Contact SAMSUNG WORLD-WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Contacte con SAMSUNG WORLD-WIDE Si tiene alguna pregunta o comentario referente a nuestros productos, por favor contacte con nuestro Servicio de Atención al Cliente...
Contents CONNECTING AND PREPARING YOUR TV List of Parts ... 2 Installing the Stand ... 2 Installing the Wall Mount Kit ... 2 Viewing the Control Panel ... 3 Viewing the Connection Panel ... 4 Viewing the Remote Control ... 6 Installing Batteries in the Remote Control ...
Wall Mount items. Contact a technician for assistance when installing the wall mounted bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.
Viewing the Control Panel The product colour and shape may vary depending on the model. SOURCE Toggles between all the available input sources (TV, Ext.1, Ext.2, AV, S-Video, Component, PC, HDMI, DTV). In the on-screen menu, use this button as you use the ENTER/OK button on the remote control.
Viewing the Connection Panel [Rear Panel Jacks] (32 inch/37 inch/40 inch) [Rear Panel Jacks] (27 inch) Whenever you connect an external device to your TV, make sure that power on the unit is turned off. When connecting an external device, match the colour of the connection terminal to the cable. Connecting an Aerial or Cable Television Network To view television channels correctly, a signal must be received by the set from one of the following sources: - An outdoor aerial / A cable television network / A satellite network...
Page 7
Connecting HDMI/DVI - Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players, AV receivers and digital TVs). - No additional Audio connection is needed for an HDMI to HDMI connection. What is HDMI? - “High Definition Multimedia interface” allows the transmission of high definition digital video data and multiple channels of digital audio (5. 1 channels). - The HDMI/DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied).
4. Is there a power outage, or is the power cord unplugged? 5. Is there a special fluorescent light or neon sign nearby? Selects a target device to be controlled by the Samsung remote control (TV, DVD, STB, CABLE, VCR) (Refer to page 30~34)
Switching On and Off The mains lead is attached to the rear of your set. 1. Plug the mains lead into an appropriate socket. The standby indicator lights up on the front of the set. 2. Press the button on the front of the set. You also can press the POWER button or the The programme that you were watching last is reselected automatically.
Storing Channels Automatically You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated programme numbers may not correspond to actual or desired programme numbers. However, you can sort numbers manually and clear any channels you do not wish to watch. 1.
Setting the Channel Manager You can select these options by simply pressing the CH MGR button on the remote control. Activating the Child Lock Set the channels according to your preference. You can easily delete, add, or lock the channel you want. Press the MENU button to display the menu.
Sorting the Stored Channels Assigning Channels Names Fine Tuning Channel Reception You can exchange the numbers of two channels, in order to: Modify the numeric order in which the channels have been automatically stored. Give easily remembered numbers to the channels that you watch most often. 1.
LNA (Low Noise Amplifier) Changing the Picture Standard Adjusting the Custom Picture Changing the Colour Tone If the TV is operating in a weak-signal area, the LNA function can improve the reception (a low-noise preamplifier boosts the incoming signal). 1. Press the MENU button to display the menu. Press the button to select "Channel", then press the ENTER/OK button.
Resetting the Picture Settings to the Factory Defaults Changing the Picture Size Freezing the Current Picture Digital Noise Reduction You can return to the factory defaults picture settings. 1. To select the desired picture effect, follow the "Changing the Picture Standard" instructions number 1 to 3 on page 11. 2.
"PIP". Samsung’s new technology brings you more detailed images with contrast and white enhancement. A new image compensation algorithm gives viewers brighter and clearer images. DNIe technology will match every signal to your eyes.
PIP Settings Ext.1 Main Ext.1 Ext.2 S-Video Component HDMI Changing the Sound Standard Adjusting the Sound Settings Connecting headphones Ext.2 S-Video You can select the type of the special sound effect to be used when watching a given broadcast. Press the MENU button to display the menu. Press the button to select "Sound", then press the ENTER/OK button.
Setting the TruSurround XT (SRS TSXT) Adjusting the Volume Automatically Selecting the Internal Mute Listening to the Sound of the Sub Picture TruSurround XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers. TruSurround delivers a compelling,virtual surround sound experience through any two-speaker playback system, including internal television speakers.
Resetting the Sound Settings to the Factory Defaults Setting and Displaying the Current Time Setting the Sleep Timer Switching the Television On and Off Automatically If Game Mode is On, the Reset Sound function is activated. Selecting the Reset function after setting the equalizer resets the equalizer setting to the factory defaults.
Choosing Your Language Using Game Mode Setting the Blue Screen Mode / Selecting the Melody 4. Press the button to adjust "Hour", then press the move to the next step. Set other items using the same method as above. When finished, press the ENTER/OK button to return. 5.
Using the Energy Saving Feature Selecting the Source Editing the Input Source Names This function adjusts the brightness of the TV so as to reduce power consumption. When you watching TV at night, set the "Energy Saving " mode option to "High" so as to reduce the dazzling of your eyes as well as the power consumption.
Previewing the DTV Menu System You can select these options by simply pressing the D.MENU button on the remote control. To help you navigate around the on-screen menu system and adjust the various settings available, refer to the following illustration. Available in the Digital TV mode.
Basic Functions Display Screen Before you can view the television program, you must perform the installation. Therefore you will see only menu images at first. After the television channels have been programmed, you will see the following picture (banner) each time you switch channels: Channel Number Signal Status...
Service List • Press the CH MGR button while you are viewing a program. • Select list by pressing the TV/RADIO button. The icon behind the channel name symbolizes scrambled channel, and the icon behind the channel name symbolizes parental locked channel. •...
Operating the DTV Menu Main Menu After installing your antenna system and TV with appropriate connectors. • Plug in the AC main power and switch on the TV. • Press the D.MENU button to bring up the main menu. The following on-screen display will appear: The sub menu topics will be displayed.
Manual Scanning To tune-in new channels and weak signals, the TV has been provided with the option “Manual Scanning” where the channel data can be entered by the user. After selecting the “Manual Scanning” from the Installation Menu, the following screen will be displayed: •...
Delete Frequency • Select the desired frequency list you want to delete by pressing the RED button. • Press the ENTER/OK button for confirmation. This feature doesn’t delete frequency itself but deletes the list of channels registered for frequency. Delete Channel •...
Parental Lock This “Parental Lock” feature sets viewing restrictions and prevents unauthorized access to your TV through the PIN (Personal Identification Number), which is a 4-digit number. (The factory preset PIN Code : 0000) On selecting this menu, you will have three options: to set lock for any desired channel and to change your PIN Code and to Set Modem Lock.
System Setup This option enables you to change the factory preset system settings as per your requirements. Language Selection The “Language Selection” option allows the user to select the desired language of the OSD, Soundtrack, Teletext, and EPG. • To accommodate user from different regions speaking different languages, OSD languages are available 5 languages.
Installing the CI card System Information If you have to contact your service provider or a service center they might ask for information available from this menu.Place the cursor on this sub menu and press the ENTER/OK button. The following will be the on-screen display. Software Upgrade You can download and upgrade the system software of the TV through a specific channel through a specific channel designated by the broadcaster.
Teletext Decoder Displaying the Teletext Information Most set channels carry " teletext ", pages of written information that provide information such as: Television programme times. News bulletins and Weather forecasts. Sports results. Subtitles for the hard of hearing. The teletext pages are organized according to six categories: Contents Part Selected page number.
Selecting a Specific Teletext Page Using Fastext to Select a Teletext Page Press the number buttons on the remote control to enter the page number directly: Enter the three-digit page number listed in the contents by pressing the corresponding numeric buttons. If the selected page is linked with several secondary pages, the secondary pages are displayed in sequence.
Setting Up Your Remote Control After it has been set up properly, your remote control can operate in five different modes: TV, DVD, Cable, Set-Top Box, VCR. Pressing the corresponding button on the remote control allows you to switch between these modes, and control whichever piece of equipment you choose.
Page 33
Setting Up the Remote to Operate Your DVD 1. Turn off your DVD. 2. Press the DVD button on your TV’s remote control. 3. Press the SET button on your TV’s remote control. 4. Using the number buttons on your remote control, enter three digits of the DVD code listed on page 33~34 of this manual for your brand of DVD.
Windows and your particular video card. Even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) 1. First, click on "Control Panel" on the Windows start menu.
Setting the PC Coarse and Fine Tuning of the Image (Image Lock): The purpose of picture quality adjustment is to remove or reduce picture noise. If the noise is not removed by Fine-tuning alone, then adjust the frequency as best as possible (coarse) and Fine-tune again.
Using the Anti-Theft Kensington Lock The Kensington lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may differ from the illustration depending on the manufacturer.
Technical and Environmental Specifications Model Name Screen Size (Diagonal) Power Consumption PC Resolution Sound Output Dimension (WxDxH) Body With stand Weight With stand Environmental Considerations Operating Temperature Operating Humidity Storage Temperature Storage Humidity Model Name Screen Size (Diagonal) Power Consumption PC Resolution Sound Output...
Page 42
Indice CONEXIÓN Y CONFIGURACIÓN DEL TELEVISOR Lista de componentes ... 2 Instalación del soporte ... 2 Instalación del equipo de montaje en la pared ... 2 Visualización del Panel de control ... 3 Visualización del Panel de conexión ... 4 Visualización del mando a distancia ...
Para la instalación del soporte mural, póngase en contacto con un técnico. Samsung Electronics no se hace responsable de los daños causados al producto o a los usuarios si éstos han efectuado personalmente la instalación del televisor. Retire el soporte, tape el agujero inferior; asegure con los dos tornillos.
Visualización del Panel de control El color y la forma del producto pueden variar según el modelo. SOURCE Cambia entre todas las fuentes de entrada disponibles (TV, Ext.1, Ext.2, AV, S-Vídeo, Componente, PC, HDMI, DTV). En el menú de la pantalla, use este botón del mismo modo que el botón ENTER/OK del mando a distancia.
Visualización del Panel de conexión [Tomas del panel posterior] (32pulg./ 37pulg. /40pulg.) Entrada de alimentación [Tomas del panel posterior] (27 pulg.) Cada vez que conecte un dispositivo externo al televisor, compruebe que la unidad esté desconectada de la alimentación. Cuando conecte un terminal externo, debe hacer coincidir los colores del terminal de conexión y del cable. Conexión a la antena o a la red de televisión por cable Para ver los canales de televisión correctamente, la unidad debe recibir una señal de una de las fuentes siguientes: - Una antena exterior / Una red de televisión por cable / Una red por satélite...
Page 46
Conexión de HDMI/DVI - Admite conexiones entre dispositivos de AV con conexión HDMI (receptores de televisión digital, reproductores de DVD, receptores de AV y televisores digitales). - No se necesita conexión de audio adicional para una conexión de HDMI a HDMI. ¿Qué...
4. ¿Ha habido un corte de luz o el cable está desenchufado? 5. ¿Hay cerca una luz fluorescente o un letrero de neón? Selecciona un dispositivo de destino que controlar con el mando a distancia Samsung (TV, DVD, STB, CABLE, VCR). (Consulte la página 30~34.) Botón de suspensión del televisor...
Encendido y apagado El cable de alimentación se encuentra en la parte posterior de la unidad. 1. Conecte el cordón eléctrico en un enchufe adecuado. Se enciende el indicador de modo en espera de la parte frontal del equipo. 2. Pulse el botón de la parte frontal del aparato.
Memorización automática de canales Puede explorar los rangos de frecuencia disponibles (la disponibilidad varía en función del país). Los números de programa adjudicados automáticamente puede que no se correspondan con los números de programa reales o deseados. No obstante, puede ordenar los números manualmente y borrar los canales que no desea ver. 1.
Configuración del Gestor de Canales Puede seleccionar estas opciones pulsando el botón CH MGR del mando a distancia. Activación del bloqueo para niños Puede configurar los canales como prefiera. Puede suprimir, añadir o bloquear fácilmente el canal que desee. 1. Pulse el botón MENU para ver el menú. Pulse los botones para seleccionar “Canal”...
Orden de los canales memorizados Asignación de nombres de canales Sintonía fina de la recepción de canales Puede intercambiar los números de dos canales para: Modificar el orden numérico en que los canales se han memorizado automáticamente. Asignar números fáciles de recordar a los canales que ve con más frecuencia. 1.
LNA (Low Noise Amplifier - Amplificador de ruido bajo) Cambio de la imagen estándar Ajuste de imagen personal Cambio del tono del color Si el TV funciona en una zona de señal débil, la función LNA puede mejorar la recepción (un preamplificador de nivel bajo de ruido aumenta la señal de entrada).
Reajuste de los valores de la imagen a los valores predefinidos de fábrica Selección del Tamaño de la imagen Congelación de la imagen actual Reducción de ruido digital Puede volver a los ajustes de imagen predefinidos de fábrica. 1. Para seleccionar el efecto de imagen deseado, siga las instrucciones 1 a 3 de “Cambio de la imagen estándar”...
“PIP”. La nueva tecnología de Samsung le ofrece imágenes más detalladas con mejoras en contraste y blancos. Un nuevo algoritmo de compensación de imagen proporciona a los usuarios una imagen más brillante y más clara.
Configuración de PIP Secundaria Ext.1 Principal Ext.1 Ext.2 S-Video Component HDMI Cambio del estándar de sonido Ajuste de los parámetros de sonido Conexión de los auriculares Ext.2 S-Video Puede seleccionar un tipo de efecto de sonido especial que se usará cuando se visualice una emisión concreta.
Configuración de TruSurround XT (SRS TSXT) Ajuste del volumen automáticamente Selección del silencio interno Cómo escuchar el sonido de la imagen secundaria TruSurround XT es una tecnología patentada de SRS que resuelve el problema de la reproducción de contenidos multicanal 5.1 con dos altavoces. TruSurround XT proporciona una convincente experiencia de sonido surround virtual a través de cualquier sistema de reproducción con dos altavoces, como los propios altavoces internos del televisor.
Reajuste de valores de sonido a los valores predefinidos de fábrica Configuración y visualización de hora actual Ajustar hora Hora Minuto Mover Ajustar Volver Ajuste del temporizador de desconexión Encendido y apagado de la televisión automáticamente Si Modo Juego está activado, la función de restablecer el sonido se activa. Si, tras configurar el ecualizador selecciona la función Reset (Restablecer), se restauran los parámetros de fábrica de la configuración del ecualizador.
Selección del idioma Uso del Modo Juego Ajuste del modo Pantalla Azul / Selección de Melodía 4. Pulse los botones para ajustar “Hora” y pulse el botón Ajuste otras opciones utilizando el mismo método que se indica anteriormente. Cuando haya terminado, pulse el botón ENTER/OK para volver. 5.
Uso de la función de ahorro de energía Selección de la fuente Edición de los nombres de fuentes de entrada Esta función ajusta el brillo del televisor, lo cual reduce el consumo de energía. Si desea ver la televisión por la noche, ajuste la opción del modo “Ahorro energía” en “Alto” sus ojos se lo agradecerán y, además, reducirá...
Previsualización del sistema de menús del DTV Puede seleccionar estas opciones pul sando el botón D.MENU del mando a distancia. Para desplazarse por el sistema de menús en pantalla y para ajustar las configuraciones disponibles, consulte la ilustración siguiente. Disponible en el modo de televisión digital. Pulse el botón D.MENU.
Funciones básicas Pantalla de visualización Antes de poder ver el programa de televisión se ha de llevar a cabo la instalación. Por tanto, al principio sólo se verán imágenes de menú. Una vez programados los canales de televisión, se verá la siguiente imagen (banda) cada vez que se cambie de canal: Número de canal Estado de la señal...
Lista de servicios • Pulse el botón CH MGR mientras está viendo un programa. • Seleccione la lista pulsando el botón TV/RADIO. El icono que aparece detrás del nombre del canal indica que está codificado, mientras que el icono significa que el canal está bloqueado. •...
Funcionamiento del menú DTV Menú principal Después de instalar el sistema de antena y el TV con los conectores adecuados. • Enchufe el televisor a la corriente de red y enciéndalo. • Pulse el botón D.MENU para ver el menú principal. Aparecerá...
1.3 Exploración manual Para sintonizar canales nuevos o señales débiles, el TV incorpora la opción “Exploración manual” en la que el usuario puede introducir los datos del canal. Tras seleccionar “Exploración manual” en el menú Instalación, aparecerá la pantalla siguiente: •...
2.1 Borrar frecuencia • Seleccione la lista de frecuencias que desea borrar pulsando el botón ROJO. • Pulse el botón ENTER/OK para confirmar. Esta función no suprime la frecuencia sino la lista de canales registrados de aquélla. 2.2 Suprimir canal •...
Bloqueo primario La función de “Bloqueo primario” establece restricciones de visionado e impide el acceso no autorizado al televisor por medio del PIN (Número de identificación personal), que es un número de cuatro dígitos. (Código PIN establecido en fábrica: 0000) Este menú ofrece tres opciones: bloquear un canal determinado, cambiar el código PIN y establecer el bloqueo para módem.
Configuración del sistema Puede cambiar los valores del sistema prefijados en fábrica en función de sus necesidades. 4.1 Selección del idioma La opción de “Selección de idioma” permite al usuario seleccionar el idioma de OSD, pista sonora, teletexto y EPG. •...
Instalación de la tarjeta CI 4.4 Información del sistema Cuando se ponga en contacto con el proveedor de servicios o con un centro de servicio, es posible que soliciten información disponible en este menú. Coloque el cursor en este submenú y pulse el botón ENTER/OK. En la pantalla aparecerá...
Decodificador de teletexto Visualización de informaciones del teletexto Muchos canales de Televisor incluyen “teletexto”, páginas de información escrita que proporciona datos como: Horas de los programas de televisión Boletines de noticias y partes meteorológicos. Resultados deportivos Subtítulos para sordos Las páginas de teletexto se organizan en seis categorías: Contenido Parte Número de página seleccionado.
Selección de una página de teletexto específica Uso de Fastext para seleccionar una página del teletexto Pulse los botón numéricos en el mando a distancia para introducir los números de página directamente: Introduzca los tres dígitos del número de la página que se enumera en el índice pulsando los botón numéricos correspondientes.
Configuración del mando a distancia Una vez configurado correctamente, el mando a distancia puede funcionar en cinco modos diferentes: TV, vídeo, Decodificador, DVD o receptor TV digital. Pulsando el botón correspondiente del mando a distancia podrá cambiar de un modo a otro y controlar cualquiera de estos equipos. El mando a distancia quizá...
Page 72
Configuración del mando a distancia para controlar el DVD. Apague el DVD. Pulse el botón DVD del mando a distancia del televisor. Pulse el botón SET del mando a distancia del televisor. Mediante los botóns de número del mando a distancia, intro duzca los tres dígitos del código del DVD correspondi-entes a la marca de su DVD, que aparece en la lista de la página 34~35 de este manual.
Pero aunque las pantallas reales tengan un aspecto diferente, se aplicarán los mismos ajustes básicos y la misma información en la mayoría de los casos. (En caso contrario, póngase en contacto con el fabricante del ordenador o con el distribuidor de Samsung.) 1. Primero, haga clic en “Control Panel” dentro del menú Inicio de Windows.
Selección del PC Sintonización gruesa y fina de la imagen (Bloqueo de Imagen): El propósito del ajuste de imagen calidad es remitir o reducir el ruido de la imagen. Si no se eliminan mediante la sintonización Fina, ajuste la frecuencia lo mejor que pueda (grueso) y vuelva a realizar la sintonización fina.
Utilización del bloqueo Kensington antirrobo El anclaje Kensington es un dispositivo utilizado para asegurar un aparato cuando se utiliza en un sitio público. Este dispositivo de bloqueo se adquiere por separado. El aspecto y método de bloqueo puede diferir del que se muestra en la ilustración dependiendo del fabricante. Consulte el manual incluido con el anclaje Kensington para utilizarlo adecuadamente.
Especificaciones técnicas y medioambientales Nombre del modelo Tamaño de pantalla (diagonal) Consumo de energía PC Resolución Sonido Salida Dimensiones (An x Pr x Al) Cuerpo principal Con soporte Peso Con soporte Factores medioambientales Temperatura de funcionamiento Humedad de funcionamiento Temperatura de almacenamiento Humedad de almacenamiento Nombre del modelo Tamaño de pantalla (diagonal)
Page 80
Esta página se ha dejado en blanco expresamente.
Page 81
Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
