3.3 Transmitting data over UART

Now that all configuration and initialization is done, data can be transmitted via UART as shown in Code 11. For that, a
function which takes a buffer holding the data and the buffer length can be build, as shown in Code 11.
Code 11. UART data transmit function
void UartDataWrite(uint8_t* buffer,
uint32_t writeTimeout = UINT32_MAX;
UARTTransceiver_WriteData(&UartTransceiverInstance,buffer, bufferLength, writeTimeout);
}
The function simply calls
UartTransceiverInstance
operation.
It is recommended to wrap the writing function, since only the data buffer itself and the buffer length can vary.
An example on how to transmit data with it is shown in Code 12, please note that for a working data transmission a
secondary device using UART need to be attached to the Extension Bus of the XDK.
Code 12. UART writing example
void appInitSystem(void
// all other initialization and preparation code here
uint8_t buffer[] = "Hello";
uint32_t bufferLength = sizeof(buffer)/sizeof(uint8_t);
UartDataWrite(buffer,bufferLength);
}
Simply a buffer is declared within the string
UartDataWrite()
function
uint32_t
UARTTransceiver_WriteData()
variable holding all UART related information as well as a predefined timeout for the write
* CmdProcessorHandle,
Hello
. The size of this buffer is dynamically calculated and passed to the
to transmit the passed data.
bufferLength){
, which takes the passed buffer and buffer length and the
uint32_t param2){
