- Page 1 PAVIRO End‑of‑line supervision module PVA‑1WEOL User manual...
-
Page 3: Table Of Contents
PAVIRO End-of-line supervision Table of contents | en module Table of contents Short information Installation Technical data Standards and compliancy Compatibility with older EOL modules Bosch Security Systems B.V. 2019-01 | V2 | F01U350870... -
Page 4: Short Information
The status LED on the module can be used to check the installation. For more information, refer to the user documentation for the IRIS-Net, Controller or Router. Parts included Quantity Component End-of-line supervision module Set of screws User manual 2019-01 | V2 | F01U350870 Bosch Security Systems B.V. -
Page 5: Installation
Connect the module to earth or ground. – Check the installation. Figure 2.1: End-of-line supervision module Item Description DIP switch S1 DIP switch S2 Status LED Connector (Speaker line + / Speaker line - / Earth) Bosch Security Systems B.V. 2019-01 | V2 | F01U350870... - Page 6 DIP switches S2 and S1 (see previous figure and following table). The module address allows for identification of the affected loudspeaker line in case an error occurred, such as an open-circuit. Module address DIP switch S2 DIP switch S1 0 (not connected) 2019-01 | V2 | F01U350870 Bosch Security Systems B.V.
- Page 7 PAVIRO End-of-line supervision Installation | en module Module address DIP switch S2 DIP switch S1 Reserved To activate the status LED for five minutes, Bosch Security Systems B.V. 2019-01 | V2 | F01U350870...
- Page 8 To make this connection, you can use: – a short wire to earth or ground near the installed module, – the cable shield, or – any free wire on the cable. 2019-01 | V2 | F01U350870 Bosch Security Systems B.V.
- Page 9 Module is ready. Rapid flashing (10 Hz), every 40 A valid command is being seconds received from the EOL Master. This indicates a good ground connection. Tab. 2.2: Status LED for checking installation Bosch Security Systems B.V. 2019-01 | V2 | F01U350870...
-
Page 10: Technical Data
3 MΩ Maximum Cg 2500 nF Number of modules Mechanical Product dimensions (Height x Width x 15 mm x 78 mm x 60 mm Depth) Net weight 30 g Environmental Operating temperature -5 °C to +45 °C 2019-01 | V2 | F01U350870 Bosch Security Systems B.V. - Page 11 Make sure the worst case situation does not exceed the maximum allowed capacitance. A capacitance calculator to check if the capacitance is in the safe zone, and an additional application note, can be downloaded from the Bosch website. Bosch Security Systems B.V. 2019-01 | V2 | F01U350870...
- Page 12 PAVIRO End-of-line supervision en | Technical data module Figure 3.1: Circuit diagram (R and C are caused by the loudspeaker installation, e.g. wire type, length) Figure 3.2: Wiring diagram C 2019-01 | V2 | F01U350870 Bosch Security Systems B.V.
-
Page 13: Standards And Compliancy
ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. – EN 54‑16 / ISO7240-16 - End-of-line supervision module tested in combination with a certified PAVIRO system. Bosch Security Systems B.V. 2019-01 | V2 | F01U350870... -
Page 14: Compatibility With Older Eol Modules
PVA-1WEOL - HW 1.1, FW 1.1 Minimum R 1.5 MΩ Maximum Cg 200 nF Number of modules PVA-1WEOL - HW 1.1, FW 1.2 Minimum R 1.5 MΩ Maximum Cg 800 nF Number of modules 2019-01 | V2 | F01U350870 Bosch Security Systems B.V. - Page 15 PAVIRO End-of-line supervision Compatibility with older EOL modules | module Bosch Security Systems B.V. 2019-01 | V2 | F01U350870...
- Page 16 PAVIRO End-of-line supervision | Compatibility with older EOL modules module 2019-01 | V2 | F01U350870 Bosch Security Systems B.V.
- Page 18 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2019...
