Operating Instructions – Washer Dryer Electrolux EWD 1214 I
Detergent dispenser drawer
The Control Panel
1. Detergent dispenser drawer
2. Drying indicator light (This light illuminates when the machine is drying)
3. Drying time selector dial
Graduated up to 120 mins for cottons and synthetics, this dial allows you to select the desired drying time according
to the type and quantity of laundry and the required degree of dryness. Blue sector – for cottons, Green sector – for
synthetics.
Turn the dial clockwise only.
Depress the dial to pop it out.
Cooling Phase
To allow the laundry to cool down, a cooling phase starts automatically 10 minutes before the end of drying and this
phase must in no circumstances be reduced or interrupted.
4. Spin speed reduction button
By depressing this button the spin speed is reduced as follows:
- Cotton and linen from 1200rpm to 650rpm
www.sacoapartments.com
welcome
Advertisement
Related Manuals for Electrolux EWD 1214 I
Summary of Contents for Electrolux EWD 1214 I
- Page 1 Operating Instructions – Washer Dryer Electrolux EWD 1214 I Detergent dispenser drawer The Control Panel 1. Detergent dispenser drawer 2. Drying indicator light (This light illuminates when the machine is drying) 3. Drying time selector dial Graduated up to 120 mins for cottons and synthetics, this dial allows you to select the desired drying time according to the type and quantity of laundry and the required degree of dryness.
-
Page 2: On/Off Button
- Synthetics and wool from 850rpm to 650rpm - Delicates from 650rpm to 450rpm 5. Quick wash button By depressing this button on programmes A,B,C,D and H the wash time is reduced. This is suitable only for garments which are lightly soiled. 6. - Page 3 3. Measure out the fabric softener if required and pour into the compartment marked not exceeding the ‘Max’ mark in the drawer. 4. Select the required option (s) Depress Spin Reduction and/or Quick Wash and/or Super Rinse and/or Rinse Hold button, if required. 5.
- Page 4 In order to save energy and to avoid too long drying times we suggest not to reduce the spin speed when you wash and dry automatically. 5. Select the required time following indications given in the programme chart on the following page. Turn the time selector dial clockwise to the appropriate number of minutes in the green sector.
- Page 5 Washing programmes for cotton and linen www.sacoapartments.com welcome...
- Page 6 Programmes for synthetics, mixed fabrics, delicates and wool www.sacoapartments.com welcome...
- Page 7 Drying programmes www.sacoapartments.com welcome...
