED Unit PWB ( QPWBXF261WJZZ QPWBXF262WJZZ) DUNTKF262WE QPWBXF262WJZZ R5109 X201 SLD5101 C377 C374 C362 IC204 C361 R1514 FB1501 IC202 C409 IC201 D5103 R5101 C5107 D5101 R1527 C703 C381 C369 IC4403 D701 R1549 R509 R556...
  • Page 41 LC-32DH500 Power Unit Layout RDENCA366WJQZ...
  • Page 42 LC-32DH500 KEY Unit Layout QPWBXF266WJ...
  • Page 43 LC-32DH500 OVERALLL WIRING DIAGRAM P151 INVERTER UNIT KEY UNIT QPLGNQ059WJZZ (DUNTKE266WE) MAIN UNIT P3071 (DUNTKF261WE) QPLGNA324WJZZY C.I. TUNER P1701 QCNW-K097WJZZ DIGITAL AUDIO OUTPUT MEDIA SPDIF INPUT PLAYER SERVICE COMPONENTS / AV SCART 2 SCART 1 (AV / S-VIDEO) (AV / RGB)

  • Page 44: Block Diagrams

    LC-32DH500 SYSTEM BLOCK DIAGRAM LCD_PANEL LC-32DX50 BLOCK DIAGRAM (DUNTKF261WE__) INV-UNIT (QPWBXF261WJN_ ) QCNW-F068WJQZ MAIN-UNIT SC8201 LV CVBS IN R/C LED_UNIT AUDIO L-R IN (DUNTKF262WE__) RGB IN BU3.3V CVBS OUT RMC 5101 IR_RECEIVER QCNW-G662WJQZ D5103 SCART 1 AUDIO L-R OUT Audio out scart 1...

  • Page 45: Schematic Diagrams

    LC-32DH500 SCHEMATIC DIAGRAMS LED Unit Diagram DUNTKF262WE01 Description: DUNTKF262WE01 VOLTAGE MEASUREMENT CONDITION: 1. The voltages at test points are measured on the stable supply voltage of AC 230V. Signals are fed by a color bar signal generator for servicing purpose and the above voltages are measured with a 20k ohm/V tester.
  • Page 46 LC-32DH500 Main Unit Diagram 1/13 DUNTKF261WE01 (System Power) DUNTKF261WE01 D+3.3V D+5V D+5V P1701 R361 R327 N0185FJ R330 4.7K TP173 TP126 R362 LAMP ERR LERROR TP114 BKL_DIM BRI_ADJ-PWM2 R345 TP115 BKL_EN R329 TP116 4.7K POWER ON VBLCTRL-P2 TP117 C332 TP185 0.1u...
  • Page 47 LC-32DH500 Main Unit Diagram 2/13 DUNTKF261WE01 (MSTAR IC) DUNTK261WE01 D+3.3V TO SHEET 002 D+3.3V VBLCTRL-P2 VBLCTRL-P2 BRI_ADJ-PWM2 BRI_ADJ-PWM2 POWER_ON POWER_ON LERROR EDID_WP LERROR R1PWR5V TO SHEET 008 MUTE_S SPDIF SPDIF R0PWR5V Tuner_AFT TUN_RESET TO SHEET 009 MUTE_SPEAKER MUTE_SPEAKER AU_DAC0_L AU_DAC0_L...
  • Page 48 LC-32DH500 Main Unit Diagram 3/13 DUNTKF261WE01 (DDR BLOCK) DUNTKF261WE01 C139 C140 C141 C142 C144 C145 C146 C159 C161 C162 C163 C165 C166 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u C147 C149 C150 C151 C153 C154 C167...
  • Page 49 LC-32DH500 Main Unit Diagram 4/13 DUNTKF261WE01 (SCART) DUNTKF261WE01 8V_AUDIO VCC5_T 2SA1530AR C3426 0210TA R173 SC1101 C198 C183 C184 ZA161WJ 0.1u R185 0.1u R193 AUOutL_SCART VXA187WJQZ R187 C3431 VXA187WJQZ R8168 R8169 C195 R8170 SCART_CVBS0 C3429 C191 C3430 C3428 R192 R8167 C196...
  • Page 50 LC-32DH500 Main Unit Diagram 5/13 DUNTKF261WE01 (HDMI INTERFACE) DUNTKF261WE01 HDMI0_HPDIN HDMI0-SDA D+3.3V HDMI0-SCL HDMI_CEC HDMI0-5V Q202 HDMI1-5V R203 RT1N441U SC1901 ZA173WJQZ R1PWR5V HDMI1-5V TP148 R247 TP149 RB425D HDMI1_VCC TP150 D+5V HDMI1_HPDIN R243 HDMI0-CLKN TP151 HDMI1-5V R242 HDMI0-CLKP C207 R250 TP152 R226 0.1u...
  • Page 51 LC-32DH500 Main Unit Diagram 6/13 DUNTKF261WE01 (AUDIO INTERFACE) DUNTKF261WE01 D+5V D+5V R293 R296 R295 R299 4.7K D+5V TO SHEET 003 R292 MUTE_SPEAKER R298 4.7K R300 AMP_STB AU_DAC0_L MUTE_EAR AU_DAC0_R R302 C3399 220u C217 EAR_Detect R8136 C3412 0.22u 2200P 12VAMP D+5V R8137 8.2K...
  • Page 52 LC-32DH500 Main Unit Diagram 7/13 DUNTKF261WE01 (AUDIO AMP. INTERFACE) DUNTKF261WE01 D+5V D+5V R293 R296 R295 R299 4.7K D+5V TO SHEET 003 R292 MUTE_SPEAKER R298 4.7K R300 AMP_STB AU_DAC0_L MUTE_EAR AU_DAC0_R R302 C3399 220u C217 EAR_Detect R8136 C3412 0.22u 2200P 12VAMP...
  • Page 53 LC-32DH500 Main Unit Diagram 8/13 DUNTKF261WE01 (VIDEO INTERFACE) DUNTKF261WE01 RGB2-YPbPr_GIN+ R321 RGB2-YPbPr_BIN+ J1401 KA007WJ R323 RGB2-YPbPr_RIN+ R324 R332 COMP_AUL2 R333 C252 C253 560P 330P R325 COMP_AUR2 C249 C248 R328 560P 330P NAME CODE VIDEO INTERFACE DH500 MAIN BOARD SHT010/17 DATE KAV N.
  • Page 54 LC-32DH500 Main Unit Diagram 9/13 DUNTKF261WE01 (PANEL INTERFACE) DUNTKF261WE01 SC8201 NA493WJ PANEL-VCC TP164 PANEL-VCC PANEL-VCC PANEL-VCC PANEL-VCC TP165 R354 SELLVDS ODSEL PANEL-VCC R357 G3-RXE0- PANEL_VCCIN VCC12V G3-RXE0- R358 G2-RXE0+ G3-RXE0+ Q701 R363 G1-RXE1- RSS040P03 R359 G1-RXE1- R360 0.56 0.56 G0-RXE1+...
  • Page 55 LC-32DH500 Main Unit Diagram 10/13 DUNTKF261WE01 (TUNER) DUNTKF261WE01 5V_TUN 3V3_T 5V_TUN_B R8133 Q117 TP166 4.7K RSR025P03 5V_TUN_B ANT_PWR R8134 C374 IC202 C375 IC203 0.1u Q118 4.7K BSP100 C410 2SC3928AR Analog B VCC12_T R1544 VCC5_T R543 VCC5_T C3396 0209TA R702 0.1u...
  • Page 56 LC-32DH500 Main Unit Diagram 11/13 DUNTKF261WE01 (USB) DUNTKF261WE01 USB0_DM +5V_USB0 USB0_DM USB0_DP TP170 USB0_DP +5V_USB0 USB0_OCDN USB0_OCDN *R409 USB0_DM *R410 USB0_DP USB_OCD USB_OCD FB301 0210TA R397 D+5V D+3.3V C340 D+3.3V AAPE 100u J8101 C339 C319 100u 6.3V 0.1u 6.3V AAPE...
  • Page 57 LC-32DH500 Main Unit Diagram 12/13 DUNTKF261WE01 (CIMAX PCMCIA) VCC-PCMCIA D+3.3V DUNTKF261WE01 SC4401 VCC-PCMCIA R417 R415 R418 R556 TS_D2 PCM_D4 MOD2 TS_D1 PCM_D5 MOD1 TS_D0 PCM_D6 MOD0 TS_SYNC PCM_D7 MOSTRT TS_VALID PCM_CE_N MOVAL PCM_REG_N PCM_A10 PCM_OE_N INP_ACK PCM_WAIT_N R425 PCM_A11 WAIT...
  • Page 58 LC-32DH500 Main Unit Diagram 13/13 DUNTKF261WE01 (RS232) DUNTKF261WE01 D+3.3V R485 4.7K R484 UART-TX C355 J4001 J0008GE D+3.3V R486 4.7K UART-RX R482 C354 NAME CODE RS232 DH500 MAIN BOARD SHT017/17 DATE KAV N. SHARP 28-07-2009...
  • Page 59 FSP GROUP EL817 FB201 102P/Y1 102P/Y1 TILE: FSP170-4F01 R240 CY111 KSP2222A CY112 3BS0234311GP size: A2 rev:1 Q205 P/N: 102P/Y1 FB202 102P/Y1 APPROVED: CHECKED: DESIGNER: CY113 CY114 R241 Paul Gigi 105P Date: 2009/9/7 PCB File:FSP170-4F01-R0 Sheet File: D:\Layout-AD6\ \170W\FSP170-4F01-R1 (SHARP 32)\FSP170-4F01-R1( :7000P-0106...

  • Page 60: Printed Wiring Boards

    LC-32DH500 PRINTED WIRING BOARD Main Unit PWB ( QPWBXF261WJZZ) LED Unit PWB ( QPWBXF262WJZZ) Side A Side A Chip Parts DUNTKF262WE DUNTKF262WE QPWBXF262WJZZ QPWBXF262WJZZ R5109 R5109 X201 X201 C377 SLD5101 C377 SLD5101 C374 C362 IC204 C361 C374 C362 IC204 C361...
  • Page 61 LC-32DH500 Main Unit PWB ( QPWBXF261WJNZZ) LED Unit PWB ( QPWBXF262WJNZZ) Side B Side B Chip Parts DUNTKF262WE DUNTKF262WE QPWBXF262WJZZ QPWBXF262WJZZ R5109 R5109 X201 X201 C377 SLD5101 C377 SLD5101 C374 C362 IC204 C361 R1514 FB1501 C374 C362 IC204 C361 R1514...
  • Page 62 LC-32DH500 Power Unit PWB ( RDENCA366WJQZ) Power Unit Power Unit , Side A , Side B...
  • Page 63 LC-32DH500 KEY Unit PWB (QPWBXF266WJ KEY Unit, Side A KEY Unit, Side A Chip Pats S155 R153 D152 S154 S152 R151 D151 S151 S153 S156 S157...

  • Page 64: Replacement Parts List

    LC-32DH500 * SN CODE EX CODE REF No. PARTS DESCRIPTION PARTS LISTING TRANSISTORS REPLACEMENT PARTS Q 0003 VS2SA1530AR-1Y TRT SA1530A-T12-1R MITSUBISHI Replacement parts which have special safety characteristics are identifi ed in this manual. Electrical components having such features are identifi ed by...
  • Page 65 LC-32DH500 * SN CODE EX CODE * SN CODE EX CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C 0018 VCEAPF1CN106MY ELEC C 10UF 20% 16V COILS AND FILTERS C 0019 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 L 0001 RBLN-0209TAZZY BALUNE BLM21PG600SN1D...
  • Page 66 LC-32DH500 * SN CODE EX CODE * SN CODE EX CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C 0095 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% C 0174 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% C 0096 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10%...
  • Page 67 LC-32DH500 * SN CODE EX CODE * SN CODE EX CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C 0336 VCCCCZ1HH220JY C CERAM 22PF 50V 5% C 0430 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% C 0337 VCKYCZ1CB103KY CAPACITOR 10NF 16V 10%...
  • Page 68 LC-32DH500 * SN CODE EX CODE * SN CODE EX CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C 3422 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% R 0055 VRS-CY1JF102FY CHIP RESISTOR 1% 1K C 3423 VCCCCZ1HH470JY C CERAM 47PF 50V 5% R 0056 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD C 3424 VCCCCZ1HH330JY S.
  • Page 69 LC-32DH500 * SN CODE EX CODE * SN CODE EX CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R 0146 VRS-CZ1JF560JY RES 0402 56 OHM 5% 1/16W SMD R 0230 VRS-CY1JF101JY RES 0603 100 OHM 5% 1/10W SMD R 0147 VRS-CZ1JF560JY RES 0402 56 OHM 5% 1/16W SMD...
  • Page 70 LC-32DH500 * SN CODE EX CODE * SN CODE EX CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R 0357 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD R 0545 VRS-CZ1JF331JY RES 0402 330 OHM 5% 1/16W SMD R 0358 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD...
  • Page 71 LC-32DH500 * SN CODE EX CODE * SN CODE EX CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION FB 0012 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD R 1547 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD FB 0013 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD...

  • Page 72: Cabinet And Mechanical Parts

    LC-32DH500 CABINET AND MECHANICAL PARTS KEY UNIT LED PWB INV. UNIT INV. SHIELD 13 LA POWER UNIT MINI AV COVER MAIN UNIT C.I. COVER...

  • Page 73: Packing Of The Set

    LC-32DH500 Supplied accessories Remote control unit • “AA” size zinc-carbon battery (g2) AC cord (g1) (g1) • Operation manual (This publication) Product shape varies in some countries. CABINET AND MECHANICAL PARTS LISTING REF No. REF No. PARTS PARTS DESCRIPTION DESCRIPTION...
  • Page 74 LC-32DH500 PACKING OF THE SET (TINS- - E407WJZZ) < EE > < EE> (TINS- - E441WJZZ) (TGAN- - A077WJZZ) < RU > (TINS- - E407WJZZ) (TGAN- - A801WJZZ) (TGAN- - A802WJZZ) < EK > (TINS- - E494WJZZ) < S >...
  • Page 75 LC-32DH500 Notes:...
  • Page 76 LC-32DH500 COPYRIGHT © 2009 BY SHARP CORPORATION ALL RIGHTS RESERVED No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

This manual is also suitable for:

Lc-32dh500eLc-32dh500ruLc-32dh500s
