(source: EN 50110-1). Taking the relevant national regulations into account, ATEX products may be commissioned only by a skilled electrician competent in the field of explosion protection. R911379011_Edition 02 Bosch Rexroth AG...
Property damage could occur. Intended use The products described here are components for Equipment Group II Category 3D, ATEX Directive 2014/34/EU, and are only allowed to be used in zone 22 or NE (negligible extent). Bosch Rexroth AG R911379011_Edition 02...
Defective ATEX products must be repaired in the manufacturer's factory or by the authorized Bosch Rexroth Service. Specific conditions with test num‐ The explosion protection marking specified in the declaration of conformity and on the type plate is marked with an "X"...
Page 18
KCU02+KSM02-PR⃞⃞-⃞⃞-P" regarding risks due to outer influences, such ● Operation only within the specified ambient conditions ● Maximum vibration and impact loads ● Protection of equipment grounding connections against dirt, corrosion, humidity and/or aggressive substances, etc. Bosch Rexroth AG R911379011_Edition 02...
Impermeability Seals (e.g., shaft sealing rings) are aging and if necessary have to be replaced on the occasion of a maintenance interval. R911379011_Edition 02 Bosch Rexroth AG...
Details of the product classification in accordance with ATEX Directive 2014/34/EU ● Technical data of the product Before installing the product, make sure that this product carries the required labels and has a sufficiently high degree of protection for your application. Bosch Rexroth AG R911379011_Edition 02...
X Marking: "Specific conditions"; see "Specific conditions with test number" on page 3 1.7.2 UL labeling for USA and Canada UL labeling in accordance with UL 508C "Power Conversion Equipment" and CSA 22.2 No. 274‑13 "Adjustable Speed Drives". R911379011_Edition 02 Bosch Rexroth AG...
If overdetermined bearings cannot be avoided, please contact Bosch Rexroth. Couplings The machine design and the attached elements used have to be carefully adapted to the motor type so that the load limits of shaft and bearing are not exceeded. Bosch Rexroth AG R911379011_Edition 02...
Page 23
NDE bearing by exceeding the maximum allowed axial force. It is recommended to use drive elements that have their own bearings and are connected to the motor shaft via axially compensating couplings. R911379011_Edition 02 Bosch Rexroth AG...
Check all components, mounting surfaces and threads to verify that they are clean. Make sure that the assembly can be carried out in a dry and dust-free environment. Ensure that the holder for the flange is without burrs. Bosch Rexroth AG R911379011_Edition 02...
If the specified holding torque (M4) is attained, the motor is ready for assembly. If the specified holding torque (M4) is not attained after multiple resurfacing procedures, the holding brake is not operational. Please contact the Rexroth Service. R911379011_Edition 02 Bosch Rexroth AG...
Check the connection of the equipment grounding conductor and of the bonding conductor. To ensure safe operation, the products have to be grounded using the hybrid cable and using the bonding conductor (see chapter 1.13.2 "Connecting the bonding conductor" on page 14). Bosch Rexroth AG R911379011_Edition 02...
Only completely closed brackets ensure that the degree of protection IP 65 can be attained and activate the vibration protection. The HAS10.1-001 accessory (fixing clip for hybrid cable connectors) increases the vibration resistance of the product and is mandatory for operating the product. R911379011_Edition 02 Bosch Rexroth AG...
Check all mechanical and electrical connections (including the bonding conductor!). Record all measures taken in the commissioning log. Activate the safety devices and monitoring systems of the installation. Procedure When all requirements have been met, proceed as follows: Bosch Rexroth AG R911379011_Edition 02...
Do not work at running or unsecured machines. ● Before disconnecting mechanical connections, secure the motor and supply lines to prevent them from falling down. ● Only work with safety gloves and use suitable mounting devices. R911379011_Edition 02 Bosch Rexroth AG...
Page 30
Wait for the cool-down times of the product and the discharge time of the electrical systems to elapse. Disconnect all electrical connections. Before dismounting the product and the supply lines, secure them against dropping or movements, before unfastening the mechanical connections. Bosch Rexroth AG R911379011_Edition 02...
1.15.2 Repair Defective ATEX products must be repaired in the manufacturer's factory or by the authorized Bosch Rexroth Service. The Bosch Rexroth Service carries out the following repairs, for example: ● Replacement of motor encoder ● Replacement of shaft sealing ring ●...
Observe the Dangerous Goods Regulations (IATA) when transporting the rotor by air. Deliver the products "free domicile" to the following address: Bosch Rexroth AG Electric Drives and Controls Buergermeister-Dr.-Nebel-Strasse 2 97816 Lohr am Main, Germany R911379011_Edition 02 Bosch Rexroth AG...
Detailed description of malfunction and circumstances ● Type plate specifications of the affected products, in particular type codes and serial numbers ● Your contact data (phone and fax number as well as your e-mail address) R911379011_Edition 02 Bosch Rexroth AG...
