XL-MP130
MINI COMPONENT SYSTEM
MODEL
CD-SW300
OPERATION MANUAL
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
CD-SW300 Mini Component System consisting of CD-SW300 (main
unit), CP-S300 (front speaker) and CP-SW300 (Subwoofer).
Accessories
Please confirm that the following accessories are included.
Remote control
1
AM loop antenna
(RRMCGA083AWSA)
(QANTL0010AWZZ)
Note:
Only the above accessories are included.
1
FM antenna
1
(92LFANT1535A)
