Table of Contents 1. Compatible Models – Page 3 2. Supported devices and formats – Page 4 3. Limitations on compatible formats – Page 5 4. Set up the display – Page 6 5. Insert USB memory and use A) Save content on USB memory and play. All still images have the same play duration.
TH-55AF1J <Content delivery via LAN> *1: Main microcomputer versions of 2.02 and later on displays are compatible with the LFE series. Refer to the website about how to verify the version. https://panasonic.net/cns/prodisplays/download/software/multi/ *2: AF series and TH-55LFV70 are not compatible.
2. Supported devices and formats <Supported devices> Commercially available USB memory devices are supported. (Those with security functions are not supported. Operation is not guaranteed.) USB memory devices other than those formatted in FAT16 or FAT32 cannot be used. ...
3. Limitaion on compatible formats <Limitation> Video Codec MPEG-4, AVC/H.264, Resolution: maximum 1920 x 1080 High Profile Frame rate: maximum 30fps (progressive) Bit rate: maximum 30Mbps - Level 4.2 or less - MVC (multi-view) is not supported. MPEG-4 Visual, Simple Profile Resolution: maximum 1920 x 1080 and Advanced Simple Profile Frame rate: maximum 30fps (progressive)
4. Set up the display Select [Setup] → [USB media player settings] on the second page with the remote control. Except for 65/75/84EF1, VF1 For SF2 series For 65/75/84EF1, VF1 (1) USB media player *Factory setting is [Enable]. Set [USB media player] to [Enable]. (2) Schedule play function (SF2 series only) *Factory setting is [Disables].
5. Insert USB memory and use A) Save content on USB memory and play. <What to prepare> Multi Monitoring USB memory & Control LAN cable Divider Software Necessary Necessary Unnecessary Unnecessary Unnecessary 1. Save content on USB memory. Save prepared content of still or moving images on USB memory using a computer.
(1) Download Multi Monitoring & Control Software (MMCS) from the Website and install it on a computer. Download from here ⇒https://panasonic.net/cns/prodisplays/download/software/index.html (2) Activate MMCS. (3) Right-click on Group and display the menu. (4) Select [Content list editing and delivery]. (5) Select [Content list editing].
Page 9
5. Insert USB memory and use (5) Selected content will be displayed in the play list. (6) Set the play time for one content item. Still images: Set within from 3 – 86,400 sec. Moving images: The play time for the moving image is displayed.
6. Deliver content on USB memory via LAN 6-1. Deliver content <What to prepare> Multiple USB memory Monitoring & LAN cable Divider Control Software Necessary Necessary Necessary Necessary Necessary 1. Set up network. Select [Setup] → [Network settings] on the second page with the remote control. (1) Network control *Factory setting is [Off].
Page 11
(1) Download Multi Monitoring & Control Software (MMCS) from the Website and install it on the computer. Download from here ⇒https://panasonic.net/cns/prodisplays/download/software/index.html (2) Activate MMCS. 5. Register the display. (1) Click [File]. (2) Click [Create New Device]. ⇒Device creation screen will appear.
Page 12
6. Deliver content on USB memory via LAN 6.1 Deliver content 6. Create content list. (1) Right-click on Group or registered device number and display the menu. (2) Click [Content list editing and delivery], and the following message will appear. * When you have necessary data into the USB memory, click Cancel and save the data beforehand.
Page 13
6. Deliver content on USB memory via LAN 6.1 Deliver content 7-1. Deliver content list. (Single-Playback) *Refer to 7-2 (page 14) for Multi-Playback *While the content is being delivered, the display screen will go black and the message [Content is being rewritten] will appear on the upper right.
Page 14
6. Deliver content on USB memory via LAN 6.1 Deliver content 7-2. Deliver content list. (Multi-Playback) *Refer to 7-1 (page 13) for Single-Playback *While the content is being delivered, the display screen will go dark and the message [Content is being rewritten] will appear on the upper right.
6. Deliver content on USB memory via LAN 6-2. Set date/time of delivery/playback and deliver A maximum of 100 lists can be set on the schedule. 1. Set schedule. (1) Click [File] and select [Schedule] from the menu. (2) Click [Add] on the schedule setting screen. (3) On the schedule creation screen, specify the date and time to deliver the content list.
Page 16
6. Deliver content on USB memory via LAN 6-2. Set date/time of delivery/playback and deliver (7) You will return to the schedule setting screen. Click [Add] again. (8) On the schedule creation screen, specify the date and time to start the content list It can be set by date/time, day of the week, and date.
7. Convert PowerPoint data to still/moving images Files created with PowerPoint can be converted to still or moving images and delivered as content. Configure PowerPoint page settings in advance! * Compatible with Microsoft PowerPoint 2010/2013. * Depending on settings, resolution may be lost when converting from PowerPoint, so we recommend that you configure these settings beforehand.
8. Light ID setting (SF1H series only) • A separate contract for a Light ID license (requiring a fee) must be concluded to configure a Light ID system. 1. Import the Light ID on MMCS (1) Save the Light ID file (***.bin) on your PC (2) Select [Light ID Information] tab (3) Select [Get a Light ID], and Import ***.bin data on MMCS (4) Input the password(HEXKEY) obtained from LinkRay portal site or administrator for light ID...
Page 19
8. Light ID setting (SF1H series only) 2. Link the ID to Content (1) Right-click on Group or registered device number and display the menu. (2) Click [Content list editing and delivery], and the following message will appear. * When you have necessary data into the USB memory, click Cancel and save the data beforehand. (3) Click [Content list editing].
Page 20
“One-Stop Website” for Professional Displays: https://panasonic.net/cns/prodisplays/ Video introducing our professional displays: https://www.youtube.com/user/PanasonicProDisplay Panasonic Corporation Connected Solutions Company June 2017_Ver.1...
