Page 2
IMPORTANT SAFETY INFORMATION ....3 INSTALLATION..........10 INNER PARTS ..........11 OPERATIONS..........13 G*-*4**/ G*-*5** Starting Before Setting The Temperature Door Alarm Self Test Controls For Freezer Compartment Controls For Refrigerator Compartment Express Freeze Child Lock (Optional) Wi-Fi Door Cooling+ Vegetable Drawer Defrosting Deodorizer Ice Making Hygiene Fresh (Optional) Water Dispenser (Optional)
Page 3
WARNING Keep ventilation openings, in the appliance enclosure or in the built-in-structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartment, unless they are recommended by the manufacturer.
Page 4
Risk of Fire and Flammable Materials This symbol alerts you to flammable materials that can ignite and cause a fire if you do not take care. This appliance contains a small amount of isobutane refrigerant (R600a), but it is also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
Page 5
Do not use or store inflammable materials like ether, benzene, alcohol, medicine, LP gas, spray or cosmetics near or in the refrigerator. It may cause explosion or fire.
Page 6
Install in places away from the fire such as the place where flammable gas is leaked. It may cause fire. If there is a gas leakage (isobutane, propane, natural gas, etc.), do not touch the appliance or power plug and ventilate the area immediately.
Page 8
Do not place glass containers, bottles or cans (especially those containing carbonated drinks) in the freezer compartment, shelves or ice bin that will be exposed to temperatures below freezing. Completely empty inside before taking out the container from the door.
Page 9
Please do not use a dishwasher to clean the lower drawers; the high temperature may cause damage to the baskets which make them unusable. If the appliance is equipped with a lock (some countries only), keep the key out of reach of children. This appliance is intended to be used in household and similar applications such as - staff...
Page 10
Dimensions and Clearances Too small of a distance from adjacent items may result in degradation of freezing capability and increased electricity costs. Allow over 50mm clearance from each adjacent wall when installing the appliance. Image for representation purpose only G*-*5** G*-*4** 1780 1680...
Page 11
Water Dispenser Model Freezer Temperature FREEZER Control Dial COMPARTMENT Smart Diagnosis Lamp Shelf Twisting Ice Serve Type Ice Making Freezer Door Rack REFRIGERATOR COMPARTMENT Water Tank Lamp Deodorizer Fresh Room Drawer /Pull Out Tray (Optional) Shelves Refrigerator Door Rack Hygiene Fresh Egg Tray (Optional) Vegetable Drawer...
Page 12
Non Water Dispenser Model Freezer Temperature Control Dial Smart Diagnosis FREEZER COMPARTMENT Lamp Shelf Twisting Ice Serve Freezer Door Rack Type Ice Making REFRIGERATOR COMPARTMENT Lamp Deodorizer Refrigerator Door Rack Fresh Room Drawer (Optional) /Pull Out Tray (Optional) Shelves Hygiene Fresh Refrigerator Door (Optional) Rack...
STARTING BEFORE SETTING THE TEMPERATURE ‘3’ or ‘4’. ‘5’. DOOR ALARM SELF TEST CONTROLS FOR FREEZER COMPARTMENT When the freezer compartment is not cold enough in winter, adjust the control for the freezer to High (6~8).
CONTROLS FOR REFRIGERATOR COMPARTMENT FOR INTERNAL CONTROLLER MODEL The default setting of the temperature control button REF. TEMP CONTROL for the refrigerator compartment is NORMAL. To control the refrigerator temperature, press the REF. TEMP CONTROL button. COLD COLDEST Whenever pressing the button, LED emitting the light. The temperature is set in 7 steps, from COLD to COLDEST cooling.
CHILD LOCK (OPTIONAL)* • CHILD LOCK Press and hold the child lock button for 3 seconds to lock the child lock. When it is locked, the Lock LED will be on and the other button will not operate. To unlock, press and hold the CHILD LOCK button for 3 seconds again.
DEFROSTING DEODORIZER ICE MAKING Twisting Ice Serve Type To make ice cubes, fill the ice tray with water and insert in its position. To remove ice cubes, hold the lever of the tray and pull turn gently. Then, ice cubes drop in to the ice cube box. WARNING Fill with potable water only.
HYGIENE FRESH (OPTIONAL) CAUTION Before installing or using the product, make sure to read the owner's manual carefully to use the product accurately as intended. This HYGIENE FRESH filter has the antibacterial function of removing the virus or bacteria inside the refrigerator and the deodorizer function to remove the scent.
WATER DISPENSER (OPTIONAL) Pour water after the water tank is in position. Necessarily separate the water tank to clean it our when not in use. When the water tank is not in position after filling it with water, water can leak out by the valve. Pouring water in the water tank Cover Cap 1.
LG ThinQ Application Turn off the Mobile data or Cellular Data on your smartphone. This feature is only available on models with Wi-Fi. The LG ThinQ application allows you to communicate with the appliance using a smartphone. LG ThinQ Application Features Connect your smartphone to the wireless router.
Page 20
Smart Diagnosis Connecting to Wi-Fi This feature is only available on models with the The Wi-Fi button, when used with the LG ThinQ application, allows the appliance to connect to a logo. home Wi-Fi network. The...
Page 21
Using Audible Diagnosis to Diagnose Issues Follow the instructions below to use the audible diagnosis method. Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided in the LG ThinQ application.
OPERATIONS LAMP REPLACEMENT NOTE : This product applies LED Lamp which cannot be replaced by the user. Please contact authorized service centre for the lamp replacement. INVERTER-ON FEATURE (Optional) 1. While using this feature, the refrigerator will work on basic requirement as required by the product. 2.
Page 23
• In the event of a blackout, call the electricity company and ask how long it is going to last. - You should avoid door openings while the power is off. - When the power supply gets back to normal, check the condition of the food. •...
Page 26
SUPPLY CORD REPLACEMENT If the supply cord is damaged, it m u s t b e r e p l a c e d b y t h e manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
Page 30
ﺗﻧﺑﯾﮭﺎت ھﺎﻣﺔ *:ﻟﻠﺑﻠدان اﻷﻋﺿﺎء ﻓﯽ اﻟﻠﺟﻧﺔ اﻷوروﺑﯾﺔ ﻟﻠﻣواﺻﻔﺎت اﻟﻛﮭروﺗﻘﻧﯾﺔ أﺳﺗراﻟﯾﺎ و ﺑﻠﺟﯾﻛﺎ و ﺑﻠﻐﺎرﯾﺎ و ﻛرواﺗﯾﺎ و ﻗﺑرص و ﺟﻣﮭورﯾﺔ اﻟﺗﺷﯾك واﻟدﻧﻣﺎرك و إﺳﺗوﻧﯾﺎ و ﻓﻧﻠﻧدا و ﻣﻘدوﻧﯾﺎ و ﻓرﻧﺳﺎ وأﻟﻣﺎﻧﯾﺎ و ﻗﺑرص و ھﻧﻐﺎرﯾﺎ وإﯾﺳﻠﻧدا وإﯾرﻟﻧدا وإﯾطﺎﻟﯾﺎ و ﻻﺗﻔﯾﺎ وﻟﯾﺗواﻧﯾﺎ وﻟﻛﺳﻣﺑورغ و ﻣﺎﻟطﺎ وھوﻟﻧدا واﻟﻧروج و ﺑوﻟﻧدا و اﻟﺑرﺗﻐﺎل...
