“ESCA” and “HABITAT” are registered trademarks of Grid Solutions, a GE and Alstom joint venture. “e-terra” is a trademark and/or service mark of E-Terra, LLC, licensed for use by GE. Other product and company names in these materials may be trademarks or registered trademarks of other companies, and are the property of their respective owners.
Page 4
Who Should Use This Document This document is suitable for field engineers with basic knowledge of Broadband Power Line Communications systems. For More Information For network design and software configuration, please refer to the e-terrapowercom Operation Manual. Proprietary – See Copyright Page...
Page 5
ANNEX - Filter configuration may-15 Heat related safety revision feb-15 GE format + annex revision (F1 & F3 inversion + serial port) feb-15 1 & 2 position inversion for filter switch may-18 ANNEX (p28) - Correction on Serial port jumper configuration...
All cables must be installed and properly fixed at a safe distance from any energized parts of the electrical environment WARNING: All recommendations included in this section shall be strictly followed. Any consequence of misuse or mishandling of the device will be user’s legal responsibility Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
The device must be installed in indoor environments or protected cubicles. The location must be protected against water, high temperatures and shocks. Please refer to supported environmental conditions in §1. The device can be mounted on a standard DIN rail (EN50022) using the back-side’s clip. Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
WARNING: to avoid any risk of electrical shock, the modem shall be disconnected to any power source during mounting procedure. Place the device over the DIN rail with the upper lip of the clip laying on the rail. Push the modem until the clip is locked Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
WARNING: to avoid any risk of electrical shock, the modem shall be disconnected to any power source during removal procedure. Pull the latch down to release the modem from the rail Flip the bottom side of the modem and pull it away from the DIN rail Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
The device shall be connected to an IEC standard appliance inlet protected by a 30 mA differential circuit breaker. The IEC standard plug for AC supply is located on the bottom side of the modem. Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
The device can be powered using a DC source in the voltage range specified in §1. The two pins connector is located on the bottom side of the modem It is recommended to secure the DC supply by screwing the connector flanges Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
Warning: positions 1 and 2 have been inverted on earlier production batches (those without the danger sign on BPL port). In this document, please refer to the picture above and consider position 1 as front position and position 2 as rear. Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
Using simultaneously BPL 1 & 2 can result in higher impedance mismatch between the modem and the coupling systems. When impedances shown by coupling systems at BPL 1 & 2 are unbalanced, the signal transmission is also unbalanced. Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
BPL signal is routed to PIN ‘+’ and ‘-‘ of the front side connectors. When using a shielded twisted pair, connect the shield to GND. It is recommanded to secure connector’s position using its screw flanges. Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
4 Ethernet ports are available on the front panel. All ports are connected to the same Ethernet bridge. Every RJ45 support auto-sensing and auto-negotiation feature for the following modes: 10 Mb Half Duplex 10 Mb Full Duplex 100 Mb Half Duplex 100 Mb Full Duplex Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
A serial port is located on the top panel. Depending on product code, a device may support RS232 or RS485 protocol. The corresponding PINOUT for each case is given in the following table: RS-232 RS-485 3.3V Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
6. Connection to MV Couplers In a usual installation, one coupler is attached to the e-terrapowercom BPL modem, using the proper connector and a shielded twisted pair. The coupler can be capacitive or inductive (please refer to the Coupler’s manual) The maximum recommended length for the twisted pair is 10 meters.
Page 23
For single coupling, use any of the the BPL ports and set the splitter switch to position 1. For double coupling, use both connectors and set splitter switch to position 2. Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
Transmitting data on RS232/485 BPL Sync Not configured, no signal available Blinking Not configured, signal detected ON (REP) Configured, synchronized ON (HE) Configured, active Power status Power status OK Blinking, OFF Power failure Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
Check the configuration of the modem and its neighbors is valid, especially regarding authentication. WARNING: if the problem persists, do not try to repair the modem yourself. Send it to a local GE representative for laboratory inspection. Proprietary – See Copyright Page...
Selectable filter feature requires a pre-configuration of the mother board. Pre-configuration procedure Open the box by removing all screws depicted below Remove the cover Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
Page 27
Locate filter bank jumpers JP100 and JP101 on both side of the filter component. J100 J101 Place the jumpers according to the required filter combination (refer to table below and §5.3.2) Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
Page 28
Top: RS232 Middle: RS485 Bottom: Off (as shown on picture) Put the board back on its original position on the chassis. Mount the cover and attach it using the original screws. Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
Page 29
Warning: positions 1 and 2 have been inverted on earlier production batches. In this document, please refer to the picture given in §5.2.1 and consider position 1 as front position and position 2 as rear. Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
Page 30
J2 + J4 + J9 + J10 Position 2 F1 Position 1 F1 J1 + J6 + J10 Position 2 F2 Position 1 F4 J8 + J11 + J10 Position 2 F3 Proprietary – See Copyright Page e-terrapowercom v2 Installation Manual...
