- Page 1 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS SP1425 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS ...
-
Page 2: Consumables And Replacement Cycles
HINT Only use the specified consumables. To purchase the consumables, contact your FUJITSU scanner dealer or an authorized FUJITSU scanner service provider. ... - Page 3 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Replacing the Pad Unit Replace the Pad Unit in the following procedure. 1. Turn off the scanner and wait for at least 15 minutes. 2. Unplug the power cable 3. Remove all documents from the ADF paper chute (feeder) 4. Open the ADF cover 5. Remove the Pad Unit Squeeze both ends of the pad unit and pull it out in the direction of the arrow. CG00002 ‐ 295501 ...
- Page 4 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Attach a new Pad Unit. Place the pad unit in its original position and push the right and left catches into slots . 7. Close the ADF cover 8. Plug in the power cable and turn on the scanner 9. Reset the sheet counter in the Software Operation Panel. CG00002 ‐ 295501 ...
- Page 5 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Replacing the Pick Roller Unit 5. Remove the Pick Roller Unit. Replace the Pick Roller Unit in the a. Rotate the bushing until it clicks in the following procedure. direction of the arrow. 1. Turn off the scanner and wait for at least 15 minutes. 2. Unplug the power cable. 3. Remove all documents from the ADF paper chute (feeder) 4. Open the ADF cover b. Move it to the right while holding the bushing, and remove it towards you. CG00002 ‐ 295501 ...
- Page 6 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS 6. Attach a new pick roller unit. 7. Close the ADF cover. a. Insert the end of the shaft into the slot while holding the bushing, and insert the other end to the left. 8. Plug in the power cable and turn on the scanner. 9. Reset the sheet counter in the Software Operation Panel. b. Rotate the bushing until it clicks in the direction of the arrow. CG00002 ‐ 295501 ...
- Page 7 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Software Operation Panel The Software Operation Panel is installed together with the PaperStream IP driver. This application allows you to configure various settings such as the operation of the scanner and management of the consumables. 1. Confirm that the scanner is connected to the computer, then turn on the scanner. 2. Display the [Software Operation Panel] Window *Windows Vista/Windows 7/Windows Server 2008 Click [Start] menu [All Programs] [SP Series] [Software Operation Panel]. *Windows Server 2012/Windows 8 Right‐click the Start screen, and select [Software Operation Panel] under [SP Series] *Windows 2012R2/Windows 8.1 Click [ ] on the lower left side of the start screen and select [Software Operation Panel] under [SP Series] *Windows 10 Click [Start] menu [All Apps] [SP Series] [Software Operation Panel]. CG00002 ‐ 295501 ...
- Page 8 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS The Software Operation Panel icon is displayed in the menu that appears when you click in the notification area. To have the Software Operation Panel always displayed in the notification area, drag the icon and drop it in onto the notification area. The notification area is located at the far right of the taskbar. CG00002 ‐ 295501 ...
- Page 9 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Checking and resetting sheet counters Checking the sheet counters The status of each consumable can be viewed to determine when to replace the consumables. When a consumable needs to be replaced soon, the background color of the counter turns light yellow or yellow when the sheet count for each consumable reaches the following. In this window, you can check the following items: 1. Start up the Software Operation Panel. 2. From the listing on the left, select [Device Setting] CG00002 ‐ 295501 ...
- Page 10 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Resetting the sheet counters When you have replaced a consumable part, reset the counter by using the following procedure: 1. Click the [clear] button for the replaced consumable. The counter is reset to 0. 2. Click the [OK] button A confirmation message appears. 3. Click the [OK] button The settings are saved. CG00002 ‐ 295501 ...
-
Page 11: Cleaning Materials And Locations That Require Cleaning
SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Cleaning Materials and Locations that Require Cleaning Cleaning Materials Attention In order to use the cleaning materials safely and correctly, read the precautions on each product thoroughly. For more information about the cleaning materials, contact your FUJITSU scanner dealer or an authorized Fujitsu scanner service provider. CG00002 ‐ 295501 ... - Page 12 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Location and Frequency Attention Cleaning cycles may vary depending on the condition of the documents. Also, cleaning must be performed more frequently when the following types of documents are scanned: • Smooth – faced documents such as coated paper • Documents with printed text/graphics that almost cover the entire surface • Documents containing a large amount of calcium carbonate • Documents written in lead pencil • Documents on which the toner is not sufficiently fused CG00002 ‐ 295501 ...
-
Page 13: Cleaning The Outside
SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Cleaning the Outside The outside of the scanner, including the paper chute (feeder) and the stacker, should be cleaned with either a piece of dry cloth, a cloth moistened with Cleaner F1/mild detergent, or a sheet of Cleaning Wipe. Attention To avoid deformation and discoloration, never use paint thinner or any other organic solvents. Be careful not to let moisture or water inside the scanner during cleaning. It may take a long time to dry if an excessive amount of Cleaner F1/mild detergent is used. Use it in small quantity. Wipe off the cleaner completely to leave no residue on the cleaned parts. CG00002 ‐ 295501 ... -
Page 14: Cleaning The Inside
SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Cleaning the Inside Cleaning the ADF (with Cleaning Paper) The ADF can be cleaned with a sheet of Cleaning Paper moistened with Cleaner F1. As the scanner continues to feed the documents, paper dust will accumulate inside the ADF and may cause scanning errors. Cleaning should be performed approximately every 3,000 sheets scanned. Note that this guideline varies depending on the types of documents you scan For instance, it may be necessary to clean the scanner more frequently when you scan documents on which the toner is not sufficiently fused. Attention • Do not use water or mild detergent to clean the ADF. • It may take a long time to dry if an excessive amount of Cleaner F1 is used. Use it in small quantity. 1. Turn on the scanner 2. Spray the Cleaning Paper with Cleaner F1. 3. Lift up the stopper 4. Load the Cleaning Paper in the ADF paper chute (feeder). CG00002 ‐ 295501 ... - Page 15 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS 5. Adjust the side guides to the width of the Cleaning Paper. Do not leave space between the side guides and the Cleaning Paper. Otherwise, the Cleaning Paper may be fed skewed. 6. Start an application available for scanning and scan the Cleaning Paper. The Cleaning Paper is fed and ejected onto the stacker. CG00002 ‐ 295501 ...
- Page 16 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Cleaning the ADF (with cloth) The ADF can be cleaned with a piece of cloth moistened with Cleaner F1, or a sheet of Cleaning Wipe. As the scanner continues to feed the documents, paper dust will accumulate inside the ADF and it may cause scanning errors. Cleaning should be performed approximately every 3,000 sheets scanned. Note that this guideline varies depending on the types of documents you scan. For instance, it may be necessary to clean the scanner more frequently when you scan documents on which the toner is not sufficiently fused. Attention • Do not use water or mild detergent to clean the ADF. • It may take a long time to dry if an excessive amount of Cleaner F1 is used. Use it in small quantity. 1. Turn off the scanner and wait for at least 15 minutes. 2. Unplug the power cable. 3. Open the ADF. CG00002 ‐ 295501 ...
- Page 17 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS 4. Clean the following locations with a cloth moistened with Cleaner F1 or a sheet of Cleaning Wipe. CG00002 ‐ 295501 ...
- Page 18 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Pad Unit (X1) Gently wipe the dust off the surface of the rubber pad. Ultrasonic Sensor (X 2) Gently wipe the dirt and dust off the surface of the ultrasonic sensors. If it is difficult to clean, use a cotton swab. Glass (X 2) Gently wipe the dirt and dust off the surface of the glass sections. Pick Roller Unit (X 1)/Plastic Idler Roller (X 4)/Feed Roller (X 4)/Eject Roller (X 2)/Rubber Idler Roller (X 2) Gently wipe off any dirt or dust as you rotate the roller manually, taking care not to damage the roller surface. In particular, if black foreign matter gets on the rollers, make sure that they are cleaned properly. Attention • Vertical streaks may appear on the scanned image when the glass sections are dirty. • When cleaning, be careful not to damage the following parts with your hands, a cloth, or a Cleaning Wipe. ‐ Pick spring (metal part) ‐ Mylar sheet ‐ Document sensor ‐ Anti‐static brush ...
- Page 19 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS 5. Close the ADF. Attention Confirm that the ADF is closed properly. Otherwise, the document may not be fed into the ADF. 6. Plug in the power cable, and turn on the scanner. CG00002 ‐ 295501 ...
- Page 20 SP1425 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Cleaning the Flatbed The Flatbed can be cleaned with a piece of cloth moistened with Cleaner F1, or a sheet of Cleaning Wipe. 1. Open the document cover. 2. Clean the document pad and the document bed with a cloth moistened with Cleaner F1, or a sheet of Cleaning Wipe. Attention Be careful not to let the cleaner in between the document bed and the plastic frame. 3. Wait for the cleaned parts to dry. 4. Close the document cover. CG00002 ‐ 295501 ...
