Summary of Contents for LG PS-M550 Series
- Page 1 PS-M550 Series 사용 전에 「안전을 위한 주의사항」 을 반드시 읽고 정확하게 사용하세요. 사용자의 안전을 지키고 재산상의 손해 등을 막기 위한 내용입니다. 사용설명서에 제품보증서가 포함되어 있습니다. 사용설명서를 읽고 난 후 사용하는 사람이 언제라도 볼 수 있는 장소에 보관하세요. P/No.:MFL31040009...
-
Page 2: The Advantages Are
- Air is first cleaned by a washable HEPA filter and then sterilized by the NPI (Nano Plasma Ion) technology. Only the LG air purifier can clean and sterilize air in this manner. Easy to Use HEPA filter system - Filter cleaning is easy with LG's convenient filter separation system. -
Page 3: Table Of Contents
Table of Contents Important Safety Issues Care and Cleaning ❏ The advantages are ............34 ❏ Exterior and Dust Sensors Cleaning Method .....59 ❏ Safety Precautions ............36~45 ❏ Filter Cleaning ..............60~61 ❏ Installation ................46 ❏ Maintenance...............62 ❏ How to Use.................47 ❏ Troubleshooting Before Calling for Service....63~64 ❏... -
Page 4: Safety Precautions
Safety Precautions For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or death. Warning / Caution This symbol will alert you to any product detail or operation that could lead to a safety hazard if the instructions in the manual are not followed properly. - Page 5 Safety Precautions Warning Installation If the power cord becomes worn Do not plug other appliances Do not remove the round or damaged, the cord should into the same outlet. grounding prong from the plug. only be replaced by a qualified Overloading of any outlet can service technician using cause a fire or create an...
- Page 6 Safety Precautions Do not use this or any appliance If you hear abnormal sounds or Make sure the Air Purifier and near flammable gases or liquids or smell smoke, immediately unplug cord is positioned where it does other combustibles, such as your Air Purifier and have the unit not create a tripping hazard.
- Page 7 Safety Precautions Operation Make sure the power cord Do not operate with wet Do not operate your Air Never pull the power plug is plugged firmly and hands. Purifier with a damaged away from outlet by completely into the power cord. A damaged pulling on the wire.
- Page 8 Safety Precautions Keep objects such as curtains Do not run power cords under Do not place the power cord or away from the air openings in the carpeting or other coverings which Air Purifier near a heater, unit. The openings must be free could fray the cord and expose the radiator, or other heat source.
- Page 9 Safety Precautions Do not move the air purifier by Do not use the top of the unit for Other than cleaning and pulling or pushing on the front storage. Keep liquids away from replacing the filters, there are no panel. the top of the unit.
- Page 10 Safety Precautions Caution Installation When using the unit, maintain a Avoid installing the Air Purifier in Never use your Air Purifier to distance of at least 3 feet direct sunlight and never operate remove toxic gasses (such as between the Air Purifier and any the unit near or around open Carbon Monoxide, Natural or Television or audio product.
- Page 11 Safety Precautions Do not use except AC 120V. This unit is not designed to Your air purifier is not designed remove combustion by-products It may cause fire or electrical to be used in moving vehicles such as those produced by open shock.
- Page 12 Safety Precautions Operation To prevent damage to plants Clean with a soft cloth and Do not start or stop Always turn off and unplug or injury to pets, make sure mild detergent. Filter operation by plugging in the air purifier when it will they are not exposed to direct not be used for extended should be cleaned once a...
- Page 13 Safety Precautions If a humidifier is used in the Do not use your Air Purifier to Do not open the front panel same room as your Air Purifier, remove food odors while cooking. during the operation of the keep the humidifier a safe Airborne oils that are released product.
-
Page 14: Installation
Installation Refer to the Installation Instructions before using the air purifier. Places to Install 1. Plug power cord into its own dedicated properly grounded outlet. 2. Make sure the power cord is positioned where it does not cause a tripping hazard and will receive adequate ventilation. -
Page 15: How To Use
How to Use Cleaning the Air Purifier • The air filter should be cleaned on a regular basis. Depending on the air quality, more frequent cleaning may be required. The filter can be washed in warm water using a mild detergent. Allow the filter to completely dry before reinstalling. -
Page 16: Key Parts And Components
Key Parts and Components Mainframe Remote Control Receiver Dust Sensor Display Air Outlet Filter Case Safty Net: –The inside of air outlet Photo-Catalyst Handle Plasma Filter Power On/Off Button Pre-Filter Odor Sensor Filter Handle Controller Front Panel Power Plug Air Inlet Air Purifier... -
Page 17: Display And Controller
Key Parts and Components Display and controller Filter self-checking indicator Operation indicator Check the filter when indicated by the light. Dust/Odor indicator Purity level indicator Reflects how well air is moving Level reflects how well the air purifier is through the unit. cleaning the air. -
Page 18: Filters System
※ Allow the filter to dry completely before reinstalling. If not completely dried, it may cause the air purifier to malfunction or cause bad odors to be emitted during use. ※ A replacement filter (Anti-Allergic Filter) can be purchased at an LG service center. -
Page 19: Remote Controller
Key Parts and Components Remote Controller Power On/Off Turns the air purifier on and off Mode Fan speed button Set Fan speed Switches the operation speed, auto mode, sand mode and sleep timer. Off timer button Function selection button Adjust the timer delay time When turned on, the unit produces negative ions which can help sterilize the air. -
Page 20: Remote Controller Guide
• Remove batteries when the air purifier is stored for extended periods of time. • If controller fails to work after new batteries are installed, contact an LG service center for service. • If controller fails to work, replace the batteries. Always replace both batteries at the same time. Do not mix old and new batteries. -
Page 21: Operation Mode
Operation Mode Air Purifying Operation Purify Indoor Air 1⃞ Power ON/OFF Turns the air purifier on and off. Press once to turn on, again to turn it off. A confirmation tone will sound to indicate that the unit is powering on or turning off. The unit will also produce a tone when the unit is first plugged in. -
Page 22: Speed Mode
Operation Mode Speed mode User may manually adjust fan speed 1⃞ Power ON/OFF 2⃞ MODE switches allows the user to select the various modes of operation including auto fan and sleep, sandstorm and self timer modes. 3⃞ Fan Speed Adjusts the circulation fan speed between low, medium, high and turbo. -
Page 23: Yellow Sandstorm Mode
Operation Mode Yellow Sandstorm Mode Purifies indoor air even in extreme conditions such as a sandstorm 1⃞ Power ON/OFF 2⃞ Switch to sandstorm mode by pressing the mode button. The correct fan speed will automatically be selected by the unit. The consumer can increase the fan speed to the next highest level by depressing the fan speed button. -
Page 24: Additional Functions
Additional Functions Off timer mode function Automatically shuts down after a preset amount of time Example:shut down automatically after 3 hours 1⃞ Power ON/OFF 2⃞ Allows you to set a delay from 1 to 9 hours that will turn the air purifier off automatically. -
Page 25: Negative Ion / Sterilization Function
Additional Functions Negative ion / sterilization function In the Negative Ion mode, the unit generates and adds negative ions to the air stream. When in the sterilization mode, the negative ions will also remove bacteria from the air. 1⃞ Power ON/OFF 2⃞... -
Page 26: Filter Checking Function
Additional Functions Filter Checking Function May remind users to clean or replace the filter after use for a certain period. 1⃞ Filter self check light indicates to check filter. 2⃞ Power ON/OFF to shut the unit off. 3⃞ Open front panel to remove filter. Check filter, clean if necessary. (see page 60~61 to clean filter). -
Page 27: Exterior And Dust Sensors Cleaning Method
Exterior and Dust Sensors Cleaning Method Exterior Cleaning Method Wipe the exterior of the air purifier with a soft cloth with warm water and mild detergent. • Do not use harsh cleaners or very hot water. Do not wash in dishwasher. Caution •... -
Page 28: Filter Cleaning
Filter Cleaning • The prefilter should be cleaned on a monthly basis. • Check the filter when the filter indicator light is on. 1⃞ Turn unit off and unplug before cleaning. Grasp the grips on the front panel, pull forward to open. 2⃞... - Page 29 Filter Cleaning 5⃞ Separate filter case to remove the filter. 6⃞ HEPA and Deodorizing washable filter. Soak in warm water for an hour. Rinse. NOTE: The anti allergic filter should NOT be washed. Washing this filter will reduce its efficiency. Clean the washable HEPA filter and deodorization filter with warm water and rinse under running water.
-
Page 30: Maintenance
Maintenance 1⃞ Remove plug from grounded outlet. 2⃞ Clean and protect the air purifier's mainframe. Cover the air purifier when storing for an extended period of time. Clean with a soft cloth and mild detergent. Exterior case may scratch easily Air Purifier... -
Page 31: Troubleshooting Before Calling For Service
Troubleshooting Before Calling for Service When product goes wrong, before contacting the service center please confirm the following items. Problem Possible Cause Solutions Air Purifier will not start The air purifier plug is not completely inserted in the Make sure electrical plug is plugged completely into a live, ●... - Page 32 Dust sensor light is always on a high level. Sensor Indicator ● ● The LG air purifier is designed to detect pollutants in the air. Odor sensor level is on a high level. ● ● It may not be able to sense food odors. Steam particles from cooking may cause the sensor level to go up.
-
Page 33: Product Specification
Product Standards For the reason of enhancing product quality, this product exterior, design, specification may differ relatively. Model Number PS-M550 Series Power Supply 120 V, 60 Hz Room Capacity 45 sq. meters/146 sq ft. Product Weight 9.5 KG/21 lbs Product Size 16 (W) X 21.7 (H) X 9.9 (D) - Page 34 각종필터 구입방법 안내 및 SVC 직접구입 LG-Livart Co.Ltd 2110 S. Tubeway Ave, Commerce, CA 90040 구입상담 (323)887-7750 Service Center Information Address LG-Livart Co.Ltd 2110 S. Tubeway Ave, Commerce, CA 90040 Call (323)887-7750 Printed in Korea...
