1 Warning Caution: • Pb free solder has a higher melting point that standard solder; Typically the melting point is 50 - 70 °F (30 - 40 °C) higher. Please use a soldering iron with temperature control and adjust it to 750 ± 20 °F (400 ± 10 °C). In case of using high temperature soldering iron, please be careful not to heat too long.
Page 5
3.2. Trial Operation (after checking Troubleshooting Guide). 3.2.1. Assembly • Confirm if there is no gap between housing A and B by pinching lead wires. • There is no dust or deformation on battery terminals. • Confirm all screws are tightened firmly. •...
4 Disassembly and Assembly Instructions * To reduce the risk of injury, always remove battery pack before removing/installing the tool. * To assemble the tool, start with 4-4 and proceed to 4-1 4.1. How to remove the Housing. 1. After removing the plate hook, remove 4 DPT sems tapping screws. 2.
Page 7
4.3. How to remove the Driving cover assembly and Driving shaft assembly. 1. Remove the protector. 2. Remove the interior components from the driving cover assembly. Note: (when assembling)
Page 8
4.4. How to remove the Switch assembly, LED harness assembly and Battery terminal. 1. Remove the connector(6-pin/2-pin) covers. 2. Disconnect the connecters or lead wires in order to (1) to (4). Note: Exercise care not to bend the terminal fitting. Note: (when assembling) The connect cover cannot be reused after being repaired.
5 Exploded View and Replacement Parts List Model No. : EY75A8 Exploded View...
Page 11
Model No. : EY75A8 Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks WEY75A8K9108 DPT SEMS TAPPING SCREW WEY6230K9216 TORX TAPPING SCREW WEY7441K6217 SCREW (K4*14) WEY7543K3187 PLATE HOOK WEY75A8K3079 HOUSING AB SET (for EUROPE) WEY75A8K3071 HOUSING AB SET...
