Product Information
Connection set
14
13
12
11
10
Fig. 4 Connection set
No. Component
1 Solar hose (TSS150/300: 3.3 m / TSS200: 2.9 m) 1
2 Return pipe bracket
3 Cap ½"
4 Gasket 24 × 17
5 Angled ferrule G1xD21
6 Clamping washer
7 Nut G1
8 Solar hose, 97 mm (TSS300)
9 Hose clip TSS150/200
Hose clip TSS300
10 Solar hose, 55 mm with plug and hose clip
11 Solar pressure relief valve 2.5 bar
12 Potable water pressure relief valve 8 bar
13 Storage tank connection pipe, bent
14 Storage tank connection pipe, straight
1) TSS200: 2
2) TSS200: 0
Table 4 Connection set
Memory
1
9
8
Fig. 5 Storage tank for thermosiphon system
6
1
9 8
Number
1
1
2
1
1
1
2
4
8
2
1
1
1)
1
2)
1
2
3
4
5
7 6
0010014993-01
2 3
7 6
No. Component
1 Connection G½for solar pressure relief valve
2 Filler Solar G½
3 Integrated nuts for handle accessories
4 Data plate position
5 Handhole cover
6 Cold water connection G½
7 Solar return connection G¾
8 Domestic hot water connection G½
9 Solar flow connection G¾
Table 5 Storage tank for thermosiphon system
Collector
1
3
2
Fig. 6 Collector
No. Component
1 Flow connection
2 Return connection
3 Data plate position
Table 6 Collector
4
1
5
0010015800-01
1
2
0010014994-01
