Operation
Status indicators
The status indicators will be shown depending on the operational
mode and the selected settings.
• Read the individual meanings on the status indicators in
"Table 2".
• Observe the different positions of the status indicators in
Figure B-26.
Fig.: B-26 The status indicators are located in the corners of the
indicator.
Symbol Name
00:00 Time
Internal battery
(Position "A")
Light (position "A")
00 km/h Speed
Compass
Zoom (Position "B") Displays map scale.
Range
(Position "B")
e-bike
rechargeable battery
Riding modes
Bluetooth
®
(Position "C")
Internet
(Position "C")
GPS
Table 2: Status indicators
Description
Displays the time
(determined by GPS).
Indicator for the remaining
(internal) rechargeable battery
power.
The light is activated.
Displays the speed.
Displays the direction "North".
Displays the projected remaining
range.
Displays the remaining recharge-
able battery power for the e-bike.
Displays the selected mode.
Indicator for an existing
Bluetooth connection.
®
Indicator for an existing
Wi-Fi connection.
Indicator for an existing
GPS connection.
