The vibration total value (tri-axial vector sum) deter- and saw blade program, the tool can be used for many mined according to EN62841-2-11: purposes and is very well suited for curved or circular Model 4350T cuts. Work mode : cutting boards Power supply Vibration emission (a ) : 7.0 m/s...
If operating a power tool in a damp location WARNING: The vibration emission during actual is unavoidable, use a residual current device use of the power tool can differ from the declared val- (RCD) protected supply. Use of an RCD reduces ue(s) depending on the ways in which the tool is used the risk of electric shock.
Service Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Follow instruction for lubricating and chang- ing accessories. Jig saw safety warnings Hold the power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wir-...
Switch action FUNCTIONAL DESCRIPTION CAUTION: • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Selecting the cutting action ► 1 . Switch trigger 2. Lock button CAUTION: • Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the "OFF"...
Page 6
Installing or removing saw blade Workpiece to be cut Number on adjusting dial Wood 4 - 5 Mild steel 3 - 5 CAUTION: Stainless steel 3 - 4 • Always clean out all chips or foreign matter Aluminum 3 - 5 adhering to the blade and/or blade holder.
To remove the blade, open the tool opener to the posi- tion shown in the figure. Pull the saw blade out toward the base. ► 1 . Cutting line 2. Base Turn the tool on and wait until the blade attains full speed. Then rest the tool base flat on the workpiece ► 1 . Jig saw blade and gently move the tool forward along the previously marked cutting line.
Tilt the base until the desired bevel angle is obtained. For internal cutouts without a lead-in cut from an The V-notch of the gear housing indicates the bevel edge, pre-drill a starting hole 12 mm or more in angle by graduations. Then tighten the bolt firmly to diameter. Insert the blade into this hole to start secure the base.
The dust nozzle can be installed on either left or right side of the base. Then connect a Makita vacuum cleaner to the dust nozzle. ► 1 . Hex wrench 2. Bolt 3. Fence guide When repeatedly cutting widths of 160 mm or less, use of the rip fence will assure fast, clean, straight cuts.
► 1 . Fence guide 2. Threaded knob 3. Circular guide ► 1 . Bolt 2. Rule bar Install the guide rail adapter on the rail of the guide rail. When cutting circles or arcs of 170 mm or less in Insert the rule bar into the square hole of the guide rail radius, install the rip fence as follows.
The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. • Jig saw blades • Hex wrench 4 •...
