- Page 1 OWNER’S MANUAL KARAOKE MINI Hi-Fi System Please read this manual carefully before operating your set and retain it for future reference. MDT356K(MDT356K, MDS356V, MDS356W) P/NO : MFL67233824 MDT356-A5U-ARUSLL-ENG.indd 1 MDT356-A5U-ARUSLL-ENG.indd 1 11. 04. 05 11. 04. 05 6:00 6:00...
-
Page 2: Getting Started
Getting Started Safety Information CAUTION CAUTION: This product employs a Laser System. RISK OF ELECTRIC SHOCK To ensure proper use of this product, please read DO NOT OPEN this owner’s manual carefully and retain it for future CAUTION: TO REDUCE THE RISK OF ELECTRIC reference. - Page 3 This device is equipped with a portable battery or You have to set the disc format option to [Mastered] accumulator. in order to make the discs compatible with the LG players when formatting rewritable discs. When Safety way to remove the battery or the...
-
Page 4: Table Of Contents
Table of Contents Operating Table of Contents Basic Operations – Disc/USB Operations Other Operations Getting Started – Displaying Disc Information on-screen – To display the DVD Menu Safety Information – To display the DVD title Unique Features – Selecting a subtitle language Accessories –... - Page 5 Table of Contents Troubleshooting Troubleshooting Appendix Specifi cations Maintenance – Handling the Unit – Notes on Discs Trademarks and Licenses Language Codes Area Codes MDT356-A5U-ARUSLL-ENG.indd 5 MDT356-A5U-ARUSLL-ENG.indd 5 11. 04. 05 11. 04. 05 6:00 6:00...
-
Page 6: Unique Features
Getting Started Unique Features Introduction USB Direct Recording Playable Discs Records music to your USB device. This unit plays DVD±R/RW and CD-R/RW that contains audio titles, DivX, MP3, WMA and/or AUTO DJ JPEG fi les. Some DVD±RW/DVD±R or CD-RW/ CD-R cannot be played on this unit due to the Auto DJ blends the end of one song into the recording quality or physical condition of the disc, beginning of another for seamless playback. -
Page 7: Symbol Used In This Manual
Getting Started Symbol Used in this Manual Playable fi le DVD and fi nalized DVD±R/RW Requirement DivX fi les MP3/WMA fi les, Audio CDs JPG fi les MP3/WMA music fi le requirement Regional Codes MP3/ WMA fi le compatibility with this unit is limited This unit has a regional code printed on the rear of as follows : the unit. -
Page 8: Usb Device Requirement
Getting Started USB device requirement DivX fi le requirement Devices which require additional program DivX fi le compatibility with this unit is limited as installation when you have connected it to a follows : computer, are not supported. Available resolution: up to 800 x 600 (W x H) pixels. -
Page 9: Remote Control
EQ ($) : You can choose sound PRESET (W/S) : Selects impressions. programme of Radio. LG EQ (9) : Select a Natural or TUN. -/+(A/D) : Tunes in the Local Specialization equalizer desired radio station. eff ect by LG EQ. - Page 10 TV. (LG TV only) Controlling the TV. You can control the sound level, input source, and power switching of LG TVs as well. Hold POWER (TV) and press PR/CH (+/–) button repeatedly until the TV turns on or off .
-
Page 11: Rear Panel
Getting Started Rear panel a VIDEO OUT connector b ANTENNA (FM, AM) c AUX IN connector d OUTPUT (COMPONENT VIDEO OUT (PROGRESSIVE SCAN)) connector e SPEAKERS terminal f Cooling fan MDT356-A5U-ARUSLL-ENG.indd 11 MDT356-A5U-ARUSLL-ENG.indd 11 11. 04. 05 11. 04. 05 6:00 6:00... -
Page 12: Front Panel
Getting Started Front panel MDT356-A5U-ARUSLL-ENG.indd 12 MDT356-A5U-ARUSLL-ENG.indd 12 11. 04. 05 11. 04. 05 6:00 6:00... - Page 13 You can choose sound impressions. t STOP g LG EQ u R (Record) Select a Natural or Local Specialization Recording. equalizer eff ect by LG EQ. v USB port h USER EQ Controls sound register. w < Headphone jack i BASS BLAST...
-
Page 14: Connecting
Connecting Connecting to Antenna Connection speakers Connect the supplied FM/ AM antenna for listening to the radio. Attaching the speakers to the unit To connect the cable to the unit, press each plastic fi nger pad to open the connection terminals on the unit. -
Page 15: Connections To Your Tv
Connecting Video Connection Connections to Your Connect the VIDEO OUT jack on the unit to the video in jack on the TV using a video cable. Make one of the following connections, depending on the capabilities of your existing equipment. Note Depending on your TV and other equipment you wish to connect, there are... -
Page 16: Component Video Connection
Connecting Component Video Connection Optional Equipment Connect the COMPONENT VIDEO OUT Connection (PROGRESSIVE SCAN) jacks on the unit to the corresponding input jacks on the TV using component cables. You can hear the sound through the system’s AUX In Connection speakers. -
Page 17: Usb Connection
Connecting USB Connection Adjust the Setup Connect the USB port of USB Memory (or MP3 settings player, etc.) to the USB port on the front of the unit. By using the Setup menu, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup menu, among other things. -
Page 18: To Display And Exit The Setup Menu
Connecting To display and exit the Setup LANGUAGE Menu Menu Language 1. Select the DVD/CD or USB function by pressing Select a language for the Setup menu and then on FUNCTION. screen display. 2. Press SETUP. Displays the [SETUP] Menu. Disc Audio/Disc Subtitle/Disc Menu 3. -
Page 19: Display
Connecting DISPLAY AUDIO TV Aspect 2.1 Speaker Setup Select which screen aspect to use based on the Make the following settings for the built-in 2.1 shape of your TV screen. channel surrounds decoder. 1. Press SETUP. [4:3] 2. Use W/S to select AUDIO menu and then Select when a standard 4:3 TV is connected. -
Page 20: Lock (Parental Control)
Connecting DRC (Dynamic Range Control) Rating Make the sound clear when the volume is turned Blocks playback of rated DVDs based on their down (Dolby Digital only). Set to [On] for this eff ect. contents. Not all discs are rated. 1. -
Page 21: Others
Connecting Note Area Code DVD, DVD Karaoke discs with more than 2 Enter the code of the area whose standards were tracks are available discs for this function. used to rate the DVD video disc, based on the list When you watch movies, “off ” the Semi on page 39. -
Page 22: Operating
Operating Basic Operations Do this Stop Press Z. Disc/USB Operations Playback Press d. 1. Insert the disc by opening the Disc tray or Pause During playback, press M. connect the USB device to the USB port. Press M repeatedly to play title Frame-by-Frame 2. -
Page 23: Other Operations
Operating To display the DVD Menu Other Operations When you play a DVD which contains several menu, Displaying Disc Information you can select the menu you want using the Menu. 1. Press MENU. on-screen The disc’s menu appears. You can display various information about the disc 2. -
Page 24: Starting Play From Selected Time
Operating Starting play from selected Creating your own program time You can play the contents of a disc in the order you want by arranging the order of the songs on To start playing at any chosen time on the fi le or the disc. -
Page 25: Viewing A Photo Fi Le As A Slide Show
Operating Viewing a PHOTO fi le as a Using your player as an alarm slide show clock 1. Turn the power on. 1. Highlight the fi le (not folder) which you like 2. Press TIMER. Each functions fl ashes. beginning slide show. 3. -
Page 26: Sleep Timer Setting
Operating Sleep Timer Setting Turning off the sound temporarily Press SLEEP one or more times to select delay time between 10 and 180 minutes, after which the unit Press MUTE to mute your unit. turn off . You can mute your unit in order, for example, to To cancel the sleep function, press SLEEP answer the telephone, appears the “... -
Page 27: Auto Dj Playback
Operating AUTO DJ playback Using Microphone 1. Connect your microphone to the MIC 1, 2. Auto DJ blends the end of one song into the 2. Play the music you want. beginning of another for seamless playback. It 3. Sing along with the accompaniment. Adjust the equalizes volume across tracks for uninterrupted microphone volume by pressing playback. -
Page 28: Radio Operations
Operating Presetting the Radio Stations Radio Operations You can preset 50 stations for FM and AM. Before tuning, make sure that you have turned Be sure that both FM and AM aerials are connected. down the volume. (Refer to the page 14) 1. -
Page 29: Sound Adjustment
LG EQ/EQ You can not choose the VIRTUAL option, You can change the LG EQ/EQ using A/D arrow when the MIC is connected to the unit. key while the sound eff ect information is displayed... -
Page 30: Advanced Operations
Operating Note Advanced Operations You can check the recording percentage rate for the USB record on the display window during the recording. (MP3/ WMA Listening to music from your CD Only) During recording MP3/ WMA, there is no external device sound. -
Page 31: Karaoke Basic Playback
Operating Karaoke Basic Playback To adjust ECHO Volume You can give an echo eff ect to the sound from the 1. Turn on the power of TV and unit. microphones. 2. Open the disc tray and insert supplied karaoke Press the ECHO VOL (+/-) on the remote control disc by using OPEN/CLOSE. - Page 32 Operating Using Microphone Reserving a song 1. Connect your microphone to the MIC1/ MIC 2 When you want to make a reservation of next Jacks. melody, you can enjoy the reservation without “MIC IN” will be shown in the display window. waiting.
-
Page 33: Karaoke Menu Playback
Operating Karaoke MENU Playback 1. To move to the main menu by using MENU The main menu appears on the screen. Select initial of song title or entire title. 3. RANDOM You can enjoy songs randomly. 4. CHALLENGE 2. Select a desired option on the menu by using You can enjoy a song game dividing by two teams W/S/A/D and ENTER (b). -
Page 34: Troubleshooting
Troubleshooting Troubleshooting Problem Cause & Correction The power cord is not plugged in. Plug in the power cord. No Power. The TV is not set to receive the DVD signal. Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen. No picture. -
Page 35: Appendix
Appendix Specifi cations General Power supply Refer to main label Power consumption Refer to main label Net Weight 5.2 kg External dimensions (W x H x D) 272 x 336 x 352 mm 5 °C to 35 °C (41 °F to 95 °F) Operating conditions Temperature Operation status: Horizontal Operating humidity... - Page 36 Appendix Front Speakers Type 2 Way 2 Speaker Impedance 4 Ω Rated Input Power 100 W Max. Input Power 200 W Net Dimensions (WxHxD) 222 x 344 x 261 mm Net Weight(1EA) 3.4 kg Passive Subwoofer Type 1 Way 1 Speaker Impedance 3 Ω...
-
Page 37: Maintenance
Appendix Notes on Discs Maintenance Handling Discs Handling the Unit Never stick paper or tape on the disc. Storing Discs When shipping the unit After playing, store the disc in its case. Do not Please save the original shipping carton and expose the disc to direct sunlight or sources of heat packing materials. -
Page 38: Language Codes
Appendix Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Afar 6565 French 7082 Lithuanian 7684 Sindhi 8368 Afrikaans 6570 Frisian 7089 Macedonian... -
Page 39: Area Codes
Appendix Area Codes Choose an area code from this list. Area Code Area Code Area Code Area Code Afghanistan Fiji Monaco Singapore Argentina Finland Mongolia Slovak Republic Australia France Morocco Slovenia Austria Germany Nepal South Africa Belgium Great Britain Netherlands South Korea Bhutan Greece... - Page 40 Импортер LG Electronics RUS Адрес импортера 143160 Российская Федерация, Московская область, Рузский район, сельское поселение Дороховское, 86 км. Минского шоссе, д.9 Адрес производителя: Юсан Технолоджи (Шэньчжэнь) Лтд. Г уандун, Китайская Народная республика, Хаои Технолоджи парк, Нан Хуан Роад, Шаяинг Вест, Баоан...
