CP 1543-1
SIMATIC NET
S7-1500 - Industrial Ethernet
CP 1543-1
Operating Instructions
12/2019
C79000-G8976-C289-08
Preface
Guide to the documentation
Product overview, functions
Installation, connecting up,
commissioning, operation
Configuration, programming
Diagnostics and upkeep
Technical specifications
Approvals
1
2
3
4
5
6
7

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIMATIC NET S7-1500

Summary of Contents for Siemens SIMATIC NET S7-1500

  • Page 1 CP 1543-1 Preface Guide to the documentation Product overview, functions SIMATIC NET Installation, connecting up, commissioning, operation S7-1500 - Industrial Ethernet CP 1543-1 Configuration, programming Diagnostics and upkeep Operating Instructions Technical specifications Approvals 12/2019 C79000-G8976-C289-08...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    Preface Article number, validity and product names This description contains information on the following product: CP 1543-1 Article number 6GK7 543-1AX00-0XE0 Hardware product version 2 Firmware version V2.2 Communications processor for SIMATIC S7-1500 View of the CP 1543-1 ① LEDs for status and error displays ②...
  • Page 4 – IP routing via the backplane bus Replaced edition Edition 05/2017 Current manual release on the Internet You will find the current version of this manual on the Internet pages of Siemens Industry Online Support: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15340/man) CP 1543-1 Operating Instructions, 12/2019, C79000-G8976-C289-08...
  • Page 5 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers’...
  • Page 6 You will find the SIMATIC NET glossary on the Internet at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/view/50305045) Device defective If a fault develops, please send the device to your Siemens representative for repair. Repairs on-site are not possible. Recycling and disposal The product is low in pollutants, can be recycled and meets the requirements of the WEEE directive 2012/19/EU "Waste Electrical and Electronic Equipment".

  • Page 7: Table Of Contents

    Table of contents Preface ..............................3 Guide to the documentation ........................9 Product overview, functions ........................11 Communication services ......................11 Further functions ........................12 Industrial Ethernet Security ..................... 14 Configuration limits and performance data ................15 2.4.1 General characteristic data ..................... 15 2.4.2 Characteristics of S7 communication ..................
  • Page 8 Table of contents DNS configuration ........................42 FTP communication ....................... 42 4.7.1 FTP server ..........................42 4.7.1.1 Configuring the FTP server function ..................42 4.7.2 FTP client ..........................45 4.7.2.1 The program block FTP_CMD (FTP client function) .............. 45 4.7.2.2 Input parameter - FTP_CMD ....................

  • Page 9: Guide To The Documentation

    Table 1- 1 Overview of the documentation for S7-1500 Topic Documentation Most important contents System descrip- System manual: S7-1500 Automation System Application planning • tion (https://support.industry.siemens.com/cs/ww/e Installation • n/view/59191792) Connecting • Commissioning • System diagnos- Function manual: System diagnostics Overview •...
  • Page 10 The "Version History/Current Downloads for SIMATIC NET S7 CPs (Industrial Ethernet)" document provides information on all CPs available up to now for SIMATIC S7 (Industrial Ethernet). The current versions of the document can be found on the Internet: Link: (https://support.industry.siemens.com/cs/ww/en/view/109474421) CP 1543-1 Operating Instructions, 12/2019, C79000-G8976-C289-08...

  • Page 11: Product Overview, Functions

    Product overview, functions Application The CP is intended for operation in an S7-1500 automation system. It allows the S7-1500 to be connected to Industrial Ethernet. With a combination of different security measures such as firewall and protocols for data encryption, the CP protects the S7-1500 or even entire automation cells from unauthorized access.

  • Page 12: Further Functions

    Product overview, functions 2.2 Further functions ● FTP/FTPS FTP functions (File Transfer Protocol) for file management and access to data blocks in the CPU – FTP server Can be activated via the configuration – FTP client Configurable via program blocks. ●...
  • Page 13 Product overview, functions 2.2 Further functions IP configuration - IPv4 and IPv6 The essential features of IP configuration for the CP: ● The CP supports the use of IP addresses according to IPv4 and IPv6. ● You can configure how and with which method the CP is assigned the IP address, the subnet mask and the address of a gateway.

  • Page 14: Industrial Ethernet Security

    Product overview, functions 2.3 Industrial Ethernet Security S5/S7 addressing mode for FETCH/WRITE The addressing mode can be configured for FETCH/WRITE access as S7 or S5 addressing mode. The addressing mode specifies how the position of the start address is identified during data access (S7 addressing mode applies only to data blocks / DBs).

  • Page 15: Configuration Limits And Performance Data

    Product overview, functions 2.4 Configuration limits and performance data ● SMTPS Foe secure transfer of e-mails via port 587 ● SNMPv3 For secure transmission of network analysis information safe from eavesdropping Observe the information in section Security recommendations (Page 31). Configuration limits and performance data 2.4.1 General characteristic data...
  • Page 16 Product overview, functions 2.4 Configuration limits and performance data The following characteristics are important (OUC + FETCH/WRITE): Characteristic Explanation / values Number of connections Number of configured and programmed connections (ISO transport + ISO-on-TCP + TCP + UDP + FETCH/WRITE + e-mail): Max.

  • Page 17: Characteristics Of S7 Communication

    Product overview, functions 2.4 Configuration limits and performance data Restrictions for UDP ● Restrictions UDP broadcast / multicast To avoid overloading the CP due to high broadcast / multicast frame traffic, the receipt of UDP broadcast / multicast on the CP is limited. ●...

  • Page 18: Characteristic Data For Ftp / Ftps Mode

    Product overview, functions 2.4 Configuration limits and performance data 2.4.3 Characteristic data for FTP / FTPS mode TCP connections for FTP FTP actions are transferred from the CP over TCP connections. The following characteristics apply: ● FTP client mode You can use a maximum of 32 FTP sessions. Up to 2 TCP connections are occupied per activated FTP session (1 control connection and 1 data connection).

  • Page 19: Requirements For Use

    Product overview, functions 2.5 Requirements for use Requirements for use 2.5.1 Configuration limits When using the CP type described here, the following limits apply: ● The number of CPs that can be operated in a rack depends on the CPU type being used. By operating several CPs, you can increase the configuration limits listed below for the station as the whole.

  • Page 20: Program Blocks - Overview

    Product overview, functions 2.5 Requirements for use 2.5.3 Program blocks - overview Program blocks - overview The following program blocks (instructions) are available for the CP. Table 2- 1 Blocks of the Open User Communication Protocol Program block (instruction) System data type TSEND_C/TRCV_C TCON_IP_v4 •...

  • Page 21: Leds

    Product overview, functions 2.6 LEDs LEDs LEDs ① RUN LED ② ERROR LED ③ MAINT LED ④ LINK/ACT LED ⑤ Reserve LED Figure 2-1 LED display of the CP 1543-1 (without front cover) Meaning of the LED displays of the CP The CP has the following 3 LEDs to display the current operating status and the diagnostics status: (one-color LED: green)
  • Page 22 Product overview, functions 2.6 LEDs The following table shows the meaning of the various combinations of colors of the RUN, ERROR and MAINT LEDs. Table 2- 4 Meaning of the LEDs "RUN", "ERROR", "MAINT" ERROR MAINT Meaning No supply voltage on the CP or supply voltage too low.

  • Page 23: Gigabit Interface

    Product overview, functions 2.7 Gigabit interface Meaning of the LED displays of the Ethernet interface: X1 P1 The LED LINK/ACT (two color green/yellow) is assigned to the port of the Ethernet interface. The table below shows the LED patterns. Table 2- 5 Meaning of the "LINK/ACT"...
  • Page 24 Product overview, functions 2.7 Gigabit interface CP 1543-1 Operating Instructions, 12/2019, C79000-G8976-C289-08...

  • Page 25: Installation, Connecting Up, Commissioning, Operation

    Installation, connecting up, commissioning, operation Important notes on using the device Safety notices on the use of the device Note the following safety notices when setting up and operating the device and during all associated work such as installation, connecting up or replacing the device. NOTICE LAN attachment A LAN or LAN segment with the attachments belonging to it should be within a single low-...

  • Page 26: Notes On Use In Hazardous Areas According To Atex / Iecex

    Zone 2, the device must be installed in a cabinet or a suitable enclosure. WARNING DIN rail In the ATEX and IECEx area of application only the Siemens DIN rail 6ES5 710-8MA11 may be used to mount the modules. 3.1.2...

  • Page 27: Notes On Use In Hazardous Areas According To Ul Hazloc

    Installation, connecting up, commissioning, operation 3.1 Important notes on using the device 3.1.3 Notes on use in hazardous areas according to UL HazLoc WARNING EXPLOSION HAZARD You may only connect or disconnect cables carrying electricity when the power supply is switched off or when the device is in an area without inflammable gas concentrations.

  • Page 28: Installing And Commissioning The Cp 1543-1

    Installation, connecting up, commissioning, operation 3.2 Installing and commissioning the CP 1543-1 Installing and commissioning the CP 1543-1 Installation and commissioning WARNING Read the system manual "S7-1500 Automation System" Prior to installation, connecting up and commissioning, read the relevant sections in the system manual "S7-1500 Automation System"...

  • Page 29: Operating Mode Of The Cpu: Reaction Of The Cp

    D4 bidirectional - You will find additional information on the topics of "Connecting up" and "Accessories (RJ-45 plug)" in the system manual: Link: (https://support.industry.siemens.com/cs/ww/en/view/59191792) Operating mode of the CPU: Reaction of the CP Switching the CPU: RUN → STOP You can switch the operating mode of the CPU between RUN and STOP via STEP 7.
  • Page 30 Installation, connecting up, commissioning, operation 3.3 Operating mode of the CPU: Reaction of the CP ● The following functions remain enabled: – Configuration and diagnostics of the CP System connections for configuration, diagnostics and PG channel routing still exist. – Web diagnostics –...

  • Page 31: Configuration, Programming

    ● Do not connect the device directly to the Internet. Operate the device within a protected network area. ● Check regularly for new features on the Siemens Internet pages. – Here you can find information on Industrial Security: Link: (http://www.siemens.com/industrialsecurity) –...
  • Page 32 Configuration, programming 4.1 Security recommendations Security functions of the product Use the options for security settings in the configuration of the product. These includes among others: ● Protection levels Configure access to the CPU under "Protection and Security". ● Security function of the communication –...
  • Page 33 Configuration, programming 4.1 Security recommendations Protocols Secure and non-secure protocols ● Only activate protocols that you require to use the system. ● Use secure protocols when access to the device is not prevented by physical protection measures. ● Deactivate DHCP at interfaces to public networks such as the Internet, for example, to prevent IP spoofing.

  • Page 34: Restricting Communications Services In The Cpu

    Configuration, programming 4.2 Restricting communications services in the CPU Protocol / Port number (pro- Default of the port Port status Authentication function tocol) Online security 8448 (TCP) Closed Open after configuration diagnostics HTTP 80 (TCP) Closed Open after configuration HTTPS 443 (TCP) Closed Open after configuration...

  • Page 35: Network Settings

    Configuration, programming 4.3 Network settings "Permit access with PUT/GET communication from remote partner" ● Option enabled Access to CPU data from the client side is permitted. ● Option disabled Read and write access to CPU data is only possible with communication connections that require configuration or programming both for the local CPU and for the communications partner.

  • Page 36: Ip Configuration

    Configuration, programming 4.4 IP configuration IP configuration 4.4.1 Points to note about IP configuration Configured S7 and OUC connections cannot be operated if the IP address is assigned using DHCP Note If you obtain the IP address using DHCP, any S7 and OUC connections you may have configured will not work.

  • Page 37: Virtual Interface Of The Cpu

    Configuration, programming 4.4 IP configuration Please note: If you use multiple CPs in a station and wish to use IP routing, you can only configure a router for one CP in the station. When the security function is activated, additional IP firewall rules are created, which you can modify in advanced firewall mode of the Global Security settings.
  • Page 38 Configuration, programming 4.4 IP configuration Figure 4-1 Principle of the virtual interface Configuration of the virtual interface W1 The virtual interface is configured in STEP 7 in the parameter group "Advanced configuration > Access to PLC via communication module". Here, the virtual interface is assigned to a CP of the station, via which external access to the CPU can take place.
  • Page 39 Configuration, programming 4.4 IP configuration The virtual interface W1 is displayed in the diagnostics view under "Online & Diagnostics". The hardware ID of the virtual interface is displayed in the system constants in the CPU properties. Note Address change during runtime and restart When the IP parameters of the virtual interface are loaded, you can then change them via the display of the CPU, via T_CONFIG or online.

  • Page 40: Programmed Connections: Restriction Of Firewall Rules

    Configuration, programming 4.4 IP configuration Security settings of the CP The settings of the internal CP firewall do not have an effect on communication over the virtual interface. This means the security functions of the communication module cannot protect the data traffic via the virtual interface. NOTICE Connecting to non-secure networks Use of the virtual interface via the CP is only possible when the security functions of the CP...

  • Page 41: Time-Of-Day Synchronization

    Configuration, programming 4.5 Time-of-day synchronization Time-of-day synchronization General rules The CP supports the following mode for timeofday synchronization: ● NTP mode (NTP: Network Time Protocol) Note Recommendation for setting the time Synchronization with a external clock at intervals of approximately 10 seconds is recommended.

  • Page 42: Dns Configuration

    Configuration, programming 4.6 DNS configuration DNS configuration DNS server A DNS server may be required when the module itself, a communications partner, or for example an FTP server should be reachable via the host name (FQDN). If you specify the address of a device as FQDN, you need to configure a DNS server.
  • Page 43 Configuration, programming 4.7 FTP communication S7-1500 CP as FTP server The functionality described here allows you to transfer data in the form of files to or from an S7-1500 station using FTP commands. At the same time, the conventional FTP commands for reading, writing and managing files can also be used.
  • Page 44 Configuration, programming 4.7 FTP communication You make the data block assignment in the STEP 7 configuration of the CP (FTP configuration). Figure 4-3 S7-CPU with CP 154x-1 as FTP server for the S7 CPU data DB assignment in STEP 7 The fields of the table in the data block assignment in STEP 7 have the following meaning and syntax: Column title...

  • Page 45: Ftp Client

    Configuration, programming 4.7 FTP communication 4.7.2 FTP client 4.7.2.1 The program block FTP_CMD (FTP client function) FTP_CMD Using the FTP_CMD instruction, you can establish FTP connections and transfer files from and to an FTP server. Data transfer is possible using FTP or FTPS (secure SSL connections). You will find the block in STEP 7 in the "Instructions"...
  • Page 46 Configuration, programming 4.7 FTP communication How it works The FTP_CMD instruction references a job block (ARG) in which the FTP command is specified. Depending on the type of FTP command (CMD), this job block uses different data structures for parameter assignment. Suitable data types (UDTs) are available for these various structures.

  • Page 47: Input Parameter - Ftp_Cmd

    Configuration, programming 4.7 FTP communication Requirements in the CPU configuration Use the following settings to allow FTP access: ● For all data blocks being used as file DBs, disable the "Optimized block access" attribute. ● Only when using a CPU V1.x and a CP V1.1.x: Enable the "Access via PUT/GET communication..."...
  • Page 48 Configuration, programming 4.7 FTP communication FTP commands in the "CMD" parameter The following table shows you the significance of the commands of the "CMD" parameter and which UDTs you use to supply the job blocks. Table 4- 3 Command types CMD (command type) Relevant job blocks / Meaning / handling...

  • Page 49: Job Blocks For Ftp_Cmd

    Configuration, programming 4.7 FTP communication 4.7.2.3 Job blocks for FTP_CMD Meaning You supply the FTP_CMD instruction with a job block using the ARG parameter. The structure depends on the FTP command type. By using the default data types (UDT), the instruction recognizes the type of the job block.
  • Page 50 Configuration, programming 4.7 FTP communication Parameter Type Range of values Meaning / remarks Password STRING[32] ’passwort’ Password for the login on the FTP server FTPserverIPaddr IP_V4 ADDR(1) ... IP address of the FTP server as Array[1..4] of Byte, where ADDR(4) 1 byte specifies one block of the address.
  • Page 51 Configuration, programming 4.7 FTP communication Job block for FTP connection establishment with server name For FTP connection establishment specifying the server name, the following data structure is used. The server name is assigned to an IP address using DNS. Table 4- 6 FTP_CONNECT_NAME Parameter Type...
  • Page 52 Configuration, programming 4.7 FTP communication Job block for write and read access and other FTP commands The following data structure is used for the FTP commands store, retrieve, delete and append. Table 4- 7 FTP_FILENAME Parameter Type Range of values Meaning / remarks InterfaceID HW_ANY...
  • Page 53 Configuration, programming 4.7 FTP communication Job block for the RETR_PART FTP command The following data structure is used for the RETR_PART FTP command. Table 4- 8 FTP_FILENAME_PART Parameter Type Range of values Meaning / remarks InterfaceID HW_ANY Module start address When you call an instruction, you transfer the module start address of the CP in the LADDR parameter.

  • Page 54: Output Parameters And Status Information Ftp_Cmd

    Configuration, programming 4.7 FTP communication Parameter Type Range of values Meaning / remarks DataBlockNumber UINT The data block specified here contains the file DB to be read / written. LenFilename UINT 0...1000 The "LenFilename" parameter for specifying the total length of the file name is not evaluated.
  • Page 55 Configuration, programming 4.7 FTP communication Evaluating status codes Note Evaluation • Evaluation for BUSY = 0 Do not evaluate the status displays until BUSY = 0. • Status 8Fxx For entries coded with status 8Fxx , refer to the information in the STEP 7 Standard and System Functions reference manual.
  • Page 56 Configuration, programming 4.7 FTP communication DONE ERROR STATUS Meaning 8414 Error sending data 8415 Specified CMD (command type) was rejected by the client. 8416 Connection was closed by the FTP server. 8418 Error in the user data. Possible causes: File name is empty. •...
  • Page 57 Configuration, programming 4.7 FTP communication DONE ERROR STATUS Meaning 8476 Nothing was received from the FTP server. In the current status, an incorrect response must be assumed. 8477 The specified "Crypto engine" (cryptographic module) was not found. 8478 The attempt to set the selected SSL "Crypto engine" as the default failed.

  • Page 58: Structure Of The Data Block (File Db) For Ftp Client Operation

    Configuration, programming 4.7 FTP communication 4.7.2.5 Structure of the data block (file DB) for FTP client operation How it works To transfer data with FTP, create data blocks (file DBs) on the CPU of your S7 station. These data blocks must have certain structure to allow them to be handled as transferable files by the FTP services.
  • Page 59 Configuration, programming 4.7 FTP communication File DB header for FTP client mode The file DB header described here is identical to the file DB header described for server mode. Parameter Type Value / meaning Supply EXIST BOOL The EXIST bit indicates whether The DELETE FTP command sets the user data area contains valid EXIST=0.
  • Page 60 Configuration, programming 4.7 FTP communication Parameter Type Value / meaning Supply WRITEACCESS BOOL During the configuration of the DB, the bit 0: The user program has write • is set to an initialization value. access rights for the file DBs Recommendation: on the S7 CPU.

  • Page 61: Security

    Configuration, programming 4.8 Security Security You will find an overview of the range and use of the security functions in section Industrial Ethernet Security (Page 14). For the configuration limits of the security functions refer to the section Characteristics security (Page 18). To be able to configure the security functions, you need to create a security user;...
  • Page 62 Configuration, programming 4.8 Security data, it transports its own network packets and therefore operates independent of the rest of this network. ● VPN allows communication of the VPN partners with the assigned network. ● VPN is based on tunnel technology, can be individually configured, is customer-specific and is self-contained.

  • Page 63: Creating Vpn Tunnel Communication Between S7-1500 Stations

    Configuration, programming 4.8 Security 4.8.2.1 Creating VPN tunnel communication between S7-1500 stations Requirements To create a VPN tunnel between two S7-1500 stations, the following requirements must be met: ● Two S7-1500 stations have been configured. ● Participating CP 1543-1 are configured with a firmware version ≥ V1.1. ●...
  • Page 64 Configuration, programming 4.8 Security "Activate security features" option enabled ● After logging on, you must enable the "Activate security features" option for both CPs. The security functions are now available to you for both CPs. Creating the VPN group and assigning security modules Note Current date and current time of day on the security modules When using secure communication (for example HTTPS, VPN...), make sure that the...

  • Page 65: Establishment Of Vpn Tunnel Communication Between The Cp And Scalance M

    Configuration, programming 4.8 Security 4.8.2.2 Establishment of VPN tunnel communication between the CP and SCALANCE M Setting up VPN tunnel communication between the CP and SCALANCE M is essentially the same as described in Procedure for S7-1500 stations (Page 63). VPN tunnel communication will only be established if you have enabled the "Perfect Forward Secrecy"...

  • Page 66: Firewall

    Configuration, programming 4.8 Security This is the case in the following typical configuration: VPN subscriber (active) ⇔ gateway (dyn. IP address) ⇔ Internet ⇔ gateway (fixed IP address) ⇔ CP (passive) Configure the permission for VPN connection establishment for the CP as a passive subscriber as follows: 1.

  • Page 67: Firewall Settings For Connections Via A Vpn Tunnel

    Configuration, programming 4.8 Security 4.8.3.4 Firewall settings for connections via a VPN tunnel IP rules in advanced firewall mode If you have configured connections between CPs, note the following setting if you operate the CPs in advanced firewall mode. In the parameter group "Security > Firewall > IP rules" select the setting "Accept" for tunnel connections for both CPs.

  • Page 68: Online Security Diagnostics Via Port 8448

    Configuration, programming 4.9 Program blocks for OUC 4.8.4.2 Online security diagnostics via port 8448 Security diagnostics via port 8448 Requirement: Access to the Web server of the CP is activated via HTTPS. If you want to perform security diagnostics in STEP 7 Professional, follow the steps below: 1.
  • Page 69 Configuration, programming 4.9 Program blocks for OUC Supported program blocks for OUC The following instructions in the specified minimum version are available for programming Open User Communication: ● TSEND_C V3.1 / TRCV_C V3.1 Compact blocks for connection establishment/termination and for sending and receiving data ●...
  • Page 70 Configuration, programming 4.9 Program blocks for OUC manually in the declaration table of block instead of selecting an entry from the "Data type" drop-down list. The corresponding SDT is then created with its parameters. The following SDTs can be used. ●...

  • Page 71: Diagnostics And Upkeep

    Diagnostics and upkeep Diagnostics options You have the following diagnostics options available for the module: LEDs of the module For information on the LED displays, refer to the section LEDs (Page 21). STEP 7: The "Diagnostics" tab in the Inspector window If your engineering station is connected to the module via Ethernet, information on the connection status of the ES with the module can be found here.

  • Page 72: Connect Online

    Diagnostics and upkeep 5.2 Connect online Functions You can run the following functions here: ● Firmware update For a description, see section Update firmware (Page 75). ● Assign IP address ● Assign PROFINET device name ● Save service data STEP 7: Online connection Establish the online connection to the module via the "Connect online"...

  • Page 73: Diagnostics With Snmp

    The information on the properties of SNMP-compliant devices is entered in MIB files (MIB = Management Information Base). You will find detailed information on SNMP and the Siemens Automation MIB in the manual "Diagnostics and Configuration with SNMP" that you will find on the Internet: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15392/man)
  • Page 74 – UDP – SNMP ● LLDP MIB ● Siemens Automation MIB Note the rights for writing to the MIB objects, see the next section (SNMPv3). Supported MIB objects in SNMPv3 If SNMPv3 is enabled, the CP returns the contents of the following MIB objects: ●...

  • Page 75: Update Firmware

    Diagnostics and upkeep 5.4 Update firmware ● LLDP MIB ● Siemens Automation MIB Note that write access is permitted only for the following MIB objects of the "System" group: – sysContact – sysLocation – sysName A set sysName is sent as the host name using DHCP option 12 to the DHCP server to register with a DNS server.
  • Page 76 Diagnostics and upkeep 5.4 Update firmware There are different ways of loading a new firmware file on the CP: ● Online functions of STEP 7 via Ethernet ● Loading the firmware file into the CPU from an SD card Note SD card only for firmware file For the firmware file, you need a SIMATIC SD memory card, for example (article numbers):...
  • Page 77 Diagnostics and upkeep 5.4 Update firmware 6. Connect using the "Connect" button. The "Connect online" wizard guides you through the remaining steps in installation. 7. Select the CPU in the network view and select the "Online & Diagnostics" shortcut menu (right-click).

  • Page 78: Replacing A Module Without A Programming Device

    Diagnostics and upkeep 5.5 Replacing a module without a programming device Replacing a module without a programming device Configuration data when swapping modules The configuration data of the CP is stored on the CPU. This makes it possible to replace this module with a module of the same type (identical article number) without a PG.

  • Page 79: Technical Specifications

    Technical specifications Technical specifications of the CP Note the information in the System description of SIMATIC S7-1500 (Page 9). In addition to the information in the system description, the following technical specifications apply to the module. Technical specifications - CP 1543-1 Product name CP 1543-1 Article number...

  • Page 80: Pinout Of The Ethernet Interface

    Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180 • Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet • See also Siemens Mall: (https://mall.industry.siemens.com) Permitted cable lengths - Gigabit Ethernet Permitted cable lengths - Gigabit Alternative combinations Ethernet 0 ...

  • Page 81: Approvals

    The approvals for shipbuilding are an exception to this. Certificates for shipbuilding and national approvals The device certificates for shipbuilding and special national approvals can be found in Siemens Industry Online Support on the Internet: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15340/cert) EC declaration of conformity...
  • Page 82 Approvals You will find the EC Declaration of Conformity on the Internet at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15340/cert) The current versions of the standards can be seen in the EC Declaration of Conformity and in the certificates. IECEx The product meet the requirements of explosion protection according to IECEx.
  • Page 83 ● On the SIMATIC NET Manual Collection DVD under "All documents" >"Use of subassemblies/modules in a Zone 2 Hazardous Area" ● On the Internet at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/view/78381013) The product meets the requirements of the EC Directive 2014/30/EU "Electromagnetic Compatibility" (EMC directive).
  • Page 84 Approvals c(UL)us Applied standards: ● Underwriters Laboratories, Inc.: UL 61010-1 (Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use - Part 1: General Requirements) ● IEC/UL 61010-2-201 (Safety requirements for electrical equipment for measurement, control and laboratory use. Particular requirements for control equipment) ●...
  • Page 85 SIMATIC NET products are regularly submitted to the relevant authorities and approval centers for approvals relating to specific markets and applications. If you require a list of the current approvals for individual devices, consult your Siemens contact or check the Internet pages of Siemens Industry Online Support: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15340/cert)
  • Page 86 Approvals CP 1543-1 Operating Instructions, 12/2019, C79000-G8976-C289-08...

  • Page 87: Index

    Index FTP, 35 Response if the reference to the FTP job block is missing, 54 FTP (FTP client), 15 Autocrossing mechanism, 35 FTP client Autosensing, 35 Configuration limits, 18 FTP server Configuration limits, 18 FTP_CMD, 45 Cell protection concept Block execution time, 18 VPN, 62 FTPS, 14 Commissioning...
  • Page 88 Index ISO-on-TCP connections, 16 Recycling, 6 RUN → STOP, 29 LED display, 21 Logging, 14 S5/S7 addressing mode, 14 S7 communication, 11 S7 connections, 11, 15 MAC address, 3, 12 Number of freely usable, 17 Manual Collection, 10 Safety notices, 25 MIB, 73 Security diagnostics, 68 Multicast...
  • Page 89 Index VPN, (Virtual Private Network) Areas of application, 62 Cell protection concept, 62 Web server, 13 CP 1543-1 Operating Instructions, 12/2019, C79000-G8976-C289-08...
  • Page 90 Index CP 1543-1 Operating Instructions, 12/2019, C79000-G8976-C289-08...
