The AEL (accessible emission level )of the laser power output is less than CLASS 1 but the laser component is capable of emitting radiation exceeding the limit for CLASS 1. A specially instructed person should do servicing operation of the apparatus. AVH-280BT/XNUC...
Page 3
CAUTION Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent type recommended by the manufacturer. Discord used batteries according to the manufacturer's instructions. AVH-280BT/XNUC...
Be careful not to burn yourself. MOTHER PCB (Side A) MOTHER PCB (Side B) IC1301 L902 C1319 IC1201 IC111 IC601 IC741 IC861 DVD Mechanism Module Top Case Heat Sink 1F & 2F Rear Holder AVH-280BT/XNUC...
For the Mechanism Module which is provided as service part, the shorting-solder has been done to protect the LD. When replacing the Mechanism Module, please connect it to the product at first and then remove the shorting-solder in reverse order of the previous procedure for removing. AVH-280BT/XNUC...
For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit. Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs accompanied by reworking of soldering. AVH-280BT/XNUC...
2. SPECIFICATIONS 2.1 SPECIFICATIONS For all items except the backup current, refer to the Owner's Manual. Backup current......5.0 mA or less 2.2 DISC/CONTENT FORMAT is a trademark of DVD Format/Logo Licensing Corporation. AVH-280BT/XNUC...
3.2 PCB LOCATIONS Mother Unit Relay Unit Key PCB Monitor PCB A:AVH-280BT/XNUC B:AVH-280BT/XNEU5 C:AVH-285BT/XNRC D:AVH-285BT/XNRD E:AVH-285BT/XNRI F:AVH-289BT/XNID Unit Name : Mother Unit Unit Number : QWM4221(A) Unit Number : QWM4220(B) Unit Number : QWM4223(C) Unit Number : QWM4224(D) Unit Number...
DVD Mechanism Modulet 3.4 CLEANING Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools: Portions to be cleaned Cleaning tools DVD pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 AVH-280BT/XNUC...
4. BLOCK DIAGRM Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST". REAR VIEW WIRED BT MIC CAMERA POWER SUPPLY FM/AM USB IF REMOTE WIRED REMOTE RREOUT VIDEO OUT JA3191 JA3151 JA3101...
SYSTEM BLOCK DIAGRAM MOTHER UNIT SYSB Mute TUN3.3 RCAout TUNL,TUNR Tuner Rear/S.W IC2201 TEF6686HN E-VOL TUN_SCL,TUN_SDA RCAout IC1201 Front PM9012A B.UP BT3.3 BT1.8 BT_L , BT_R SPout FL BT Module Power IC U2901 VDD3.3 SPout FR SYStoBT , BTtoSYS IC1301 CWX4772 SPout RL Mute...
Page 14
AUDIO VIDEO BLOCK DIAGRAM AUDIO VIDEO MUTE MOTHER UNIT LITHIO Tuner Mute TUNL,TUNR CH2 CH3 IC2201 TEF6686HN SAPPHIRE Mute E-VOL IC1201 AM P PM9012A BT Module BT_L , BT_R Active U2901 Power IC Mute CWX4772 IC1301 +4.2 B E.VOL MUTE soft mute) PA2032A Active µ-com...
Is it OK? PICK UP Perform lens RF level check cleaned? cleaning Replace the Check2 CRG chassis Error rate check PICK UP Perform lens Is it OK? cleaned? cleaning Replace the CRG chassis Ckeck parts Finished other than PICK UP AVH-280BT/XNUC...
Page 20
Criteria for voltage Remarks: LD current 449 mV (Ave) 45 mA (Ave) TCD-782 REFVCC5_1 - CDLD1 660 mV (Max) 60 mA (Max) MOTHER UNIT (SIDE A) REFVCC5_1 CDLD1 Notes: Please pay attention to the laser diode damage by static electricity. AVH-280BT/XNUC...
Page 21
528 - 832 (mVp-p) Check2 : Error rate check <Check> Status: Error Rate Mode of DVD TEST MODE Remarks (Disc Type) Disc Check Point Threshold less than GGV1025 1. Inner Measurement 1.000E-3 less than TCD-782 1. Inner Measurement 2.500E-3 AVH-280BT/XNUC...
- : Error is not cancelled by operation. *2 B0-BFh : Notice IDs which are not listed in the LS Mechanism list * : No setting C0-FFh : Notice IDs such as ATN which attempt the servo system notice AVH-280BT/XNUC...
Page 23
DivX file’s frame rate is more than 30 fps. — Select a file that can be played. Audio Format not supported This type of file is not supported on this product. — Select a file that can be played. AVH-280BT/XNUC...
Selection cursor up movement Selection cursor down movement Down Menu enter Band Description: 1. SWC TEST MODE : For checking Steering Wheel Control 2. TOUCH PANEL SETTING : For Touch Panel calibration 3. FLICKER ADJUSTMENT : For Flicker adjustment AVH-280BT/XNUC...
Page 26
: Cannot be selected. When Adapter setting is “No” : Select JAPAN or KOREAN. Operational description Remote controller key Return to test mode menu RETURN Selection cursor up movement Selection cursor down movement Down Switching setting value FF / REV AVH-280BT/XNUC...
Page 27
2. AD Measurement result Operational description Remote controller key Return to test mode menu RETURN Description: When a key on the steering remote is pressed, the voltage value is displayed on the screen. AVH-280BT/XNUC...
Page 28
Selection cursor down movement Down Menu enter Band Description: When the touch keys do not respond correctly, perform the touch panel calibration by using this test mode. For the touch panel calibration, perform "1. Effective Area Calibration" and "2. 16 Point Calibration". AVH-280BT/XNUC...
Page 29
Finished normally Finished abnormally Operational description Remote controller key Return to Touch Panel Setting Menu Band When the calibration is completed correctly, "Result : OK" is displayed. Press [BAND] key on Remote controller to return Touch Panel Setting Menu. AVH-280BT/XNUC...
Page 30
Return to Touch Panel Setting Menu Band 16 Point Calibration result screen Operational description Remote controller key Return to Touch Panel Setting Menu Band When the calibration is completed, "Finished" is displayed. Press [BAND] key on Remote controller to return Touch Panel Setting Menu. AVH-280BT/XNUC...
Page 31
Touch the cursor [+] displayed on the screen. By touching it correctly, it disappears and another cursor appears. Otherwise, the cursor is displayed in red. Repeating this action for 4 points and by pressing the last 4th point, “O.K.” is displayed. Operational description Remote controller key Return to top menu RETURN AVH-280BT/XNUC...
Page 32
Calibration confirmation result screen Operational description Remote controller key Return to top menu RETURN 5. Data Initialize Operational description Remote controller key Return to test mode menu RETURN Selection cursor up movement Selection cursor down movement Down Menu enter Band AVH-280BT/XNUC...
Page 33
1: DVD Single Layer 2: DVD Dual Layer 3: CD 4: CD-RW Operational description Remote controller key Return to DVD test mode menu RETURN Selection cursor up movement Selection cursor down movement Down Menu enter Band < LD ON > Now Running AVH-280BT/XNUC...
Page 34
< Error Rate > 1: DVD Single Layer 1: DVD Single Layer 2: CD 2: CD Operational description Remote controller key Return to DVD test mode menu RETURN Selection cursor up movement Selection cursor down movement Down Menu enter Band AVH-280BT/XNUC...
Page 35
Menu enter Band 2. Error Rate < Rate Inner > Now Running < Error Rate Inner > 1: Power OFF Error Rate : X.XXE-XX Operational description Remote controller key Return to DVD test mode menu RETURN Menu enter Band AVH-280BT/XNUC...
Page 36
1: DVD Single Layer 2: DVD Dual Layer 3: CD 4: CD-RW Operational description Remote controller key Return to DVD test mode menu RETURN Selection cursor up movement Selection cursor down movement Down Menu enter Band < Move Outer > Now Running AVH-280BT/XNUC...
Page 37
ERROR < ERROR > 1: Power OFF Code : 00000000 Operational description Remote controller key Return to test mode menu RETURN Menu enter Band < ERROR > < ERROR > Please Reset Please Reset Code : 00000000 Communication Failure AVH-280BT/XNUC...
Do not remove the USB memory stick or turn off the power until the updating procedure is completed. Removing the USB memory stick or turning off the power while the update is in progress may damage the software. AVH-280BT/XNUC...
Page 39
Confirm that the “It succeeded” screen appears and the updating procedure is completed. Remove the USB memory stick and turn off the power. 4. Repeat Step 2 and Step 3 to update the remaining software. EX) Screen display when System µcom upgrade AVH-280BT/XNUC...
Page 40
2. Press the RESET key while pressing and holding the “ - ” and “ ” keys at the same time. RESET 3. Check the software version on the screen after the system starts up in the Version Information mode. AVH-280BT/XNUC...
Disconnect the four connectors. Remove the four screws and then remove the Monitor PCB. 2pin Cable from TFT LCD Attention at assembly: When you connect the FFC and 2pin Cable from TFT LCD, set the 2pin Cable lower side. Fig.2 AVH-280BT/XNUC...
Page 42
Bracket to the DVD Mechanism Module, tighten the screws. Put the dowels of the DVD Mechanism Module in the slits of the Bracket securely. Attention of removing Don’t remove this screws excluding the dismantlement of the DVD Mechanism Module. Fig.4 AVH-280BT/XNUC...
Page 43
Slide the Bracket in the direction indicated by an arrow and then release the dowel. (Left side and Right side) Remove the Bracket. Attention at assembly: When installing the Bracket, put the dowels of the Chassis in the slits of the Bracket securely. dowel Fig.6 AVH-280BT/XNUC...
Page 44
The two sheets are used for the heat radiation of the two IC chips.The heat of the IC chips radiates to the holder through the sheets. Stick them on the predetermined position not to protrude from the IC chips. Sheet Holder Sheet Fig.8 AVH-280BT/XNUC...
8. EACH SETTING AND ADJUSTMENT 8.1 ADJUSTMENT REQUIRED WHEN HTE UNIT IS REPLACED When any of the following assemblies is replaced, it is necessary to perform the adjustment. "8.2 FLICKER ADJUSTMENT" Mother Unit Monitor PCB AVH-280BT/XNUC...
When the screen is flickering, perform the flicker adjustment by using this test mode. Minimize the flicker by changing adjustment value. < Flicker Adjustment > COM DC COM DC : Flicker adjustment value Operational description Remote controller key Return to test mode menu RETURN Down AVH-280BT/XNUC...
Screw adjacent to mark on the product are used for disassembly. For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions,apply as you think it appropriate.) 9.1 PACKING AVH-280BT/XNUC...
Page 48
See Contrast table (2) Card Remote Control Unit See Contrast table (2) IM CD-ROM See Contrast table (2) (2) CONTRAST TABLE AVH-280BT/XNUC, AVH-280BT/XNEU5, AVH-285BT/XNRC, AVH-285BT/XNRD, AVH-285BT/XNRI, and AVH- 289BT/XNID are constructed the same except for the following: AVH-280BT/ AVH-280BT/ AVH-285BT/ AVH-285BT/...
Page 49
Dutch *QRB3548 Swedish *QRB3549 Norwegian *QRB3550 Finnish *QRB3551 Danish *QRB3552 Portuguese *QRB3553 Greek *QRB3554 Turkish All operation manuals are supplied in PDF files by the CD-ROM. Regarding the availability of paper manual, contact Pioneer Service representative in your region. AVH-280BT/XNUC...
9.3 EXTERIOR(2) RC, RI, ID UC, RC, RD, RI, ID AVH-280BT/XNUC...
Page 53
CND7260 Bracket CND6985 Sheet CNN5016 Bracket CND6986 Mother Unit See Contrast table (2) (2) CONTRAST TABLE AVH-280BT/XNUC, AVH-280BT/XNEU5, AVH-285BT/XNRC, AVH-285BT/XNRD, AVH-285BT/XNRI, and AVH- 289BT/XNID are constructed the same except for the following: AVH-280BT/ AVH-280BT/ AVH-285BT/ AVH-285BT/ AVH-285BT/ AVH-289BT/ Mark Description...
10. SCHEMATIC DIAGRAM Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST". 1/11 MOTHER UNIT(SENSE) 9/11 (10A) FUSE YEK5001 > 8/11 NOTE : NM : No Mount Symbol indicates a resistor. The >...
4/11 MOTHER UNIT (I/F) 9/11 MODEL 11/11 A AVH-280BT/XNUC B AVH-280BT/XNEU5 C AVH-285BT/XNRC D AVH-285BT/XNRD E AVH-285BT/XNRI F AVH-289BT/XNID 8/11 5/11 C,D,E,F 5/11 8/11 9/11 2/11 9/11 11/11 9/11 9/11 11/11 9/11 10/11 CN5003 4/11 4/11...
11/11 MOTHER UNIT (SOC) Except F MODEL A AVH-280BT/XNUC B AVH-280BT/XNEU5 C AVH-285BT/XNRC D AVH-285BT/XNRD E AVH-285BT/XNRI F AVH-289BT/XNID 9/11 4/11 5/11 CN102 4/11 11/11 11/11...
KEY PCB MODEL A AVH-280BT/XNUC B AVH-280BT/XNEU5 C AVH-285BT/XNRC D AVH-285BT/XNRD E AVH-285BT/XNRI F AVH-289BT/XNID MONITOR KEY UNIT Consists of MONITOR PCB KEY PCB...
11. PCB CONNECTION DIAGRAM NOTE FOR PCB DIAGRAMS 1.The parts mounted on this PCB include all necessary parts for several destination. For further information for MOTHER UNIT respective destinations, be sure to check with the schematic dia- gram. > P303 (A,61,19) Fuse 750 mA CEK1398 2.Viewpoint of PCB diagrams SIDE A Capacitor...
11.3 RELAY UNIT SIDE A RELAY UNIT PU UNIT (DP11) VR101 CN101 R101 C103 HOME C101 M2 SPINDLE MOTOR S101 C102 M1 CRG(L/E) MOTOR C107 C112 C105 GREEN WHITE C106 C109 C108 C114 CN102 CN801 AVH-280BT/XNUC...
Page 83
SIDE B RELAY UNIT C104 C111 S103 R102 C113 C110 S102 12EJ R103 AVH-280BT/XNUC...
The expression of the unit in this manual is shown by u instead of . Please do not make a mistake. Circuit Symbol and No. Part No. Circuit Symbol and No. Part No. MISCELLANEOUS A:AVH-280BT/XNUC B:AVH-280BT/XNEU5 IC 101 (B,54,64) Regulator IC NJW4181U3-33B IC 111...
Page 86
(B,27,30) Diode DZ2S068C R 324 (A,158,6) RS1/10SR0R0J R 401 (A,48,67) RS1/16SS473J D 3191 (B,156,90) Diode EZAEG2A50AX D 3192 (B,156,88) Diode EZAEG2A50AX R 402 (A,54,60) RS1/16SS473J L 301 (A,158,26) Inductor CTH1254 R 403 (B,46,70) RS1/16SS473J L 302 (A,145,26) Inductor CTH1253 AVH-280BT/XNUC...
Page 87
R 470 (A,58,65) RS1/16SS473J R 724 (A,110,23) RS1/16SS473J R 501 (A,12,38) RS1/16SS102J R 725 (A,106,23) RS1/16SS473J R 502 (A,13,42) RS1/16SS102J R 726 (B,109,27) RS1/16SS0R0J R 503 (A,15,40) RS1/16SS222J R 727 (B,108,27) RS1/16SS101J R 504 (A,9,41) RS1/16SS222J R 741 (A,94,36) RAB4CQ330J AVH-280BT/XNUC...
Page 88
R 891 (B,135,13) RS1/16SS104J R 1271 (B,81,64) RS1/16SS183J R 892 (B,133,16) RS1/16SS103J R 1272 (B,71,61) RS1/16SS102J R 893 (B,133,15) RS1/16SS103J R 1273 (B,71,62) RS1/16SS102J R 894 (B,142,12) RS1/16SS0R0J R 1274 (B,71,60) RS1/16SS183J R 895 (B,142,11) RS1/16SS0R0J R 1275 (B,71,63) RS1/16SS183J AVH-280BT/XNUC...
Page 89
(B,161,52) 10 uF CCG1236 R 3104 (B,133,89) RS1/10SR101J C 316 (B,158,41) CCSSCH8R0D50 R 3106 (B,131,87) RS1/16SS223J C 317 (B,160,42) CKSSYB104K16 R 3107 (B,133,87) RS1/16SS223J C 318 (B,146,43) CKSSYB104K16 R 3108 (B,128,94) RS1/16SS750J C 319 (B,146,41) CCSSCH8R0D50 R 3127 (A,36,56) RS1/16SS1001D AVH-280BT/XNUC...
Page 90
C 626 (B,124,47) CKSSYB104K10 C 865 (B,90,12) CKSSYB473K16 C 627 (B,125,46) CKSSYB104K10 C 866 (B,92,13) CKSSYB224K6R3 C 628 (A,119,39) CKSSYB104K10 C 867 (B,102,13) CKSSYB104K16 C 629 (A,119,40) CKSSYB104K10 C 868 (B,104,13) CKSSYB104K16 C 630 (A,121,41) CKSSYB104K10 C 869 (B,88,13) CKSSYB104K16 AVH-280BT/XNUC...
Page 91
(A,42,20) 4.7 uF CCG1201 C 1261 (B,107,62) CKSSYB122K50 C 2904 (A,48,20) 4.7 uF CCG1201 C 1262 (B,101,59) 10 uF CCG1192 C 2905 (A,44,20) CKSSYB104K10 C 1263 (B,95,60) CCSSCH221J50 C 2906 (A,44,22) CKSSYB104K10 C 1264 (B,96,62) CCSSCH221J50 C 2907 (A,23,23) CEVW221M4 AVH-280BT/XNUC...
Page 92
R 5209 (B,36,63) RS1/16SS104J R 5210 (A,27,64) RS1/16SS103J L 5101 (A,130,63) Inductor ATH7068 L 5201 (A,27,61) Choke Coil 22 uH CTH1426 R 5211 (A,38,66) RS1/16SS472J L 5301 (A,35,53) Inductor CTF1765 R 5212 (B,31,68) RS1/16SS1003D L 5402 (B,73,36) Inductor CTF1547 AVH-280BT/XNUC...
Page 93
C 5203 (A,40,70) CKSRYB105K10 R 5409 (A,74,50) RS1/16SS330J C 5204 (A,39,68) CKSSYB224K6R3 R 5410 (A,74,48) RS1/16SS330J C 5205 (A,32,70) CKSRYB224K16 R 5411 (A,73,50) RS1/16SS330J C 5206 (A,26,56) CKSSYB472K50 C 5207 (A,33,60) CKSSYB102K50 R 5412 (A,72,48) RS1/16SS330J R 5413 (B,69,59) RS1/16SS473J AVH-280BT/XNUC...
Page 94
CCSSCJ3R0C50 C 5410 (A,64,45) CCSSCH100D50 C 5411 (B,74,36) 10 uF CCG1244 C 5412 (B,74,38) 10 uF CCG1244 C 5413 (B,71,39) CKSSYB104K10 C 5414 (A,80,39) CCSSCH101J50 C 5415 (B,72,39) 10 uF CCG1244 C 5416 (A,72,66) CKSSYB104K10 C 5417 (B,68,35) CCSSCH101J50 AVH-280BT/XNUC...
