Summary of Contents for Bosch Smart Home Thermostat AA
- Page 1 LET´S GET STARTED Radiator Thermostat Quick start guide...
- Page 2 1. Install Smart Home Controller 2. Start Smart Home App If not yet installed: Download the Bosch Smart Now start the Bosch Smart Home app and Home app and install the Bosch Smart Home select “Add device”. Follow the instructions in Controller.
-
Page 3: Mounting Instructions
For some radiator valves an adapter is required. If none of the included adapters fit, please find a detailed overview of adapters to be used under Products, Radiator thermostat at: www.bosch-smarthome.com Please refer to our website for an explanatory video on how to install the Bosch Smart Home Radiator Thermostat at: www.bosch-smarthome.com/installation... - Page 4 Pos. Part Explanation For setting the operation mode or Button restarting calibration (when “-|” is displayed) Buttons +/– For increasing/decreasing the target temperature Indicator for status and errors...
- Page 5 Pos. Symbol Name Status Battery status Battery is weak Child-proof lock Device locked Radio status Radio connection to controller established Fault indication Radio connection to controller lost/not established Airing detection Window open, valve closed Operation mode Manual / automatic operation mode is active Value indication Normal operation Target temperature...
- Page 6 Technical data Model Thermostat AA Batteries 2× LR6/Mignon/AA Battery life ≥ 2 years Max. current consumption 120 mA Receiver category SRD category 2 Radio frequency 868.3 MHz / 869.525 MHz Max. transmission power 10 mW Radio range in free-field conditions ≤...
- Page 7 Protection class IP20 Method of operation Type 1 Degree of pollution Ambient temperature 0 °C to +50 °C Humidity 5 % to 80 % Software class Class A Dimensions (W × H × D) 48 mm × 57 mm × 103 mm Weight (without batteries) 140 g...
- Page 8 Open-Source-Software ▶ Neither the name of ARM nor the names of its This Bosch Smart Home product uses open-source contributors may be used to endorse or promote software. You will find the license information for products derived from this software without the components used on the opposite side.
- Page 9 ▶ The product may only be used indoors with Bosch ence and knowledge, if they have been supervised Smart Home original components and recom- or instructed in the safe use of the device and mended partner products.
- Page 10 ▶ When controlling a device remotely or using automa- ted control, due to external circumstances (such as the radio connection to the Smart Home Controller being interrupted) it cannot always be guaranteed that commands will actually be carried out or that the correct status of the device will be displayed in the app and on other Smart Home display devices (e.g.
- Page 11 Declaration of conformity Environmental protection and disposal Robert Bosch Smart Home GmbH declares that Electrical and electronic equipment that is no this Bosch Smart Home wireless radio equipment longer usable and defective or used batteries must Radiator Thermostat (Thermostat AA) is in com- be separated from other waste and recycled in an pliance with Directive 2014/53/EU.
- Page 12 Incorrect handling or non-observance of hazard online at: www.bosch-smarthome.com/faq warnings may compromise the protection afforded by the device. Robert Bosch Smart Home GmbH Schockenriedstraße 17 70565 Stuttgart-Vaihingen 0808 1010 151 (United Kingdom)* 1800 200 724 (Ireland)* Mon-Fri 7:00 am –...
