AutoDome Easy II IP
VEZ Series
en
Installation Manual

Advertisement

Table of Contents
loading

Related Manuals for Bosch VEZ-221-ECCE

Summary of Contents for Bosch VEZ-221-ECCE

  • Page 1 AutoDome Easy II IP VEZ Series Installation Manual...

  • Page 3: Table Of Contents

    Installing the Camera to the Mounting Plate Installing a Recessed Mount Description 6.1.1 Additional Requirements 6.1.2 Preparing the Ceiling for Installation 6.1.3 Installing the Camera to the Mounting Plate Bosch Security Systems, Inc. Table of Contents | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 4 Connecting the AutoDome Easy II IP to the PC 11.4 Configuring the AutoDome Easy II IP Camera 11.5 The LIVEPAGE 11.5.1 Entering a Keyboard Control Command 11.6 Saving Snapshots 11.7 Recording Video Sequences F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 5: Autodome Easy Ii Ip Table Of Contents | En

    Common User Commands (unlocked) 14.1 Setting AutoPan Mode 14.2 Setting Preset Shots 14.3 Configuring Preposition Tours 14.4 Programming the Inactivity Operation 14.5 Recorded Tours Bosch Security Systems, Inc. Table of Contents | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 6 17.1 AutoDome Easy II IP Operation and Control BVIP Firmware Updates 18.1 Upgrading the AutoDome Easy II IP 18.2 Beginning the Firmware Update Process Index F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 7: Safety

    This will prevent damage to the unit from lightning and power line surges. Bosch Security Systems, Inc. Installation Manual Safety | en F.01U.164.576 | 2.0 | 2010.03...
  • Page 8 11. Servicing - Do not attempt to service this unit yourself. Opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 9 16. Attachments, changes, or modifications - Only use attachments/accessories specified by the manufacturer. Any change to or modification of the equipment not expressly approved by Bosch could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.

  • Page 10: Safety Precautions

    3 mm in each pole, into the electrical installation of the building. If it is needed to open the housing for servicing and/or other activities, use this all-pole F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 11 Your Bosch product was developed and manufactured with high-quality material and components that can be recycled and reused. This symbol means that electronic and electrical...
  • Page 12 | Safety Environmental statement - Bosch has a strong commitment to the environment. This unit has been designed to respect the environment as much as possible. Electrostatic-sensitive device - Take proper CMOS/MOS-FET handling precautions to avoid electrostatic discharge. NOTE: You must wear grounded wrist straps and observe proper ESD safety precautions when handling the electrostatic- sensitive printed circuit boards.
  • Page 13 Network Voltage (TNV) circuits. Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. To minimize the risk of lost digital information, Bosch Security Systems recommends multiple, redundant recording systems, and a procedure to back up all analog and digital information.
  • Page 14 Federal Communications Commission, helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet is available from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 15 AVERTISSEMENT: Ce produit est un appareil de Classe A. Son utilisation dans une zone résidentielle risque de provoquer des interférences. Le cas échéant, l’utilisateur devra prendre les mesures nécessaires pour y remédier. Bosch Security Systems, Inc. Installation Manual Safety | en F.01U.164.576 | 2.0 | 2010.03...
  • Page 16 CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT. Copyright This user guide is the intellectual property of Bosch Security Systems, Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.

  • Page 17: Customer Support And Service

    AutoDome Easy II IP Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Service Centers Repair Center Telephone: 800-566-2283 Fax: 800-366-1329 E-mail: repair@us.bosch.com Customer Service...

  • Page 18: Unpacking

    Verify that all the parts listed in Section 2.1 Parts List are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. The original packing carton is the safest container in which to transport the unit and must be used if returning the unit for service.

  • Page 19: Safety Rules

    – Do not allow children or unauthorized personnel to use the device. – Do not block any ventilation openings. – Keep this manual for future reference. Bosch Security Systems, Inc. Installation Manual Unpacking | en F.01U.164.576 | 2.0 | 2010.03...

  • Page 20: Description

    P r o d M o n C l r S h o t 10 10 11 11 Installation Manual AutoDome Easy II IP 12 12 13 13 15 15 14 14 AutoDome Easy II IP Network Computer Encoder/Decoder Bosch Security Systems, Inc.
  • Page 21 This installation should be made by qualified service personnel and conform to the National Electrical Code and applicable local codes. NOTICE! A grounded conduit is required in order to meet the EMC Regulation Requirements. Bosch Security Systems, Inc. Installation Manual Description | en F.01U.164.576 | 2.0 | 2010.03...

  • Page 22: Installing A Surface Mount

    Prolonged exposure to bright lights may cause bleaching of the sensor's color filters. This will be visible as colored spots in the picture and is irreversible. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 23: Additional Tools Required

    Surface Mount. Determine a secure location for the surface mount dome. R50.6 (1.99) Figure 4.1 Indoor Surface Mount Dimensions Bosch Security Systems, Inc. Installing a Surface Mount | en ø 153.0 (6.02) 149.9...
  • Page 24 Mounting Plate Junction Box Skip to Section 4.1.4 Installing the Camera to the Mounting Plate, page 29, to continue the installation. F.01U.164.576 | 2.0 | 2010.03 90 mm (3.54 in.) Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 25: Preparing The Surface Mount For An Outdoor Installation

    Box as a template to mark the location of the four (4) M4 or #10 pan head screws (Item 1, below). Figure 4.5 Location of M4 or #10 pan head screws Bosch Security Systems, Inc. Installing a Surface Mount | en ø...
  • Page 26 CAUTION! You must ensure that the gasket is attached to the retaining ring as shown above to ensure an environmentally tight seal. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 27 Apply a 1/2-inch (15-mm) NPS fitting to the chosen knockout. Ensure a water-tight fitting to maintain the IP Environmental Protection Rating for the unit. Bosch Security Systems, Inc. Installing a Surface Mount | en M3 – .5 x 6 Phillips flat head machine screws...
  • Page 28 11. Route the external wires through the conduit and into the Surface Mount Junction Box. CAUTION! All wires for installation applications must be routed through a grounded conduit. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 29: Installing The Camera To The Mounting Plate

    Connect the mating connectors with the flying leads to the user supplied wiring (see Section 8 Preparing the Wiring, page 63 for wiring information). Bosch Security Systems, Inc. Installing a Surface Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 30 Figure 4.10 Connect Cables Locking Screw Vertical Tab Mounting Plate Align wires on side of mounting plate with crescent shaped cut-out. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 31 Note: Do not loosen brass mounting buttons. Figure 4.12 Attach Dome to Mounting Plate Vertical tab Bosch Security Systems, Inc. Installing a Surface Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 32 10. Outdoor Installation: Thread the 2.89 mm I.D. by Ø1.78 mm O-ring (item 1, below) onto the Safety Screw. 11. Secure the safety locking screw with the user supplied locking torx wrench (T-10). F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 33: Installing A Wall Mount

    This will be visible as colored spots in the picture and is irreversible. Bosch Security Systems, Inc. Installing a Wall Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 34: Additional Tools Required

    Figure 5.1 Wall Mount Dimensions Fit a user-provided metal single-gang junction box to the wall. F.01U.164.576 | 2.0 | 2010.03 (12.5) 204.1 (8.0) 203.5 (8.01) 280.0 (11.02) Installation Manual AutoDome Easy II IP 349.7 (13.8) 316.7 Bosch Security Systems, Inc.
  • Page 35 Attach the mounting cap to the arm. Fit the arm to a metal single-gang junction box. Figure 5.3 Fit to Gang Junction Box Bosch Security Systems, Inc. Installing a Wall Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 36: Preparing The Wall Mount For An Outdoor Installation

    The fasteners and mounting surface must be capable of supporting a maximum load of 11.33 kg (25 pounds). Figure 5.4 Wall Mount Dimensions F.01U.164.576 | 2.0 | 2010.03 (12.5) 204.1 (8.0) 203.5 (8.01) 280.0 (11.02) Installation Manual AutoDome Easy II IP 349.7 (13.8) 316.7 Bosch Security Systems, Inc.
  • Page 37 CAUTION! You must ensure that the gasket is attached to the retaining ring as shown above to ensure an environmentally tight seal. Bosch Security Systems, Inc. Installing a Wall Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 38 All wires for installation applications must be routed through a grounded conduit. F.01U.164.576 | 2.0 | 2010.03 O-ring; 21.82 mm I.D. by Ø3.00 mm Retaining ring with gasket M3 – .5 x 6 Phillips flat head machine screws Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 39 Figure 5.6 Secure arm to wall with flat gasket Skip to Section 5.1.4 Installing the Camera to the Mounting Plate, page 40, to continue the installation. Bosch Security Systems, Inc. Installing a Wall Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 40: Installing The Camera To The Mounting Plate

    Connect the mating connectors with the flying leads to the user supplied wiring (see the Section 8 Preparing the Wiring, page 63 for wiring information). F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 41 Plug the matching connectors from the camera into the mating connectors from the ceiling. Figure 5.9 Connect Cables Align wires on side of mounting plate with crescent shaped cut-out. Bosch Security Systems, Inc. Installing a Wall Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 42 Note: Do not loosen brass mounting buttons. Figure 5.11 Attach Dome to Mounting Plate F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 43 12. Secure the safety locking screw with the user supplied locking torx wrench (T-10). 13. Pull excess wire back into the mount tube. 14. Confirm that the housing is electrically grounded. Bosch Security Systems, Inc. Installing a Wall Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 44: Installing A Recessed Mount

    Appropriate tool for cutting a hole in drywall or ceiling tile (if applicable) – 4 in. x 4 in. junction box (optional) – T-10 Torx wrench – LTC 9349MK mounting kit (optional) F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 45: Preparing The Ceiling For Installation

    LTC 9349MK mounting kit is recommended (supplied separately). See the instruction book supplied with the mounting bracket for installation instructions. Bosch Security Systems, Inc. Installing a Recessed Mount | en 194.0 (7.64) Installation Manual 96.0...
  • Page 46 Bracket with plate should be in the lower position for AutoDome Easy II analog models. Figure 6.3 Adjust Mounting Clamps F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 47 (0.50 in.) minimum ceiling thickness). Tighten both clamps to the ceiling using supplied screws and a #2 Phillips screwdriver. Figure 6.4 Tighten Mounting Clamps Bosch Security Systems, Inc. Installing a Recessed Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 48: Installing The Camera To The Mounting Plate

    Wiring, page 63 for wiring information). Remove the single safety locking screw on the base of the unit using the user-supplied Allen wrench. Figure 6.5 Unlock Safety Locking Screw F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 49 Figure 6.7 Attach Safety Locking Screw Bosch Security Systems, Inc. Installing a Recessed Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 50 Note: Do not loosen brass mounting buttons. Figure 6.8 Attach Dome to Mounting Plate Recess Mounting Bracket Mounting Plate Mounting Bracket Tether Point F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 51 15. Snap trim ring into place. Ensure snaps are secure by attempting to lightly turn unit. Note: Unit should not turn. Bosch Security Systems, Inc. Installing a Recessed Mount | en Installation Manual...

  • Page 52: Installing A Pipe Mount

    Prolonged exposure to bright lights may cause bleaching of the sensor's color filters. This will be visible as colored spots in the picture and is irreversible. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 53: Tools/Supplies Required

    Determine a secure hard surface location for the ceiling pipe mount (supplied separately). 88.8 (3.5) Ø11.2 (4x) (0.44) Figure 7.1 Pipe Mount Dimensions Bosch Security Systems, Inc. Installing a Pipe Mount | en 88.8 (3.5) 3/4-14 NP 544.9 SM Threads (21.5)
  • Page 54 505 mm (20 in.). Outdoor Installation: Apply the following O-rings (supplied with the AutoDome Easy II Outdoor Camera) to the locations specified below: F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 55 Thread a 29.74 mm I.D. by Ø3.00 mm O-ring (item 2, above) between any interface between a pipe and a coupler. Bosch Security Systems, Inc. O-ring; 21.82 mm I.D. by Ø3.00 mm O-ring; 29.74 mm I.D. by Ø3.00 mm Installation Manual Installing a Pipe Mount | en F.01U.164.576 | 2.0 | 2010.03...
  • Page 56 Fit the dome cap to the bottom of the pipe. Outdoor Installation: Apply the following O-ring and the retaining ring (supplied with the AutoDome Easy II Outdoor Camera) to the locations specified below: F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 57 Moly or Toggle bolts. Outdoor Installation: Place the flat gasket (item 1, below) between the flange and the surface before securing. Bosch Security Systems, Inc. O-ring; 21.82 mm I.D. by Ø3.00 mm Dome Cap Retaining ring with gasket M3 –...
  • Page 58 Figure 7.5 Attach Pendant Pipe Mount to Ceiling CAUTION! Select a rigid mounting location to prevent excessive vibration to the AutoDome Easy II Camera. 10. Attach user supplied ground lug. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 59 (3) screws supplied (Figure 1.7). Figure 7.6 Attach Mounting Plate to Dome Cap Crescent Shape Ground Lug Dome Cap Mounting Plate Bosch Security Systems, Inc. Installing a Pipe Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 60: Installing The Camera To The Mounting Plate

    Plug the matching connectors from the camera into the mating connectors from the ceiling. Align wires on side of mounting plate with crescent shaped cut-out. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 61 Note: Do not loosen brass mounting buttons. Figure 7.9 Attach Dome to Mounting Plate Bosch Security Systems, Inc. Installing a Pipe Mount | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 62 11. Secure the safety locking screw with the user supplied locking torx wrench (T-10). 12. Pull excess wire back into the mount tube. 13. Confirm that the housing is electrically grounded. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 63: Preparing The Wiring

    24 VAC to AutoDome Easy II 18 / 10 24 VAC to Heater Table 8.1 Max. Wire Distances from Power Supply to AutoDome Easy II Bosch Security Systems, Inc. Preparing the Wiring | en VA / Watts 14 AWG (2.5 mm)

  • Page 64: Connecting The Power

    Cameras, page 65 Section 8.3 Ethernet Connection (IP models), page 67 Section 8.2.2 Power Connections to Outdoor Cameras, page 66 Section 8.2.3 Power Connections to Heater (all outdoor models), page 67 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 65: Power Connections To Indoor Cameras

    Connect the other lead of the 24 VAC power source to the red wire. Connect the green earth ground cable to a suitable grounded conduit. Bosch Security Systems, Inc. Preparing the Wiring | en Installation Manual Color Black F.01U.164.576 | 2.0 | 2010.03...

  • Page 66: Power Connections To Outdoor Cameras

    Connect the other lead of the 24 VAC power source to the red wire. Connect the green earth ground cable to a suitable grounded conduit. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Color Black Bosch Security Systems, Inc.

  • Page 67: Power Connections To Heater (All Outdoor Models)

    Refer to Section 11 Using the AutoDome Easy II IP, page 74, for instructions on configuring an IP environment. CAUTION! Ethernet connections must be made to non-exposed (indoor) networks only. Bosch Security Systems, Inc. Preparing the Wiring | en Installation Manual Color White/Red White/Black F.01U.164.576 | 2.0 | 2010.03...
  • Page 68 Maximum Distance Bandwidth PoE (indoor models only) IEEE 802.3af standard Terminal Connector F.01U.164.576 | 2.0 | 2010.03 CAT-5E or CAT 6 Ethernet 100 m (328 ft) 10 Base-T/100 Base-TX RJ45 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 69: Alarms And Relay Connections

    You wire alarms either Normally Open (N.O.) or Normally Closed (N.C.), and must program the alarm inputs N.O. (the default) or N.C. through the AutoDome Easy II main menu. Bosch Security Systems, Inc. Alarms and Relay Connections | en Alarm Out...

  • Page 70: Connecting Alarms (Inputs 1 Through 2)

    F.01U.164.576 | 2.0 | 2010.03 Alarm In 1 or Alarm In 2 (Ref. #3) Ground (Ref. #4) Alarm Indication Normal Alarm Installation Manual AutoDome Easy II IP Color Brown IN 1 or Orange IN 2 Green Bosch Security Systems, Inc.

  • Page 71: Connecting A Normally Closed Alarm

    Setup>Inputs Setup, and set Alarm Input # to N.C. See the table below for contact and condition details. AutoDome Easy II Programmed N.C. Circuit Open Closed Bosch Security Systems, Inc. Alarms and Relay Connections | en Alarm In 1 or Alarm In 2 (Ref. #3) Ground (Ref. #4) Alarm Indication...

  • Page 72: Alarm Outputs

    Connect the appropriate stripped wire to the open collector of the transistor’s white wire. Connect the appropriate stripped wire to the ground (GND) connector. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Color White Green Bosch Security Systems, Inc.

  • Page 73: Getting Started

    20 seconds and ends with a splash screen. WARNING! Before powering the dome on, remove the clear protective plastic sheet on top of the bubble. Bosch Security Systems, Inc. Installation Manual Getting Started | en F.01U.164.576 | 2.0 | 2010.03...

  • Page 74: Using The Autodome Easy Ii Ip

    Video images from a single camera can be simultaneously received on several receivers. Refer to Section 18 BVIP Firmware Updates, page 132, for firmware upgrade instructions. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 75: Overview Of Features

    You can record video from the Livepage to a hard drive or you can opt to store up to 8 MB of video on the IP module. Bosch Security Systems, Inc. Using the AutoDome Easy II IP | en Installation Manual...

  • Page 76: System Requirements

    – A computer with the Microsoft Windows XP or Vista operating system, network access, and reception software such as the Bosch VIDOS software or the Bosch Divar XF, – A compatible hardware decoder from Bosch Security Systems as a receiver and a connected video monitor.

  • Page 77: Connecting The Autodome Easy Ii Ip To The Pc

    Ethernet crossover cable with RJ45 connectors (see option B below). Figure 11.1 AutoDome Easy II IP System Configuration AutoDome Easy II IP IP Connection Network Switch Computer Bosch Security Systems, Inc. Using the AutoDome Easy II IP | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 78: Configuring The Autodome Easy Ii Ip Camera

    IP connection, configuring the IP network settings and accessing the AutoDome Easy II IP images from a Web browser. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 79: The Livepage

    Depending on the unit and network configuration, each AutoDome Easy II IP can have up to 25 Web browser connections or up to 50 connections via VIDOS or Bosch Video Management System. Protected If the AutoDome Easy II IP is password protected against...
  • Page 80 Focus near Iris close Iris open Sets the position for corresponding pre- sets 1 – 6 Moves the camera to pre-set shot numbers 1, 2, 3, 4, 5, and 6 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 81 To activate this, click the icon for the relay next to the video image. The icon will be red when the relay is activated. Bosch Security Systems, Inc. Using the AutoDome Easy II IP | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 82: Entering A Keyboard Control Command

    (Show Shot, Set Shot Aux On or Aux Off). A valid combination either issues a command to the camera or displays an on-screen menu. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 83: Keyboard Commands By Number

    Set a preset shot Initiates a command Deletes a number in the Command Number field Used to select a menu item Stops a command Bosch Security Systems, Inc. Using the AutoDome Easy II IP | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 84 For more information about the AutoDome Easy II IP settings and controls, click the Help on this page? link to open the AutoDome Easy II IP online help. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 85: Saving Snapshots

    Click the icon again to stop recording. NOTICE! You can play back saved video sequences using the Player from Bosch Security Systems, which can be installed from the product CD supplied. Image Resolution Sequences are saved at the resolution that has been preset in the configuration for the encoder (see Section 12.4 Basic Mode:...

  • Page 86: Configuring The Autodome Easy Ii Ip

    Click one of the menu items in the left window margin. The corresponding submenu is displayed. Click one of the entries in the submenu. The Web browser opens the corresponding page. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 87: Basic Mode: Device Access

    The name makes the task of administering multiple units in larger video monitoring systems easier, for example using the VIDOS or Bosch Video Management System programs. The device name is used for the remote identification of a unit, in the event of an alarm for example.

  • Page 88: Basic Mode: Date/Time

    If necessary, you can synchronize the unit with your computer's system settings.  Click the Sync to PC button to copy your computer's system time to the AutoDome Easy II IP. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 89: Basic Mode: Network

    IP addresses, you can activate acceptance of IP addresses automatically assigned to the AutoDome Easy II IP. Certain applications (VIDOS, Bosch Video Management System, Archive Player, Configuration Manager) use the IP address for the unique assignment of the unit. If you use these applications,...

  • Page 90: Basic Mode: Encoder Profile

    – Low bandwidth High resolution, connections with low bandwidth, resolution 704 × 576/480 pixels – DSL connections with 500 kbps, resolution 352 × 288/240 pixels F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 91: Basic Mode: Recording

    You can select all required text on this page with the mouse and copy it to the clipboard with the [Ctrl]+[C] key combination, for example if you want to send it via e-mail. Bosch Security Systems, Inc. Configuring the AutoDome Easy II IP | en Installation Manual...

  • Page 92: On-Screen Display Menu Navigation

    Time Saver Tip: Scrolling through menus can be time consuming; to quickly return to “exit” prompt, just twist the joystick or use the zoom in feature. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 93 Alarm Setup Accesses the alarm settings such as: inputs, outputs, and rules. Language Displays the language. Diagnostics Displays the status of diagnostic events. Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 94: Camera Setup Menu

    * Shutter: * Auto SensUP Max: * Pre-Comp Restore Defaults... * = Factory Setting Focus / Iris: Select F.01U.164.576 | 2.0 | 2010.03 EXT ATW AUTO Internal Auto SensUP 1/60 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 95 AUTO. Sharpness Adjusts the sharpness level of the picture. Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en Sub-menu / Description Extended ATW: Adjusts camera color using extended range. ATW: Adjusts camera color constantly.
  • Page 96 ON or OFF Auto SensUP or OFF Sliding scale: – (1/60 (1/50) at extreme left to 1/10000) + Installation Manual AutoDome Easy II IP Default Setting INTERNAL 0º Auto SensUP 1/60 sec. (NTSC) or 1/50 sec. (PAL) Bosch Security Systems, Inc.

  • Page 97: Lens Setup

    * Max Zoom Speed: * Digital Zoom: Restore Defaults * = Factory Setting Focus / Iris: Select Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en Sub-menu / Description NTSC: 15x, 7.5x, 4x, or PAL: 50x, 25x, 16.7x, 8.3x, 4x, or 2x Sliding scale: –(1 to 10)+...
  • Page 98 Sliding scale: – (1 to 15) + Sliding scale: – (1 to 8) + Sliding scale: – (1 to 10) + SLOW, MEDIUM, or FAST Installation Manual AutoDome Easy II IP Default Setting SPOT CONSTANT FAST Bosch Security Systems, Inc.

  • Page 99: Ptz Setup Menu

    * Freeze Frame On Preposition Tilt Up Limit Restore Defaults * = Factory Setting Focus / Iris: Select PTZ Menu Choices: Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en Sub-menu / Description OFF or ON 30 deg/sec 5 sec...
  • Page 100 Aux commands 1, 2, 7, 8, 50, or 52. OFF: Remains on the current scene indefinitely. Sliding scale: – (3 sec. to 10 min.) + Installation Manual AutoDome Easy II IP Default Setting 30º/sec. 5 sec. 2 min. Bosch Security Systems, Inc.
  • Page 101 Restore Restores the Defaults default setting for this menu only. Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 101 Sub-menu / Description OFF or ON INVERTED or NORMAL OFF or ON Installation Manual Default...

  • Page 102: Display Setup Menu

    F.01U.164.576 | 2.0 | 2010.03 MOMENTARY Sub-menu / Description OFF: Titles are hidden. ON: Titles are displayed continuously. MOMENTARY: Titles are displayed for a few seconds then disappear from the screen. Installation Manual AutoDome Easy II IP Default Setting MOMENTARY Bosch Security Systems, Inc.
  • Page 103 Available sectors are 1 through 8. Follow the on- screen instructions. Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 103 Sub-menu / Description OFF or ON Exit: Exits the menu. Up: Moves screen title up. Down: Moves screen title down.
  • Page 104 Edit Scene Title to access the character palette. See Section 13.5.1 Specifying a Shot or a Sector Title, page 105, for instructions. – Clear Scene to delete the selected scene title. Installation Manual AutoDome Easy II IP Default Setting Bosch Security Systems, Inc.

  • Page 105: Specifying A Shot Or A Sector Title

    Move the joystick up to bring the cursor back into the character palette. To save the title: Use the joystick to highlight the Exit prompt. Press Focus/Iris to save the title. Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 105 Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 106: Communication Setup Menu

    2400 to 57600. (Note: If stepping from 2400 to 57600 baud, you must first set the controller to 19200 for AutoBaud to detect the higher baud rate.) Installation Manual AutoDome Easy II IP Default Setting Bosch Security Systems, Inc.
  • Page 107 Turns on Bilinx control communication. (Only available when not connected to a Bilinx data interface unit.) Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 107 Sub-menu / Description Choices are 2400, 4800, 9600, 19200, 38400, and 57600. Then follow the OSD to confirm the selection.

  • Page 108: Alarm I/O Setup

    4. Aux Off 5. Shot Front Door 6. Aux Off 7. NONE 8. NONE 9. NONE Focus / Iris: Select Type Right / Left: Select Mode Installation Manual AutoDome Easy II IP Physical Inputs 1 Event Inputs Bosch Security Systems, Inc.
  • Page 109 7. OSD 8. NONE 9. NONE Focus / Iris: Select Type Right / Left: Select Mode Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 109 Sub-menu / Description N.O.: Normally open dry contact. N.C.: Normally closed dry contact.
  • Page 110 Section 15 Keyboard Commands by Number, page 122 for available Aux commands. F.01U.164.576 | 2.0 | 2010.03 Sub-menu / Description N.O.: Normally open circuit N.C.: Normally closed circuit Installation Manual AutoDome Easy II IP Default Setting N.O. Bosch Security Systems, Inc.

  • Page 111: Alarm I/O Rule Setup Menu

    7. Rule 7 Empty 8. Rule 8 Empty 9. Rule 9 Empty Empty Empty Empty Focus / Iris: Select Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 111 Rule 1 Exit... Enabled Input: Physical Input 1 NONE NONE NONE...
  • Page 112 Invalid: The rule has a missing or invalid input or output. Empty: The rule has no inputs or outputs defined. Sub-menu / Description Default YES to enable or NO to disable Installation Manual AutoDome Easy II IP Default Setting Empty Setting Bosch Security Systems, Inc.
  • Page 113 NOTICE! You can include up to four (4) Input and Output events in a single rule. Each input and output, however, must be true for the alarm's rule to be valid and enabled. Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 113 Sub-menu / Description Default Alarm Inputs 1 –...

  • Page 114: Language Menu

    Menu Description Exit Saves and exits the menu. Choose a language Select a language in which the system displays the on-screen menus. F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Default Setting English Bosch Security Systems, Inc.

  • Page 115: Diagnostics Menu

    Alarm Status Enters the Alarm Status menu and displays the real time status of alarm inputs and outputs. Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 115 83F / 28C 90F / 32C 73F / 23C 1hr 57 Min...
  • Page 116 Sub-menu / Description YES to start test. NO to exit the menu. Typical results displayed as follows: BIST Exit... Data Flash: FPGA: Bilinx: Homing: Fan Speed: Installation Manual AutoDome Easy II IP PASS PASS PASS PASS PASS Bosch Security Systems, Inc.
  • Page 117 Displays the number of time that video was lost. Events Total Time On Displays the total of time that the video was on. Bosch Security Systems, Inc. On-Screen Display Menu Navigation | en 117 Sub-menu / Description Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 118: Common User Commands (Unlocked)

    118 en | Common User Commands (unlocked) Common User Commands (unlocked) This chapter details the commonly used Bosch keyboard setup commands. See Section 15 Keyboard Commands by Number, page 122, for a complete list of commands. 14.1 Setting AutoPan Mode AutoPan mode pans the AutoDome Easy II camera 360º...

  • Page 119: Setting Preset Shots

    To stop a Preposition Tour:  Press OFF-8-ENTER or move the joystick to stop either type of tour. Bosch Security Systems, Inc. Common User Commands (unlocked) | en 119 Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 120: Programming The Inactivity Operation

    Press OFF-100-ENTER to stop recording. To playback Recorded Tour A: Press ON-50-ENTER to begin continuous playback. Press OFF-50-ENTER or move the joystick to stop playback F.01U.164.576 | 2.0 | 2010.03 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 121 Press OFF-101-ENTER to stop the tour. To playback Recorded Tour B: Press ON-52-ENTER to begin continuous playback. Press OFF-52-ENTER or move the joystick to stop playback. Bosch Security Systems, Inc. Common User Commands (unlocked) | en 121 Installation Manual F.01U.164.576 | 2.0 | 2010.03...

  • Page 122: Keyboard Commands By Number

    Activate/Deactivate Enters menu (Off, Return to Scene 1, Recall Previous PTZ Command) Enters Iris Level Adjustment menu Enters speed adjustment slide bar Enters dwell adjustment slide bar Enables/disables AutoPivot Backlight Compensation Enters Shutter Speed slide bar Bosch Security Systems, Inc.
  • Page 123 Rule Output On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off Bosch Security Systems, Inc. Keyboard Commands by Number | en 123 Comm Command White Balance Mode Restore Camera Settings Line Lock Phase Adjust Sync Mode Auto Gain...
  • Page 124 Sector Title, page 105. Enters Alarm Status menu Acknowledge alarm or deactivate physical outputs Displays software version number Turns digital zoom on and off On–activates output Off–deactivates output Enters Sector Blanking menu Enters Privacy Masking menu Bosch Security Systems, Inc.
  • Page 125 Rule Output On/Off On/Off On/Off On/Off On/Off On/Off Shot Set/ Shot Set/ Shot Bosch Security Systems, Inc. Keyboard Commands by Number | en 125 Comm Command Command Lock/Unlock Lens Polarity menu Lens Polarity menu Lens Polarity menu Record A Record B...
  • Page 126 Tour 1 Installation Manual AutoDome Easy II IP Description Set–recalibrate home position Restores all settings to original defaults and clears all user- programmed settings Enters the Tour add/ remove menu Set ###–adds preset Shot ###–removes preset Bosch Security Systems, Inc.

  • Page 127: Preventive Maintenance

    Attaching the Bubble The AutoDome Easy II is shipped with the bubble secured to the upper housing. Bosch does not recommend removing the bubble from the housing. If a situation requires you to remove the bubble, however, you must use a Torx T-10 driver to secure the three screws on the bubble to the upper housing each with a torque of 5 in.-lbs.

  • Page 128: Troubleshooting

    Is the power frequency set properly in sync? If the power frequency is not set correctly, the line lock synchronization mode cannot be used. Set the synchronization mode to INT.NTSC Model power frequency in LL mode: 60 Hz. Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.

  • Page 129: Autodome Easy Ii Ip Operation And Control

    Faulty cable connections. Incorrect encoder stream property set for connection to hardware decoder. Bosch Security Systems, Inc. Troubleshooting | en 129 Recommended solution Check all cables, plugs, contacts, terminals and connections. Check the other serial interface.
  • Page 130 Select possible alarm sources on the Alarm Inputs configuration page. Specify the desired alarm response on the Alarm Connections configuration page, change the IP address if necessary. Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 131 Web browser Active proxy server in contains empty network. fields. Bosch Security Systems, Inc. Troubleshooting | en 131 Recommended solution Check all cable connections and ensure all plugs are properly fitted. Make sure that the settings of all units involved are compatible.

  • Page 132: Bvip Firmware Updates

    The AutoDome Easy II IP also allows an operator to update the BVIP firmware via the TCP/IP network. The latest BVIP firmware is available on the Bosch Security Systems Web site. To download the service pack from the Web, navigate to www.boschsecurity.us, click the CCTV link, then click Cameras, PTZ and navigate to the product page for the AutoDome Easy II IP.
  • Page 133 Note: Once the progress bar reaches 100% the system opens the reset page. Allow the reset page to complete its action. Once the reset is complete the upgrade is complete. Bosch Security Systems, Inc. BVIP Firmware Updates | en 133 Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 134 95 outdoor white balance 95 supervised pre-compensation 97 sharpness 95 shutter 96 synchronization menu 96 white balance 95 CAT-5E 68 CAT-6 68 CCD cameras 22 command numbers 82 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 135 65 constant iris 98 controlling image area 81 CTFID 116 custom tour setting dwell time 120 Tour Period menu 120 Bosch Security Systems, Inc. defining physical inputs 109 physical outputs 110 rules 112 Description 3 device name 87 devices...
  • Page 136 98 constant iris 98 digital zoom 99 focus speed 98 iris speed 98 manual iris 98 maximum zoom speed 98 line lock 96 low temperature events 116 threshold 116 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 137 110 normally closed supervised contact normally open circuit 110 normally open dry contact 109 normally open supervised contact number of connections 79 Bosch Security Systems, Inc. OFF-90-ENTER 120 ON-9-ENTER 120 on-screen display 92 OSD 92 outdoor white balance 95...
  • Page 138 Show Shot command 82 shutter 96 shutter mode 96 snapshots 75 SNTP server 89 software DirectX 76 standard tour setting dwell time 120 Tour Period menu 120 storage medium 91 subnet mask 78 Installation Manual AutoDome Easy II IP Bosch Security Systems, Inc.
  • Page 139 87 UTP CAT-5 68 video loss events 117 VIDOS 76 VIP XD 76 white balance 95 wires alarm 63 control 63 power 63 video 63 Bosch Security Systems, Inc. Installation Manual Index | en 139 F.01U.164.576 | 2.0 | 2010.03...
  • Page 140 140 en | Index AutoDome Easy II IP F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
  • Page 141 AutoDome Easy II IP Index | en 141 Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03...
  • Page 142 142 en | Index AutoDome Easy II IP F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
  • Page 144 Bosch Security Systems, Inc. 850 Greenfield Road Lancaster, PA 17601 U.S.A. www.boschsecurity.com © Bosch Security Systems, Inc., 2010; Data subject to change.

This manual is also suitable for:

Vez-221-ewteVez-221-ewtsVez-221-icceVez-221-iccsVez-221-eccsVez-221-ects ... Show all

Table of Contents
